Infinity Brands 4023100-BK User manual

Microwave Oven Instructions
Model: 4023100-BK
Please read these instructions carefully before installing and operating the oven.

1
Content
Important Safety Instructions ....................................................................................................... 2
Precautions to Avoid Possible Exposure to Excessive Microwave Energy ................................ 4
Specifications ............................................................................................................................... 4
Installation Guide ......................................................................................................................... 5
Grounding Instructions ................................................................................................................ 5
Cooking Techniques .................................................................................................................... 7
Cooking Utensils Guide ............................................................................................................... 8
Product Diagram .......................................................................................................................... 9
Control Panel ............................................................................................................................. 10
Operation Instructions ................................................................................................................ 11
Setting Clock............................................................................................................................... 11
Timer Function ............................................................................................................................ 11
Microwave Cooking .................................................................................................................... 11
Speed Defrost ............................................................................................................................ 12
Cook By Weight ......................................................................................................................... 12
Defrost By Weight ...................................................................................................................... 13
Setting Child Lock ...................................................................................................................... 13
Auto Cook Menus ...................................................................................................................... 14
Cleaning and Care ..................................................................................................................... 15

2
Important Safety Instructions
When using electrical appliance basic safety precautions should be followed, including the
following:
WARNING!--To reduce the risk of burns, electric shock, fire, injury to persons or exposure to
excessive microwave energy:
1. Read all instructions before using the appliance.
2. Read and follow the specific "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY" on page 4.
3. This appliance must be grounded. Connect only to properly grounded outlet. See
"GROUNDING INSTRUCTIONS" on page 5.
4. Install or locate this appliance only in accordance with the provided installation instructions.
5. Some products such as whole eggs and sealed containers -for example, closed glass jars-
are able to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in this manual. Do not use
corrosive chemicals or vapors in this appliance. This type of oven is specifically designed
to heat, cook, or dry food. It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary when used by children.
8. To reduce the risk of fire in the oven cavity:
a) Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible
materials are placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from paper or plastic bags before placing bag in oven.
c) If materials inside the oven should ignite, keep oven door closed, turn oven off, and
disconnect the power cord or shut off power at the fuse or circuit breaker panel.
d) Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils
or food in the cavity when not in use.
9. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point
without appearing to be boiling due to surface tension of the liquid. Visible bubbling or
boiling when the container is removed from the microwave oven is not always present.
THEIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN A
SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. To reduce the risk of
injury to person:
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through heating it.
c) Do not use straight-sided containers with narrow necks.
d) After heating, allow the container to stand in the microwave oven for a short time before
removing the container.
e) Use extreme care when inserting a spoon or other utensil into the container.
SAVE THESE INSTRUCTIONS

3
10. Do not heat oil or fat for deep-frying. It is difficult to control the temperature of oil in
microwave oven.
11. Pierce foods with heavy skins such as potatoes, whole squash, apples and chestnuts
before cooking.
12. The contents of feeding bottles and baby jars should be stirred or shaken and the
temperature should be checked before serving in order to avoid burns.
13. Cooking utensils may become hot because of heat transferred from the heated food.
Potholders may be needed to handle the utensil.
14. Do not cover or block any openings on the appliance.
15. Do not store or use this appliance outdoors. Do not use this product near water, for
example, near a kitchen sink, in a wet basement, near a swimming pool, or similar
locations.
16. Do not operate this appliance if it has a damaged cord or a plug, if it is not working properly
or if it has been damaged or dropped.
17. Do not immerse cord or plug in water. Keep cord away from heated surface. Do not let cord
hang over edge of table or counter.
18. Use only thermometers, which are specifically designed for use in microwave ovens.
19. Do not operate any heating or cooking appliance beneath this appliance.
20. Be certain the glass tray and roller rings are in place when you operate the oven.
21. This appliance should be serviced only by qualified service personnel, contact nearest
authorized service facility for examination, repair, or adjustment.
22. When cleaning surfaces of door and oven that comes together on closing the door, use
only mild, nonabrasive soaps, or detergents applied with a sponge or soft cloth.
23. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
l Reorient or relocate the receiving antenna.
l Increase the separation between the equipment and receiver.
l Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
l Consult the dealer or an experienced radio/TV technician for help.
SAVE THESE INSTRUCTIONS

