Inotech IT-5500 Series User manual

IT-5500seriesHigh-power 1550nm
FiberAmplifierManual
（With PON Port）

-
- 2 2 - -
Table of Contents
Table of Contents.......................................................................................................- 1 -
Foreword....................................................................................................................- 2 -
1.Application............................................................................................................ - 3 -
2. Performance Characteristics..................................................................................- 3 -
3. Block diagram....................................................................................................... - 3 -
4. Technique Parameter............................................................................................. - 4 -
4.1 Technique Parameter.................................................................................... - 4 -
4.2 Model and Power Comparison Table........................................................... - 5 -
5. External Function Description...............................................................................- 6 -
5.1 Front Panel Description................................................................................- 6 -
5.2 Rear Panel Description.................................................................................- 7 -
5.2.1 DC Power Module Introduction.........................................................- 7 -
Foreword
This manual applies to WE-1550-YZBCW series fiber amplifier. It mainly
describes the performance characteristics, technical parameters, installation and
debugging, common troubleshooting, and other related content of the product. In
order to ensure that the equipment can be successfully installed and safely operated,
please read this manual carefully before installing and debugging the equipment. And
the installation and debugging should be strictly according to the specified steps on
the manual to avoid unnecessary damage to equipment or accident harm to the operator.
Any questions, please contact with us in time.
Special Tips:
■Er Yb Codoped Fiber Amplifier is high end professional equipment, and its
installation and debugging must be operated by special technician. Read this
manual carefully before operating to avoid damage to equipment caused by fault
operation or accident harm to the operator.
■While the fiber amplifier is working, there is an invisible laser beam from the
optical output adapter on the front panel. Avoiding permanent harm to the body
and eye, the optical output should not aim at the human body and human should
not look directly at the optical output with the naked eye!
■Please make sure that the ground terminal of the case and power outlet has been
reliably grounding before turning on the power (Grounding resistance should be

-
- 3 3 - -
＜4Ω) to prevent the static damage the pump laser device and harm to human
because of case charged.
■To ensure the equipment can work stable over a long time, in voltage unsteady or
poor voltage wave region, it´s recommend to the customer that he equips special
AC regulated power supply, or even AC uninterrupted power supply (UPS) system
for conditional users. In the region with large temperature variation environment
(The equipment's ideal work environment temperature is 25°C) or bad room
environment, it´s recommend to the customer that he equips special air-condition
system to improve the work environment.
1. Application
 Single-mode fiber 1550 amplification network
 FTTH network
 CATVnetwork
2. PerformanceCharacteristics
WE-1550-YZBCW is a low noise high-performance Er Yb codoped fiber
amplifier. Each output built-in CWDM (1310/1490/1550) wavelength division
multiplexer. Conveniently multiplex the data stream of OLT and ONU to the fiber
amplifier output by 1310nm and 1490nm optical connector. Thus reduced the
equipment quantity, improved the system indexes and reliability. It is the ideal
equipment for FTTx network, provides a flexible and low cost solution for the
integration of three networks and the FTTH.
 Adopts Er Yb Codoped double-clad fiber technology;
 Output ports: 4-64optional;
 Optical output power: total output up to 8W;
 Low noise figure: <6dB when input is 0dBm;
 Perfect network management interface, in line with standard SNMP
network management;
 Intelligent temperature control system make the power consumption lower;

-
- 4 4 - -
3. Blockdiagram
B uilt-in WDM schematic diagram
4. TechniqueParameter
4.1 Technique Parameter
Item
Unit
Techniqueparameters
CATVpass through wavelength
nm
1545 - 1565
PON pass through wavelength
nm
1260 – 1360 & 1480 - 1500
PON insertion loss
dB
<0.8
Isolation
db
>15
CATVoptical input power range
dBm
-5 - +10
Maximum optical output power
dBm
38.5
Output power stability
dBm
±0.5
Noise figure dB
≤6.0 (Optical input power 0dBm,
λ=1550nm)
Return loss
Input
dB
≥45
Output
dB
≥45

