IKEA ANRATTA 004 432 34 User manual

400011368259
© Inter IKEA Systems B.V. 2019 18535 AA-2119061-2
400011368259

ENGLISH 4
5 يبرع

4
Before using the appliance, read
these safety instructions. Keep
them nearby for future reference.
These instructions and the
appliance itself provide
important safety warnings, to
be observed at all times. The
manufacturer declines any
liability for failure to observe
these safety instructions,
for inappropriate use of the
appliance or incorrect setting of
controls.
Very young children (0-3
years) should be kept away
from the appliance. Young
children (3-8 years) should be
kept away from the appliance
unless continuously supervised.
Children from 8 years old
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge can
use this appliance only if they
are supervised or have been
given instructions on safe use
and understand the hazards
involved. Children must not play
Safety Information
Table of contents
with the appliance. Cleaning and
user maintenance must not be
carried out by children without
supervision.
WARNING!: If the door or
door seals are damaged, the
oven must not be operated until
it has been repaired – risk of
injury.
WARNING!: Liquids and
foods must not be heated in
sealed containers – risk of
explosion, heating of beverages
can result in delayed eruptive
boiling, care must be taken when
handling the container – risk of
burn.
The microwave oven is
intended for heating food and
beverages. Do not dry food or
clothing or heat warming pads,
slippers, sponges and similar -
risk of re. When heating food
in plastic or paper containers,
remains vigilant on the oven -
risk of re.
The contents of feeding
bottles and baby food jars must
Safety Information 4
Product description 7
Control panel 8
First use 8
Daily use 9
Cooking tables 13
Cleaning and maintenance 14
What to do if ... 15
Technical data 16
Installation 16
Electrical connection 17
Environmental concerns 18
IKEA GUARANTEE 19
GB
ENGLISH

ENGLISH 5
be stirred or shaken and their
temperature checked - risk of
burn. Do not heat eggs in their
shells and whole hard-boiled
eggs - risk of explosion.
Only use utensils that are
suitable for microwave cooking.
Do not use metallic containers -
risk of injury.
Only use a temperature
probe recommended for this
oven - risk of re.
If smoke is emitted switch off
or unplug the appliance and
keep the door closed in order to
stie any ames.
If the appliance is installed
850 mm or more above the
oor, take care not to displace
the turntable when removing
containers – risk of injury.
Do not use your microwave
oven for deepfrying, because
the oil temperature can not be
controlled.
Metallic containers for food
and beverages are not suitable
during microwave cooking.
Do not remove the microwave
inlet protection plates on the
side of the cavity walls (certain
models only). They prevent
grease and food particles from
entering the microwave inlet
channels.
PERMITTED USE
CAUTION: The appliance is
not intended to be operated by
means of an external switching
device, such as a timer, or
separate remote controlled
system.
This appliance is intended
to be used in household and
similar applications such as: staff
kitchen areas in shops, ofces
and other working environments;
farm houses; by clients in hotels,
motels, bed & breakfast and
other residential environments.
This appliance is not for
professional use. Do not use the
appliance outdoors.
INSTALLATION
The appliance must be
handled and installed by two or
more persons - risk of injury. Use
protective gloves to unpack and
install - risk of cuts.
Installation, including
water supply (if any), electrical
connections and repairs must
be carried out by a qualied
technician. Do not repair
or replace any part of the
appliance unless specically
stated in the user manual.
Keep children away from the
installation site. After unpacking
the appliance, make sure that
it has not been damaged

ENGLISH 6
during transport. In the event of
problems, contact the dealer or
your nearest Aftersales Service.
Once installed, packaging waste
(plastic, styrofoam parts etc.)
must be stored out of reach of
children - risk of suffocation. The
appliance must be disconnected
from the power supply before
any installation operation - risk
of electric shock.
During installation, make sure
the appliance does not damage
the power cable - risk of re or
electric shock. Only activate the
appliance when the installation
has been completed.
This appliance is intended to
be used built-in.
Do not use it freestanding or
place into a cabinet.
After unpacking the appliance,
make sure that the appliance
door closes properly. In the event
of problems, contact the dealer
or your nearest After-sales
Service.
ELECTRICAL WARNINGS
It must be possible to
disconnect the appliance from
the power supply by unplugging
it if plug is accessible, or by
a multi-pole switch installed
upstream of the socket in
accordance with the wiring
rules and the appliance must
be earthed in conformity
with national electrical safety
standards.
Do not use extension leads,
multiple sockets or adapters.
The electrical components must
not be accessible to the user
after installation. Do not use the
appliance when you are wet or
barefoot.
Do not operate this appliance
if it has a damaged power
cable or plug, if it is not working
properly, or if it has been
damaged or dropped.
If the supply cord is
damaged, it must be replaced
with an identical one by the
manufacturer, its service agent
or similarly qualied persons in
order to avoid a hazard - risk of
electric shock.

