TP-Link TD-8811 User manual

TD-8811
External ADSL2+ ROUTER
 遡□Ī瀁

COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice. is a registered
trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are
trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to
make any derivative such as translation, transformation, or adaptation without permission
from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2008 TP-LINK TECHNOLOGIES
CO., LTD.
All rights reserved.
http://www.tp-link.com

FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that
may cause undesired operation.
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.

Package contents
The following contents should be found in your box:
¾One TD-8811 External ADSL2+ ROUTER
¾One AC power Adapter for TD-8811 External ADSL2+ ROUTER
¾One Resource CD for TD-8811 External ADSL2+ ROUTER, including:
•This User Guide
•Quick installation Guide Program
•Other Helpful Information
•USB driver
¾Quick installation Guide
¾One RJ45 cable
¾Two RJ11 cable
¾One ADSL splitter
¾One USB cable
)Note:
If any of the above items are damaged or missing, please contact the retailer from whom
you purchased the TD-8811 External ADSL2+ ROUTER for assistance.

CONTENTS
Chapter 1. Product Overview ....................................................................1
1.1 Product main specification .............................................................................1
1.2 Supporting protocol ........................................................................................1
1.3 Transmit data-rate ..........................................................................................1
1.4 ATM property..................................................................................................2
1.5 System support ..............................................................................................2
1.6 Working environment .....................................................................................2
1.7 Electric parameter ..........................................................................................2
Chapter 2. Hardware Installation Guide....................................................3
2.1 System requirement .......................................................................................3
2.2 LED explanation .............................................................................................3
2.3 Rear-panel......................................................................................................4
2.4 Hardware installation procedures...................................................................4
Chapter 3. System Configuration..............................................................5
3.1 Computer Configuration .................................................................................5
3.2 Login...............................................................................................................7
3.3 Quick Setup....................................................................................................8
3.3.1 PPPoA .................................................................................................................9
3.3.2 PPPoE ...............................................................................................................11
3.3.3 MER ...................................................................................................................13
3.3.4 IPoA ...................................................................................................................14
3.3.5 Bridging..............................................................................................................16
3.4 Web Setup....................................................................................................18
3.5 Software Dial ................................................................................................27
3.6 USB Configuration........................................................................................28
Chapter 4: Advantage management setup ................................................32
Appendix A: FQA .........................................................................................33
Appendix B: Default Configuration ............................................................34

TD-8811 External ADSL2+ ROUTER
1
Chapter 1. Product Overview
The TP-LINK TD-8811 External ADSL2+ ROUTER is the latest product designed and
manufactured by TP-LINK TECHNOLOGIES CO., LTD. With TP-LINK’s excellent circuit design
and high quality production, we guarantee its high performance, great stability and easy to use.
The TD-8811 is a complete plug-and-play solution. With standard Ethernet interface, it can be
directly connected to any 10M/100M Ethernet devices, support Auto-MDI/MDIX.
The TD-8811 not only uses html (web mode through Ethernet port) to configure the router but also
uses external utility software, too. You can download it from our website (http://www.tp-link.com).
1.1 Product main specification
¾High speed and asymmetrical data transmit mode, provides safe and exclusive bandwidth
¾Supports All ADSL2+ industrial standards
¾Compatible with all mainstream DSLAM (CO)
¾Firmware upgradeable
¾Provides integrated access of internet and route function which face to SOHO users
¾Advanced DMT modulation and demodulation
¾Real-time Configuration and device monitoring
¾Quick response semi-conductive surge protection circuit, provides reliable ESD and
surge-protect function
1.2 Supporting protocol
- G.992.1 (G.dmt) - Annex A
- G.992.2 (G.lite) - Annex A
- ANSI T1.413
- G.992.3 (ADSL2) - Annex A compliant
- G.992.5 (ADSL2+) Annex A compliant
- ADSL dual latency (fast path and interleaved path)
- I.432 ATM physical layer compliant
-Supports RFC2364 (PPPoA)
-Supports RFC2516 (PPPoE)
-Supports RFC1483 (EoA) (Bridged *and route)
-Supports RFC1577 (IPoA)
1.3 Transmit data-rate
¾Max download data-rate: 24Mbps
¾Max line length: 6Km

TD-8811 External ADSL2+ ROUTER
2
1.4 ATM property
¾AAL0, AAL5, OAM, RM, and raw cell types supported
¾Direct hardware support for 4 Receive VCs, with additional RX VCs and TX VCs supported in
software
¾Full 24-bit Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI)
1.5 System support
¾Support PVC
¾Support NAT、DHCP and so on
¾Support IEEE 802.3、IEEE 802.3u
¾Support 10Base-T/100BASE-TX full-duplex or half duplex Ethernet
¾Support Auto-MDIX
¾Support USB 1.1 device interface
1.6 Working environment
¾Operating temperature: 0 ~40℃℃
¾Storage temperature: -40 ~70℃℃
¾Humidity: 10%~90% (non-condensing)
1.7 Electric parameter
¾Adaptor power Output: 9VAC/0.8A, 50Hz or 60 Hz
¾Power consumption: 4W Maximum

