Inaxsys IN-4024G User manual

IN-4024G
Quick Installation Guide
24 Ports
Gigabit Ethernet Switch
FCC Warning
This device has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 2 and 15 of FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates and radiates radio
frequency energy and, if not installed and
used in accordance with the user’s manual, it
may cause interference in which case users
will be required to correct interference at their
own expenses.
CE Warning
This is a Class B product. In a domestic
environment, this product may cause radio
interference in which case the user may be
required to take adequate measures.
Introduction
The Switch provides 24 10/100/1000M ports.
It was designed for easy installation and high
performance in an environment where traffic
on the network and the number of user
increase continuously. With newest Gigabit
chip set, 19” Gigabit Ethernet switch can fully
support highest speed without hanging on
problem even when Full-Duplex full loaded.
The switch also provides automatic crossover
detection functionality on each port. It is
simple and friendly to up-link to another
switch without crossover cable.
The rack-
mount size was specifically
designed for medium to large workgroups.
The Switch can be installed where space is
limited; moreover it provides smooth network
migration and easy upgrade to network
capacity. The 19” size can be rack-mount on
19” cabinet.
Key Features
Complies with the IEEE802.3 Ethernet,
IEEE802.3u Fast Ethernet and IEEE
802.3ab Gigabit Ethernet Standards
24 Port 10/100/1000M
(Auto-negotiation) Switch
19”rack-mount size
Non-blocking & Non-head-of-line blocking
full wire speed forwarding
Store-and-forward operation support
Embedded 500 KB packet buffer
Supports 9.6 KB JUMBO packet
Provides 8K MAC address entry
Supports broadcast storm filtering
All ports provide Auto-Negotiation and Auto
-MDI/ MDI-X functions
Supports flow control: Back pressure for
Half-duplex and IEEE 802.3x for
Full-duplex mode
Smart plug & play
Package Contents
Before you start to install this Switch, please
verify your package contain the following
items:
•One Gigabit Ethernet Switch
•Rack-mount Kit for Rack Installation
•One AC Power Cord
•One User’s Manual
Note: If any of these items is found missing or
damaged, please contact your local supplier for
replacement.
Front Panel (LEDs)
LED Indicators of 24 Ports Gigabit
Ethernet Switch
LED Status Description No. Of LED
Power On Power on Power
1000M On Link 1000Mbps 24 (1~24)
off Link 10/100Mbps
Link/ ACT On Link 24 (1~24)
Flashing
Data activating
24 (1~24)

Connections
Switch/Hub to this 24 Ports Gigabit
Ethernet Switch
This switch provides automatic crossover
detection functionality for any port. It is
simple and friendly to up-link to another switch
without crossover cable.
PC/Other devices to this 24 Ports Gigabit
Ethernet Switch
Via a twisted pair cable straight through, this
switch can be connected to PCs, servers and
other network devices.
Rear Panel (Power)
AC input
AC input (90~260V/AC, 50~60Hz) UL Safety
Technical Specifications
Standards
IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX
IEEE 802.3ab 1000BaseT
IEEE 802.3x Flow control
Features
Number of Ports: 24
MAC Address: 8K
Buffer Memory: 500 KB
Jumbo Frames: 9.6 KB
Method: Store and
Forward
Filtering/
Forwarding
Rates
1000Mbps port –
1,488,000pps
100Mbps port – 148,800pps
10Mbps – 14,880pps
Transmission
Media
10BaseT Cat. 3, 4, 5
UTP/STP
100BaseTX Cat. 5 UTP/STP
1000BaseT Cat. 5E
UTP/STP
LED
Indicators
Per Port: LINK/ACT,
1000M
Per Unit: Power
Power
Requirement
90~260V/AC, 50~60Hz
Power
Consumption 25 Watts (Max)
Dimensions 440 × 220 × 44 mm
(L x W x H)
Weight 3 kg
Operating
Temperature
0 to 40
℃
Storage
Temperature -20 to 90
℃
Humidity 10 to 90% RH
(non-condensing)
Certifications FCC Class B, CE
