QUICK START GUIDE - WINSLOW™ PS40 PELLET STOVE
W ARNING
Before you set up or operate your stove, review all safety, installation,
and operation instructions in your “Installation and Operation Manual.”
USING THIS GUIDE
This guide contains 5 easy steps to help you learn more about using
your new Winslow™ PS40 pellet stove. Detailed operating and cleaning
instructions are located in the “Installation and Operation Manual.”
1
PURCHASING THE CORRECT FUEL FOR THE STOVE
The Winslow pellet stove has been designed to burn wood pellets. We recommend burning
Premium Grade wood pellet fuel manufactured by companies who are members of the Pellet
FuelsInstitute (PFI). Although similar in appearance to those made of wood, other pelletized
fuels such as wheat, barley, cherry pits, etc. will adversely affect the performance of the stove
and may compromise safety and void warranty.
PFI LOGO
RECOMMENDED FUEL INCORRECT FUEL
• PFI APPROVED
• PREMIUM GRADE
• LESS THAN 1% ASH CONTENT
• LESS THAN 300 PPM CHLORIDES
• MOISTURE DAMAGE
• EXCESSIVE SA WDUST
• HIGH CHLORIDE OR
ASH CONTENT
• OVERSIZED PELLETS
(LONGER THAN 1-1/2”)
• COMMERCIAL GRADE
• ECONOMY GRADE
• WHEAT PELLETS
• BARLEY PELLETS
• BARK PELLETS

2
M ANUAL OPERA TION *
STARTING THE WINSLOW™ PS40 PELLET STOVE
1. Fill the hopper with pellets
2. Make sure the hopper lidis completely closed
3. Turn the control board dial to the desired heat
setting and press the “Start” button to begin the
ignition cycle.
RE-FUELING WHILE IN OPERA TION
1. Open hopper lid and fill hopper with pellets
Hopper lidmust
be closed during
operation.
2. Make sure the hopper lidis completely closed
3. Check to make sure the stove remains lit
4. If the flame goes out, press the “Start” button to
re-ignite the stove
STOPPING THE WINSLOW PS40 PELLET STOVE
1. Turn the control board dial to the “OFF” position
(The blowers will automatically turn off once the stove
has cooled down)
Indicator Lights
The lights on the control board will indicate
Control Dial
The level at which the stove heats is controlled by a
the status of the stove.If the “Ready” light
blinks red, you have an error. Consult the
Installation and Operation Manual foras-
sistance.
single dial on the control board. Adjusting the dial will
affect the pellet feed rate and room air movement.
* Refer to the Installation and Operation Manual if you are connecting your stove to a thermostat. Ignition and
control board functions for automatic (thermostat) operation may be different from the explanations given above.
3
FLAME APPEARANCE
The appearance of the flame can be a good indicator of the overall performance of the stove. A bright clean flame indicates
there is a proper balance of fuel and combustion air which results in efficient burning. A dark slow-moving flame indicates
incomplete combustion and a stove that may be in need of service and/or adjustment (see Damper Adjustment, next page).
PROPERLY ADJUSTED FLAME IMPROPERLY ADJUSTED FLAME
The stove burns cleanly and heats efficiently. Requires more frequent maintenance and can be unsafe
tooperate.
• SHARP, ACTIVE
FLAME
• BRIGHT YELLOW HUE
• PELLET EMBERS
ACTIVELY MOVE IN
THE BURN POT
• SLOW LAZY FLAME
• DARK ORANGE HUE
• LARGE FLAME WITH
BLACK SOOTY TIPS
• PELLETS BUILD UP IN
THE BURN POT
• WINDOW BECOMES
DIRTY MORE QUICKLY

4
DAMPER ADJUSTMENT
The Winslow™ PS40 pellet stove is equipped with a damper adjustment which is used to fine tune combustion.
Although everyunit is test burned and calibrated at the factory, periodic adjustment may be necessary at times to
compensate for variables such as fuel, venting, climate, altitude, and maintenance intervals.
OPENING THE DAMPER
Opening the damper increases the amount of
combustion air. This can help increase pellet activity in
the burn pot and correct a dark orange or sooty flame.
CLOSING THE DAMPER
Closing the damper decreases the amount of
combustion air. This can be a useful adjustment if your
stove is burning out. However, if the damper isclosed
too much, your stove will burn less efficiently and
require more maintenance.
REFER TO THE “INSTALLATION AND OPERA TION
MANUAL” FOR DETAILED INSTRUCTIONS ON MAKING
ADJUSTMENTS TO THE DAMPER.
The damper is located inside the left door.
5
CLEANING AND MAINTENANCE SCHEDULE
Maintaining a clean burn pot is vital to the safe and efficient operation of the stove.It is a good idea to verify your
burn pot is clean prior to ignition each time you operate your stove.
Properly cleanedburn pot: The
holes in the bottom and sides are
clean and all the openings are clear .
Dirty burn pot: The holes in the bot-
tom and sides are not completely
visible. The burn pot should be
cleaned.
Above is an example of a pellet
“clinker”. This mass ofimpurities
can reduce airflow through the burn
pot and create an unsafe burning
condition.
IMPORTANT NOTE:
UNPLUG POWER CORD AND ENSURE APPLIANCE IS COLD BEFORE PERFORMING ANY MAINTENANCE WORK.

CLEANING AND MAINTENANCE SCHEDULE (CONTINUED)
In
addition to the regular maintenance procedures described below, the “Installation and Operation Manual” out-
lines yearly service that should be performed by a qualified technician.
Burn Pot
Theburn pot should be checked
for clinkers prior tooperating
the stove. Any non-combustible
material blocking the burn pot
should be emptied prior to
ignition.
1-7 Days*
Heat Exchanger Keeping
the heat exchanger tubes clean
will maximize the heating
efficiency of your stove. When
the stove is cold, pull
the tube scraper rod back and
forth to release any ash build-up
inside the firebox.
2 Days - 2Weeks*
Ash Drawer
The ash drawer serves as a recepta -
cle to hold ash that has accumu-
lated in the firebox and embers
that drop from the burn pot. Refer
to the Installation and Operation
Manual for proper ash disposal.
2
Days - 2 W eeks*
Additional Y early
Maintenance*
• Clean Proof of Fire Switch
• Clean Ash Clean-Out Ports
• Clean Exhaust Passages/Vent
Pipe and Creosote Removal
• Clean the Combustion and
Convection Blowers
• Check Glass Door and Ash
Drawer Seal
• Clean Rear Stove Compart -
ment
*Burning fuel with a high ash content or an improperly adjusted damper may require more frequent cleaning and stove maintenanc e.
IMPORTANT NOTE:
BURNING POOR QUALITY FUEL WILL SIGNIFICANTLY INCREASE THE FREQUENCY OF REQUIRED CLEANING.
FAILURE TO PROPERLY CLEAN AND MAINTAIN YOUR STOVE AS INDICATED IN THE INSTALLATION AND OP -
ERATION MANUAL CAN RESULT IN A STOVE THAT IS UNSAFE TO OPERA TE.
W ARNING
• Hot! Do not touch! The glass and surface of this appliance will
be hot during operation and will retain heat for a while after
shutting off the appliance. Severe burns may result.
• Carefully supervise children in the same room as appliance.
• IronStrike™ pellet-burning appliances are designed for use as
supplemental heaters. They are not intended for continuous use
as primary heat sources.
© 2009 Innovative Hearth Products LLC
Visit us at www.IronStrike.us.com
P/N 506033-38
Rev. A 10/2013