4
Precautions to Avoid Possible Exposure to
Excessive Microwave Energy
1. Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper
with the safety interlocks.
2. Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is very important that the oven door close
properly and that there is no damage to the
a) Door (including any dents),
b) Hinges and latches (broken or loosened),
c) Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except qualified service
personnel.
Specifications
Power Consumption 120V/60Hz, 1100W (microwave)
Output 700W
Operation Frequency 2450MHz
Outside Dimensions(H x W x D) 10 5/16 ×17 13/16×12 3/4 inches
Oven Cavity Dimensions(H x W x D) 8 11/16×12 3/8×11 9/16 inches
Oven Capacity 0.7cu.ft.
Cooking Uniformity Turntable System
Net Weight Approx. 23.1 lbs
Outlet 125V/15A
Power Cord 1800mm

5
Installation Guide
1. Make sure that all the packing materials are removed from the inside of the door.
2. Check the oven for any damage, such as misaligned or bent door, damaged door seals and
sealing surface, broken or loose door hinges and latches and dents inside the cavity or on
the door. If there is any damage, do not operate the oven and contact qualified service
personnel.
3. This microwave oven must be placed on a flat, stable surface to hold its weight and the
heaviest food likely to be cooked in the oven.
4. Do not place the oven where heat, moisture, or high humidity are generated, or near
combustible materials.
5. For correct operation, the oven must have sufficient air flow. Allow 20cm of space above the
oven, 10cm at back and 5cm at both sides. Do not cover or block any openings on the
appliance. Do not remove feet on which oven stands.
6. The appliance shall be only used on a countertop over 3 feet above the floor.
7. Do not operate the oven without glass tray, roller support, and shaft in their proper positions.
8. Make sure that the power cord is undamaged and does not run under the oven or over any
hot or sharp surface.
9. The socket must be readily accessible so the microwave oven can be easily unplugged in an
emergency.
Grounding Instructions
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces
risk of electric shock by providing an escape wire for the electric current.
WARNING!-- Improper use of the grounding plug can result in a risk of electric shock.
This appliance must be connected to a grounded, metallic, permanent wiring system, or an
equipment grounding conductor should be run with the circuit conductors and connected to the
equipment grounding terminal or lead on the appliance.
Consult a qualified electrician or serviceman if the grounding instructions are not completely
understood, or if doubt exists as to whether the appliance is properly grounded, and either:
1) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a
3-blade grounding plug and a 3-slot receptacle that will accept the plug on the appliance. The
marked rating of the extension cord shall be equal to or greater than the electrical rating of the
appliance, or 2) Do not use an extension cord. If the power supply cord is too short, have a
qualified electrician or servicemen install an outlet near the appliance.

6
Electrical Requirements
The electrical requirements are a 120 volt 60 Hz, AC only, 15 amp. It is recommended that a
separate circuit serving only the oven be provided. The oven is equipped with a 3-prong
grounding plug. It must be plugged into a wall outlet properly installed and grounded.
Power Cord
l A short power supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
l Longer cord sets or extension cords are available and may be used if care is exercised in
their use.
l If long cord or extension cord is used：
l The marked electrical rating of the cord set or extension cord should be at least as great as
the electrical rating of the appliance.
l The extension cord must be a grounding-type 3-wire cord, and The longer cord should be
arranged so that it will not drape over the counter top or table top where it can be pulled on
by children or tripped over unintentionally.
Note:
l If you have any questions about the grounding or electrical instructions, consult a qualified
electrician or service person.
l Neither the manufacturer nor the dealer can accept any liability for damage to the oven or
personal injury resulting from failure to observe the electrical connection procedures.
Radio or TV Interference
Should there be any interference caused by the microwave oven to your radio or TV, check that
the microwave oven is on a different circuit, relocated the radio or TV as far away from the oven
as feasible or check position and signal of receiving antenna.
Outlet
Plug of other household appliances can be inserted in the outlet (back of the microwave oven).
A household appliance combination can help saving kitchen space, make your kitchen tidier
and make cooking more convenient.

