iLoq P55S User manual

Document ID
239669
05/2023
Rev 1.2
iLOQ Oy
www.support.iloq.com
P55S Programming Key
User Guide
iLOQ P55S Programming Key
iLOQ A00.18 Desktop Programming Adapter
iLOQ A00.17 Programming Cable
iLOQ A00.20 Handheld Programming Adapter

1. Contents ................................................................................................................. 2
2. Safety Information.................................................................................................. 3
2.1 Safety signs .................................................................................................... 3
2.2 Warnings......................................................................................................... 3
3. Products .................................................................................................................. 4
4. Care and Maintenance .......................................................................................... 4
5. Before use............................................................................................................... 4
6. Operating instructions of the P55S Programming Key....................................... 5
6.1 Connecting the P55S Programming Key to the
A00.18 Desktop Programming Adapter ...................................................... 5
6.2 Programming with the A00.18 Desktop Programming
Adapter connected to a PC.......................................................................... 5
6.3 Programming without an A00.18 Desktop Programming Adapter ........... 6
6.4 Programming offline (without a PC connection) ......................................... 8
6.5 LED functions of the P55S Programming Key ............................................. 8
6.6 Charging the P55S Programming Key ......................................................... 9
6.7 Battery charging specifications .................................................................... 9
7. Accessories............................................................................................................. 10
8. Disposal of Decommissioned Products ............................................................... 11
9. Compliance ............................................................................................................ 12
1. Contents
2
P55S Programming Key
User Guide
P55S Programming Key

2. Safety Information
2.1 Safety signs
Sign Description
General notice sign. Indicates particularly important
information about the installation and deployment.
Read these instructions carefully before using products.
This information is to ensure your safety and the long
lifetime of the products.
2.2 Warnings
Sign Description
Warning! K55S / P55S contains a non-replaceable rechargeable
battery. Disposal of a battery into fire or a hot oven, or
mechanically crushing or cutting of a battery can result in an
explosion.
Warning! Leaving a battery in an extremely high temperature
environment can result in an explosion or the leakage of
flammable liquid or gas.
Warning! A battery subjected to extremely low air pressure may
result in an explosion or the leakage of flammable liquid or gas.
3
P55S Programming Key
User Guide
P55S Programming Key

3. Products
1
24
3
1. iLOQ A00.18 Desktop Programming Adapter
2. iLOQ P55S Programming Key
3. iLOQ A00.17 Programming Cable
4. iLOQ A00.20 Handheld Programming Adapter
4. Care and Maintenance
• The product is designed to be maintenance-free. It does not require any regular maintenance.
• Do not use the P55S Programming Key for other purposes except those mentioned in these instructions.
• Using the P55S Programming Key for other purposes may damage it.
• The P55S Programming Key is to be kept secure so that only an authorized person can use it.
• In case of losing the P55S Programming Key, contact the administrator of the locking system.
• Maximum temperature range for use: -20 - +60C
• Maximum temperature range for charging: 0 - +45C
• Ingress protection rating: IP68. Keep the P55S Programming Key clean and dry. If the P55S
Programming Key is wet or dirty, use a soft cloth for drying and cleaning.
• For more detailed technical information, see the P55S Programming Key datasheet.
• The P55S Programming Key is an electronic product including a Lithium-Ion
rechargeable battery. Appropriate recycling as WEEE waste must be followed.
• For customer claims, technical support etc., please contact your administrator.
Your administrator will contact the appropriate iLOQ partner for support.
• Recharge the P55S Programming Key if operation is abnormal. During charging, the P55S
Programming Key resets. If abnormal operation continues, contact locking system administrator.
5. Before use
To ensure correct operation, charge the P55S Programming Key before first use.
4
P55S Programming Key
User Guide
P55S Programming Key

6. Operating instructions of the P55S Programming Key
The P55S Programming Key is used with the iLOQ Manager software. All programming tasks are prepared in the
Manager and then transferred to the P55S Programming Key via USB.
6.1 Connecting the P55S Programming Key to the A00.18 Desktop
Programming Adapter
The A00.18 Desktop Programming Adapter allows a PC and an A00.17 Programming Cable to be connected to
the P55S Programming Key at the same time. This way you can transfer programming tasks to the memory of
the P55S Programming Key and also use the A00.17 Programming Cable without having to swap cables.
1. Connect the P55S Programming Key to the custom USB cable inside the adapter.
Note: This cable is a custom-made cable and cannot be replaced with a standard USB Micro-B cable, if
broken.
6.2 Programming with the A00.18 Desktop Programming Adapter
connected to a PC
1. Connect a computer to the adapter PC port with a standard USB Micro-B cable.
5
P55S Programming Key
User Guide
P55S Programming Key

6
P55S Programming Key
User Guide
P55S Programming Key
2. If you need to program key operated locks, connect the A00.17 Programming cable to the
adapter PROG port.
3. Execute the programming tasks from the iLOQ Manager to transfer them to the P55S Programming Key.
4. When programming K5S Key operated locks, use the A00.17 Programming cable. When programming
other iLOQ products, use the programming area of the A00.18 Programming Adapter.
6.3 Programming without an A00.18 Desktop Programming Adapter
1. Connect the P55S Programming Key directly to the USB port of a PC with a standard USB Micro-B cable.

