1. Introduction
User Manual © InfraTec GmbH 2015 1
1Introduction
Dear User,
Congratulations on the purchase of your new thermographic system VarioCAM®hr head.
Please read these instructions carefully before operating the system for the first time. This will enable you
to make full use of the features of your new thermographic system. Please especially note the advice
regarding device safety in Chapter 2 in order to avoid damage to the thermographic system.
All the specifications in this user manual describe a completely equipped thermographic system
VarioCAM®hr of the “head” series. Technical data, the scope of features and accessories included in
your thermographic system may deviate from the specifications described here depending on the model
chosen and on individual adjustments. Features relating to optional equipment are marked *in this
manual.
Principally, the description of technical data and the specific scope of features provided in the relevant
shipping documents (confirmation of order/delivery note) apply.
Further development is subject to technical progress.
Jenoptik ESW GmbH
07745 Jena / GERMANY
InfraTec GmbH
01217 Dresden / GERMANY
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Note:
No part of this instruction manual may be reproduced in any form (print, photocopy, microfilm or any other
method) or processed, duplicated or distributed using electronic systems without the written permission of
JENOPTIK Laser, Optik, Systeme GmbH. This instruction manual was compiled with the necessary
diligence. No liability is accepted for damage arising from non-observance of the information contained in
this instruction manual.
Any product names and trademarks mentioned herein remain the property of their respective owners.

User Manual for the Thermographic System VarioCAM®hr head
1. Introduction
2 © InfraTec GmbH 2015 User Manual
VarioCAM®high resolution head (hereinafter VarioCAM®hr head) is a modern thermographic system for
the precise, quick and non-contact measurement of surface temperatures of objects. Its compact and
robust design and high degree of protection make it especially suitable for industrial applications even
under unfavorable external conditions. Its low weight as well as its long battery life provide for its effective
use.
A wide range of accessories and several software packages for handling images and their further
processing make the VarioCAM®hr head a universal thermographic system for use in a wide field of
applications.
Its high measuring precision, precision lenses of extraordinary imaging quality and its universal interface
design for the digital recording of real-time thermographic data via FireWire/IEEE 1394* permit the
application of the VarioCAM®hr head in the most varied fields of research and development.
Typical applications of the thermographic system include:
■Inspection of electrical and mechanical systems and power units
■Optimisation of components and units
■Control of process temperatures
■Quality assurance

User Manual for the Thermographic System VarioCAM®hr head
2. Advice on Device Safety
User Manual © InfraTec GmbH 2015 3
2Advice on Device Safety
General
The VarioCAM®hr head is a high-quality, thoroughly calibrated optical measuring instrument. Handle it
with appropriate care. Avoid soiling it, particularly its optical surfaces.
The device has protection class IP 65.
Please observe the conditions specified under Technical Data (see Chapter 3.3, Technical Data, page 9)
for use, save and transport of the device.
For transporting the VarioCAM®hr head, exclusively use the transportation case included.
Opening the camera case is reserved for customer service or authorised staff only. Any interference by
the user or unauthorised persons is not permitted and will void any warranty.
Only use accessories or spare parts which are expressly recommended by JENOPTIK Laser, Optik,
Systeme GmbH for use with the VarioCAM®hr head. Otherwise malfunctions or damage can occur.
Warranty shall be excluded for such damage.
Standards, Guidelines
The VarioCAM®hr head complies with the requirements of the following standards:
■EN 61010-1:2001 Safety requirements for electrical equipment for measurement, control and
laboratory use – Part1: General requirements (IEC 61010-1:2011)
■EN 61326-1:2006 Electrical equipment for measurement, control and laboratory use – EMC
Requirements – Part1: General requirements (IEC 61326-1:2005)

User Manual for the Thermographic System VarioCAM®hr head
2. Advice on Device Safety
4 © InfraTec GmbH 2015 User Manual
Handling
The VarioCAM®hr head is equipped with a highly sensitive uncooled microbolometer detector. Object
radiation occurring in thermographic practice does not cause any changes in the detector. However,
black-body radiation overdrive exceeding 1,000 °C in measuring ranges 1 and 2 or 2,000 °C in
measuring ranges 3 and 4, may result in irreversible damage and must therefore be avoided by
selecting a suitable calibration range* prior to measuring.
The VarioCAM®hr head must, neither in operation nor when switched off, directly be focused into the
sun or other sources of intensive radiation (e.g. lasers), since this may result in changes of the
microbolometer detector, whose origin can unambiguously be proven. The manufacturer waives any
warranty for such damage.
It is also imperative to avoid indirectly capturing any sunlight or other highly energetic radiation via
reflective surfaces directed into the field of view of the VarioCAM®hr head!
Under certain conditions, it cannot be excluded, even when the system is switched off, that the
detector may be damaged when directed into sunlight. Therefore, when the VarioCAM®hr head is not
in use, the lens must be capped with the protective cover included.
Only use SecureDigital cards in the SD slot of the VarioCAM®hr head. Otherwise damage to the
camera or the memory card can arise, for which no liability will be accepted.
Lens changes should not be carried out in rooms of high dust load or humidity, since IP 54 protection
class is not guaranteed with the lens removed.