7
Cooking Techniques
Your microwave makes cooking easier than conventional cooking, provided you keep these
considerations in mind:
STIRRING
Stir foods such as casseroles and vegetables while cooking to distribute heat evenly. Food at
the outside of the dish absorbs more energy and heats more quickly, so stir from the outside to
the center. The oven will turn off when you open the door to stir your food.
ARRANGEMENT
Arrange unevenly shaped foods, such as chicken pieces or chops, with the thicker, meatier
parts toward the outside of the turntable where they receive more microwave energy. To
prevent overcooking, place delicate areas, such as asparagus tips, toward the center of the
turntable.
SHIELDING
Shield food with narrow strips of aluminum foil to prevent overcooking. Areas that need
shielding include poultry wing tips, the ends of poultry legs, and corners of square baking
dishes. Use only small amounts of aluminum foil. Larger amounts can damage your oven.
TURNING
Turn foods over midway through cooking to expose all parts to microwave energy. This is
especially important with large foods such as roasts.
STANDING
Foods cooked in the microwave build up internal heat and continue to cook for a few minutes
after heating stops. Let foods stand to complete cooking, especially foods such as cakes and
whole vegetables. Roasts need this time to complete cooking in the center without overcooking
the outer areas. All liquids, such as soup or hot chocolate, should be shaken or stirred when
cooking is complete. Let liquids stand a moment before serving. When heating baby food, stir
well at removal and test the temperature before serving.
ADDING MOISTURE
Microwave energy is attracted to water molecules. Food that is uneven in moisture content
should be covered or allowed to stand so that the heat disperses evenly. Add a small amount of
water to dry food to help it cook.

8
Cooking Utensils Guide
This section lists which utensils can be used in this microwave, which have limited use for short
periods, and which should not be used in this microwave.
RECOMMENDED
Microwave browning dish — Use to brown the exterior of small items such as steaks, chops,
or pancakes. Follow the directions provided with your browning dish.
Microwaveable plastic wrap — Use to retain steam. Leave a small opening for some steam to
escape and avoid placing it directly on the food.
Paper towels and napkins — Use for short-term heating and covering; these absorb excess
moisture and prevent spattering. Do not use recycled paper towels, which may contain metal
and could ignite.
Glass and glass-ceramic bowls and dishes — Use for heating or cooking.
Paper plates and cups — Use for short-term heating at low temperatures. Do not use recycled
paper, which may contain metal and could ignite.
Wax paper — Use as a cover to prevent spattering.
Thermometers — Use only those labeled "Microwave Safe" and follow all directions. Check
the food in several places. Conventional thermometers may be used on microwave food once
the food has been removed from the oven.
LIMITED USE
Aluminum foil — Use narrow strips of foil to prevent overcooking of exposed areas. Using too
much foil can damage your oven, so be careful. You should keep distance of 1 inch (2.54cm)
between aluminum foil and cavity.
Ceramic, porcelain, and stoneware— Use these if they are labeled "Microwave Safe". If they
are not labeled, test them to make sure they can be used safely.
Plastic — Use only if labeled "Microwave Safe". Other plastics can melt.
NOT RECOMMENDED
Glass jars and bottles — Regular glass is too thin to be used in a microwave. It can shatter
and cause damage and injury.
Paper bags — These are a fire hazard, except for popcorn bags that are designed for
microwave use.
Styrofoam plates and cups — These can melt and leave an unhealthy residue on food.
Plastic storage and food containers — Containers such as margarine tubs can melt in the
microwave.
Metal utensils — These can damage your oven. Remove all metal before cooking.
Note:
Should you wish to check if a dish is safe for microwaving, place the empty dish in the oven and
microwave on HIGH for 30 seconds. A dish which becomes very hot should not be used.

9
Product Diagram
4
5
76
3
2
1
① Door Safety Lock System
② Oven Window
③ Turntable Support
④ Door Release Button
⑤ Control Panel
⑥ Wave Guide
(Please do not remove the mica
plate covering the wave guide)
⑦ Glass Tray
⑧ Outlet
⑨ Power Cord Hole

10
Control Panel
l DISPLAY
Cooking time, power, indicators and clock time
are displayed.
l AUTO COOK MENUS
There are 6 kinds of auto cook menus. Use to
set auto cook program.
l POWER
Use to select microwave power level.
l TIMER
Use to set timer program.
l COOK
Use to set multistage cooking program.
l COOK BY WEIGHT
Programmed cooking based on weight of foods
to be cooked.
l DEFROST BY WEIGHT
Use to defrost food based on weight enter.
l SPEED DEFROST
Use to set speed defrost program.
l NUMBER PADS (0-9)
Use to set time or food weight.
l CLOCK
Use to set the current time.
l RESET
Use to cancel all settings or set child lock.
l START/STOP
Use to start or stop a cooking program.

