Siemens CT66 User manual

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Final\CT66_Cingular\Frame_und_Grafik\CT66_en_us\C66_IVZ.fm
Table of Contents 1
VAR Language: am; VAR issue date: 040720
See also Index at the end of this User Guide
left page (1) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (04.08.2004, 17:00)
Legal notices ...............................3
Safety precautions ......................5
Antenna care ............................7
Phone operation .......................7
Electronic devices .....................8
Overview of phone
(schematic) ...............................11
Display symbols ........................13
Getting started .........................15
Insert SIM card/battery ............15
Charge battery ........................16
Changing covers .....................18
Switch on/off, PIN entry ............19
Entering the PIN .....................19
Emergency number (SOS) .......19
General instructions .................20
Signal strength .......................20
Digital Rights Mgmt. (DRM) .....20
Standby mode ........................20
Main menu .............................20
Standard functions ...................22
Menu speed dialling ...............23
Security .....................................24
Codes .....................................24
Preventing accidental
activation ...............................25
Text entry .................................26
My phone ..................................30
Calling .......................................31
Swap between two calls .........33
Set Default Book ...................... 36
Address Book ............................ 37
New Entry .............................. 37
Change entry ......................... 39
Call entry ............................... 39
Show Groups ......................... 40
SmartChip ................................ 41
New Entry .............................. 41
Call (search for an entry) ........ 42
Change entry ......................... 42
<Other Books> ....................... 43
Recent Calls .............................. 44
Camera ..................................... 45
Main Inbox ............................... 47
Start menu ............................. 48
Login ..................................... 49
Contact lists ........................... 49
Start chat ............................... 51
Msg. History ........................... 52
Setting ................................... 52
Text Message ........................... 55
Write/send ............................. 55
Read ...................................... 57
Setting ................................... 59
Multimedia Msg ....................... 61
Create .................................... 61
Templates .............................. 63
Send ...................................... 64
Receive .................................. 65
Read ...................................... 66
Setting ................................... 67
Table of
Contents
See also In-
dex at the end
of this User
Guide

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Final\CT66_Cingular\Frame_und_Grafik\CT66_en_us\C66_IVZ.fm
2 Table of Contents
VAR Language: am; VAR issue date: 040720
See also Index at the end of this User Guide
left page (2) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (04.08.2004, 17:00)
Voice message/mailbox ........... 69
Games ...................................... 71
Games ................................... 71
MEdia Mall ............................... 73
Media Player ............................ 74
MEdia Net ................................ 75
Internet ................................ 75
Bookmarks ............................. 77
My Account .............................. 78
My MEdia ................................. 79
Favorites ................................ 80
Organizer ............................... 81
Extras .................................... 87
Fast access ............................... 92
Settings .................................... 94
Set Ringtones ......................... 94
Set Wallpaper ......................... 94
Set Screensaver ..................... 94
Set Themes ............................ 96
Audio Settings ....................... 96
Display Settings ..................... 98
Call Settings ........................... 99
Profile Settings ..................... 100
Phone Settings .....................102
Set Date/Time ....................... 103
Connectivity .........................104
Security ................................106
Network Settings ..................107
Accessories ..........................109
Mobile Phone Manager .......... 110
Questions & Answers ............. 113
Customer Care ........................ 116
Care and maintenance ........... 118
Limited Warranty ....................119
Product data ........................... 121
Accessories .............................122
Quality ....................................124
U.S. FDA .................................. 125
FCC/Industry Canada Notice ... 131
Ten driving safety tips ............ 132
Intellectual property .............. 134
SAR (CT66) ..............................135
End user license agreement ...137
Menu tree ...............................142
Index ....................................... 147

