IKI Mobile KF5 User manual

Model KF5
USER MANUAL

Trademarks
The IKIMOBILE is a registered trademark of Univercosmos , Lda. , a company
of Grupo FF, with a participation in Technology Solutions IT INT .
Android e Google Search™ are registered trademarks by Google Inc.
Wi-Fi® is a registered trademark by Wi-Fi Alliance.
Bluetooth® is a registered trademark by Bluetooth SIG, Inc.
MicroSDTM is a registered trademark and logo by SD-3D, LLC.
Dolby, Dolby Audio and the double D symbol are registered trademarks by
Dolby Laboratories.
Other trademarks are property of their respective owners. All rights reserved.
Contents
1. Introduction 3
2. Safety & Notice 3
3. Start to use 3
3.1 Touch & type 3
3.2 Assemble & charge 3
3.3 Home screen - Quick start: Home screen 4
3.4 Text entry 4
3.5 Shortcut 4
3.6 Bluetooth 4
3.7 GPS 4
4. Phone 4
4.1 Make a call 4
4.2 During a call 4
4.3 Emergency calls 5
4.4 Make International Calls 5
4.5 Answer Calls 5
4.6 Call History 5
5. Contacts 5
5.1 Add a contact 5
5.2 Search contacts 5
5.3 Additional options 5
5.4 Contact groups 5
5.5 Favorites 5
6. Messaging 5
6.1 New message 5
6.2 Delete message threads 5
6.3 Forward a message 6
7. Web application 6
7.1 Wi-Fi Networks 6
7.2 Browser 6
8. Multimedia 6
8.1 Camera 6
8.2 Music 6
8.3 Video player 6
8.4 FM Radio 6
8.5 Sound recorder 6
9. Other application 6
9.1 Clock 6
9.2 Calculator 6
9.3 File manager 6
9.4 Connect to a computer via USB 6
10. Troubleshooting 6

KF5 USER MANUAL - ENGLISH
3
1. Introduction
Thank you for purchasing this product.
For your cellular phone to work property, please follow the instruc-
tions in this manual. To prevent any possible incidents or malfunc-
tion, please follow all safety warnings. If function upgrade causes
descriptions in the manual content not according with actual prod-
ucts, please refer to our company subsequent release of information.
2. Safety & Notice
WARNING: Please pay attention to these guidelines, it’s
dangerous and may break the law, even the manufacturer
will not undertake any responsibility to the user who does
not follow with the following recommendations or improper
use of the Smart Phone.
•If the phone supports the “Flight mode” function, please set the
mode as “Flight mode” on the plane. If not supported, please turn
off the phone before boarding, because the phone may cause in-
terference in aircraft. Please follow any restrictions on the airplane.
• Switch the device off near the fuel, chemicals, or blasting areas.
Keep the device away from children.
• While driving please obey local laws and regulations with regard
to Smart Phone use. When talking on the phone while driving,
please obey the following rules: Concentrate on driving and be
aware of traffic conditions; if your Smart Phone has a hands-free
function, please use it in this mode. Under poor driving condi-
tions, please stop the car before you dial or pick up the phone.
• Switch off the Smart Phones in the hospital or other forbidden us-
ing Smart Phone place. The Smart Phones will affect the normal
work of electronic equipment and medical devices, such as pace-
makers, hearing aids and other medical electronics equipment.
• Non-original accessories and components are not provided with
repair warranty qualification.
• Please do not disassemble your phone by yourself, if your phone
is out of order, please contact your supplier.
• Please do not charge the Smart Phone before battery is installed.
Do not short-circuit the battery.
• Smart Phone must be charged in the good ventilated and cooling
environment, and away from flammable and explosive materials.
• In order to demagnetization, please keep Smart Phone away from
the magnetic material, such as disks, credit card etc.
• Keep the device dry. Precipitation, humidity, and all types of liq-
uids or moisture can contain minerals that will corrode electronic
circuits. If your device does get wet, remove the battery, and con-
tact with the supplier.
• Do not use the Smart Phone in too high or too low temperature
environment, and do not expose the Smart Phone to strong sun-
light or high humidity.
• Do not use liquid or wet cloth with strong detergent to clean the
device.
• This Smart Phone is provided photograph, video recording and sound
recording functions; please follow the relevant laws and regulations
to use those functions. Photograph, video recording and sound re-
cording without authorization may violate laws and regulations.
• While using the network functions, please do not download the
files which have virus, do not install any photos and ring tones
which have been damaged. If it results the phone abnormally, our
company will not undertake any responsibility.
