MINICUBE-60
Order No. 38.7980
INSTRUCTION MANUAL
Compact LED Moving Head
MONACOR INTERNATIONAL GmbH & Co. KG • Zum Falsch 36 • 28307 Bremen • Germany
www.monacor.com 01.21.02.2017

Introduction
Unpacking: Thank you for purchasing the MINICUBE-60.
Every fixture has been thoroughly tested and has been shipped in perfect
operating condition. Carefully check the shipping carton for damage that may
have occurred during shipping. If the carton appears to be damaged,
carefully inspect your fixture for any damage and be sure all accessories
necessary to operate the unit has arrived intact. In the case damage has
been found or parts are missing, please contact the manufacturer or your
dealer for further instructions. Do not return this unit to your dealer without
first contacting.
Warning! To prevent or reduce the risk of electrical shock or fire, do not
expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not attempt
any repairs yourself; doing so will void your manufactures warranty. In the
unlikely event your unit may require service please contact the manufacturer
or your dealer.
Features:Technical Specification
◇Extremely small, fast and powerful LED moving beam.
◇DMX Channels: 69/27/23/8 CH
◇Pan: 540°, speed adjustable; Tilt: 360° continuous rotation
◇Each LED and LED stripe can be controlled individually
◇Electronic strobe with pulse and random effects
◇High efficiency, low power consumption
◇Super compact, low weight
◇Beam angle: 8°
Voltage: AC 230 V, 50 Hz
Light source: 6*12 W 4 in 1 RGBW OSRAM+12*6*5050SMD 3 in 1 RGB LED
Power: 170 VA
Dimensions: W 270 x H 350 x D 200 mm
Net Weight: 6.0 kg
How to control the unit
You can operate the unit in two ways.
1.Master/slave built-in preprogram function
2.Universal DMX controller
No need to turn the unit off when you change the DMX address, as new
DMX address setting will be effect at once.
Every time you turn the unit on, it will show MINICUBE-60 on the display
and move the motors to their position and you may hear some noises for
about 20 seconds, after that the unit will be ready to receive DMX signal or
run the built in programs.
Sound sense
Select Sound sense, press the enter button to confirm, present mode will
blink on the display. Use the down and up button to change the
sound sense from 0-100. Once the mode has been selected, press the
ENTER button to setup, to go back to the functions without any change the
MENU button again. Hold and press the MENU button about one second or
wait for one minute to exit the menu mode.
Pan Reverse
With this function you can reverse the Pan-movement.
211

34/37/40/43/46/49
52/55/58/61/64/67
0-255 5050 LED-Green dimmer0-100%
35/38/41/44/47/50
53/56/59/62/65/68
0-255 5050 LED-Blue dimmer0-100%
69 000-199 No function
200-209 Reset
210-239 No function
240-255 Sound active
Set Up
Power Supply: Before plugging your unit in, be sure the source voltage in your
area matches the required voltage for your fixture, The model is
workable in AC230V,50Hz. Please make sure your unit voltage matches
the wall outlet voltage before attempting to operate you fixture.
DMX Linking: To ensure proper DMX data transmission, when using several
DMX fixtures try to use the shortest cable path possible. The order in which
fixtures are connected in a DMX line does not influence the DMX addressing. For
example; a fixture assigned a DMX address of 1 may be placed anywhere in a
DMX line, at the beginning, at the end, or anywhere in the middle. When a fixture
is assigned a DMX address of 1, the DMX controller knows to send DATA
assigned to address 1 to that unit, no matter where it is located in the DMX chain.
LED display menu:
DMX address DMX Address (1-512)
Channel mode 69/27/23/8 CH
Slave mode Master mode
Slave 1
Slave 2
Auto Run Mode Auto 0—16(speed 0—9)
Show model Show 0
Show 1--16
Sound State On/off
Sound Mode 0-100 from slow to fast
Backlight ON/OFF
Pan Inversion YES/NO
Test testing
Fixture Time Fixture work hours 0---9999
Firmware Version Ver
Reset
10 3