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
3Legal notices
VAR Language: am; VAR issue date: 040720
left page (3) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (04.08.2004, 16:57)
Legal notices
The mobile phone described in this guide is approved for use on the GSM and
GPRS networks operating on the GSM 900, 1800 (DCS/PCN) and 1900 (PCS)
bands. It is approved for use in the country where it was originally sold and
may be approved for use in other countries.
© 2004 Siemens Information and Communication Mobile, LLC.
All rights reserved.
Siemens and the CT66 model phone
are trademarks or registered trade-
marks of Siemens AG and/or its affili-
ates in the United States and/or
other countries.
T9® is a registered trademark of
America Online, Inc. in the United
States. Java and all Java-based trade-
marks and logos are trademarks or
registered trademarks of Sun Micro-
systems, Inc. in the U.S and other
countries. The names of actual com-
panies and products mentioned
herein may be the trademarks of
their respective owners.
Disclaimer
THE INFORMATION CONTAINED IN
THE USER GUIDE IS WRITTEN FOR
THE CT66 PHONE. SIEMENS
RESERVES THE RIGHT TO MAKE
CHANGES AND IMPROVEMENTS TO
THE PRODUCTS AND ANY OF THE
FEATURES OF THE PRODUCTS
DESCRIBED IN THIS DOCUMENT
WITHOUT PRIOR NOTICE. THE CON-
TENTS OF THE USER GUIDE ARE PRO-
VIDED "AS IS". EXCEPT AS REQUIRED
BY APPLICABLE LAW, NO WARRAN-
TIES OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRAN-
TIES OF MERCHANTABILITY AND FIT-
NESS FOR A PARTICULAR PURPOSE,
ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CON-
TENTS OF THIS DOCUMENT.
SIEMENS RESERVES THE RIGHT TO
REVISE THE USER GUIDE OR WITH-
DRAW IT AT ANY TIME WITHOUT
PRIOR NOTICE. UNDER NO CIRCUM-
STANCES SHALL SIEMENS BE
RESPONSIBLE FOR ANY LOSS OF
DATA OR INCOME OR ANY SPECIAL,
INCIDENTAL, CONSEQUENTIAL OR
INDIRECT DAMAGES HOWSOEVER
CAUSED.
Export Information
The mobile phone may be subject to
export regulation of the United
States and other countries. Diversion
contrary to law is prohibited. You
must comply with all applicable
export laws, restrictions and regula-

