ifs AT1000 Installation instructions

AT1000
AT1000-R3
AT1020
AT1020-R3
AT1025
AT1025-R3
AR1000
AR1000-R3
AR1030
AR1030-R3
AR2000
AR2000-R3
AR2020
AR2020-R3
AR2025
AR2025-R3
AR2010WDMA
AR2010WDMA-R3
AR2010WDMB
AR2010WDMB-R3
Installation/Operation Instructions
Warranty Information
www.ifs.com
888-999-9IFS
GE Security

AT1000
AUDIO INPUT 3
2
1Audio Input
Audio Input
Ground
AR1000
AUDIO OUTPUT 3
2
1Audio Output
Audio Output
Ground
NOTE:
For an unbalanced connection, tie pin 2 to pin 3 and utilize pins 2 and 3 for the audio
input to the AT1000 Series module. Utalize pins 1 and 2 for the audio output from the
AR1000 Series module.

Balanced
Audio Input*
Blue
Green
Brown
Blue
Green
Brown
ifs International
Fiber
Systems
Incorporated
203.426.1180
AT1000
FM AUDIO TRANSMITTER
12 VAC/12 VDC- 3
GRD- 2
12 VAC/12 VDC- 1
GRD- 3
AUDIO IN- 2
AUDIO IN- 1
POWER POWER
OPTICAL OUT
POWER
ifs International
Fiber
Systems
Incorporated
203.426.1180
AR1000
FM AUDIO TRANSCEIVER
12 VAC/12 VDC- 3
GRD- 2
12 VAC/12 VDC- 1
GRD- 3
AUDIO OUT- 2
AUDIO OUT- 1
POWER POWER
OPTICAL IN
POWER
CARRIER
Audio Output
}
}
Simplex multimode
fiber optic cable
Audio Input
Audio Input
Ground Tie together
}
*Note: For unbalanced audio input, use the following setup
WWW.IFS.COM
WWW.IFS.COM

AR2000
AUDIO INPUT
NOTE:
For an unbalanced connection, tie pin 2 to pin 3 and utilize pins 1 and 2 for the audio
input to the AR2000 Series module. Utalize pins 4 and 5 for the audio output from the
AR2000 Series module.
6
5
4
3
2
1Audio Input
Audio Input
Ground
6
5
4
3
2
1
Audio Output
Audio Output
Ground
AUDIO OUTPUT

Balanced
Audio Input*
}Balanced
Audio Input*
Blue
Green
Brown
Blue
Green
Brown
ifs International
Fiber
Systems
Incorporated
203.426.1180
AR2000
FM AUDIO TRANSCEIVER
12 VAC/12 VDC- 3
GRD- 2
12 VAC/12 VDC- 1
GRD- 6
AUDIO OUT- 5
AUDIO OUT- 4
GRD- 3
AUDIO IN- 2
AUDIO IN- 1
POWER POWER
OPTICAL IN
OPTICAL OUT
POWER
CARRIER
ifs International
Fiber
Systems
Incorporated
203.426.1180
AR2000
FM AUDIO TRANSCEIVER
12 VAC/12 VDC- 3
GRD- 2
12 VAC/12 VDC- 1
GRD- 6
AUDIO OUT- 5
AUDIO OUT- 4
GRD- 3
AUDIO IN- 2
AUDIO IN- 1
POWER POWER
OPTICAL IN
OPTICAL OUT
POWER
CARRIER
Audio Output
}
}
Audio Output
}
Duplex multimode
fiber optic cable
Audio Input
Audio Input
Ground Tie together
}
*Note: For unbalanced audio input, use the following setup

AR1000/AR2000
B
A Carrier LED
Power LED
B
A
AT1000
A
APower LED
NOTE: WITHOUT PROPER FIBER CONNECTION, LED's DO NOT INDICATE
CORRECT OPERATIONAL STATUS OF THE UNIT.