-
- 5 5 - -
Optical Connector Type
PON port
：
SC/UPC or LC/UPC
COM port
：
SC/APC or LC/APC
C/N
dB
≥50
Test condition
according to
GT/T 184-2002.
C/CTB
dB
≥63
C/CSO
dB
≥63
Power supply voltage
V
A: AC160V - 250V(50 Hz); B: DC48V
Consumption
W
≤70
Operating temperature range
°C
-10 - +42
Maximum operating relative
humidity
% Max 95% no condensation
Storage temperature range
°C
-30 - +70
Maximum storage relative
humidity
% Max 95% no condensation
Dimension
mm
483(L)
×
440(W)
×
88(H)
4.2 Model and Power Comparison Table
Model
Total output
power dBm
Output ports
number
Output power per
port dBm
WE-1550-YZBCW-4 -18
25.5
4
18
WE-1550-YZBCW-4 -19
26.5
4
19
WE-1550-YZBCW-4 -20
27.5
4
20
WE-1550-YZBCW-4 -21 28.5 4 21
WE-1550-YZBCW-4 -22 29.5 4 22
WE-1550-YZBCW-4 -23
30.5
4
23
WE-1550-YZBCW-4 -24 31.5 4 24
WE-1550-YZBCW-8 -15
26.5
8
15
WE-1550-YZBCW-8 -16 27.5 8 16
WE-1550-YZBCW-8 -17
28.5
8
17
WE-1550-YZBCW-8 -18
29.5
8
18
WE-1550-YZBCW-8 -19 30.5 8 19
WE-1550-YZBCW-8 -20
31.5
8
20
WE-1550-YZBCW-8 -21 32.5 8 21
WE-1550-YZBCW-8 -22
33.5
8
22
WE-1550-YZBCW-8 -23
34.5
8
23
* WE-1550-YZBCW-8 -24
35.5
8
24
WE-1550-YZBCW-16 -15
29.5
16
15
WE-1550-YZBCW-16 -16
30.5
16
16
WE-1550-YZBCW-16 -17 31.5 16 17
WE-1550-YZBCW-16 -18
32.5
16
18
WE-1550-YZBCW-16 -19 33.5 16 19
WE-1550-YZBCW-16 -20
34.5
16
20
* WE-1550-YZBCW-16 -21 35.5 16 21
WE-1550-YZBCW-32 -15
32.5
32
15

-
- 6 6 - -
WE-1550-YZBCW-32 -16
33.5
32
16
WE-1550-YZBCW-32 -17
34.5
32
17
* WE-1550-YZBCW-32 -18 35.5 32 18
* WE-1550-YZBCW-32 -19
36.5
32
19
* WE-1550-YZBCW-32 -20
37.5
32
20
* WE-1550-YZBCW-32 -21
38.5
32
21
* WE-1550-YZBCW-64 -16
36.5
64
16
* WE-1550-YZBCW-64 -17 37.5 64 17
* WE-1550-YZBCW-64 -18
38.5
64
18
The models with “*” are ultra high power output EDFA.
5. ExternalFunction Description
5.1 Front Panel Description
Schematic diagram of the front panel
1) Power indicator: One switching power supply is working – yellow; two switching
power supplies are working – green.
2) Optical input power indicator：This light turns on when the optical input power
is > -10dBm.
3) Pump working status indicator: Red light means the pump is not working, but the
machine parameters are normal; flashing red light means the machine has broken
down, related fault reason see the alarm menu of the display menu; green light
means the pump is working normal.
4) Optical output power indicator: This light turns on when the optical output power is
> +10dBm.
5) 160×32 dot-matrix LCD screen: used to display all the parameters of the
machine.
6) Display the exit or cancel key of the setup menu.
7) Display the up or increase key of the setup menu.
8) Display the down or decrease key of the setup menu.
9) Display the enter key of the setup menu.
10) 1310&1490nm signal in/out (PON port).
11) Optical signal input: The default connector type is SC/APC. Other specification
requirements are specified by the customer.
12) Pump laser switching key: used to control the working status of pump laser.

-
- 7 7 - -
“ON” means the pump laser is open and “OFF” means the pump laser is closed.
Ensure the key is on “OFF” position before power on. After passing self-test,
rotate the key to “ON” position according to the displayed message.
13) Public port (COM port): This interface is the 1550nm signal output port of the
device, also is the 1310&1490nm signal in/out port. Ports number: 4-64 optional.
Warning!!! There is an invisible laser beam from this port while working
normal. So the port should not be aligned to the human body or the naked eye to
avoid accidental injury.
5.2 Rear Panel Description
1) Fan outlet.
Schematic diagram of the rear panel
2) RS232 interface: Used for configuring the network management parameters.
3) LAN interface: correspond to IEEE802.3 10Base-T, used for network management.
4) The AC 220V input port of power supply 1.
5) The fuse of power supply 1.
6) The switch of power supply 1.
7) The AC 220V input port of power supply 2.
8) The fuse of power supply 2.
9) The switch of power supply 2.
10) Ground stud of the chassis: used for the connection of device and ground wire.
5.2.1 DC Power Module Introduction
1
Mountingscrews
2
+ Positive terminal block
3
- Negative terminal block