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
Legal notices4
VAR Language: am; VAR issue date: 040720
left page (4) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (04.08.2004, 16:57)
tions of the United States foreign
agencies or authorities, and may not
export, or transfer for the purpose of
re-export, the mobile phone or any
part of the phone in violation of any
applicable restrictions, laws or regu-
lations, or without all necessary
approvals.
Network Services
A number of features included in this
guide are called Network Services.
They are special services provided by
wireless service providers. In order
to use any of these Network Ser-
vices, you must subscribe to these
service(s) from your service provider
and obtain instructions for their use.
Some of these Network Services may
not be available when roaming on a
network other than your home
network.
Standby and
Talk Time Information
The mobile phone incorporates fea-
tures that are new to the mobile
phone world. These may include
color displays and lighting, graphic
games, music reproduction and
browsing the Internet. The way you
use the display and the features will
affect the performance of the bat-
tery and how long it lasts between
charge cycles. The quoted standby
times and talk times show the mini-
mum and maximum performance
that can be expected from the bat-
tery under normal network condi-
tions and with the default settings as
set by the factory. However, playing
games (particularly with the back-
light continuously switched on) and
listening to music will shorten the
time available for standby and to
make and receive telephone calls.
Operation times also vary depending
on network conditions, SIM settings,
charging and battery condition, how
you use your phone and other
factors.
Memory
The mobile phone contains an inter-
nal memory device that stores the
software required to operate the
mobile phone, communicate with
the GSM/GPRS network and provide
the user interface. Some features in
the internal memory run additional
devices and some additional games
and utilities. The amount of memory
available in the mobile phone is
finite and may be insufficient to
store large numbers of applications
and files.
Warning!
Remember to back up your data and to do
so frequently. Always back up all data and
programs before sending the mobile phone
in for repair.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
5Safety precautions
VAR Language: am; VAR issue date: 040720
left page (5) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (06.08.2004, 11:26)
Safety precautions
Information for parents
Please read the operating instructions and safety precautions carefully before use.
Explain the content and the hazards associated with using the phone to your children.
Remember to comply with legal
requirements and local restric-
tions when using the phone. For
example, in airplanes, gas sta-
tions, hospitals or while driving.
Cellular phones can interfere
with the functioning of medical
devices such as hearing aids or
pacemakers. Keep at least 8
inches (21 cm) between phone
and pacemaker. When using
the cell phone hold it to the ear
which is farthest from the pace-
maker. For more information
consult your doctor.
The ringtone (p. 94), info tones
(p. 97) and speakerphone talk-
ing are reproduced through the
loudspeaker. Do not hold the
phone to your ear when it rings
or when you have switched on
the speakerphone function
(p. 33). Otherwise you risk seri-
ous, permanent damage to your
hearing.
Do not use an optical magnifier
to look at the activated infrared
interface [Class 1 LED product
(classification as per
IEC 60825-1)].
Use only original Siemens bat-
teries (100% mercury-free) and
charging devices. Otherwise
you risk serious damage to
health and property: The battery
may explode, for instance.
The SIM card may be removed.
Caution! Small parts like this
could be swallowed by young
children.
The mains voltage specified on
the power supply unit (V) must
not be exceeded. Otherwise
the charging device may be
destroyed.
Do not open the phone. Only
the battery (100% mercury-
free) or SIM card may be re-
placed. You must not open the
battery under any circumstanc-
es. Any other changes to this
device are strictly prohibited, as
they will invalidate the type ap-
proval required for operation of
the unit.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
Safety precautions6
VAR Language: am; VAR issue date: 040720
left page (6) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (06.08.2004, 11:26)
Important
Please dispose of unwanted
batteries and phones as speci-
fied by the laws in your country.
The phone may cause interfer-
ence close to TVs, radios and
PCs.
Use only Siemens original ac-
cessories. This will avoid poten-
tial risks to health or property
and ensure compliance with all
relevant regulations.
Improper use will invalidate the warranty!
These safety instructions also apply to
Siemens original accessories.
Product attributes are subject to changes in
technology, design and availability.
Siemens reserves the right to modify prod-
ucts without prior notice.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
7Safety precautions
VAR Language: am; VAR issue date: 040720
left page (7) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (06.08.2004, 11:26)
Antenna care
Use only the supplied or an approved
replacement antenna. Unauthorized
antennas, modifications, or attach-
ments could damage the phone and
may violate FCC regulations.
Phone operation
Normal position
Hold the phone as you would any
other telephone with the antenna
pointed up and over your shoulder.
Tips on efficient operation
For your phone to operate most
efficiently:
• Extend your antenna fully
(if applicable).
• Do not touch the antenna unnec-
essarily when the phone is in use.
Contact with the antenna affects
call quality and may cause the
phone to operate at a higher pow-
er level than otherwise needed.
Driving
Laws pertaining to the use of mobile
