Infinity Kappa Series 32.9cf User manual

INFINITY
®
KAPPA
®
SPEAKERS
Looking for a moremoving audio experience? Take Infinity®
car audio for a ride. Innovative materials and breakthrough
engineering have always put Infinity products out in front
ofthe competition’s. So expectextreme output from us. But be
prepared for accuracy and detail that may surprise you. The
Kappa line of premium loudspeakers – which incorporates the
very best in high-end design and proven technology – has long
been one ofthe world’smost recognized and admired.

multielements
32.9cf
3-1/2" Two-Way Loudspeaker
Plus One®(patent pending)
woven-glass-fiber woofer cone
MMD®-dome tweeter
True 4-ohm
Direct-connect crossover dongle
Impedance: 2 ohms
Sensitivity: 92dB
Frequency response: 85Hz – 25kHz
Power handling, RMS: 35 watts
Power handling, Peak: 105 watts
42.9i
4" Two-Way Loudspeaker
Plus One®(patent pending)
woven-glass-fiber woofer cone
Edge-driven MMD®-dome tweeter
True 4-ohm
Direct-connect crossover dongle
Tweeter-level adjustment on tweeter
Impedance: 2 ohms
Sensitivity: 93dB
Frequency response: 75Hz – 25kHz
Power handling, RMS: 50 watts
Power handling, Peak: 150 watts
52.9i
5-1/4" Two-Way Loudspeaker
Plus One®(patent pending)
woven-glass-fiber woofer cone
Edge-driven MMD®-dome tweeter
with UniPivot™(patent no. 6,002,780)
True 4-ohm
Direct-connect crossover dongle
Tweeter-level adjustment on tweeter
Impedance: 2 ohms
Sensitivity: 94dB
Frequency response: 55Hz – 25kHz
Power handling, RMS: 55 watts
Power handling, Peak: 165 watts
62.9i
6-1/2" Two-Way Loudspeaker
Plus One®(patent pending)
woven-glass-fiber woofer cone
Edge-driven MMD®-dome tweeter
with UniPivot™(patent no. 6,002,780)
True 4-ohm
Direct-connect crossover dongle
Tweeter-level adjustment on tweeter
Intermount III (patent no. 6,505,705) woofer
mounting system
Impedance: 2 ohms
Sensitivity: 95dB
Frequency response: 45Hz – 25kHz
Power handling, RMS: 75 watts
Power handling, Peak: 225 watts
New Kappa loudspeakers take car audio speaker technology to a
whole new level with features such as Plus One®(patent pending)
cones; true-four-ohm topology; UniPivot™(patent no. 6,002,780)
edge-driven tweeters; and industry-leading mounting systems,
including Intermount III (patent no. 6,505,705) and I-Mount™
(patent no. 5,859,917), and the Starfish™tweeter-mounting adapter.
With all this technology in a single speaker series, it’s no wonder
our competitors are scrambling to keep up.
For years, the design of upscale car audio speakers has been
loosely based on the design of at-home speaker systems, where
amplifiers are big and power is plentiful. The audio systems in new
cars are different. Almost all new systems include two-ohm
speakers and small, efficient amplifiers or head units designed
todrive them. Replacing those two-ohm factory speakers with
four-ohm models cuts the available power in half, and that’s
no upgrade. Kappa speakers are optimized for these new systems
and work beautifully with old-school aftermarket gear, too.

