iLiving i3 User manual

i3 Foldable Electric Mobility Scooter
User Manual

Table of Contents:
I. Introduction [pg. 3]
a. Legal Disclaimer [pg. 3]
b. What’s In the Box / Optional Accessories [pg. 4]
c. Warranty Information [pg. 5]
II. Removing the Scooter from the Box [pg. 6 –pg. 8]
III. General Safety Warnings and Recommendations [pg.
9 –pg. 12]
IV. Using Your iLIVING Scooter [pg. 15 –pg. 19]
a. Folding/Unfolding the Scooter [pg. 20 –pg. 23]
b. Installing the Battery [pg. 25 –pg. 27]
c. Operating the Scooter [pg. 27 –pg. 30]
V. Care, Maintenance, and Basic Troubleshooting [pg.
30]
VI. Support and Contact Information [pg. 35]

Introduction
Thank you for your purchase of this brand new iLIVING Foldable Mobility
Scooter. For almost 10 years now, iLIVING has been creating and distributing the
finest products for your home, health, and well-being. Now, iLIVING introduces
its newest and most advanced product to date. This foldable mobility scooter is
designed to be comfortable, mobile, and travel-friendly. The iLIVING scooter
easily folds up in less than a minute, and features a nimble, lightweight design,
ensuring that this will be the best foldable mobility scooter you ever buy.
At iLIVING, we’re all about creating products that help foster an active,
healthy lifestyle. We believe that mobility scooters should complement an on-the-
go lifestyle, rather than hindering it. As such, creating a scooter that both carries
easily and folds up quickly became our driving goal.
It is imperative to the safe and effective operation of your iLIVING scooter
that you read and understand the User Manual in its entirety. Prior to
using/operating the iLIVING scooter for the first time, familiarize yourself with
the instructions and recommendations in this User Manual. If there is anything
within this User Manual which you do not understand, or you have questions
regarding the operation or maintenance of this scooter, please contact us right
away. Our Customer Service Department can be reached at 1-800-317-1688,
between the hours of 9 AM –5 PM (PST), Monday through Friday. We can also
be reached by email at [e-mail].
Legal Disclaimer:
iLIVING USA, including its affiliates and partners, cannot be held
responsible for personal injury or property damage that results from the unsafe or
improper use of the iLIVING i3 Scooter. Upon purchase of the iLIVING i3
Scooter, you agreed to use the iLIVING i3 Scooter in a manner consistent with the

instructions, recommendations, and directions provided to you in this User Manual.
iLIVING USA is not responsible for any injuries and/or damage resulting from any
person’s failure to exercise good judgment and common sense regarding the
operation of the iLIVING Scooter.
From time to time, iLIVING USA may make improvements, modifications,
adjustments, and other design changes to the iLIVING i3 Scooter. As a result of
this, there may be minor differences between the product you have purchased and
the images and instructions for the Mobility Scooter in this User Manual. If you
have any questions or concerns about your product or purchase, please feel free to
call us or email us.
What’s in the Box:
Inside the box of your new iLIVING i3 Foldable Electric Mobility Scooter should
be the following items:
iLIVING i3 Foldable Electric Mobility Scooter
2 Keys
A/C Wall Charger
1 Battery
Owner’s Manual
If there is anything missing from the box, please contact iLIVING USA
immediately. Please keep the original box that the iLIVING Scooter was shipped
to you in as this may prove useful and handy if you end up moving or need to send
in the scooter for service.
Optional Accessories:
Basket
Additional Battery
Armrests

Bigger Seat
Carrying Bag
Portable Charger
Lift
These accessories are available for purchase either at the time of your Scooter
purchase or by contacting iLIVING USA.
Warranty Information
The iLIVING Scooter comes with a (3) three year limited parts and components
warranty for the frame/structure of the scooter and a (1) one year limited parts and
components warranty for the electrical components on the scooter. The battery for
the iLIVING Scooter is only covered under warranty for (6) six months. If a
problem arises with your iLIVING Scooter, please contact us immediately.
If a problem arises with your iLIVING Scooter within 30 days of purchase, we will
bring in the scooter for service at no cost to you. We will pay for the shipping of
the scooter to and from our service center. In addition, all parts and labor fees will
be waived. We require a proof of purchase; please keep your receipt/invoice from
the purchase of the iLIVING Scooter.
After 30 days from purchase, and within the warranty period, you will be
responsible for covering the shipping of the scooter to our service center. The parts
and labor fees will still be waived. Once the scooter has been serviced and
repaired, we will ship the scooter back to you at our cost.
We also offer the option of sending you a part directly to replace yourself on your
iLIVING Scooter. Please note that under warranty, the part(s) is/are free. A
shipping and handling fee does apply. The warranty covers parts and service; it
does not cover shipping/handling.
Due to safety considerations, there are a few actions which would cause the
warranty to be voided. Please note that any unauthorized changes to the design of

the iLIVING Scooter, as well as the use of any non-authorized parts in the repair of
the iLIVING Scooter will void the warranty. Further, the warranty for the
iLIVING Scooter does not cover any mechanical damage caused by accidents
involving the scooter with property or persons, or for any mechanical damage
caused by improper use of the iLIVING Scooter. Proper and appropriate use of the
iLIVING Scooter is necessary at all times. The following pages of this User
Manual will give detailed instructions on using, operating, and maintaining your
iLIVING Scooter.
Please note that the warranty for this iLIVING Scooter is non-transferrable and
only applies to the original owner of the iLIVING Scooter. We do not provide any
warranty coverage for scooters that are re-sold, as we cannot guarantee the quality
or safety of the product.

