INNLED TA39 User manual

User Manual // PAK - ref. TA39/39W V01.a

INNLED - 360 avenue des Compagnons, 34070 Castelnau-le-Lez, FRANCE
Tel: [phone] // Fax: [phone] // mail : [email protected] 2 / 10
Thankyou for purchasing an INNLED product.
« Commited to supporting the french industry, this product
was developed and assembled within our Montpellier
workshop. We attach particular importance to our clients’
feedback so feel free to contact us in case of any comment
or suggestion.
So we can continue ’’ lighting up your ideas ’’ in the most
efficient way... »
The Innled team
Terms of use and Warranty terms, read page 10.

3 / 10
INNLED - 360, Avenue des Compagnons, 34170 Castelnau-le-Lez - FRANCE
Tel : [phone] // Fax : [phone] // mail : [email protected]
COMPOSITION AND DIMENSIONS
INSTALLATION AND ASSEMBLY TYPES
• Magnets and Velcro®straps
• Microphone 3’8’’ insert
• Counter plate
OPTIONS AND ACCESSORIES
• Wireless driving
• Use
• Power
• Packaging
DMX OPTION AND SETTINGS
• DMX addressing
TECHNICAL SPECIFICITIES
WARRANTY TERMS
p 4
p 5
2.
p 6
3.
p 7
4.
p 9
5.
p 10
6.
1.
Contents
INNLED products are designed to light up your greatest moments, however organised
or totally improvised they are ! Whether you are indoors or outdoors, whether you have
access to power or not, we will continue lighting up your ideas at all times.

Stop screw
Cable clamp
Micro 3’8’’ insert
OR Kensington security
lock
Neodymium magnet
Power
Switch
3W Nanopa spots
x3
The DMX option determines which switch you will find on your PAK. The standard
version is equipped with a 3 position switch, the DMX version is equipped a 2 position
switch.
Standard DMX option
INNLED - 360 avenue des Compagnons, 34070 Castelnau-le-Lez, FRANCE
Tel: [phone] // Fax: [phone] // mail : [email protected] 4 / 10
The PAK is a compact product equipped
with three powerful spotlights.
Its many accessories provide a great
flexibility of use.
COMPOSITION AND DIMENSIONS
1.
Composition
35mm
35 mm
52 mm
270 mm

*These accessories are included in the « suspension kit » option and is composed of : 2 Velcro® straps,
2 mounting plates and a steel counter plate.
INNLED - 360 avenue des Compagnons, 34070 Castelnau-le-Lez, FRANCE
Tel: [phone] // Fax: [phone] // mail : [email protected] 5 / 10
This allows the PAK to cling
to all structures and standard
ceilings, thanks to the velcro
magnetized straps.
The magnets are included in the
standard version.
Magnets and
Velcro straps
(option *)
(option *)
(Black PAK : standard
White PAK : option)
Microphone 3’8’’
insert
Counter - plate
Allows the PAK to be mounted
on a microphone stand.
Allows the PAK to be fixed to a
parasol, tarp, canvas or liner.
INSTALLATION AND ASSEMBLY TYPES
2.
Thanks to its accessories, PAK offers a number of features and can be integrated to any
type of structure or medium.
Steel structure
Other type of
structure
Steel counter
plate

INNLED - 360 avenue des Compagnons, 34070 Castelnau-le-Lez, FRANCE
Tel: [phone] // Fax: [phone] // mail : [email protected] 6 / 10
OPTIONS AND ACCESSORIES
3.
The suspension kit is composed of :
• 2 Velcro® straps
• 2 mounting plates
• 1 steel counter plate.
• type “Kensington”
• with code
• 1/4 turn locking
• length :1,80m
BEWARE : THE WHITE PAK IS
EQUIPPED WITH KENSINGTON LOCK
(STANDARD VERSION)
Integrated option (to be mounted upon
order)
• Frequency 2,4GHz
• Automatic scan on 21 frequencies
• 3 DMX channels (dimmer, strobe,
white)
• 1 Output on 60cm cable with Power
Jack 2mm connector
• Power supply : 90-240V AC
• Charge voltage : 12,6V
• Light indicator : “on charge” (red),
“charging” (orange) and “charged”
(green)
• Charging time : 7-8H
• Dimensions :L 80 mm x l 30mm x
H 60mm
1. WIRELESS DMX TRANSMITTER + WIFI - TA51W2
5. SUSPENSION KIT 6. SECURITY CABLE
7. 12V DC POWER SUPPLY
3. APPLICATION LAPPS 4. DMX RECEIVER
2. WIRELESS DMX TRANSMITTER - TA51
Wireless
Use
Power
• 2,4GHz
• no wifi
• XLR3 in/out
• 512 channels
• Diversity 21 frequencies
• Power supply on USB connector
(transformer and cable provided).
• Distance : 100m maximum between
transmitter and receivers
• Delivered with antenna, USB cable
and external power supply
• 2,4 GHz
• wifi
• XLR5 in/out
• 512 channels
• Diversity 21 frequencies
• Power supply on USB connector
(transformer and cable provided).
• Distance : 100m maximum between
transmitter and receivers
• Delivered with antenna, USB cable
and external power supply
Control from a distance, one or several
lamps of the INNLED range.
• Simple and intuitive use handling
• 2 Modes : Basic or Expert
• Range of colours to chose from
• Light intensity setting
• 6 effects to chose from within the
Expert Mode
• Requires a wifi / wireless DMX
interface