multielements
62.9is
6-1/2" Two-Way Shallow
Mount Loudspeaker
Plus One®(patent pending)
woven-glass-fiber woofer cone
Edge-driven MMD®-dome tweeter
Direct-connect crossover dongle
Tweeter-level adjustment on tweeter
Intermount III (patent no. 6,505,705) woofer
mounting system
Impedance: 2 ohms
Sensitivity: 94dB
Frequency response: 45Hz – 25kHz
Power handling, RMS: 65 watts
Power handling, Peak: 195 watts
63.9i
6-1/2" Three-Way Loudspeaker
Plus One®(patent pending)
woven-glass-fiber woofer cone
MMD®-dome midrange and UHF tweeter
Direct-connect crossover dongle
Tweeter-level adjustment on tweeter
Impedance: 2 ohms
Sensitivity: 95dB
Frequency response: 45Hz – 30kHz
Power handling, RMS: 75 watts
Power handling, Peak: 225 watts
652.9i
165mm Two-Way Loudspeaker
Plus One®(patent pending)
woven-glass-fiber woofer cone
Edge-driven MMD®-dome tweeter with UniPivot™
(patent no. 6,002,780)
Direct-connect crossover dongle
Tweeter-level adjustment on tweeter
Impedance: 2 ohms
Sensitivity: 95dB
Frequency response: 45Hz – 25kHz
Power handling, RMS: 75 watts
Power handling, Peak: 225 watts
UNIPIVOT
TOENSURE
PROPER IMAGING
TWEETER
LEVEL CONTROL
Installation of Kappa speakers is easy, thanks to a new
crossover dongle, that is permanently connected to the
speaker’s terminals at the factory. No special tools or
connectors are required to connect standard Kappa
speakers tothe car’s wiring. Additionally, Kappa speakers
include frames designed to fit most factory speaker
locations without modification.
Kappa Series Speakersalso include Plus One cone
technology, which delivers a cone with more surface
area than competing models of the same size. This
increase can be as much as 30%, depending on the
individual speaker model. The benefit is increased
bass output and increased efficiency.

multielements
692.9i
6" x 9" Two-Way Loudspeaker
Plus One®(patent pending)
woven-glass-fiber woofer cone
Edge-driven MMD®-dome tweeter with
UniPivot™(patent no. 6,002,780)
Direct-connect crossover dongle
Tweeter-level adjustment on tweeter
Impedance: 2 ohms
Sensitivity: 96dB
Frequency response: 35Hz – 25kHz
Power handling, RMS: 110 watts
Power handling, Peak: 330 watts
693.9i
6" x 9" Three-Way Loudspeaker
Plus One®(patent pending)
woven-glass-fiber woofer cone
MMD®-dome midrange and UHF tweeter
Direct-connect crossover dongle
Tweeter-level adjustment on tweeter
Impedance: 2 ohms
Sensitivity: 96dB
Frequency response: 35Hz – 30kHz
Power handling, RMS: 110 watts
Power handling, Peak: 330 watts
462.9cfp
4" x 6" Two-Way Plate Loudspeaker
Plus One®(patent pending)
woven-glass-fiber woofer cone
Edge-driven MMD®-dome tweeter
Direct-connect crossover dongle
Tweeter-level adjustment on tweeter
Impedance: 2 ohms
Sensitivity: 94dB
Frequency response: 75Hz – 25kHz
Power handling, RMS: 60 watts
Power handling, Peak: 180 watts
682.9cf
6" x 8"/5" x 7" Two-Way Loudspeaker
Plus One®(patent pending)
woven-glass-fiber woofer cone
Edge-driven MMD®-dome tweeter with
UniPivot™(patent no. 6,002,780)
Direct-connect crossover dongle
Tweeter-level adjustment on tweeter
Impedance: 2 ohms
Sensitivity: 94dB
Frequency response: 40Hz – 25kHz
Power handling, RMS: 100 watts
Power handling, Peak: 300 watts
All Kappa Series speakersare“true
four-ohm” – they include reduced
voice-coil impedance designed to
extract the most power possible from
all amplifiers engineered to drive
loads of four ohms or less. Many
factory-installed systems incorporate
two-ohm speakers and include
amplifiers designed to drive those
loads. Replacing those reduced-
impedance speakers with four-ohm
models is hardly an upgrade, since
the power output from the amplifier
will be reduced. True-four-ohm
addresses this as well.
Other features – An ultra-wideband
UHF soft-dome tweeter is used on the
component systems for accurate music
reproduction from 25kHz up to 35kHz.
Edge-driven-MMD®dome tweeters are
used. These arenotcommonlyused
W-domes, but fully edge-driven-dome
tweeters like those found in better
home-audio speakers. The benefit is
increased power handling and reduced
distortion at high output levels.
Anew ceramic woofer motor with a
much longer voice coil for drastically
reduced distortion at high listening
levels (up to 15dB less!) is used. This
results in a much tighter and better
sounding bass.

