Philips Energy Advantage PL-T User manual

Philips Energy Advantage
P -T amps
amps featuring A TO®
amp Technology
Ideal for applications
requiring maximum
energy savings
ENERGY ADVANTAGE P -T
Energy savings ma e simple.
Philips Energy Advantage P -T lamps are
a simple way to save energy.
Save energy without changing a ballast
• Two wattages available—27W and 33W
–27W is a direct replacement for a P -T 32W lamp, saving 5 watts of energy
–33W is a direct replacement for a P -T 42W lamp, saving 9 watts of energy
• Up to 21% energy savings when replacing the above 32W and 42W lamps*
• No new ballast required
Broad range of color temperatures
• Available in 3000K, 3500K and 4100K
High light output in a compact size
• ight output is comparable to the standard P -T 32W or 42W lamps
• 88% lumen maintenance
Excellent color rendering
• 82 CRI
New design
• New bridged design allows for better efficiency and an even more compact size
* 32 watt-27 watt=5 watt/32 watt=15%
42 watt-33 watt=9 watt/42 watt=21%
† This lamp is better for the environment because of
its re uce mercury content.All Philips ALTO®
lamps give you en -of-life options which can simplify
an re uce your lamp isposal costs epen ing on
your state an local regulations.
P-5973 PL-T EA Prod Bulle in.qxd:Layou 1 1/6/09 1:26 PM Page 1

100%
96%
92%
88%
84%
78%
Lamp Operating HoursLamp Operating Hours
Light Output (%)Light Output (%)
0 5,000 10,000 15,000 20,000
88% Lumen Maintenance
Philips Energy Advantage P -T amps
A
D
B
C
Philips Energy Advantage P -T amps featuring A TO®amp Technology
Ordering, Electrical and Technical Data (Subject to change without notice)
Color Rated Average Life (Hrs.)1Approx.
Product Ordering Nom Pack. Temp. MOL 3-hr 12-hr Initial Design Lumen
Number Code atts Base Qty. (Kelvin) (In.) Start2Start3Lumens4Lumens5CRI Maint.
22021-0 P -T 32W/830/XEW/4P/A TO 27W 27 Gx24q-3 10 3000K 51⁄216,000 20,000 1875 1725 82 88%
22022-8 P -T 32W/835/XEW/4P/A TO 27W 27 Gx24q-3 10 3500K 51⁄216,000 20,000 1875 1725 82 88%
22024-4 P -T 32W/841/XEW/4P/A TO 27W 27 Gx24q-3 10 4100K 51⁄216,000 20,000 1875 1725 82 88%
22026-9 P -T 42W/830/XEW/4P/A TO 33W 33 Gx24q-4 10 3000K 61⁄316,000 20,000 2615 2400 82 88%
22028-5 P -T 42W/835/XEW/4P/A TO 33W 33 Gx24q-4 10 3500K 61⁄316,000 20,000 2615 2400 82 88%
22029-3 P -T 42W/841/XEW/4P/A TO 33W 33 Gx24q-4 10 4100K 61⁄316,000 20,000 2615 2400 82 88%
© 2008 Philips ighting Company. All rights reserved.
Printed in USA 12/08
P-5973
www. philips.com
Philips ighting Company
200 Franklin Square Drive
P.O. Box 6800
Somerset, NJ 08875-6800
1-800-555-0050
A Division of Philips Electronics North America Corporation
Philips ighting
281 Hillmount Road
Markham, Ontario
Canada 6C 2S3
1-800-555-0050
A Division of Philips Electronics td.
1) Rate average life is the length of operation (in hours) at which point an average of 50% of a large sample of lamps will still be operational an 50% will not.
2) Average life un er specifie test con itions with lamps turne off an restarte no more frequently than once every 3 operating hours. Lamp life is appreciably longer if lamps are starte less frequently.
3) Average life un er engineering ata with lamps turne off an restarte once every 12 operating hours.
4) Approximate initial lumens.The lamp lumen output is base upon lamp performance after 100 hours of operating life, when the output is measure uring operation on a reference ballast un er stan ar laboratory
con itions. For expecte lamp lumen output, commercial ballast manufacturers can a vise the appropriate ballast factor for each of their ballasts when they are informe of the esignate lamp.The ballast factor is a
multiplier applie to the esignate lamp lumen output.
5) Design lumens are the approximate lamp lumen output at 40% of the lamp’s rate average life.This output is base upon measurements obtaine uring lamp operation on a reference ballast un er
stan ar laboratory con itions.
This lamp is better for the environment because of its re uce mercury content.All Philips ALTO®lamps give you en -of-life options which can simplify an re uce your lamp isposal costs
epen ing on your state an local regulations.
Printed on chlorine free paper from Sappi Fine Paper mills, who are accredited with EMAS environmental certification.
Sappi claims that the pulp used in the manufacture of Magno Dull paper is derived from environmentally certified forests.
Rated Average Life in HoursRated Average Life in Hours
BASED ON 3 HOURS PER START2
16,000
BASED ON 12 HOURS PER START3
20,000
Programmed Start Ballast
0 5,000 10,000 15,000 20,000
Rated Average Life
Philips Energy Advantage P -T amps
Dimensions
27 33
A ––––––––3.9"/99mm –––––––––––4.8"/122mm
B–––––––––4.8"/122mm ––––––––––5.7"/145mm
C ––––––––5.5"/140mm ––––––––––6.3"/160mm
D ––––––––1.6"/41mm –––––––––––1.6"/41mm