TD-8811 External ADSL2+ ROUTER
3
Chapter 2. Hardware Installation Guide
The TD-8811 maintains three separate interfaces, one Ethernet, one USB interface and one
ADSL interface. The Router should not be located where it will be exposed to moisture or
excessive heat. Place the Router in a location where it can be safely connected to the various
devices as well as to a power source.
2.1 System requirement
Confirm your computer has been installed with networking interface card (NIC) before connecting
ADSL2+ ROUTER to your computer, with the operating system supporting the TCP/IP protocol.
2.2 LED explanation
The front panel of ADSL2+ ROUTER includes one power indicator (RED) and five function
indicators (GREEN), as explained in chart 1-1:
Indicator Description Status Function Details
Power Power On
Off
Power OK
Power fail
Act Data
On
Off
There is data transmitting or receiving on WAN
port
No data is transmitting or receiving on WAN port
Alarm Mistake
On
Off
There is a mistake when ADSL is transmitting
data or receiving data
ADSL works normally
ADSL ADSL
status
Quick flash
On
Connecting to the telecom network
Connection to telecom network is OK
LAN Ethernet
On
Off
Flash
LAN port works normally
Connection on LAN port is abnormal
Data is transmitting or receiving on LAN port
USB
USB status
On
Off
Flash
Connection to telecom network is OK
Connection on USB port is abnormal
Data is transmitting or receiving
Chart 1-1

TD-8811 External ADSL2+ ROUTER
4
2.3 Rear-panel
¾ON/OFF: Turn on/off the ADSL2+ Router’s power.
¾POWER (9VAC/0.8A input): please do not use any unknown power adapter, otherwise your
ADSL2+ Router may be damaged.
¾RESET (reset default): Press the reset button, then turn on the Router's power (keep the
button pressed) for at least three seconds, it will restore the settings to the default factory
configuration.
¾LAN: Connect with your computer’s NIC.
¾USB: Connect with your computer’s USB interface
¾LINE (WAN): Connect to the MODEM Port of Splitter or connect the telephone line.
2.4 Hardware installation procedures
The procedure to install the Router can be described in the following steps:
First Step: Connect the MODEM port of Splitter with the LINE port of the TD-8811 ADSL2+
ROUTER by telephone line.
Second Step: Connect category 5 cable with RJ45 jacks to ADSL2+ Router’s LAN port and your
computer’s NIC. Or connect USB cable to ADSL2+ Router’s USB port and your computer’s USB
interface.
Third Step: Plug one end of the AC Power Adapter into the Power jack on the Ethernet ADSL2+
Router and the other end to a standard electrical outlet.
Last Step: Check the line connection to see if everything is ready. Power up finally.

TD-8811 External ADSL2+ ROUTER
5
Figure 2-1
Chapter 3. System Configuration
3.1 Computer Configuration
1. Connect the cable according to Chapter 2, turn on the power.
2. Change the IP address of your PC（Figure 3-1）: Open TCP/IP Properties of the LAN card in
your PC, enter the IP address as 192.168.1.* (* is any value between 2 to 254, Network mask
is 255.255.255.0, Gateway is 192.168.1.1, DNS address is the value provided by ISP).

TD-8811 External ADSL2+ ROUTER
6
Figure 3-1
)Note:
1) Users of Windows 98 can open TCP/IP Properties according to the following: Right-click
(Mouse) Network Neighbor -> Choose Properties -> Double-click TCP/IP PCI Fast
Ethernet Adapter.
2) The users of Windows 2000/NT/XP can do the following: Right-press Network Neighbor
->Choose Properties->Right-press Local Connection ->Choose Properties->Double- click
Internet Protocol (TCP/IP).
3) The words may be different with this guide in fact.
You can check whether your configuration is successful through PING command. Enter “Ping
192.168.1.1”.
If the screen looks like the following, the connection between your computer and TD-8811 is OK
now.

TD-8811 External ADSL2+ ROUTER
7
Figure 3-2
If the screen looks like the following, the connection fails. Repeat the previous steps again.
Figure 3-3
3.2 Login
Startup Internet Explorer, and enter 192.168.1.1, then enter default user name(admin) 、
password(admin), When ADSL2+ connection is OK, you will see the Figure 3-4.

TD-8811 External ADSL2+ ROUTER
8
Figure 3-4
3.3 Quick Setup
1) Figure 4 is the main page of the Router.
Figure 3-5

TD-8811 External ADSL2+ ROUTER
9
2) Please select Quick Setup. Enter the VPI and VCI values provided by your Internet Service
Provider and click Next.
Figure 3-6
3) Select the relevant Connection Type and Encapsulation mode as the settings provided by
your Internet Service Provider and click Next.
3.3.1 PPPoA
a) Select PPP over ATM(PPPoA) Connection Type, and click Next.

TD-8811 External ADSL2+ ROUTER
10
Figure 3-7
b) Enter the Username and Password provided by your Internet Service Provider and click
Next.
Figure 3-8
c) Turn on the selected functions according to your demands. Clicking the next button to
enter the next step.
Figure 3-9
d) Click Save/Reboot.

TD-8811 External ADSL2+ ROUTER
11
Figure 3-10
3.3.2 PPPoE
a) Select PPP over Etherner(PPPoE) Connection Type, and click Next.
Figure 3-11
b) Enter the Username and Password provided by your Internet Service Provider and click
Next.

TD-8811 External ADSL2+ ROUTER
12
Figure 3-12
c) Click Save/Reboot.
Figure 3-13
Note：
The Router will restart when you complete the configuration, so you have to wait for a while until it

TD-8811 External ADSL2+ ROUTER
13
restarts successfully.
3.3.3 MER
a) Select MAC Encapsulation Routing(MER) Connection Type, and click Next.
Figure 3-14
b) Enter the parameter and the way which is provided by your ISP, then click Next.
Figure 3-15
c) Turn on the selected functions according to your needs. Click Next.

TD-8811 External ADSL2+ ROUTER
14
Figure 3-16
d) Click Save/Reboot.
Figure 3-17
3.3.4 IPoA
a) Select IP over ATM(IPoA) Connection Type, and click Next.

TD-8811 External ADSL2+ ROUTER
15
Figure 3-18
b) ] Enter the parameter and the way which is provided by your ISP, then click Next.
Figure 3-19
c) Turn on the selected functions according to your needs. Click Next
