Indesit IFW6230IXUK Installation and operation manual

EN
1
PRODUCT DESCRIPTION
DAILY REFERENCE
GUIDE
CONTROL PANEL
Before using the appliance carefully read the Health and Safety guide.
1. Control panel
2. Lamp
3. Shelf runners
(the level is indicated on the wall of
the cooking compartment)
4. Door
5. Upper heating element / grill
6. Identification plate
(do not remove)
7. Lower heating element
(not visible)
1. SELECTION KNOB
For switching the oven on by
selecting a function.
Turn to the position to switch the
oven off.
2. TIMER KNOB
Useful as a timer.
Does not activate or interrupt
cooking.
3. THERMOSTAT KNOB
Turn to select a desired
temperature, activating the
selected function.
4. LED THERMOSTAT /
PREHEATING
Switches on during the heating
process. Switches off once the
desired temperature is reached.
THANK YOU FOR PURCHASING
AN INDESIT PRODUCT
To receive more comprehensive help and
support, please register your product at
www.indesit.com/register
WWW
You can download the Safety Instructions
and the Use and Care Guide by visiting our
website docs.indesit.eu and following the
instructions on the back of this booklet.
1
2
3
4
6
7
5
0
5
10
15
20
25
30
35
40
45
50
60
60
80
100
120
140
160
180
200
220
250
1 2 3 4

2
ACCESSORIES Download the Use and Care Guide from
docs.indesit.eu for more information
WWW
WIRE SHELF BAKING TRAY (IF PRESENT) DRIP TRAY (IF PRESENT)
The number of accessories may vary depending on which model is purchased.
Other accessories can be purchased separately from the After-sales Service.
INSERTING THE WIRE SHELF
AND OTHER ACCESSORIES
• Insert the wire shelf onto the level you require
by holding it tilted slightly upwards and resting
the raised rear side (pointing upwards) down first.
Afterwards, slide it horizontally along the shelf
runners as far as possible.
• The other accessories, such as the baking tray, are
inserted horizontally by sliding them along the shelf
runners.
Download the Use and Care Guide from
docs.indesit.eu for more information
WWW
FUNCTIONS
OFF
For switching off the oven.
LIGHT
For switching on the light in the compartment.
BOTTOM
For browning the bottom of the dishes. The
function can also be used for slow cooking, to finish
cooking very liquid dishes (sweet or savour) or to
thicken sauces and gravies.
CONVENTIONAL
For cooking any kind of dish on one shelf only.
It is advisable to place food on 2nd level.
GRILL
For grilling steaks, kebabs and sausages,
cooking vegetables au gratin or toasting bread.
When grilling meat, we recommend using a Baking
tray to collect the cooking juices: position the pan on
any of the levels below the wire shelf and add 200 ml
of drinking water.

EN
3
. HEAT THE OVEN
A new oven may release odours that have been left
behind during manufacturing: this is completely
normal.
Before starting to cook food, we therefore
recommend heating the oven with it empty in order
to remove any possible odours.
Remove any protective cardboard or transparent film
from the oven and remove any accessories from inside
it.
Heat the oven to 250° C for about one hour.
The oven must be empty during this time.
Follow the instructions for setting the function
correctly.
Notes: it is advisable to air the room after using the appliance
for the rst time.
USING THE APPLIANCE FOR THE FIRST TIME
1. SELECT A FUNCTION
To select a function, turn the selection knob to the
symbol for the function you require.
2. ACTIVATE A FUNCTION
To start the function you have selected, turn the
thermostat knob to set the temperature you require.
To interrupt the function at any time, switch off the
oven, turn the selection knob and the thermostat knob
to to and .
3. PREHEATING
Once the function has been activated, the LED
thermostat will switch on signalling that the
preheating process has begun.
At the end of this process, the LED thermostat
switches off indicating that the oven has reached the
set temperature: at this point, place the food inside
and proceed with cooking.
Please note: Placing the food in the oven before preheating
has nished may have an adverse eect on the nal cooking
result.
. SETTING THE TIMER
This option does not interrupt or activate cooking but
allows you to use the display as a timer, both while a
function is active and when the oven is off.
To activate the timer, turn the timer knob to the
desired length of time: an acoustic signal will warn
you when the count-down is finished.
DAILY USE