Removing the Scooter from the Box:
NOTE: First take out the Accessory Box and the protective
paper columns on the side.
Step 1: Step 2:
Open the Tiller Adjustment Carefully tilt the box to the side.
Latch and pull the handlebars up
towards you.
Step 3: Step 4:
Lay the box flat on the Pull up the handlebars with
ground. both hands.

Step 5: Step 6:
Pull up the handlebars to Carefully pull the scooter
the top edge of the box. outward along the rails.
Step 7: Step 8:
Pull out the entire Scooter. Reposition the scooter so
that it is upright as shown.

General Safety Warnings and Recommendations
Before you begin operating your iLIVING Scooter, it is imperative that you read
and understand these health warnings, safety guidelines, and recommendations for
use.
Please read and review this User Manual as often as needed.
IMPORTANT NOTICE –READ BEFORE OPERATING
YOUR iLIVING SCOOTER
1. Every iLIVING Scooter is a little bit different. Just like with a new car,
please take the time to familiarize yourself with your iLIVING Scooter.
Take in the feel of the seat and get a sense of your surroundings while sitting
on the scooter. Check to see that you understand all the functions on the
scooter dashboard in front of you before beginning to operate your scooter.
2. We recommend that you consult a health care professional as to the
adjustments on this scooter that would best suit your individual needs. Every
person’s body type is different. The iLIVING Scooter should be adjusted to
fit your individual needs and to ensure the smoothest and most comfortable
ride possible.
3. Before attempting to operate your new iLIVING Scooter for the first time,
you should take the time to read and understand how to safely operate your
iLIVING Scooter. If you need additional information, please contact us at
any time.

4. Have someone help you practice reaching, transferring to, and/or bending
towards the iLIVING Scooter until you are comfortable doing these actions
safely on your own.
5. It is important that you familiarize yourself with the areas where you plan on
using the iLIVING Scooter. As much as possible, check for potential
hazards in these areas and learn how to avoid terrain that may be unstable or
uneven. Uneven/unstable terrain will increase the risk of your iLIVING
Scooter tipping over.
6. The iLIVING Scooter is intended for one person only. There should never
be additional persons riding or hanging onto the scooter or armrests while
the scooter is in operation.
7. The weight capacity of the iLIVING i3 Scooter is 300 lbs. The scooter
operator and any additional items on the scooter should not exceed 300 lbs.
Exceeding the weight capacity on the scooter will likely cause damage to the
seat, frame, and fasteners, leading to scooter failure.
8. Exceeding the weight limit will void the warranty.
9. Whenever your scooter is parked or idle, please power down the scooter.
This action serves several purposes. By powering down the scooter, you can
prevent the scooter from moving forward or backward as a result of
accidental contact with the throttle lever and/or interference from EMI
sources.
10.It will take some time for you, the scooter operator, to become familiar with
the display functions on the dashboard of the scooter as well as the
sensitivity of the throttle lever in adjusting speed and slowing down to a
stop.

11.Never attempt to go up or down stairs or escalators on your iLIVING
Scooter. The scooter was never designed for that sort of operation and doing
so will cause severe damage to the scooter and potential injury to you.
12.The iLIVING Scooter is not waterproof or water-resistant. You should never
use your iLIVING Scooter in the rain or very wet surfaces. If your iLIVING
Scooter will be stored outdoors, please make sure that it is covered with a
waterproof tarp to ensure that no water gets into the electrical components of
the scooter.
13.Contact with water can cause an electrical malfunction and severely damage
the scooter.
14.Similarly, the iLIVING Scooter was not designed for use in the snow, on icy
surfaces, or in the sand or on rocky and uneven surfaces that may damage
the undercarriage of the mobility scooter.
15.If you feel that any of the wheels on the iLIVING Scooter is losing traction,
stop immediately. All four wheels of the iLIVING Scooter must have
traction in order for the scooter to perform properly. Otherwise, the scooter
may lose control and risk tipping over.
16.As with all electrical devices and electrically-powered vehicles, the
iLIVING Scooter may be susceptible to electromagnetic interference (EMI)
from a variety of radio wave sources. Electromagnetic waves emitted from
sources such as, but not limited to, TV stations, two-way radios, cell phones,
radio stations, and “HAM” radio transmitters may cause the iLIVING
Scooter to move by itself, move in a direction un-intended by the operator of
the scooter, and/or cause the brakes to accidentally release or engage. These
EMI sources may also permanently damage the iLIVING Scooter’s control
system.
17.Electromagnetic interference from various sources vary in intensity as well
as potential for effect on your iLIVING scooter. Every electrically powered
vehicle can resist EMI sources up to a certain intensity. That means that each