• Please dispose of batteries according to local regulations, please
recycle when possible. Please do not dispose as household waste.
STATEMENT: Our Company reserves the right to revise this
manual’s content without prior notice.
3. Start to use
3.1 Touch & type
Use your fingers to manipulate icons, buttons, menus, the onscreen
keyboard, and other items on the touch screen. You can also change
the screen’s orientation.
To select or activate something, touch it.
To type something, such as a name, password, or search terms, just
touch where you want to type. A keyboard pops up that lets you
type into the field.
Other common gestures include:
•Touch & hold: Touch & hold an item on the screen by touching it
and not lifting your finger until an action occurs.
• Drag: Touch & hold an item for a moment and then, without lifting
your finger, move your finger on the screen until you reach the
target position. For example, you can drag to reposition shortcuts
on the Home screen.
•Swipe or slide: Quickly move your finger across the surface of
the screen, without pausing when you first touch (so you don’t drag
something instead). For example, you can slide a Home screen left
or right to view the other Home screens.
• Double-tap: Tap quickly twice on a webpage, map, or other screen
to zoom. For example, double-tap a webpage in Browser to zoom
in, and double-tap again to zoom out.
• Pinch: In some apps (such as Maps, Browser, and Gallery), you
can zoom in and out by placing two ngers on the screen at once
and pinching them together (to zoom out) or spreading them apart
(to zoom in).
• Rotate the screen: On most screens, the orientation of the screen
rotates with your device as you turn it. You can change this Display
setting.
3.2 Assemble & charge
• SIM card in: Please according to the label on the phone. Make sure
that the clipped corner of the SIM card is facing the correct direc-
tion and the metallic contacts are facing the correct direction. Slide
the SIM card into the card slot until it stops.
• SD card in: Slide the SD card into the SD card slot with the metallic
pins facing downwards. Push the card until it locks into place.
Warning: Use only compatible memory cards for use with
this device. Incompatible memory cards may damage the
card or the device and corrupt the data stored in the card.
• Battery in: With the metallic contacts of the battery facing the
metallic contacts in the battery slot, press the battery down until
it locks into place.
• Charge up: Ensure the battery is inserted in the handset. To
charge the battery, plug in the charger connector at your phone
(USB interface) and then plug the other end into an AC power
socket. The battery symbol indicates the charging status. While
charging, the charge indicators will scroll. When all the scroll
bars are steady, the battery is fully charged. Disconnect the
charger from the phone. Disconnect the charger from the AC
power socket.
Attention: Charge the phone in a well ventilated place in
which the temperature is from -10ºC to +55ºC. Use the
charger provided by the manufacturer only. The use of
unconfirmed charger may lead to dangers and violate the
manufacturer’s warranty clause. If the temperature is too

KF5 USER MANUAL - ENGLISH
4
high or too low during the charge, the device will automati-
cally send a warning and stop charging to avoid damage to
the battery or any danger.
3.2.1 Switch On and Off
Keep Switch ON/OFF key pressed to switch ON/OFF the phone. If
the device is switched ON but the SIM card isn’t inserted, the lock
screen will show “No SIM card”.
After inserting the SIM card, the screen will show the notes in the
following order when the phone is switched on:
Type in PIN — If you have already set the SIM code.
Search —The handset will be searching for proper network connection.
3.2.2 Unlock SIM card
To avoid illegal use, the SIM card is enciphered with PIN (personal
identification number ) as a protection. When this function is ON
and you have already set a PIN code, you need to type in PIN code
every time the handset is switched on in order to unlock SIM card
and use the handset.
You can turn off the SIM PIN code. Yet in this situation, the SIM card
can’t prevent illegal use.
• Input PIN code, press arrowhead icon to erase typing error and
press OK to end typing. For example, if the PIN code is set as
1234, then type “1234” then press OK.
The SIM card will be locked if you type in wrong code for three times
continuously. The handset will inform you to type in PUK code.
Attention: Your network provider will set a standard PIN code (four
to eight numbers) for your SIM card. It is recommended that you
change the code into a personal code as soon as possible.
3.3 Home screen
Quick start: Home screen
The Home screen gives you all your latest information in one place.
It’s what you see when you turn on the phone. It is the equivalent of
the desktop on a computer. It’s your gateway to the main features in
your phone. You can customize your Home screen with shortcuts,
widgets, folders, and wallpapers.
You need to slide the Home screen left or right to view more con-
tent in other panels on the Home screen. You can add shortcuts,
widgets, folders, etc. to Home screen.