ENGLISH 7
Product description
1
2
3
4
1Control Panel
2Grill element (Quartz)
3Cavity Lamp
4Door
Accessories
Turntable support
1x
Glass turntable
1x
Crisp-plate
1x
Crisp handle
1x
General
There are a number of accessories available
on the market. Before you buy, ensure they are
suitable for microwave use.
Ensure that the utensils you use are oven proof
and allow microwaves to pass through them
before cooking.
When you put food and accessories in the
microwave oven, ensure that they do not come
in contact with the interior of the oven.
This is especially important with accessories
made of metal or metal parts.
If accessories containing metal come in contact
with the oven interior, while the oven is in
operation, sparking can occur and the oven
could be damaged.
Always ensure that the turntable is able to turn
freely before starting the oven.
All accessories are dishwasher safe with the
exception of the crisp plate.
The crisp plate should be cleaned using water
and a mild detergent. For stubborn dirt, rub
gently with a cloth. Always leave the crisp
plate to cool down before cleaning.
Aluminium foil can be used safely to shield
small areas of food as long as it does not
come in contact with the oven interior.
Turntable support
Fit rst the internal weel and then the external
part of the turntable support.
Use the turntable support under the Glass
turntable. Never put any other utensils on the
turntable support.
Glass turntable
Place the Glass turntable on the turntable
support.
Use the Glass turntable with all cooking
methods. It collects the dripping juices and
food particles that otherwise would stain and
soil the interior of the oven.
Crisp handle
Use the supplied special Crisp handle to
remove the hot Crisp plate from the oven.
Crisp-plate
Place the food directly on the Crisp-plate.
Always use the Glass turntable as support
when using the Crisp-plate.
Do not place any utensils on the Crisp-plate
since it will quickly become very hot and is
likely to cause damage to the utensil.

ENGLISH 8
Control panel
A
Selection push-push knob
B
Back button
C
Stop
D
Display
E
Start
F
Conrmation button
G
Adjust push-push knob
Retractable knobs
To use this type of knob,
press it in the middle.
The knob comes out.
Turn it to the required position.
Once cooking is over, turn the
knob to and press it again to
restore it to its original position.
A D GB CFE
Settings
When the appliance is rst plugged in it will
ask you to set the clock.
After a power failure the clock will ash and
needs to be reset.
Your microwave oven has a number of
functions which can be adjusted to your
personal taste.
GFA
1. Turn the Aknob until Setting is shown
(aprox. 3 sec).
2. Push the Gknob out and turn it to choose
one of the following settings to adjust:
Clock, Sound, ECO, Brightness
3. Press the Fbutton to exit the settings
function and save all your changes when
you are done.
• Clock
GF
1. Press the
F
button (the left-hand digits
hour’s icker).
2. Push the
G
knob out and turn it to set
hours.
First use
3. Press the
F
button (the two right hand
digits (minutes) icker).
4. Turn the
G
knob to set the minutes.
5. Press the
F
button again.
The clock is set and in operation.
• Sound
GF
1. Press the
F
button.
2. Push the
G
knob out, and turn it to turn
the buzzer ON or OFF.
3. Press the
F
button again to conrm the
change.
• Eco
GF
1. Press the
F
button.
2. Push the
G
knob out and turn it to turn
the ECO setting ON or OFF.
3. Press the
F
button again to conrm the
change.
When the ECO mode is on, the brightness
of the display will automatically switch to

ENGLISH 9
Start protection / Safety lock
This automatic safety function is activated
one minute after the oven has returned to
“stand by mode“. (The oven is in “stand by”
when the 24-hour clock is displayed or if the
clock has not been set, when the display is
blank).
Open and close the door, then press
F
to
start the function.
Cooling down
When a function is nished, the oven may
carry out a cooling procedure. This is normal.
After this procedure the oven switches off
automatically.
The cooling procedure can be interrupted
without any harm to the oven by opening the
door or pressing the
C
Button.
Setting the timer
Use this function when you need a kitchen
timer to measure exact time for various
purposes such as cooking eggs or letting the
dough rise before baking etc.
GFA
Daily use
1. Push the
A
knob out and turn it until zero
position.
2. Push the
G
knob out and turn it to set the
desired length of the timer.
3. Press the
F
button.
An acoustic signal will be heard when the
timer has nished to count down.
Pressing any button to turn off the acoustic
signal
WARNING : Overheating the liquid beyond
boiling point can occur without evidence
of bubbling. This could result in a sudden
boil over of the hot liquid. To prevent this
possibility the following steps should be
taken :
1. Avoid using straight-sided containers with
narrow necks.
2. Stir the liquid before placing the container
in the appliance and let the teaspoon
remain in the container.
3. After heating, allow standing for a short
time, stirring again before carefully
removing the container from the appliance.
Jet start
This function is used for quick reheating of
food with a high water content such as; clear
soups, coffee or tea.
With the knob in the upright postion, press
Start button to switch on the Jet Start
function.
a lower level after 1 minute. If the ECO
mode is off, the brightness will switch to
the same lower level after 3 minutes. It
will automatically switch back to the set
brightness level when a button is pressed or
the door is opened.
• Brightness
GF
1. Press the
F
button.
2. Push the
G
knob out and turn it to set
the level of brightness suitable to your
preference.
3. Press the
F
button again to conrm the
change.

