10.2 Setting the sensor parameters
During parameter setting the unit remains in the operating mode. It continues its
monitoring function with the existing parameters until the parameter setting has
been completed.
The following steps must be taken for each parameter setting:
1►Connect the sensor to PP2001.
> The unit passes the initialisation
phase and then displays the current
measured value.
2Selection of the parameter
►Press [Mode/Enter] until the re-
quested parameter is displayed.
3Setting of the parameter value
►Press [Set] and keep it pressed.
> Current setting value of the param-
eter flashes for 5 s.
> After 5 s: setting value is changed:
incrementally by pressing the button
once or continuously by keeping the
button pressed.
Numerical values are incremented continuously. For reducing the value: let the dis-
play move to the maximum setting value. Then the cycle starts again at the minimum
setting value.
4Acknowledgement of the parameter
value
►Press [Mode/Enter] briefly.
> [SEND] is briefly displayed, then the
parameter designation.
> The new setting value is stored in the
sensor and now effective.
Setting of other parameters:
►Start again with step 1.
Finishing the parameter setting:
►Press [Mode/Enter] several times until the current measured value is displayed or wait
for 15
s. The unit returns to the operating mode if no button is pressed for 15 s after
acknowledgement of the new parameter value.
Finishing the parameter setting and storing the changed parameter set in PP2001:
► Carry out the [COPY] action (→ 10.3)