3.4 Text entry
Touch the keys of the on-screen QWERTY keyboard to enter text
conveniently. You can open this keyboard by touching a text field.
3.4.1 Enter text
Touch the keys on the keyboard to type.
• Use the Delete key to erase characters to the left of the cursor.
• When you nished typing, Press Back key to close the keyboard.
HWF_S5060
Enter Various Characters
• Touch the Symbols key to switch to the numbers and symbols
keyboard.
• Touch on the symbols keyboard to view additional symbols.
3.4.2 Edit Text
You can edit the text you enter in text fields and use menu com-
mands to cut, copy, and paste text, within or across applications.
Some applications do not support editing some or all of the text
they display. Others may offer their own way to select text you want
to work with.
• Touch and hold the text eld that contains the text to select the
word.
• Cut or copy the text.
3.4.3 Select Text
You can select text for cutting or copying. The selected text is
highlighted in blue.
• Touch and hold the portion that contains text. Some options
open with icons.
• Move the cursor to select the text.
3.5 Shortcut
To add a shortcut to Home screen
1. From Home screen, touch Launcher icon.
2. From APPS tab, you will see application menu.
3. Touch and hold an application icon until it vibrates, then back to
the Home screen, and drag it to the desired location.
To remove a shortcut on Home screen
If you want to remove the shortcut, you can touch and hold the
shortcut icon on Home screen until it vibrates, and then drag it
to remove tab.
3.6 Bluetooth
Bluetooth is a short-range wireless communications technology
that devices can use to exchange information over a distance of
about 10 meters.
Turn Bluetooth on or off, search for available Bluetooth devices,
and make your phone visible or invisible to other Bluetooth devices.
1. Rename phone: check and rename device name.
2. Visibility timeout: set the time of others can find your Device.
3. Show received files: show the files download and upload.
3.7 GPS
From Settings into the location access, open the GPS satellites,
connection on the GPRS or WLAN, can navigation and positioning.
4. Phone
4.1 Make a call
Touch phone icon on the Home screen.
In dialing screen, input number and touch Dial icon to dial the in-
putted number.
4.2 During a call
During a call, there are some call options available to you. These
call options can be seen only during a call. When a call is in pro-
gress, you can put it on hold, initiate a phone conference, mute your
microphone, etc.
Touch Go to the key pad
Touch To turn on/off the speaker.
Touch Mute your voice so that the other party cannot hear you.
Touch To place a call on hold.
Touch Open dial pad to dial the second call.
Conference*
In Conference call mode, you answer the incoming call and add it to
the conference in accordance with the instructions; Hold multipar-
ty conference; Have a private conversation with one party and hold
other parties’ call; Connect one party to the other and end the confer-
ence call; Put one party on hold; End current call and all hold on calls.
Attention: Menu items market by * happen only under certain
situations. Users need to apply for opening the conference call
functions to relevant service provider.

KF5 USER MANUAL - ENGLISH
5
4.3 Emergency calls
You can call for emergency service as long as you are in the network
coverage (check the signal strength indication bar on the upper right
side of the handset screen). If your network provider doesn’t provide
roaming service in this area, there will be “Emergency Calls” on
the lock screen. If you are in the network coverage, you can have
emergency calls even without a SIM card.
4.4 Make International Calls
If you need to make an international call, do a long press on the 0
key on the virtual keyboard until there appears the sign “+” for in-
ternational call prefix, which helps you call from any country (For
example, in China that is 86) even if you don’t know the international
call prefix of that country.
You can make an international call according to the following typing
order: + › country code › complete phone number › dialing icon (type
in the prefix code, and then continue to enter the country code and
complete phone number). Country code usually follows conven-
tional practice: German is 49, Britain 44, Sweden 46 and so on.
4.5 Answer Calls
Drag the icon to answer to answer an incoming call. If your head-
phone is connected to the handset, you can use the headphone key
on the headphone answer calls.
Attention: A short press of the headphone key will answer the call
while a long one will refuse to answer the phone.
4.6 Call History
This handset not only can list all calls in reverse chronological order,
but also list a floating menu with all, answered, dialed, missed calls
for checking call history of different kinds.
5. Contacts
The Contacts application offers you to store and manage all your
contacts.
5.1 Add a contact
1. From your Home screen, touch People icon or find it:
Application menu > People.
2. Touch .
3. Select a location to save.
4. Enter the information for the contact.
5. After you finish, touch DONE.
5.2 Search contacts
1. From your Home screen, touch People icon or find it:
Application menu > People.