User Manual for the Thermographic System VarioCAM®hr head
3. Technical Description
User Manual © InfraTec GmbH 2015 5
3Technical Description
3.1 Operating Principle
The VarioCAM®hr head is a thermographic system for the long wave infrared spectral range (LWIR) of
(7.5 ... 14) µm. The lens images the object scene onto a microbolometer array at a resolution of
(640 x 480) or (384 x 288) pixels. The electrical signal of the detector arrays is further processed by the
internal electronics. The electronics contains all the functions necessary for camera operation, such as
activation of the microbolometer array, A/D conversion, offset and gain correction, defective pixel
treatment, video and PC interfaces.
Operating the system is effected via the PC interfaces, available as FireWire (IEEE 1394) and RS232*.
The use of these interfaces which are available depending on their versions of equipment requires special
software packages. You will find relevant details from Chapter 8 on, Hardware and Software Installation
for VarioCAM®hr head*, page 5.
3.2 Description of the Functional Units
Lens
The camera lens captures the IR radiation emitted by the object in the field of view and images it on the
detector array. Field of view (FOV) and resolution/size of the measuring point (IFOV, Instantaneous Field
of View) are determined at the same distance from the focal length f of the lens used.
The following standard lenses are available:
Thermographic system of resolution (384 x 288) pixels
lens focal length (mm) min. focus (m) IFOV (mrad) FOV (°)
wide-angle lens 12.5 0.2 2.8 (57 x 44)
standard lens 25 0.3 1.4 (30 x 23)
telephoto lens 1 50 2.0 0.7 (15 x 12)
telephoto lens 2 75 2.0 0.47 (10 x 8)
telephoto lens 3 130 5.0 0.27 (6 x 4)
close-up lens focal length (mm) focus (mm) field of view (mm²) resolution (μm)
close-up 0.17x for 25 149 (80 x 60) 209
close-up 0.5x for 25 50 (27 x 20) 70
microscopic lens 1.0x - 50 (13 x 10) 35

User Manual for the Thermographic System VarioCAM®hr head
3. Technical Description
6 © InfraTec GmbH 2015 User Manual
Thermographic system of resolution (640 x 480) pixels
lens focal length (mm) min. focus (m) IFOV (mrad) FOV (°)
wide-angle lens 12.5 0,2 2.0 (65 x 51)
standard lens 30 0,3 0.8 (30 x 23)
telephoto lens 1 50 2,0 0.5 (18 x 14)
telephoto lens 2 75 2,0 0.3 (12 x 9)
telephoto lens 3 130 5,0 0.2 (7 x 5)
close-up lens focal length (mm) focus (mm) field of view (mm²) resolution (μm)
close-up 0.17x for 30 150 (80 x 60) 125
close-up 0.5x for 30 50 (27 x 20) 42
microscopic lens 1.0x - 50 (16 x 12) 25
Detector
The VarioCAM®hr head has an uncooled microbolometer FPA detector (uncooled Focal Plane Array).
The detector is thermally stabilised with high precision using a Peltier element and is thus independent of
the ambient temperature.
The various elements of the detector are microscopically minute thin-film resistors on wafer-thin
membranes, which are arranged cantilevered a few micrometers above the silicon read-out circuit. The
thermal radiation of the scene is imaged by the lens of the thermographic system on these detector
elements and absorbed by them. The temperature change of the detector elements resulting therefrom
yields electronically evaluable signals which can be read out line-wise and column-wise by a read-out
circuit.
Applying an uncooled detector guarantees quick availability of the camera function after switching it on
(start-up time < 60 seconds) and long service life (MTTF) in permanent use.
Detector electronics
The detector electronics supplies the BIAS voltages required for detector operation and further control
signals, and it takes care of the pre-processing and digitalisation of the analog video output signal from
the detector.
Image processing electronics
Real-time image processing with the following essential functions (depending on the equipment) is
implemenmted with the help of an FPGA (Field Programmable Gate Array) and an embedded PC
(modular compact internal PC):
■Detector electronics interface
■Gain and offset correction
■Defective pixel treatment
■Low-pass filtering
■Zoom generator
■Graphic overlay
■FireWire (IEEE 1394) interface
■Embedded PC interface
■Standard-format video-image generator (PAL/NTSC-FBAS, S-Video, RGB)