DMX MODE:
8 CH MODE:
Channel DMX Value Function
1000-255 10W R LED Dimmer0%~ 100%
2000-255 10W RGBW LED Strobe from slow to fast
3000 - 255 5050 R LED Dimmer 0%~ 100%
4000-255 5050 LED Strobe from slow to fast
5000-007 0
008-022 Pan/Tilt Movement 01
023-037 Pan/Tilt Movement 02
038-052 Pan/Tilt Movement 03
053-067 Pan/Tilt Movement 04
068-082 Pan/Tilt Movement 05
083-097 Pan/Tilt Movement 06
098-112 Pan/Tilt Movement 07
113-127 Pan/Tilt Movement 08
128-142 Pan/Tilt Movement 09
143-157 Pan/Tilt Movement 10
158-172 Pan/Tilt Movement 11
173-187 Pan/Tilt Movement 12
188-202 Pan/Tilt Movement 13
203-217 Pan/Tilt Movement 14
218-232 Pan/Tilt Movement 15
233-247 Pan/Tilt Movement 16
248-255 Sound active
6000-255 Movement Speed slow to fast
7000-014 Color
015-255 Color Chase
8000 - 255 Chase Speed slow to fast
068-082 Pan/Tilt Movement 05
083-097 Pan/Tilt Movement 06
098-112 Pan/Tilt Movement 07
113-127 Pan/Tilt Movement 08
128-142 Pan/Tilt Movement 09
143-157 Pan/Tilt Movement 10
173-187 Pan/Tilt Movement 12
188-202 Pan/Tilt Movement 13
203-217 Pan/Tilt Movement 14
218-232 Pan/Tilt Movement 15
233-247 Pan/Tilt Movement 16
248-255 Sound active
27 000-255 Movement Speed slow to fast
69 CH MODE:
Channel DMX
Value
Function
10-255 Pan 0°~ 540°
20-255 Pan fine
30-255 Pan Speed fast to slow
4000- 127 Tilt 0°~ 360°
128- 189 Tilt clockwise Rotation fast to slow
190- 193 Tilt Stop
194- 255 anticlockwise Rotation slow to fast
50-255 10W RGBW LED- -Dimmer
60-255 10W RGBW LED- Strobe slow to fast
7/11/15/19/23/27 0-255 RGBW LED--Red dimmer0-100%
8/12/16/20/24/28 0-255 RGBW LED--Green dimmer0-100%
9/1317/21/25/29 0-255 RGBW LED--Blue dimmer0-100%
10/14/18/22/26/30 0-255 RGBW LED--White dimmer0-100%
31 0-255 5050 LED All dimmer 0-100%
32 0-255 5050 LED strobe slow to fast
33/36/39/42/45/48/51/
54/57/ 60/ 63/66 0-255 5050 LED--Red dimmer0-100%
49

11 0-255 RGBW LED6--Color
12 0-255 5050 LED- Dimmer 0%~ 100%
13 000-255 Strobe from slow to fast
14 000 - 007 5050 LEDs Strip1--Blackout
008 - 024 5050 LEDs Strip1--color1
025 - 041 5050 LEDs Strip1--color2
042 - 057 5050 LEDs Strip1--color3
058 - 074 5050 LEDs Strip1--color4
075 - 090 5050 LEDs Strip1--color5
091--107 5050 LEDs Strip1—color6
108 - 123 5050 LEDs Strip1 -color7
124 - 140 5050 LEDs Strip1 -color8
141 - 156 5050 LEDs Strip1 -color9
157 - 173 5050 LEDs Strip1 -color10
174 - 189 5050 LEDs Strip1 -color11
190 - 206 5050 LEDs Strip1 -color12
207 - 222 5050 LEDs Strip1--color13
223 - 239 5050 LEDs Strip1--color14
240 - 255 5050 LEDs Strip1--color15
15 000 - 255 5050 LEDs Strip2--Color
16 000 - 255 5050 LEDs Strip3--Color
17 000 - 255 5050 LEDs Strip4--Color
18 000 - 255 5050 LEDs Strip5--Color
19 000 - 255 5050 LEDs Strip6--Color
20 000 - 255 5050 LEDs Strip7--Color
21 000 - 255 5050 LEDs Strip8--Color
22 000 - 255 5050 LEDs Strip9--Color
23 000 - 255 5050 LEDs Strip10--Color
24 000 - 255 5050 LEDs Strip11--Color
25 000 - 255 5050 LEDs Strip12--Color
26 000-007 0
008-022 Pan/Tilt Movement 01
023-037 Pan/Tilt Movement 02
038-052 Pan/Tilt Movement 03
053-067 Pan/Tilt Movement 04
23 CH MODE:
Channel DMX Value Function
1000 - 255 Pan 0°~ 540°
2000 – 255 Speed fast to slow
3000 - 127
128 - 189
190 - 193
194 - 255
Tilt 0°~ 360°
clockwise Rotation fast to slow
Stop
anticlockwise Rotation slow to fast
4000 - 007 RGBW LED1--Blackout
008 - 024 RGBW LED1--R
025 - 041 RGBW LED1--G
042 - 057 RGBW LED1--B
058 - 074 RGBW LED1--W
075 - 090 RGBW LED1--R + G
091 - 107 RGBW LED1--R + B
108 - 123 RGBW LED1--R + W
124 - 140 RGBW LED1--G + B
141 - 156 RGBW LED1-- G + W
157 - 173 RGBW LED1--B + W
174 - 189 RGBW LED1--R + G + B
190 - 206 RGBW LED1--R + G + W
207 - 222 RGBW LED1--R + B + W
223 - 239 RGBW LED1--G + B + W
240 - 255 RGBW LED1--R + G + B + W
5000 - 255 RGBW LED2--Color
6000 - 255 RGBW LED3--Color
7000 - 255 RGBW LED4--Color
8000 - 255 RGBW LED5--Color
9000 - 255 RGBW LED6--Color
10 000 - 007 5050 LEDs Strip1-- Blackout
008 - 024 5050 LEDs Strip1 --color1
025 - 041 5050 LEDs Strip1--color2
042 - 057 5050 LEDs Strip1--color3
058 - 074 5050 LEDs Strip1--color4
85