7
P55S Programming Key
User Guide
P55S Programming Key
2. Execute the programming tasks from the iLOQ Manager to transfer them to the P55S Programming Key.
3. Place the P55S Programming Key on the product you intend to program while the PC is connected.
For best performance, touch the reader antenna or K5S key bow with the bottom of the P55S
Programming Key as shown in the following illustration.

6.4 Programming offline (without a PC connection)
After transferring the tasks to the P55S Programming Key, disconnect the P55S Programming Key from the
computer and program the intended locks and keys on-site. To program key operated locks, you need the
A00.17 Adapter Cable.
6.5 LED functions of the P55S Programming Key
Light indicators Description
• Amber light while programming • Programming Key communicating
• Green light after amber • Programming completed
• Red light after amber • Programming failed
• Red blinks, 0,1 sec once a minute • Battery empty. Charge the battery.
• Amber blinks, 1 sec once a minute • Battery low. Charge the battery.
8
P55S Programming Key
User Guide
P55S Programming Key

6.6 Charging the P55S Programming Key
To charge the P55S Programming Key, use the USB Micro-B connector.
6.7 Battery charging specifications
Unit Value
• Voltage • 5 V
• Current • 100 mA
• Charging time • 3 hours
• Capacity • 150 mAh
Light indicator Meaning
• Solid red light • Battery charging
• Solid green light • Battery fully charged
9
P55S Programming Key
User Guide
P55S Programming Key

7. Accessories
• The A00.20 Handheld Programming Adapter can be used to help hold a P55S Programming Key on
round readers during programming.
• The AK50.1-AK50.9 Color Markers can be used to personalize P55S Programming Keys.
To replace the Color Marker, remove the old one with a suitable tool and replace it with a new one.
10
P55S Programming Key
User Guide
P55S Programming Key

11
P55S Programming Key
User Guide
P55S Programming Key
8. Disposal of Decommissioned Products
Never discard an electrical appliance in household waste. Follow
the local laws and regulations for safe and environmentally friendly
product disposal.
Before discarding products, bear in mind that most iLOQ products
are reusable. All programmable products can be reset to factory
settings, after which they can be reused in another system or an
entirely new system.
Recycling instructions of decommissioned products are depicted below.
Decommisioned product Sorting
Decommissioned iLOQ fittings, mounting accessories and thumb
turn knobs can be recycled as scrap metal.
Decommissioned iLOQ products containing electronics and circuit
boards, such as iLOQ Lock Cylinders, keys, net bridges, door
modules, key and RFID readers, and relay cards, must be recycled
at an electrical and electronic equipment collection point.
iLOQ products containing batteries and accumulators, such as key
fobs, programming keys and clock circuits, should be recycled at a
regional collection point for batteries and small accumulators.
Most iLOQ packaging materials are suitable for cardboard and
plastic recycling.

12
P55S Programming Key
User Guide
P55S Programming Key
9. Compliance
The products mentioned inside this user guide are in conformity with the requirements of the directives
declared on this page.
CE
SIMPLIFIED EU DECLARATION OF CONFORMITY:
Hereby, iLOQ Oy declares that the radio equipment type H50S Padlocks are in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address:
https://www.iloq.com/en/company/patents-and-approvals/
Communication standard: NFC 13,56 MHz Load modulation (ASK) ISO/IEC 14443A, no transmitter.
FCC
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s) and complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operation of the device.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications made to this equipment not expressly approved by iLOQ Oy may void the FCC
authorization to operate this equipment.
System Frequency Maximum SAR
• NFC • 13.56 MHz • 0.03 W/kg (SAR1g)

13
P55S Programming Key
User Guide
P55S Programming Key
UKCA
Hereby, iLOQ Oy declares that the radio equipment type H50S Padlocks are in compliance with the UK
relevant statutory requirements. The full text of the declaration of conformity is available at the following
internet address: https://www.iloq.com/en/company/patents-and-approvals/

iLOQ
www.support.iloq.com
Elektroniikkatie 10
90590 Oulu
Finland