When the DMX PAK is switched on but doesn’t detect any transmitter, it switches on to
100%.
Furthemore, if the DMX signal disappears, the PAK keeps the last luminous state in memory
INNLED - 360 avenue des Compagnons, 34070 Castelnau-le-Lez, FRANCE
Tel: [phone] // Fax: [phone] // mail : [email protected] 7 / 10
The PAK exists in a wireless DMX version, but it is an option which is mounted ONLY upon order.
In the case of the DMX version, the switch has 2 positions :
DMX OPTION AND SETTINGS
4.
8. CARRYING CASE x5
Packaging
Carrying case
• machined foam
• for 5 PAK et 5 chargers.

INNLED - 360 avenue des Compagnons, 34070 Castelnau-le-Lez, FRANCE
Tel: [phone] // Fax: [phone] // mail : [email protected] 8 / 10
DMX addressing
The TA51/TA51W2 transmitters set the parameters of the PAK’s DMX addresses.
The addressing of the PAKs can only be done with the TA51/TA51W2 transmitters through the
ASSIGN menu.
The transmitters have 512 DMX channels which allow you to drive 170 PAKs with the same
transmitter.
The transmitter has 31 DMX universes, and 21 frequencies.
For instructions concerning the TA51 an T151W2, please read the TA51/TA51W2 user manuals.

INNLED - 360 avenue des Compagnons, 34070 Castelnau-le-Lez, FRANCE
Tel: [phone] // Fax: [phone] // mail : [email protected] 9 / 10
TECHNICAL SPECIFICITIES
5.
MATERIALS
• Housing : PVC 3mm
• Spotlight : Anodized black aluminium
• Black finish
LED SPOT POWER
• 6W (3x2W)
TECHNOLOGY
• LED Cree 3W 500mA
LIGHTING SOURCE
• 500 lumens
EXTERNAL CHARGER
• 90-230V - 12,6V DC
• Connector Power jack 2mm
• Charging time : 3-4h
BATTERY Li-ON
• 2800mA/H
AUTONOMY
• 5h at 100% et 12h at 50%
TEMPERATURE RANGE
• 0°C a +40°C
INTEGRATED FIXING SYSTEMS
• 2 powerful magnets (16Kg)
• Screw terminal 3/8” (microphone)
WARRANTY
• 2 ans
CHARGE VOLTAGE
• 12,6V DC
CLASS
• III
IP CLASS
• IP20
• IK07
NORMS
• CE, EN60598-1
DIMENSIONS
• L 270 (without antenna) x l 36 x D
36mm
WEIGHT
• 450g
ORDER OPTIONS
COLOUR TEMPERATURE
• Standard : 3000K (neutral white)
• Upon order : 4000K (warm white)
OPTICAL LENSES
• Standard : 26°
• Upon order : 6° / 16° / 46° /
asymmetrical 38°x21°
DMX HF
Upon order :
• Integrated receiver
• Setting address by transmitter
• Fréquency 2,4GHz
• 3 DMX channels : Dimmer, strobe,
white

INNLED - 360 avenue des Compagnons, 34070 Castelnau-le-Lez, FRANCE
Tel: [phone] // Fax: [phone] // mail : [email protected] 10 / 10
Please refer to INNLED’s general warranty terms
Furthermore, INNLED products are designed for professional use only, they are not to be used
in a domestic environment.
Committed to an approach based on quality, INNLED reserves the right to adapt or modify
the technical characteristics of its products at any given moment and without any given notice,
the adaptations or modifications then apply to all the orders placed after the date upon which
those adaptations or modifications were made.
Warranty Terms