075 - 090 5050 LEDs Strip1--color5
091 - 107 5050 LEDs Strip1--color6
108 - 123 5050 LEDs Strip1--color7
124 - 140 5050 LEDs Strip1--color8
141 - 156 5050 LEDs Strip1--color9
157 - 173 5050 LEDs Strip1--color10
174 - 189 5050 LEDs Strip1--color11
190 - 206 5050 LEDs Strip1--color12
207 - 222 5050 LEDs Strip1--color13
223 - 239 5050 LEDs Strip1--color14
240 - 255 5050 LEDs Strip1--color15
11 000 - 007 Blackout 008-255 5050 LEDs Strip2--Color
12 000 - 007 Blackout 008-255 5050 LEDs Strip3--Color
13 000 - 007 Blackout 008-255 5050 LEDs Strip4--Color
14 000 - 007 Blackout 008-255 5050 LEDs Strip5--Color
15 000 - 007 Blackout 008-255 5050 LEDs Strip6--Color
16 000 - 007 Blackout 008-255 5050 LEDs Strip7--Color
17 000 - 007 Blackout 008-255 5050 LEDs Strip8--Color
18 000 - 007 Blackout 008-255 5050 LEDs Strip9--Color
19 000 - 007 Blackout 008-255 5050 LEDs Strip10--Color
20 000 - 007 Blackout 008-255 5050 LEDs Strip11--Color
21 000 - 007 Blackout 008-255 5050 LEDs Strip12--Color
22 000-007 0
008-022 Pan/Tilt Movement 01
023-037 Pan/Tilt Movement 02
038-052 Pan/Tilt Movement 03
053-067 Pan/Tilt Movement 04
068-082 Pan/Tilt Movement 05
083-097 Pan/Tilt Movement 06
098-112 Pan/Tilt Movement 07
113-127 Pan/Tilt Movement 08
128-142 Pan/Tilt Movement 09
143-157 Pan/Tilt Movement 10
158-172 Pan/Tilt Movement 11
173-187 Pan/Tilt Movement 12
188-202 Pan/Tilt Movement 13
203-217 Pan/Tilt Movement 14
218-232 Pan/Tilt Movement 15
233-247 Pan/Tilt Movement 16
248-255 Sound active
23 000-255 Movement Speed slow to fast
27 CH MODE:
Channel DMX Value Function
10-255 Pan 0°~ 540°
20-255 Pan Speed fast to slow
3000 - 127 Tilt 0°~ 360
128 - 189 Tilt clockwise rotation fast to slow
190 - 193 Stop
194 - 255 Tilt anticlockwise rotatiojn slow to fast
40-255 10W RGBW LED Dimmer 0%~ 100%
5000-007 10W RGBW LED Strobe slow to fast
6000 - 007 10W RGBW LED1--Blackout
008 - 024 10W RGBW LED1--R
025 - 041 10W RGBW LED1--G
042 - 057 10W RGBW LED1--B
058 - 074 10W RGBW LED1--W
075 - 090 10W RGBW LED1--R + G
091 - 107 10W RGBW LED1--R + B
108 - 123 10W RGBW LED1--R + W
124 - 140 10W RGBW LED1--G + B
141 - 156 10W RGBW LED1--G + W
157 - 173 10W RGBW LED1--B + W
174 - 189 10W RGBW LED1--R + G + B
190 - 206 10W RGBW LED1--R + G + W
207 - 222 10W RGBW LED1--R + B + W
223 - 239 10W RGBW LED1--G + B + W
240 - 255 10W RGBW LED1--R + G + B + W
70-255 RGBW LED2--Color
80-255 RGBW LED3--Color
90-255 RGBW LED4--Color
10 0-255 RGBW LED5--Color