ENGLISH 10
Jet Start automatically starts with full
microwave power level and the cooking time
set to 30 seconds. Each additional press
increases the time with 30 seconds.
You may also alter the time by the Adjust
knob to increase or decrease the time.
Press the
F
button to conrm the cooking
time.
Microwave oven functions table
Function Description of
function
12:00 For switching off the oven.
MICRO
For quickly cooking
and reheating food or
beverages.
CRISP
For perfectly browning a
dish, both on the top and
bottom of the food. This
function must only be used
with the special Crisp plate.
GRILL
For browning, grilling and
gratins. We recommend
turning the food during
cooking. For best results,
preheat the grill for 3-5
minutes.
COMBI
For quickly cooking
and gratinating dishes,
combining the microwave
and grill functions.
DEFROST
To defrosting meat, poultry,
sh, vegetables and bread.
Microwave
Use this function for normal cooking and
reheating, such as vegetables, sh, potatoes
and meat.
G
F
A
E
1. Push the
A
knob out and turn it until you
nd the microwave function.
2. Push the
G
knob out and turn it to set the
microwave power level.
3. Press the
F
button to conrm your
selection.
4. Turn the
G
knob to set the cooking time.
5. Press the
E
button.
Once the cooking process has been
started: the time can easily be increased
in 30-second steps by pressing the Start
button. Each press increases the time with 30
seconds.
You may also alter the time by turning the
adjust knob to increase or decrease the time.
Power level can be altered during cooking
by pressing the Back button and then turning
the Adjust knob.
Press the
E
or
F
button to conrm the
cooking time.
Power level Microwaves only
Power Suggested use:
1000 W Reheating of beverages, water, clear
soups, coffee, tea or other food with
a high water content. If the food
contains egg or cream choose a
lower power.
800 W Cooking of vegetables, meat etc.
650 W Cooking of sh.
500 W More careful cooking e.g. high
protein sauces, cheese and egg
dishes and to nish cooking
casseroles.
350 W Simmering stews, melting butter and
chocolate.
160 W Defrosting. Softening butter, cheeses.
90 W Softening Ice cream
Grill Combi
Use this function to cook such food as
Gratins, Lasagne, Poultry and Baked
potatoes.
G
F
A
E
1. Push the
A
knob out and turn it until you
nd the Combi function.

ENGLISH 11
2. Turn the
G
knob to set microwave power
level.
3. Press
F
to conrm your selection.
4. Turn the
G
knob to set cooking time.
5. Press the
E
button.
The Max. possible microwave power level
when using the Grill is 650W.
Power Suggested use:
650 W Cooking Vegetables and Gratins
350 - 500 W Cooking Poultry and Lasagne
160 - 350 W Cooking Fish and frozen gratins
90 W Gratinating fruit
Grill
G
F
A
E
Use this function to quickly give a plesant
brown surface to the food.
1. Push the
A
knob out and turn it until you
nd the grill function.
2. Push the
F
button to conm.
3. Push the
G
knob out and turn it to set the
cooking time.
4. Press the
E
button.
Ensure that the utensils used are heat
resistant and ovenproof before grilling with
them.
i
IMPORTANT: Do not use plastic utensils
when grilling. They will melt. Items of
wood or paper are not suitable either.
Defrost
Use this function for defrosting Meat, Poultry,
Fish, Vegetables and Bread.
Auto Defrost should only be used if the net
weight is between 100 g-2.5 kg.
Always place the plate on the glass
turntable.
G
F
A
E
1. Push the
A
knob out and turn it until you
nd the Auto Defrost function.
2. Push the
G
knob out and turn it to select a
food class.
3. Press the
F
button to conrm your
selection.
4. Turn the
G
knob to set the weight.
5. Press the
F
button to conrm your
selection.
6. Press the
E
button.
Weight:
This function needs to know the net weight
of the food. The oven will then automatically
calculate the needed time to nish the
procedure.
Frozen foods:
If the food is warmer than deep-freeze
temperature (-18°C), choose lower weight of
the food.
If the food is colder than deep-freeze
temperature (-18°C), choose higher weight of
the food.
Food Hints
Meat
(100 g - 2.0 Kg)
Minced meat, cutlets, steaks or
roasts. Turn food when oven
prompts.
Poultry
(100 g - 2.5 Kg)
Chicken whole, pieces or llets.
Turn food when oven prompts.
Fish
(100 g - 1.5 Kg)
Whole, steaks or llets. Turn
food when oven prompts.
Vegetables
(100 g - 1.5 Kg)
Mixed vegetables, peas,
broccoli etc. Turn food when
oven prompts.
Bread
(100 g - 1.0 Kg)
Loaf, buns or rolls. Turn food
when oven prompts.