2. Touch .
3. Input to keyword search contacts.
4. The matched contacts listed phone automatically.
5.3 Additional options
From contacts list screen, press Menu key, some additional op-
tions will be available to you. For example, import/export, and
share visible contacts.
• Delete contact: You can mark much more than one contact, and
then delete these marked contacts.
• Contacts to display: To select which contacts to display in the
contacts list.
• Import/export: Copy contacts to which you want import.
• Accounts: You can synchronize your phone contacts with a syn-
chronization account.
• Settings: change the display options.
• Share visible contacts: You can share contacts via Bluetooth,
Email, MMS, and so on.
5.4 Contact groups
You can assign contacts to groups to get quicker access to them
from the Contacts application. It allows you to create a new group
such as VIP, schoolmate, friends, family or co-worker.
To create a new group
1. From your Home screen, touch People icon or find it:
Application menu > People.
2. Touch Groups tab.
3. Touch .
4. Input the information of group, then touch DONE.
To assign a contact to a group
1. From your Home screen, touch people icon or find it:
Application menu > People.
2. Touch Groups tab.
3. Touch a group to which you want to assign contacts.
4. Press Menu key, touch Edit in the menu that opens.
5. Touch Type person’s name to input the contact’s name, then
the corresponding contact entry will pop up, select the desired
contact entry.
6. After you finish editing, touch DONE
5.5 Favorites
You can set contacts as favorites so that you can get access to them
from the Contacts application. Only the contacts stored in phone
memory can be set as favorites.
To set a contact as favorite
1. From your Home screen, touch Contacts icon or find it:
Application menu > Contacts.
2. From contacts list, touch a contact which you want to set as
favorite.
3. Touch . If you want to cancel the favorite, touch .
6. Messaging
You can compose, send and receive text messages from your phone,
and also can compose, send and receive multimedia messages,
which contain media files such as pictures, videos and audios.
When you view your messages, they appear as conversations,
which means that all messages to and from a particular person are
grouped together.
6.1 New message
1. From your Home screen, touch Messaging icon or find it:
Application menu > Messaging.
2. Touch .
3. To add recipient(s), touch , then find and mark the contact
name. To add more than one contact, mark the contact name for
the desired recipients. You can also enter the recipient’s phone
number manually.
5. Touch Type text message to enter your message text.
6. If you want to insert a media file, touch , and select an attachment.
7. To send the message, touch .
When editing message, press Menu key, some additional options
will be available to you. For example, insert quick text, insert con-
tact and add subject. You can touch the options to do actions.
6.2 Delete message threads
1. From your Home screen, touch Messaging icon or find it:
Application menu > Messaging
2. Touch and hold the message thread.
3. Select the conversations you want to delete.
4. Touch .
You can also press Menu key and touch Delete all threads to

KF5 USER MANUAL - ENGLISH
6
delete all message threads from the window.
6.3 Forward a message
1. From your Home screen, touch Messaging icon or find it:
Application menu > Messaging.
2. Touch the conversation containing the message you want to forward.
3. Touch and hold the message you want to forward.
4. Touch Forward in the menu that opens.
5. Add recipient(s), touch , then find and mark the contact name.
To add more than one contact, mark the contact name for the desired
recipients. You can also enter the recipient’s phone number manually.
6. Touch to send the message.
7. Web application
7.1 Wi-Fi Networks
Wi-Fi is a wireless networking technology that can provide internet
access at distance of up to 100 meters. To use Wi-Fi on your phone,
you access a wireless access point, or “hotspot”. Some hotspots
are open and you can simply connect to them. Others are hidden or
implement other security features, so you must configure your
phone so it can connect to them.
TIP: Turn off Wi-Fi when you are not using it, to extend the life of
your battery.
Connect to Wi-Fi Network
1. Touch Launcher icon, and from Application menu, touch Set-
tings.
2. Touch Wi-Fi.
3. Check Wi-Fi to turn it on. The phone scans for available Wi-Fi net-
works and displays the names of those it finds. Secured networks are
indicated with a Lock icon.
4. Touch a network to connect to it
If the network is secured, you are prompted to enter a password or
other credentials (Ask your network administrator for details)
7.2 Browser
Use your web browser to view and navigate web pages, add pages
as bookmarks, and save pages for offline reading. You can open
several windows at the same time and switch among them easily.
You can also request the desktop version of a web page if you don’t
want to view the mobile version.
Open the web browser
From your Home screen, touch Browser icon or find it:
Application menu > Browser.
Search and address bar
8. Multimedia
8.1 Camera
Take a photo or record a video with the camera in your phone.
