Illumination SF100 User manual

SF100 Series
INSTALLATION INSTRUCTIONS
REMODEL NON-INSULATED CEILING INSTALLATION TYPE
Type Model No. Input
VoltageWattage Frequency Lumen Cutout Dimming Type
Light Engine Kit
LTE100RXX-XXXX-X-RM 1200lm Ø105mm(4.13”)
LTE100SXX-XXXX-X-RM 1200lm □105mm(4.13”)
Power-supply
Assembly
LTE100RME1-XXX 120-277V 20W 50/60Hz TRIAC/ELV
(DIM ON 120V)
LTE100RMA3-XXX 120-277V 20W 50/60Hz 0~10V
Frame Kit LTE100FK-RD(SQ)
1Prepare frame kit for ceiling installation
1x Light engine kit 1x Power supply
assembly
1x Frame kit
Installation Instruction
For Lithe 100 Family
WARNING
&
CAUTION
1. This luminaire must be installed in accordance with National Electrical Code and
local electrical and construction regulations. To assure full compliance with local
codes and regulations, check with your local electrical inspector before installation.
2. To prevent electrical shock, turn off electricity at fuse box before installation.
3. Product is not rated for insulation contact. Do not install insulation within 3 inches of
fixtures sides or drivers sides.
4. Do not exceed product specified luminaire voltage. Any other source will void
warranty.
5. Do not install if luminaire, parts or connectors are damaged.
6. Product must be installed with provided LF Illumination drivers and housings only.
Use of other manufacturers’ components will void warranty.
New construction non-insulated ceiling installation type
a. Make sure end tab on hanger bars is
facing outward.
b. Extend bar hangers to fit between
joists and position fixture by
hammering nail on bars into the joists.
c. Use T-Bar slot in the bottom of the
hanger bars for suspended ceilings,
bending the tabs to hold T-Bar tightly.
Components Delivered
WARNING
&
CAUTION
It is IMPORTANT TO READ instruction sheets completely before installation
Components Delivered
1Make ceiling cutout 2Run wires to power supply assembly
1x Light engine kit 1x Power supply assembly
Flex-conduit connector/
duplex connector
(supplied by others)
HEADQUARTERS
9200 Deering Avenue
Chatsworth CA 91311
Telephone: [phone]
Toll Free: 855-885-1335
Fax: [phone]
©2020 LF ILLUMINATION LLC
We reserve the right to change or
withdraw specifications without prior notice.
www.lfillumination.com
PAGE 1
rev: 012220

HEADQUARTERS
9200 Deering Avenue
Chatsworth CA 91311
Telephone: [phone]
Toll Free: 855-885-1335
Fax: [phone]
©2020 LF ILLUMINATION LLC
We reserve the right to change or
withdraw specifications without prior notice.
www.lfillumination.com
PAGE 2
rev: 012220
3Wiring scheme 4Install power supply assembly
into ceiling
5Connect power supply assembly to
light engine 6Lift clamps
7Install light engine to the ceiling
Dimming
The luminaire is compatible with leading & trailing edge phase cut
dimmers (TRIAC/ELV) and 0~10V dimmers. Please consult Factory for
compatibility.
Type A B C D E T
SF100 ≧3”
[75mm]
≧1¾”
[30mm]
Ø1¾”
[43mm]
≧3”
[75mm]
≧3”
[75mm]
¼”-¾”
[5-18mm]
Luminaire not
suitable for covering
with thermally
insulating materials
(ELV dimming) (0-10V dimming)
CAUTION:
ALL WORK MUST BE DONE WITH CIRCUIT OFF AND
COMPONENTS SHOULD NOT BE INSTALLED WHEN
ENERGIZED.