AR2000
AB
B
A Power Connector
Audio Connector
1 2 3 4 5 61 2 3
AT1000
AB
B
A Power Connector
Audio Input Connector
1 2 3 1 2 3
AR1000
AB
B
A Power Connector
Audio Output Connector
1 2 3 1 2 3
C
D
Optical In
Optical Out
CD
C
C
COptical Out
COptical In

Comprehensive
Lifetime Warranty
(a) Seller warrants to the original End User that products and any
services furnished hereunder will be free from defects in material
and workmanship as of the date of delivery,and will conform to
Seller’spublished technical specifications. The foregoing shall
apply only to failures to meet said warranties which appear within
that period of time during which the Products are installed in their
original installation for the original End User and operator of such
Products; provided, however, that in the event of product discontin-
uance, warranty support is limited to five (5) years from the
announcement of discontinuance. Notwithstanding the preceding
sentence, the duration of the warranty period for
products not
manufactured by Seller (e.g., fiber optic cabling, test equipment,
power supplies or batteries) shall be the warranty period offered by
the original manufacturer, if any.
(b) The conditions of any tests shall be mutually agreed upon and
Seller shall be notified of, and may be represented at, all tests that
may be made. The warranties and remedies set forth herein are
conditioned upon (a) proper storage, installation, use and mainte-
nance, and conformance with any applicable recommendations of
Seller and (b) Buyer promptly notifying Seller of any defects and,
if required, promptly making the product available for correction.
(c) If any product or service fails to meet the foregoing warranties,
Seller shall thereupon correct any such failure either at its option,
(i) by repairing any defective or damaged product or parts of the
products, or (ii) by making available any necessary repaired or
replacement products or parts thereof. Any repaired or replacement
part or product shall be warranted for the remaining period of the
original Warranty Period. Seller shall pay, or credit Buyer for, the
cost of freight for all return shipments of products or parts to
Buyer. Where a failure cannot be corrected by Seller's reasonable
efforts, the parties will negotiate an equitable adjustment in price.
(d) The preceding paragraph sets forth the exclusive remedies for
claims based on defect in or failure of products or services,
whether the claim is in contract, indemnity, warranty, tort
(including Seller's negligence), strict liability or otherwise and
however instituted. Upon the expiration of the warranty period,
all such liability shall terminate and BUYER shall have a reason-
able time, within thirty days after the warranty period, to give
written notice of any defects which appeared during the warranty
period. The foregoing warranties are exclusive and in lieu of all
other warranties, whether written, oral, implied or statutory.
NO IMPLIED OR STATUTORY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR PARTICULAR
PURPOSE SHALL APPLY. Seller does not warrant any
products or services of others which BUYER has designated.
DESIGN CENTER (888) 999-9IFS or (203) 426-1180
Europe, Middle East, Africa Tel: +44 113 238 1668
Asia Pacific Tel: +65 6235 2661 •Latin America (512) 477-8787
NOTE: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to cor-
rect the interference at his own expense.
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesirable operation.
Changes or modifications not expressly approved by International Fiber Systems, Inc. could
void the user’s authority to operate the equipment.
CLASS 1 LASER PRODUCT
(For purposes of IEC 60825-1)
Complies with FDA Performance Standard for Laser Products
Title 21
Code of Federal Regulations
Subchapter J

PROPER MOUNTING METHOD
FOR THE AT/AR2000
1) Locate unit on solid flat horizontal or vertical surface.
2) Position unit no closer than 24 inches from any power source or machinery.
3) Securely mount unit using (4) four mounting screws (not provided).
4) Select the correct voltage requirements for your application, +12VDC or 12VAC.
+12VDC attach black w/white stripe wireto pin 1 and black stripe to pin 2 (GND).
For 12VAC connect brown to pin 1, green to pin 2 and blue to pin 3 from adapter.
5) Plug power brick into approved 120v AC outlet.
6) Check power LED to insure device is properly powered, LED will illuminate green.

Product Disassembly Instructions for WEEE
Per European Directive 2002/95/EC Waste Electrical and
Electronic Equipment
Required Tools:
One number 2 Phillips (crosstip) screwdriver.
One number 2 flat screwdriver.
For the enclosed box version:
1. Locate and remove box cover securement screws. Usually, but not limited to, at least
4 screws.
2. Lift off box top cover.
3. Locate and remove securement screws for printed circuit board.
4. If there are multiple boards to the assembly, continue removing securement screws
until none are left.
5. Lift off printed circuit board.
6. Disassembly of box version of product is complete.
For rack version:
1. Locate and remove securement screws for printed circuit board. Usually, but not
limited to, at least 4 screws.
2. If there are multiple boards to the assembly, continue removing securement screws
until none are left.
3. Lift off printed circuit board(s).
4. Disassembly of rack card version of product is complete.