phones while driving vary signifi-
cantly from state to state and some-
times even from locality to locality
within states. For example, some ar-
eas may allow persons to use their
mobile phones only if they employ a
hands-free device, and some areas
may prohibit the use of cell phones
entirely. Accordingly, Siemens rec-
ommends that persons check the
laws for the areas in which they drive
or will be driving. For areas where
the use of mobile phones while driv-
ing is permitted, Siemens encourag-
es persons to use their phones re-
sponsibly and to employ hands-free
devices. Also, if using your phone
while driving, please:
• Give full attention to driving –
driving safely is your first
responsibility;
• Use hands-free operation, if
available;
• Pull off the road and park before
making or answering a call, if
driving conditions so require.
For vehicles equipped with
air bags
An air bag inflates with great force.
DO NOT place objects, including ei-
ther installed or portable wireless
equipment, in the area over the air
bag or in the air bag deployment ar-
ea. If in-vehicle wireless equipment
Important
Read this information before using
your wireless handheld phone.
As this mobile phone is equipped
with a fixed (non-retractable) an-
tenna, some paragraphs in the text
below may not be applicable.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
Safety precautions8
VAR Language: am; VAR issue date: 040720
left page (8) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (06.08.2004, 11:26)
is improperly installed and the air
bag inflates, serious injury could re-
sult.
Electronic devices
Most modern electronic equipment
is shielded from radio frequency (RF)
signals. However, certain electronic
equipment may not be shielded
against the RF signals from your
wireless phone.
Pacemakers
The Health Industry Manufacturers'
Association recommends that a min-
imum separation of six inches (6")
be maintained between a handheld
wireless phone and a pacemaker to
avoid potential interference with the
pacemaker. These recommenda-
tions are consistent with the inde-
pendent research by and recommen-
dations of Wireless Technology
Research.
Persons with pacemakers
• should ALWAYS keep the phone
more than six inches from their
pacemaker when the phone is
turned ON;
• should not carry the phone in a
breast pocket;
• should use the ear opposite the
pacemaker to minimize the poten-
tial for interference;
• should turn the phone OFF imme-
diately if there is any reason to
suspect that interference is taking
place.
Hearing aids
Some digital wireless phones may
interfere with some hearing aids. In
the event of such interference, you
may want to consult your service
provider or your hearing aid manu-
facturer to discuss alternatives.
Other medical devices
If you use any other personal medi-
cal devices, consult the manufactur-
ers of your devices to determine if
they are adequately shielded from
external RF energy. Your physician
may be able to assist you in obtain-
ing this information.
Turn your phone OFF in health care
facilities when any regulations post-
ed in these areas instruct you to do
so. Hospitals or health care facilities
may be using equipment that could
be sensitive to external RF energy.
Vehicles
RF signals may affect improperly
installed or inadequately shielded
electronic systems in motor vehicles.
Check with the manufacturer or its
representative regarding your vehi-
cle. You should also consult the
manufacturer of any equipment that
has been added to your vehicle.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
9Safety precautions
VAR Language: am; VAR issue date: 040720
left page (9) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (06.08.2004, 11:26)
Posted facilities
Turn your phone OFF in any facility
where posted notices so require.
Airplanes
FCC and Airline Regulations prohibit
using your phone while in the air.
Turn your phone OFF when request-
ed by the airline.
Check and comply with the policy of
your airline regarding the use of your
phone while the airplane is on the
ground.
Blasting areas
To avoid interfering with blasting op-
erations, turn your phone OFF when
in a “blasting area” or in areas post-
ed: “Turn off two-way radio.” Obey
all signs and instructions.
Potentially explosive
atmospheres
Turn your phone OFF when in any
area with a potentially explosive
atmosphere and obey all signs and
instructions. Sparks in such areas
could cause an explosion or fire
resulting in bodily injury or even
death.
Areas with a potentially explosive at-
mosphere are often but not always
clearly marked. They include: fueling
areas such as gasoline stations; be-
low deck on boats; fuel or chemical
transfer or storage facilities; vehicles
using liquefied petroleum gas (such
as propane or butane); areas where
the air contains chemicals or parti-
cles, such as grain, dust or metal
powders; and any other area where
you would normally be advised to
turn off your vehicle engine.
Emergency calls (SOS)
Your wireless phone can be used
to make emergency calls. You can
make an emergency call from the
main display screen. Enter the local
emergency number such as 911 and
then press the Akey
This phone, like any wireless phone,
operates using radio signals, wire-
less and landline networks, and user-
programmed functions. Because of
this, connections in all conditions
cannot be guaranteed. Therefore,
you should never rely solely on any
wireless phone for essential commu-
nications (for example, medical
emergencies). Remember – to make
or receive any calls, the phone must
be switched on and be used in a ser-
vice area that has adequate signal
strength. Emergency calls might not
be possible on all wireless phone
networks or when certain network
services or phone features are in use.
Check with local service providers re-
garding their network features.
Always make certain that your
phone is properly charged before
attempting any emergency calls. If
you allow your battery to discharge,
you will be unable to receive or make