User Manual for the Thermographic System VarioCAM®hr head
3. Technical Description
User Manual © InfraTec GmbH 2015 7
Opto-mechanics
The following functions are performed with the help of the opto-mechanics assembly group:
■Focussing (motor focus)
■Effective range change-over (lens apertures)*
■Internal NUC (Non Uniformity Correction) using an internal shutter
Furthermore, this assembly group has an optional module for a hardware-based increase of geometric
resolution of the thermographic system onto (768 x 576) IR pixels (detector of [384 x 288] pixels) and
onto (1,280 x 960) IR pixels (detector of [640 x 480] pixels): mode “Resolution Enhancement”*. The opto-
mechanics can be modified for reducing the minimal focus distance*.
Controls
VarioCAM®hr head is mainly designed for stationary applications. For those case of operation the
camera is operated from a host computer, via the FireWire (IEEE 1394)-Interface of the device. The
relevant operating software is also described in Chapter 8 Hardware and Software Installation for
VarioCAM® hr head* – page 5.
Power supply
The VarioCAM®hr head has the following power supply options:
■External power supply unit 12 V*
■FireWire (IEEE 1394) interface*.
The mains adapter is connected to the 14-pin (left) socket at the rear of the camera.
For devices equipped with a FireWire (IEEE 1394) interface, the supply voltage can be taken directly from
the PC interface card. Please note the specification of the used interface card and the power input of the
thermographic system. In case of cable lengths > 5 m, power should principally be supplied via the
external power supply unit or the rechargeable battery.

User Manual for the Thermographic System VarioCAM®hr head
3. Technical Description
8 © InfraTec GmbH 2015 User Manual
Interfaces
The thermographic system has the following interfaces:
■Composite Video, S Video, VGA
■Input for external trigger signal/trigger output* (TTL/CMOS, 5 V)
■FireWire (IEEE 1394)
■RS232*
■Headset socket
Abb. 1: Camera-Interface
With the exception of FireWire (IEEE 1394), Headset and WLAN, parallel use of all interfaces is possible
by means of a Breakout Box. The Breakout Box* is connected to the thermographic system with a 14-pin
system cable*. Voltage is then supplied to the Breakout Box from the external power supply unit*. The
analog image information is available as Composite Video, S-Video or VGA signal. Suitable monitors can
be connected to the Breakout Box with standard cables (see Chapter 7.6, Operation with Breakout Box
(Connection via RS232)*, p. 2).
The FireWire (IEEE 1394) interface*, in connection with the software packages IRBIS® remote* and
IRBIS®online*, permits to remote-control the thermographic system and the real-time transfer* of digital
image information to a PC.
SD-driveIEEE 1394 Breakout-Box

User Manual for the Thermographic System VarioCAM®hr head
3. Technical Description
User Manual © InfraTec GmbH 2015 9
3.3 Technical Data
Spectral range (7.5 ... 14) µm
Temperature measuring range (-40 ... 1,200) °C, optional > 2,000 °C
Temperature resolution @ 30 °C better than 0.05 K, up to 0.03 K
Measurement accuracy ± 1.5 K (0 ... 100) °C; ± 2 % (< 0 and > 100) °C
Emissivity Adjustable from 0.1 to 1.0, in increments of 0.01
Recording, image format (pixels) Focal Plane Array , (320 x 240) or
(384 x 288), Resolution Enhancement onto (768 x 576)
(640 x 480), Resolution Enhancement onto (1,280 x 960)
Detector uncooled microbolometer Focal Plane Array
IR frame rate 50/60 Hz
Standard lens (field of view) 1.0/25 mm (25 x 19)° at (320 x 240)
1.0/25 mm (30 x 23)° at (384 x 288)
1.0/30 mm (30 x 23)° at (640 x 480)
Zoom function Up to 8 times digital, infinitely variable
A/D conversion 16 bit
Image memory SD card, FireWire (IEEE 1394) up to 50/60 Hz,
internal real-time storage
Interfaces PAL/NTSC-FBAS, S Video, VGA, RS232, WLAN
FireWire (IEEE 1394), Headset
Power supply mains adapter, FireWire (IEEE 1394)
Operation temperature (-15 ... 50) °C
Storage temperature (- 40 ... 70) °C
Humidity during operation and storage relative humidity 5 % to 95 %, non-condensing
Dimensions (complete system) (133 x 106 x 110) mm
Weight (complete system) approx. 1.3 kg
Tripod recepticle 1/4" screw thread
Warning: observe max. screw-in depth of 4.5 mm!
(DIN 4503)
Display functions thermogram, operator-guided, menu, results, status
Measurement functions max. 10 freely selectable ROI, auto hot/cold spot display, isotherms
Automatic functions autofocus, autoimage, autolevel, alarm,
Protection class in operation IP 65, IEC 529
Shock resistance 25 G, IEC 68-2-29
Vibration resistance in operation 2 G, IEC 68-2-6
* (Properties and technical specifications are dependent on the camera configuration and vary in the equipment packages VarioCAM®hr head.
Design and specifications are subject to permanent improvement; subject to changes in the sense of technical progress.)