electrically powered vehicle has a certain “immunity” to EMI interference.
The intensity of the interfering EMI source can be measured in volts per
meter (V/m). Your iLIVING Scooter has an immunity level of 20 V/m.
18.Electromagnetic energy rapidly gains intensity as you move closer to the
transmitting source. As such, certain devices are of particular concern if the
iLIVING Scooter is used near or around these devices. EM interference
from hand-held radio wave sources are usually of the highest intensity and
thus, most prone to cause damage to your iLIVING Scooter’s control system
or affect the functions of your scooter. These hand-held sources include, but
are not limited to, cell phones and CB radios. It is always a good idea to turn
OFF your cell phone when you are using your iLIVING Scooter.
19.If you notice that your scooter is moving on its own or that the brakes
release or engage unintentionally, power OFF your scooter immediately and
check for potential sources of EMI interference.
20.When driving your scooter up an incline, lean forward slightly in the seat
and place your feet on the floorboard. Make sure your back is not on the
backrest. This will correct your center of balance and reduce the risk of your
scooter tipping over.
The warning labels shown below are located on different parts of the scooter.
Please pay close attention to these labels. The labels are designed to help you
understand how to safely and effectively use your new iLIVING Scooter.
Battery Switching Label
Free Wheel Release Switch Label:
Neutral and DRIVE

Armrest Warning Label Weight Capacity & Do Not Drive Under
Rain/Snow Label
STOP Label

Pinch Point Warning Label Maximum incline angle Warning Label
Open Here Label Warning Label:

Using Your iLIVING i3 Scooter

Understanding the Dashboard:
The majority of the functions on your iLIVING Scooter can be found on the
dashboard. Once the key is inserted and the scooter is turned on, the battery status
display will light up and display the current battery charge of the scooter.

Once the scooter is turned on, the battery display icon should light up and
the light should remain solid. If the battery display icon light is flashing, refer to
the Basic Troubleshooting section for potential scooter malfunction reason.
The yellow horn button will only work if the Horn Switch on the back of the
scooter is turned on. If the Horn Switch is turned on, pressing the yellow horn
button will cause the scooter to emit a brief “beep,” to alert people in front of your
scooter.
If you want the scooter to move forward, push the Speed Control Throttle on
the right hand side. If you want the scooter to move backward, push the Speed
Control Throttle on the left hand side.
Remember to turn off your scooter and remove the keys when the scooter is
not in use. This will help save battery life as well as protect your scooter from
unauthorized use.

When you sit on the scooter, you will notice a small USB port underneath the
dashboard. This USB port is designed to be a cell phone or tablet charger.
Product Specifications
Model Name
i3
Number of Tires
4 Solid Wheels
Keys
2 PCS
Total Weight (w/Battery)
54 Lbs
Maximum Capacity
300 lbs
Front Wheel Size
7”
Rear Wheel Size
8”
Seat Options:
Standard 16W x 15D
Premium 18W x 18D
Ground Clearance
1.6”
Length
37” (unfolded)
Width
18
Height (Steering
Handlebar)
28” – 36”
Steering Handlebar Angle
Adjustable with variable angle
Seat Height
22” from ground
Armrest Width
Variable
Motor
120W
Battery
25.2V/11.6 AH Lithium Battery
Battery Charger
DC29.4V Off-Board Automatic Protection Charger
Input Voltage: 100-240VAC
Battery Flight Mode
Yes
Backup Beep
On/Off
Horn
On/Off
Frame Structure
Aluminum with Automobile-Grade Body Kit
Cellphone Charger
5V/0.5A
Front Safety Light
LED White
Rear Safety Light
LED Red
Braking System
Electromagnetic Brake
Drive System
Rear Wheel Drive System with Freewheel Option
Speed
Up to 4 miles an hour

Travel Range
Up to 14 miles per charge
Turning Radius
48”
Maximum Incline Angle
Up to 8 degree
Storage Compartment size
2.5 W x 8”L
You are now ready to begin using/operating your iLIVING i3 Scooter. The
following pages will guide you on how to fold and unfold your iLIVING scooter as
well as how to charge the battery, the various functions on the scooter, and how to
safety and effectively operate the iLIVING scooter.
Folding/Unfolding Your Scooter:
Unfolding the Scooter:
Push the black release lever under the handlebars on the scooter (as shown in the
diagram below) to unfold the scooter frame.
Unlocking Lever