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
Safety precautions10
VAR Language: am; VAR issue date: 040720
left page (10) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (06.08.2004, 11:26)
calls, including emergency calls. You
must then wait a few minutes after
the charging begins to place any
emergency calls.
When making an emergency call,
remember to give all of the neces-
sary information as accurately as
possible. Remember that your wire-
less phone might be the only means
of communication at the scene of an
accident, therefore you should not
terminate the call until given permis-
sion to do so.
Batteries and Chargers
Only use original Siemens batteries
(100% mercury-free) and charging
devices. Use of non-Siemens batter-
ies and/or charging devices may
cause explosion resulting in serious
injury and/or property damage. Use
original Siemens accessories in order
to avoid possible injury and property
damage and to ensure compliance
with applicable laws and regula-
tions. Improper use invalidates the
warranty.
Battery safety precautions
To reduce the risk of fire, injury or
electric shock, and to properly dis-
pose of batteries, please read and
understand the following instruc-
tions. CONTAINS LITHIUM-ION OR
NICKEL-METAL HYDRIDE BATTERY.
BATTERY MUST BE RECYCLED OR DIS-
POSED OF PROPERLY. DO NOT DIS-
POSE IN MUNICIPAL WASTE.
1. Only use the batteries specified
for use with this mobile phone.
2. Do not use batteries of different
sizes or from different manufac-
turers in this mobile phone.
3. Do not dispose of the battery in a
fire; it may explode. Dispose of
used batteries and phones in
accordance with applicable laws
and safety regulations. Do not
expose battery to water. Check
with local codes for special dis-
posal instructions.
4. Do not open or mutilate the bat-
tery. Doing so may cause damage
to the eyes or skin.
5. Exercise care in handling the bat-
tery in order not to short the bat-
tery with conducting materials
such as rings, bracelets, and keys.
The battery or conducting mate-
rial may overheat and cause burns
or fire.
6. Charge the battery provided with,
or identified for use with, this
product only in accordance with
the instructions and limitations
specified in the User's Guide. Do
not attempt to charge the battery
by any means other than those
specified in the User's Guide.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
11Overview of phone (schematic)
VAR Language: am; VAR issue date: 040720
left page (11) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (06.08.2004, 11:26)
Overview of phone (schematic)
1ACall key
Dial displayed/highlighted phone num-
bers/names, take calls. Show last
phone numbers dialled in standby
mode.
2BOn/Off/End key.
• Switched off: press and hold to switch
on.
• During a conversation or in an appli-
cation: press briefly to end.
• In menus: press briefly to go back a
level.
Press and hold to go back to standby
mode.
• In standby mode: press and hold to
switch off phone.
3Joystick
CPress the joystick down vertical-
ly to start an application or
function.
In standby mode:
COpen Cingular homepage.
GOpen text message editor.
HOpen SmartChip/Addressbook.
EOpen IM.
DOpen My MEdia.
In lists, messages and menus:
IScroll up and down.
DBack a level.
EHas the same function as the
right soft key.
During a call:
ISet volume.
ECall options.
4Soft keys
The current functions of this key are
shown in the bottom line of the display
as §Text§/symbol (e.g. ?).
5Additional symbol to display which
function pressing the joystick has in
different situations (see p. 14).
‘X
Cingular
05/07/04 03:35
Menu ?Options
P
M