User Manual for the Thermographic System VarioCAM®hr head
4. Unpacking and Checking
10 © InfraTec GmbH 2015 User Manual
4Unpacking and Checking
Upon receipt of the VarioCAM®hr head, please check for its completeness and that components are not
damaged. The supplier must immediately be informed of any damage.
The VarioCAM®hr head system comes in an equipment carrier case or in transport packaging.
The basic package contains the following components:
■Thermographic camera VarioCAM®hr head with lens
■Protective lens cover
■External power supply unit (12 V DC) with 14- pin LEMO plug, adapter Lemo 14- pin onto 6- pin
■User manual VarioCAM®hr head
■Brief instructions
■Equipment carrier case / transport packaging
■FireWire (IEEE 1394) PCI card
■FireWire (IEEE 1394) cable, 6- pin or 4- pin
Optional accessories*
■Various lenses, close-up rings
■Lens-protecting apertures, laser-protection filters
■SecureDigital card
■Card adapter for SD card
■Breakout Box, system cable, 14- pin, trigger cable
■LWL interface for FireWire (IEEE 1394)
■Tripod for device
■Thermographic software of the IRBIS®programme family

User Manual for the Thermographic System VarioCAM®hr head
5. Description of Camera Parts
User Manual © InfraTec GmbH 2015 11
5Description of Camera Parts
Fig. 2 Side view
Fig. 3 Front view
SD card slot
Lens
LEMO socket, 6-pole for:
(marked yellow)
■FireWire (IEEE 1394) cable
■Power supply unit with adapter
LEMO socket, 14-pin for:
■Power supply unit without adapter
■FBAS cable
■Breakout Box (via system cable)
■Universal cable (RS 232, FBAS, S video)

User Manual for the Thermographic System VarioCAM®hr head
6. Quick Start
12 © InfraTec GmbH 2015 User Manual
6Quick Start
The following instructions shall help to quickly familiarise with operating the VarioCAM®hr head. For
obtaining professional results, we recommend to carefully read the entire manual.
6.1 Preparation
You require the following equipment:
■VarioCAM®hr head ■SD card reader*
■Power supply unit* with LEMO plug ■SD card*
■IRBIS®software
6.2 Installation Software IRBIS®remote
■To be able to handle the camera, the operating software IRBIS®remote has to be inastalles on the
computer or notebook. The software indicates the measuring scenery taken up by the camera
■The operation of the VarioCAM®hr head occurs via the “Remote control“ of the software IRBIS®
remote. Navigate in the main menu with the buttons , ,, and choose the functions with Enter.
Abb. 4 Die Bedienung der Kamera erfolgt über das Bedienfenster der IRBIS®Software
6.3 Start
■Conect the camera to a PC or Notebook. Remove lens protective cover.
■Connect the external power supply unit to the VarioCAM®hr head (14- pin plug into left socket, with
the red indication showing upwards) to set the electrical power supply. After system initialisation, the
Operating LED, initially flashing green, subsequently turning to permanent green, signals that the
VarioCAM®hr head is ready for operation
■Start the software, connect the camera with the software and open the “”Remote Control” window to
operate the camera in the camera-menu.
■Remove cover from SD card slot, insert SD card into card slot and return cover.
(Product similar to diaplyed)