11
Operation Instructions
l During cooking, if press START/STOP pad once or open the door, the program will be
paused, then press RESET pad, the program will be canceled.
l After ending cooking, the system will sound beeps to remind user every two minute until
user press any pad or open the door.
Setting Clock
1. Touch CLOCK pad.
2. Use the number pads to enter the correct time.
3. Touch CLOCK pad again to confirm.
Note: This is a 12 hour clock. When the oven is first plugged in or when power resumes after a
power interruption, the display will show ENTER CLOCK TIME. If you prefer to not have the
clock displayed, touch RESET pad. During cooking you can check the clock time by touching
CLOCK pad.
Timer Function
1. In standby state or cooking in process, touch TIMER pad.
2. Use the number pads to enter desired time. The longest time is 99 minutes 99 seconds.
3. Touch START/STOP pad.
Note: You can check the countdown time by pressing TIMER pad, if press RESET pad when
the display shows the time, the function is cancelled.
Microwave Cooking
A. One-stage cooking
1. Use the number pads to enter cooking time. The longest time is 99 minutes 99 seconds.
2. If you want to set a power level other than 100%, touch POWER pad, and then use the
number pads to enter the power level.
3. Touch START/STOP pad.
Use single digit to set a cooking power level:
Number pad Cooking power
Number pad Cooking power
1,0 100% 4 40%
9 90% 3 30%
8 80% 2 20%
7 70% 1 10%
6 60% 0 0%
5 50%
Note: During cooking, the current power level can be seen by touching POWER pad.
B. Two-stage cooking
Some recipes require different stages of cooking at different temperatures.

12
1. SET STAGE 1:
Follow steps 1 and 2 in “One-stage Cooking”. DO NOT TOUCH START/STOP
2. SET STAGE 2:
Touch COOK then enter proper cooking time and (lower) power level. (Most 2-stage recipes use
lower power for second stage.)
3. Touch START/STOP.
Speed Defrost
1. Touch SPEED DEFROST pad.
2. Use the number pads to enter defrosting time. The longest time is 99 minutes 99 seconds.
3. Touch START/STOP pad.
Note:
· During defrosting program, the system will pause and sound beeps to remind user to turn food
over, and then press START/STOP pad to resume.
· After setting SPEED DEFROST, oven can be programmed to automatically switch to one or
two-stage cooking.
· For speed defrost and one stage cooking, follow steps above. Before touching START/STOP,
touch COOK pad once, enter time and power level and then touch START/STOP.
· For speed defrost and two stage cooking, follow steps above. Before touching START/STOP,
touch COOK, enter cooking time and power level and then touch START/STOP.
Cook By Weight
The cooking time and power level are adjusted automatically once the weight is programmed.
1. Touch COOK BY WEIGHT pad.
2. Press number pad 1, 2 or 3 to select food type (1 signs beef, 2 signs mutton, 3 signs pork).
Code
Food Type Maximum Weight
1 Beef 5 LB 16OZ
2 Mutton 5 LB 16OZ
3 Pork 5 LB 4OZ
3. Use the number pads to enter food weight.
4. Touch START/STOP pad.
Note:
· Meat must be defrosted and at refrigerated temperature.
· Weight must be in pounds and ounces. Ounce weights less than 10 must be preceded by a 0. If
label gives weight in pounds only, change the fraction of a pound to ounces by using the chart.