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
Overview of phone (schematic)12
VAR Language: am; VAR issue date: 040720
left page (12) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (06.08.2004, 11:26)
1Integrated antenna
Do not obstruct the phone above the
battery cover unnecessarily. This re-
duces the signal quality.
2Loudspeaker
3Display
4Infrared interface (IrDA)
5Camera
6Input keys
7*Ringtone
• Press and hold in standby mode:
Switch all audible signals on/off
(except alarm).
• Press and hold on incoming call:
Switch off ringtone for this call only.
8#Key lock
Press and hold in standby mode:
Switch key lock on/off.
9Connection socket
For charger, headset, flash etc.
:Connection for external antenna
!Camera lens
"Mirror (depending on phone model)
‘X
Cingular
05/07/04 03:35
Menu ?Options
P
M

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
13Display symbols
VAR Language: am; VAR issue date: 040720
left page (13) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (04.08.2004, 16:58)
Display symbols
Display symbols (selection)
`Signal strength
YCharging
WBattery charge level, e.g. 50 %
LAddress Book
PRecent Calls
MMessaging
@Camera
TSettings
ÇAll calls are diverted
ýMEdia Mall
OMEdia Net
ÿMy Account
¿Ringer off
¾Short ring (beep) only
¼Ringer only if the caller is stored
in the SmartChip.
¹Alarm set
ÄKeypad locked
ÅAuto answer feature on
T9Abc Text input with T9.
£Activated and available
¢Registered
¤Temporarily interrupted
±Browser offline
²Browser online
³Browser via GPRS online
´Browser no network
¯IrDA activated
®IrDA transmission
Events (selection)
ãSMS memory full
äMMS memory full
åPhone memory full
ÆNo network access
ÂMissed call
ÊDelete assistant
Message symbols (selection)
pUnread
qRead
rDraft
sDelivered
tMMS not sent
wMMS received
xMMS read
yMMS with DRM contents (p. 20)
ÀVoice mail received

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
Display symbols14
VAR Language: am; VAR issue date: 040720
left page (14) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (04.08.2004, 16:58)
Camera symbols
ÙBrightness
ÚZoom factor
ÛWhite balance
×Flash connected
Joystick symbols
îCamera
ñDelete
ðMake call/accept call
íMenu
ïZoom
ìOK

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
15Getting started
VAR Language: am; VAR issue date: 040720
left page (15) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (05.08.2004, 09:50)
Getting started
Insert SIM card/battery
The service provider supplies you with
a SIM card on which all the important
data for your line is stored. If the SIM
card has been delivered in credit-card
size, snap the smaller segment out
and remove any rough edges.
Press the grooved area 1, then push
the battery cover towards the front
in the direction indicated by the
arrow 2.
• Place the SIM card flat in front of
the slot with the contact surface
facing downwards. Then push
the SIM card in using gentle pres-
sure 3(ensure that the cham-
fered corner is in the correct
position).
• Insert the battery sideways into
the phone 4, then press it down-
wards 5until it clicks into
position.
• To remove, press the hook on the
right side 6outwards, turn the
phone over, and then shake out
the battery.
• Push the battery cover onto the
side hooks 7, until it clicks into
position.
1
2
3
4
5
6

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
Getting started16
VAR Language: am; VAR issue date: 040720
left page (16) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (05.08.2004, 09:50)
Charge battery
Charging procedure
The battery is not fully charged
when delivered. Plug charger cable
into the bottom of the phone, plug
power supply unit into a mains pow-
er socket and charge for at least
two hours.
YDisplay during charging.
Charging time
An empty battery is fully charged af-
ter about 2 hours. Charging is only
possible within a temperature range
of +5 °C to 45 °C (41 °F to 110 °F). If
the temperature rises/falls 5 °C
(41 °F) above/below this, the charge
symbol flashes a warning. The mains
voltage specified on the power sup-
ply unit must not be exceeded.
Additional information
Please switch off your phone before re-
moving the battery!
Only 3 V SIM cards are supported. Please
contact your service provider if you have an
older card.
SIM card problems ..........................p. 113
7