You can hold the camera horizontally or vertically. Share a photo
or a video with your friends, or upload your photos and videos to
a web service.
8.2 Music
The phone comes with a Music player that plays songs, listen to
audio book and podcasts you have stored. It gives you a host of
setting options to make your listening experience interesting.
8.3 Video player
Play video. Enter the video list, scroll the screen to browse and
choose the file you want to play.
8.4 FM Radio
The phone comes with an in-built FM Radio. You can listen to FM
radio stations, and add them to channel list. You have to plug in an
earphone, as the antenna of the FM radio. You can listen to the radio
either through an earphone, or through the speaker in the phone.
8.5 Sound recorder
Through the sound recorder function, you can record audio files.
9. Other application
9.1 Clock
The clock allows you to view time and date. You can also add an
alarm, set the alarm and turn it on. Then, the alarm can ring at a
specific time you set.
Add an alarm
1. From your Home screen, touch Launcher icon, then find it:
Application menu > Clock.
2. Touch .
3. Touch .
4. You need choose time. After you finish setting, touch “Done”,
and set time, ringtone, repeat, vibrate, etc.
5. Then the alarm can ring at a specific time you set.
9.2 Calculator
Keep your calculations on your finger tips with the calculator. Us-
ing this application allows you to make calculations. The calculator
provides the basic arithmetic functions; addition, subtraction, multi-
plication, and division. You can also use an advanced panel.
9.3 File manager
You can manage files, including Downloads, Music, and Received
Files. Press Add folder icon to create a new folder or select folders
to copy, move and delete.
9.4 Connect to a computer via USB
You can connect your phone to a computer with a USB cable to
transfer music, pictures, and other files between your phone’s SD
card and the computer.
You can not share your phone’s data connection and SD card via
USB cable at the same time. If you are using USB tethering, you
must turn that off first.

KF5 USER MANUAL - ENGLISH
7
10. Troubleshooting
If anything unusual occurs while using your Smart Phone, please
refer to the following table (next page).
Frequently
Occurring
Problems
Cause How to Fix
Poor
reception
Using the Smart Phone
in an area with poor
reception such as
near tall buildings or
in a basement where
radio waves cannot be
transmitted.
Try to avoid.
Using the Smart Phone
when the network is
busy, such as during
rush hour, when the
lines are full making
it impossible to get
through.
Try to avoid.
Related to the distance
from the base station
built by the network.
You can request that
the network service
provider provide a
service area plan.
Echo or noise
Caused by poor
network relay, a
regional problem.
Hang up and redial, if
the relay is changed
then the line may be
better.
Some calling regions
have poor lines.
Shortening of
the standby
time
Standby time is related
to the network system.
Please temporarily turn
off your Smart Phone,
as you are located
in an area with poor
reception.
Batteries need to be
replaced Replace the batteries
When you cannot get
a signal, the phone will
continue to transmit
in order to find a
base station, thereby
expending large
amounts of electricity
will cause the standby
time to decrease.
Please move to an area
with a strong signal
or temporarily turn off
your Smart Phone.
Unable to turn
on the phone The battery is empty. Look at the remaining electricity or recharge.
SIM card
malfunction
SIM card is damaged. Contact your network
service provider.
SIM card is not properly
inserted.
Confirm SIM card is
properly inserted.
There is a dirty
substance on the metal
surface of the SIM card.
Use a clean cloth to
wipe off the metal
contact point of the
SIM card.
Unable to
connect with
the network
Expired SIM card Contact your network
provider.
Outside the GSM
service area
Consult your network
provider on the service
area.
Poor signal
Please move to a place
with a better signal and
try again.
Unable to
make a call
Using the call bar
function
Cancel the call bar
function.
Using the fixed dial
function.
Cancel the fixed call
setting.
Incorrect PIN
number
Consecutively enter the
wrong password three
times.
Contact your network
provider.
Unable to
charge
The Battery or charger
is damaged.
Replace the battery or
charger.
Recharging in the
environment of less
than -10ºC or higher
than 55ºC.
Change the charging
environment.
Poor contact Check if the plug is
properly connected
Unable to add
new phone
book entries
The storage space of
the phone book is full
Delete a portion of the
phone number entries
Unable to
set certain
functions
Your network provider
does not support this
function or you have
not applied for it.
Contact your network
provider.

Rua Gaivotas em Terra · nº 2-S4 · Parque das Nações
1990-196 Lisboa · Portugal · tel. [phone]
[email protected] · www.ikimobile.com