13
Converting Fractions of a Pound to Ounces:
Fractions of a Pound Ounces Fractions of a Pound Ounces
Less than .03 0 .54 to .59 9
.03 to .09 1 .60 to .65 10
.10 to .15 2 .66 to .71 11
.16 to .21 3 .72 to .78 12
.22 to .27 4 .79 to .84 13
.28 to .34 5 .85 to .90 14
.35 to .40 6 .91 to .97 15
.41 to .46 7 above .97 go to next
even
.47 to .53 8
· During cooking, the system will pause and sound beeps to remind user to turn food over, and
then press START/STOP pad to resume.
Defrost By Weight
The defrosting time and power level are adjusted automatically once the weight is
programmed.
1. Touch DEFROST BY WEIGHT pad.
2. Use the number pads to enter food weight.
3. Touch START/STOP pad.
Note:
· Weight must be in pounds and ounces. Ounce weights less than 10 must be preceded by a 0. If
label gives weight in pounds only, change the fraction of a pound to ounces by using the chart
given above. Maximum weight is 5 LB 16OZ.
· During defrosting program, the system will pause and sound beeps to remind user to turn food
over, and then press START/STOP pad to resume.
Setting Child Lock
The lock prevents unsupervised operation by children.
l To set the child lock: In standby mode, press RESET pad for 3 seconds, then a beep will
sound. In the lock state, the oven can’t be operated.
l To cancel the child lock: Press RESET pad for 3 seconds, then a beep will sound, and the
oven can be operated.

14
Auto Cook Menus
POPCORN
1. Touch POPCORN pad once.
POPCORN automatically sets the cooking
time for a 3.5 oz bag of microwave
popcorn.
2. Touch START/STOP pad.
Note: To change the preset POPCORN time:
Touch POPCORN pad twice. ENTER TIME
appears in the display. Touch number pads to
enter minutes and seconds, the longest time
is 99 minutes 99 seconds. Touch
START/STOP pad. This new cooking time
will be set as the default one until you reset it
or next power on.
BAKED POTATO
For small potatoes (4 to 6 oz/each):
1. Touch BAKED POTATO once.
2. Enter number of potatoes by touching
number pads from 1 to 4.
3. Touch START/STOP pad.
For larger potatoes (8 to 10 oz/each):
1. Touch BAKED POTATO twice.
2. Enter number of potatoes by touching
number pads from 1 to 4.
3. Touch START/STOP pad.
PIZZA
Reheating a slice of pizza:
1. Touch PIZZA pad once.
2. Touch START/STOP pad.
Heating a whole pizza:
1. Touch PIZZA pad twice.
2. Touch START/STOP pad.
BEVERAGE
For cups (5 to 7 oz/each):
1. Touch BEVERAGE pad once.
2. Enter number of cups by touching number
pads from 1 to 4.
3. Touch START/STOP pad.
For larger coffee cups (9 to11 oz/each):
1. Touch BEVERAGE pad twice.
2. Enter number of mugs by touching number
pads from 1 to 4.
3. Touch START/STOP pad.
FROZEN DINNER
For small frozen dinners (7 to 9 oz/each):
1. Touch FROZEN DINNER pad once.
2. For 1 entree or 2 entrees, touch the
number pad “1” or “2”.
3. Touch START/STOP pad.
For large frozen dinners (10 to 12
oz/each):
1. Touch FROZEN DINNER pad twice.
2. For 1 entree or 2 entrees, touch the
number pad “1” or “2”.
3. Touch START/STOP pad.
REHEAT
1. Touch REHEAT pad.
2. Press START/STOP pad.

15
Cleaning and Care
1. Turn off the oven and unplug the power cord from the wall when cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls,
wipe with a damp cloth. Mild detergents may be used if the oven gets very dirty. Avoid using
spray or other harsh cleaners. They may stain, streak or dull the door surface.
3. The outside of the oven should be cleaned with a damp cloth. To prevent damage to the
operating parts inside the oven, water should not be allowed to seep into the ventilation
openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a
damp cloth to remove any spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning
the control panel, leave oven door open to prevent oven from accidentally turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth.
This may occur when the microwave oven is operated under high humidity condition. And it
is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm
sudsy water or in a dishwasher.
8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply
wipe the bottom surface of the oven with mild detergent. The roller ring may be washed in
mild, soapy water or in a dishwasher. When removing the roller ring, be sure to replace it in
the proper position.
9. Remove odors from your oven by combining a cup of water with the juice and skin of one
lemon in a microwaveable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a
soft cloth.
10. If the light bulb burns out, please contact customer service to have it replaced.
11. The oven should be cleaned regularly and any food deposits should be removed. Failure to
maintain the oven in a clean condition could lead to deterioration of surface that could
adversely affect the life of the unit and could possibly result in a hazardous situation.
12. Please do not dispose of this appliance into the domestic rubbish bin; it should be disposed
to the particular disposal center provided by the municipalities.