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
17Getting started
VAR Language: am; VAR issue date: 040720
left page (17) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (05.08.2004, 09:50)
Operating times
The operating time depends upon
the respective conditions of use. Ex-
treme temperatures considerably re-
duce the phone’s standby time.
Avoid placing the phone in the sun
or on a heater.
Talktime: 100 to 300 minutes
Standby time: 60 to 250 hours
Charge icon not visible
If the battery has been discharged
fully, the charge icon is not immedi-
ately visible when the power supply
is plugged in. It will appear after up
to two hours. In this case the battery
is fully charged after 3 to 4 hours.
Only use the plug-in power supply unit
supplied!
Display while in service
Charge level display during opera-
tion (empty – full):
VWX
A beep sounds when the battery is
nearly empty. The charge level of the
battery is only displayed correctly af-
ter an uninterrupted charging/dis-
charging cycle. You should therefore
not remove the battery unnecessarily and
where possible not finish the charging
procedure early.
Additional information
The power supply unit heats up when used
for long periods. This is normal and not
dangerous.
If the battery is removed for longer than
30 seconds, the clock must be reset.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
Getting started18
VAR Language: am; VAR issue date: 040720
left page (18) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (05.08.2004, 09:50)
Changing covers
Dismantle the phone
To remove the upper faceplate re-
move the battery cover (see p.10).
Use your fingers to press the side
hooks 1and insert your finger nail
into the division between the upper
and lower faceplates 2to release
the hooks in the lower part.
Assemble the phone
First insert the keypad mat 3into
the upper faceplate. Ensure that it is
sitting exactly in place.
Insert the phone into the bottom of
the upper faceplate 4and then
push it in carefully until it clicks into
position 5. Finally, replace battery
cover (see p. 15).
1
2
3
Please switch the phone off before chang-
ing the keypad mat or faceplate.
The new keypad has an additional key be-
neath the joystick to permit direct access
to the Internet information from the service
provider.
4
5

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
19Switch on/off, PIN entry
VAR Language: am; VAR issue date: 040720
left page (19) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (05.08.2004, 09:50)
Switch on/off, PIN entry
Switching phone on/off
BPress and hold the On/Off/
End key.
Entering the PIN
The SIM card can be protected with a
4to8-digitPIN.
JEnter the PIN using the
number keys. The charac-
ters **** appear to en-
sure nobody can read
your PIN on the display.
Correct with ].
CConfirm by pressing the
joystick. Logging on to
the network will take a
few seconds.
Emergency number
(SOS)
Only to be used in real emergencies!
By pressing the §SOS§ soft key you can
make an emergency call on any net-
work without a SIM card and without
entering a PIN (not available in all
countries).
Switching on your phone
for the first time
Set Date/Time
Set the clock correctly on a one-off
basis when getting started.
CPress this key, then select
§Change§.
JFirst enter the date (day/
month/year), then the
time (24 hours, including
seconds).
CPress. The time and date
are updated.
Set Time Zones
Set the time zone for your area.
ISelect the city in the de-
sired time zone from the
list ...
§Set§ ... and set it.
Copy SIM addresses
The first time the SIM card is insert-
ed, the entries on it can be copied to
the Addressbook. Please do not inter-
rupt this procedure. During this time
do not accept incoming calls. Follow in-
structions in the display.
You can also copy data from the
SIM card at a later time (p. 42).
Additional information
Change PIN.......................................p. 24
Clear SIM card barring ......................p. 25

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Fi-
General instructions20
VAR Language: am; VAR issue date: 040720
left page (20) of CT66 Cingular am, A31008-H7840-A65-1-4A19 (05.08.2004, 09:50)
General instructions
Signal strength
`Strong receiving signal.
^A weak signal reduces the
call quality and may lead
to loss of the connection.
Change your location.
Digital Rights Mgmt.
(DRM)
Remember that your phone has
Digital Rights Management. The use
of downloaded pictures, sounds or
applications can be restricted by the
suppliers, e.g. copy protection, use
for a limited period of time only,
number of times it can be used etc.
(see also p. 71).
Standby mode
The phone is in standby mode and is
ready for use when the name of the
service provider appears on the
display.
BPress and hold the On/Off/
End key to return to
standby mode from any
situation.
In standby mode, the left soft key
opens the main menu (p. 20) and
the right soft key opens the standby
mode options menu.
Standby mode options
Press §Menu§, then press §Options§.
Different functions are available de-
pending on the context.
Voice Mail, Messaging, Games, IM,
Speed Dial List, Recent Calls, My MEdia,
Address Book, Settings
Main menu
The main menu is displayed graphi-
cally with symbols.
§Menu§ Call up from standby
mode:
FISelect the application
symbols.
CStart an application.
?MEdia Net 5
PMþ
ýOÿ
NLT
Favorites ìOptions