User Manual for the Thermographic System VarioCAM®hr head
6. Quick Start
User Manual © InfraTec GmbH 2015 13
6.4 Display
Fig. 5 Camera menu in live mode
■At first, select to view a scene rich in contrast (e.g. an active electrical device) and focus the
VarioCAM®hr head onto it.
■Adjust the viewfinder to your eye by using the Remote control of the software. For optimal
adjustment, relate to the sharpness of the lettering.
6.5 Image Optimisation
■Press the button AL. The thermographic system automatically focuses and the temperature scaling of
the false-colour image is automatically optimised according to the current scene.
Fig. 6 Camera menu in live mode Fig. 7 Camera menu in focus mode
■In the live mode, button movements , change the selected temperature level and button
movements , change the selected temperature range.
■Pressing the Enter button switches between the live mode and the focus mode.
■In the focus mode, buttons , focus over larger or shorter distances to the object.
Help line
Information field
Date/time
SD card symbol
Status
Colour scale with
upper and lower limit
of displayed
temperature range
Live mode Focus mode

User Manual for the Thermographic System VarioCAM®hr head
6. Quick Start
14 © InfraTec GmbH 2015 User Manual
6.6 Data Storage
■For Storage of the thermal image press the Sbutton. The live image freezes, i.e. camera goes into
stop mode.
Fig. 8 Camera menu in stop mode
■Pressing the Sbutton again saves the thermal image on the SD card. Pressung the Cbutton
interrupts the saving process. The camera will return to the live mode after the saving process.
When using the button SL, the camera saves a thermogram without changing into the stop mode in between.
6.7 Menu Functions
■VarioCAM®hr head offers a variety of analytical and automatic features. The settings and functions
are selected in the main menu of the software which can be accessed by using the remote control
function..
Fig. 9 Camera menu
■You navigate in the main menu by moving the buttons , , , and select the functions by
pressing Enter.
6.8 Switching OFF
■The camera is switched off as soon as the electricity supply is interrupted to the camera.
Stop mode

User Manual for the Thermographic System VarioCAM®hr head
6. Quick Start
User Manual © InfraTec GmbH 2015 15
6.9 Data Transfer to the Computer
■For data transfer via the FireWire (IEEE 1394) interface with the help of IRBIS® remote/online, this
software (which comes included if rewquested for) should at first be installed following the description
in the respective manual.
■Another method of the data transfer is the readout of the SD-card with a cardreader.
6.10 Evaluation with Analysing Software IRBIS®
■Install the analysing software IRBIS® on the computer and start it.
■From menu "File", select submenu "Open..." and open the desired thermograms (*.irb files).
■From menu "Thermogram", submenu "Palette", select the desired colour palette.
■Via menu "View", you can display further image elements, measurement data, annotations and
parameters in addition to the thermogram.
■By pressing the right mouse key on the colour scale, the dialogue "Level/Range", where the
temperature level and range can be adjusted as desired by moving the scroll bar. The adjustment is
also adopted for subsequent thermal images.
■With the help of the respective functional buttons on the symbol bar, points of measurement, areas,
etc. as well as the display of temperature maximum and minimum can be activated.
■For inserting the analysed thermal images into your reports, select the function "Copy to clipboard" in
the "Edit" menu. You can also use the report generator.
Fig. 10 IRBIS®Software

User Manual for the Thermographic System VarioCAM®hr head
7. Starting up
16 © InfraTec GmbH 2015 User Manual
7Starting up
7.1 Using a Tripod*
For this purpose, the thermographic camera has a 1/4" tripod threat (DIN 4503) at the bottom. The
installation of the VarioCAM®hr head on a tripod (optional accessory) is recommended for blur-free
camera exposures, especially when using the Resolution Enhancement mode.
Please note the maximum screw-in depth of the photo thread of 4.5 mm (DIN 4503).
7.2 Connecting the Power Supply
The external power supply unit* is connected to the 14- pin socket situated on the left rear of the
thermographic system.
7.3 Inserting a Memory Card
The SD card slot is located on the left of the camera. It is protected by a cover to guarantee its IP 65
protection class. In order to insert the memory card, remove the cover and put the card into the slot.
Please ensure the correct orientation of the card (▲to the top). Then cover the slot again. This is
compulsory to maintain the full protection class of the device.
7.4 Lens Replacement
Only perform replacement of lenses in dry and as dust-free as possible environment. With the lens
removed, the system's IP 65 protection class is not guaranteed!
Place the VarioCAM®hr head on a solid, plane base with the lens facing to you. Turn the lens-fastening
ring clockwise until it stops (approx. 145°) and remove the lens to the front.
For fixing the lens, the red markings on the lens, on the lens-fastening ring and on the camera must be
aligned. The lettering on the lens will then face up. In this position, the lens is gently pushed against the
corpus of the camera; the lens-fastening ring is unlocked and automatically turns to the right. Finally, the
lens-fastening ring is fully locked by gently pushing it to the right.