250 Crossways Park Drive
Woodbury, NY 11797 USA
516.674.4INF (4463)
Fax [phone]
www.infinitysystems.com
© 2008 Harman International Industries, Incorporated.
All rights reserved. Part No. INFBASSLINKPI3-08
Features, specifications and appearance are subject to change
without notice. Designed, edited and digitally produced by the
Harman Consumer Group Marketing & Design Center, Woodbury, NY.
Infinity, Kappa Series, Plus One, MMD and CMMD are trademarks
of Harman International Industries, Incorporated, registered
in the United States and/or other countries. T-Pole Motor,
I-Mount, SLI, UniPivot, EMIT, Starfish, BassLink T and
MultiMount are trademarks of Harman International Industries,
Incorporated.
c o m p o n e n t s y s t e m s
250 Crossways Park Drive
Woodbury, NY 11797 USA
516.674.4INF (4463)
Fax [phone]
www.infinitysystems.com
© 2008 Harman International Industries, Incorporated.
All rights reserved. Part No. INFKAPPASPKPI3-08
Features, specifications and appearance are subject to change
without notice. Designed, edited and digitally produced by the
Harman Consumer Group Marketing & Design Center, Woodbury, NY.
Infinity, Kappa, Plus One, and MMD are trademarks
of Harman International Industries, Incorporated,
registered in the United States and/or other countries.
I-Mount, UniPivot and Starfish are trademarks of
Harman International Industries, Incorporated.
50.9cs
5-1/4" Two-Way
Component System
Plus One®(patent pending)
woven-glass-fiber woofer cone
Edge-driven MMD®-dome tweeter
Outboard passive crossover
with air core inductors and poly caps
I-Mount™(patent no. 5,859,917)
tweeter kit with Starfish™OEM adapter
Tweeter-level adjustment
Impedance: 2 ohms
Sensitivity: 93dB
Frequency response: 55Hz – 25kHz
Power handling, RMS: 85 watts
Power handling, Peak: 255 watts
60.9cs
6-1/2" Two-Way
Component System
Plus One®(patent pending)
woven-glass-fiber woofer cone
Edge-driven MMD®-dome tweeter
Outboard passive crossover
with air core inductors and poly caps
I-Mount™(patent no. 5,859,917)
tweeter kit with Starfish™OEM adapter
Intermount III (patent no. 6,505,705)
woofer-mounting system
Tweeter-level adjustment
Impedance: 2 ohms
Sensitivity: 95dB
Frequency response: 45Hz – 25kHz
Power handling, RMS: 90 watts
Power handling, Peak: 270 watts
680.9cs
6"x8"/5" x 7" Two-Way
Component System
Plus One®(patent pending)
woven-glass-fiber woofer cone
Edge-driven MMD®-dome tweeter
Outboard passive crossover
with air core inductors and poly caps
I-Mount™(patent no. 5,859,917)
tweeter kit with Starfish™OEM adapter
Tweeter-level adjustment
Impedance: 2 ohms
Sensitivity: 93dB
Frequency response: 45Hz – 25kHz
Power handling, RMS: 90 watts
Power handling, Peak: 270 watts
10.9t
1" Textile Tweeter
Edge-driven motor structure
I-Mount™(patent no. 5,859,917)
tweeter kit with Starfish™OEM adapter
Outboard passive crossover
with air core inductors and poly caps
Impedance: 2 ohms
Sensitivity: 93dB
Frequency response: 2.5Hz – 25kHz
Power handling, RMS: 50 watts
Power handling, Peak: 150 watts
with supplied crossover