4
COOKING TABLE
RECIPE FUNCTION PREHEAT TEMPERATURE
(°C)
DURATION
(MIN)
LEVEL
AND ACCESSORIES
Leavened cakes Yes 150 - 170 30 - 90 2
Filled cake
(cheese cake, strudel, fruit pie) Yes 160 - 200 35 - 90 2
Biscuits/tartlets Yes 160 - 180 15 - 35 2 / 3
Choux buns Yes 180 - 200 40 - 60 2
Meringues Yes 90 150 - 200 2
Pizza / focaccia Yes 220 - 250 10 - 25 1 / 2
Small bread (80g) Yes 180 - 200 30 - 45 2
Bread loaf (500g) Yes 180 50 - 70 1 / 2
Frozen pizza Yes 250 10 - 20 2
Salty cakes
(vegetable pie,quiche) Yes 190 - 200 30 - 50 2
Vols-au-vents / pu pastry crackers Yes 190 - 200 20 - 30 2
Lasagne / baked pasta / canneloni /
ans Yes 190 - 200 45 - 65 2
Lamb / veal / beef /pork 1 kg Yes 190 - 200 80 - 110 2
Chicken/rabbit/duck 1 kg Yes 200 - 230 50 -100 2
Turkey / goose 3 kg Yes 180 - 200 150 - 200 2
Baked sh/en papillote 0,5 kg (llets,
whole) Yes 170 - 190 30 - 45 2
Stued vegetables
(tomatoes, courgettes, aubergines) Yes 180 - 200 50 - 70 2
Roast potatoes Yes 220 - 240 40 - 60 2
Toasted bread 5’ 250 2 - 6 5
Fish llets/slices 5’ 250 15 - 30 * 43
Sausages/kebabs/spare ribs/
hamburgers 5’ 250 15 - 30 * 54
Vegetable gratin 5’ 250 5 - 15 4
FUNCTIONS
Conventional Grill
ACCESSORIES Wire shelf Baking dish on the wire
shelf
Baking tray/Drip tray or
baking dish on the wire shelf Drip tray / Baking tray Drip tray / Baking tray with
200 ml of water

EN
5
HOW TO READ THE COOKING TABLE
The table lists the best function, accessories and
level to use to cook different types of food. Cooking
times start from the moment food is placed in the
oven, excluding preheating (where required). Cooking
temperatures and times are approximate and depend
on the amount of food and the type of accessory
used. Use the lowest recommended settings to begin
with and, if the food is not cooked enough, then
switch to higher settings. Use the accessories supplied
and preferably dark-coloured metal cake tins and
baking trays. You can also use Pyrex or stoneware
pans and accessories, but bear in mind that cooking
times will be slightly longer
. DESSERTS
• Cook delicate desserts with the conventional
function on one shelf only. Use dark-coloured metal
baking pans and always place them on the wire shelf
supplied.
• Use dark-coloured metal baking pans and always
place them on the wire shelf supplied.
• To check whether a leavened cake is cooked, insert
a wooden toothpick into the centre of the cake. If the
toothpick comes out clean, the cake is ready.
• If using non-stick cake tins, do not butter the edges
as the cake may not rise evenly around the edges.
• If the item “swells” during baking, use a lower
temperature next time and consider reducing the
amount of liquid you add or stirring the mixture more
gently
MEAT
• Use any kind of oven tray or pyrex dish suited to the
size of the piece of meat being cooked.
For roast joints, it is best to add some stock to the
bottom of the dish, basting the meat during cooking
for added flavour. Please note that steam will be
generated during this operation.
When the roast is ready, let it rest in the oven for
another 10-15 minutes, or wrap it in aluminium foil.
• When grilling pieces of meat, choose cuts of the
same thickness to obtain even cooking. Very thick
pieces of meat require longer cooking times. To
prevent the meat from burning on the outside, lower
the position of the wire shelf, keeping the food farther
away from the grill. Turn the meat two thirds of the
way through cooking. Take care when opening the
door as steam will escape.
To collect the cooking juices, we recommend placing
a dripping pan filled with 200 ml of drinking water
directly underneath the wire shelf on which the food
is placed. Refill as necessary.
Download the Use and Care Guide from
docs.indesit.eu for more information
WWW
USEFUL TIPS

6
EXTERIOR SURFACES
• Clean the surfaces with a damp microfibre cloth.
If they are very dirty, add a few drops of pH-neutral
detergent. Finish off with a dry cloth.
• Do not use corrosive or abrasive detergents. If any of
these products inadvertently comes into contact with
the surfaces of the appliance, clean immediately with
a damp microfibre cloth.
INTERIOR SURFACES
• After every use, leave the oven to cool and then
clean it, preferably while it is still warm, to remove any
deposits or stains caused by food residues To dry any
condensation that has formed as a result of cooking
foods with a high water content, let the oven to cool
completely and then wipe it with a cloth or sponge.
• The door can be easily removed and refitted to
facilitate cleaning of the glass. WWW
• Clean the glass in the door with a suitable liquid
detergent.
• The top heating element of the grill can be lowered
to clean the upper panel of the oven.
ACCESSORIES
Soak the accessories in a washing-up liquid solution
after use, handling them with oven gloves if they
are still hot. Food residues can be removed using a
washing-up brush or a sponge.
Do not use steam cleaning
equipment.
Use protective gloves during all
operations.
Carry out the required
operations with the oven cold.
Disconnect the appliance from
the power supply.
Do not use wire wool, abrasive
scourers or abrasive/corrosive
cleaning agents, as these could
damage the surfaces of the
appliance.
MAINTENANCE AND
CLEANING
Download the Use and Care Guide from
docs.indesit.eu for more information
WWW
1. Extract the heating element from its seating, then
lower it. 2. To return the heating element to its position, lift it up, pull it slightly towards you and make sure that the
tab support is in its proper seating.
LOWERING THE UPPER HEATING ELEMENT

EN
7
REMOVING AND REFITTING THE DOOR
1. To remove the door, open it fully and lower the
catches until they are in the unlock position.
2. Close the door as much as you can.
Take a firm hold of the door with both hands – do not
hold it by the handle.
Simply remove the door by continuing to close it
while pulling it upwards (a) at the same time until it is
released from its seating (b).
~60°
a
b
~15°
Put the door to one side, resting it on a soft surface.
3. Refit the door by moving it towards the oven,
aligning the hooks of the hinges with their seating
and securing the upper part onto its seating.
4. Lower the door and then open it fully.
Lower the catches into their original position: Make
sure that you lower them down completely.
5. Try closing the door and check to make sure that it
lines up with the control panel. If it does not, repeat
the steps above.
CLICK TO CLEAN  CLEANING THE GLASS
1. After removing the door and resting it on a soft
surface with the handle downwards, simultaneously
press the two retaining clips and remove the upper
edge of the door by pulling it towards you.
2. Lift and firmly hold the inner glass with both
hands, remove it and place it on a soft surface before
cleaning it.
3. To correctly reposition the inner glass, make sure
that the “R” is visible in the left-hand corner and the
clear surface (not printed) is facing up. First insert
the long side of the glass indicated by “R” into the
support seats, then lower it into position.
4. Refit the upper edge: A click will indicate correct
positioning. Make sure the seal is secure before
refitting the door.

8
Problem Possible cause Solution
The oven does not work. Power cut.
Disconnection from the
mains.
Check for the presence of mains electrical power
and whether the oven is connected to the
electricity supply.
Switch o the oven and restart it to see if the fault
persists.
400010893475
Printed in Italy
001
TROUBLESHOOTING Download the Use and Care Guide from
docs.indesit.eu for more information
WWW
PRODUCT FICHE
WWW The product fiche with energy data of this
appliance can be downloaded from the website
docs.indesit.eu
HOW TO OBTAIN THE USE AND CARE GUIDE
> WWW Download the Use and Care Guide
from our website docs.indesit.eu (you can
use this QR Code), specifying the product’s
commercial code.
> Alternatively, contact our Client After-sales Service.
CONTACTING OUR AFTERSALES SERVICE
You can find our contact details in the warranty
manual. When
contacting our Client
After-sales Service,
please state the codes
provided on your
product’s identification
plate.
Model: xxxXXXXxx
X
X
X
X
X
XX
X
X
X
X
X
XX
X
X
XX
X
X
X
X
XX
X
X
X
X
X
X
X
XX
X
X
X
X
X
X
X
X
X
XX
X
X
X
X
X
XXXXXX XXXXXX XXXXX XXXXXXX
