Insignia NS-P2000 User manual

User Guide | Guide de l’utilisateur | Guía del Usuario
Amplifier and Subwoofer | Amplificateur et caisson d'extrêmes
graves | Amplificador y Subwoofer
NS-P2000

www.insignia-products.com 3
Welcome
Congratulations on your purchase of a high-quality Insignia product.
Your NS-P2000 represents the state of the art in car power amplifier
and 12-inch sub-woofer design, and is designed for reliable and
trouble-free performance.
Cutout for speaker =
11.02 inches in diameter

4www.insignia-products.com
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Setting up your amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using your amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1 Year Limited warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Español. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Safety information
Warning Exercise extreme caution when you operate the amplifier near an
open gasoline tank or electrical wires. Failure to comply with this
warning could result in injury or death.
Caution Speaker damage can result from high volume levels.
Protect connecting wires and parts to avoid damage or short
circuits.
To protect the amplifier unit, make sure the power connection from
the positive (+) battery terminal to the amplifier is correctly fused.
The sound system must be turned off before checking the amplifier.
When you replace an amplifier fuse, make sure you use the same
fuse type and capacity (30A).

5
www.insignia-products.com
Setting up your amplifier
Wiring diagrams
2-CHANNEL STEREO CONFIGURATION
Connect to remote turn-on
lead of source unit.
Connect to
chassis ground
of vehicle Speaker impedence 4 to 8 Ohm

6www.insignia-products.com
BRIDGED-MODE CONFIGURATION
Connect to remote turn-on
lead of source unit.
Speaker impedence 4 to 8 Ohm
Connect to
chassis ground
of vehicle

7
www.insignia-products.com
Using your amplifier
Functions and controls
Item Name Function or Control
AHIGH-
INPUT Left and right high level inputs to the amplifier.
Connect high level inputs here.
BLOW-
INPUT Left and right channel inputs to the amplifier
system. Connect preamplifier outputs from a
source (such as a head unit, CD player, or DAT) or
from an external electronic crossover here.
CGAIN Set for volume range adjustment.
DHPF Set for High Pass Filter frequency (45 Hz to
300 Hz).
EBASS
BOOST Set for amount of bass boost required (0dB, +6dB,
or +12dB).
F Indicator
LED Green LED lit—Amplifier is on and functioning
correctly.
Red LED lit—Amplifier is in self-protect mode.
GX-OVER Switch for setting high pass filter (HPF), full pass
filter (FULL), or Low Pass Filter (LPF).
HLPF Set for Low Pass Filter frequency (45 Hz to
300 Hz).
B
ACD E
FGH

8www.insignia-products.com
Electrical connections
Specifications
Amplifier
RMS power @13.8VDC
Power @ 4 Ohms............................... 200W × 2
Power @ 2 Ohms............................... 300W × 2
Bridged power @ 4 Ohms ................. 500W × 1
Minimum speaker impedance.............. 2 Ohms
THD distortion ....................................... 0.08%
IMD distortion........................................ 0.08%
Frequency response............................. 20 Hz to 20 KHz
Input sensitivity..................................... 200mV to 6V
Input impedance ................................... 15K Ohms
Signal-to-noise ratio ............................. 90dB
Item Name Function or Control
APOWER/
BATTERY •+12 Volts - Connect to positive (+) battery
terminal.
•REM - Connect to the Remote cable from the
signal source to control amplifier switching.
Applied voltage must be between 7 and
15VDC.
•GND - Connect to good ground, such as the
car frame or grounded metal body. Keep
ground cable length as short as possible.
BFUSE Amplifier protection fuse. Replace with the same
type and capacity.
C SPEAKER/
BRIDGED Connect the speakers to these terminals.
ABC

9
www.insignia-products.com
Channel separation............................... 50dB
Crossover network
Low pass filter.................................... 45 Hz to 300 Hz
Bass boost ......................................... 0dB to +12dB
High pass filter ................................... 45 Hz to 300 Hz
Fuse rating............................................. 30A × 2
Size L × W × H ....................................... 18.43 × 10.16 × 2.56 inches
(468 × 258 × 65 mm)
Sub-woofer
Woofer size ................................................12 inch diameter
Woofer material .........................................Plating injection-molded
cone with polypropylene
material
Magnet size................................................82 oz.
Continuous power handling.....................200 W
Peak power handling ................................400 W
Impedance .................................................8 Ohms
Sensitivity ..................................................88.7dB
Voice coil....................................................2-inch Black anodized
aluminum ESV wire
Free air resonance frequency Fs.............36 Hz
Frequency response.................................36 Hz-2 KHz
Total Q factor (Qts)....................................0.53
Connection type........................................Screw terminals
Number of voice coils...............................One
Frame material ..........................................Stamped steel
Surround material .....................................Rubber
Dimensions:
Mounting depth ......................................6.02 inches (153 mm)
Total depth .............................................6.69 inches (170 mm)
Overall diameter.....................................12.4 inches (315 mm)
Mounting hole diameter (cutout) ............11.02 inches (280 mm)
Weight ........................................................12.10 lb. (5.5 kg)
Recommended enclosure size ................48.6 L
Other features:
• Insulated 24-gauge tinsel leads
• Linear spider improves mechanical stability under high
excursion and eliminates the need for a subwoofer break-in
period.

10 www.insignia-products.com
Troubleshooting
Before removing your amplifier, locate the problem in the following
table. Always test the speakers and speaker wires before
troubleshooting the amplifier.
Symptom Solution
The amplifier
will not turn on. • Make sure that the amplifier has a good ground connection.
• Make sure that the power at the remote
DC terminal is at least 7VDC.
• Make sure that there is battery power at
the positive (+) terminal.
• Make sure that all fuses are good.
• Make sure that the indicator LED is not
red. If the indicator LED is red, turn off
the amplifier briefly, then turn it back on.
A high hiss or
engine noise
(alternator
whine) is
audible in the
speakers.
Disconnect all RCA inputs to the amplifier. If
the hiss or noise goes away, plug in the
component driving the amplifier and unplug its
inputs. If the noise goes away, start plugging
in the inputs until the noisy component is
found.
We recommend that you set the amplifier
input sensitivity as low as possible. This will
result in the best possible S/N ratio. Also, try
to drive as high a signal level as possible from
the head unit.
The indicator
LED turns red
when the
amplifier is
turned on.
• Make sure that there are no shorts on
the speaker leads.
• Make sure that the volume control on the
head unit is turn down low.
• Remove the speaker leads and reset the
amplifier. If the indicator LED is still red,
the amplifier is faulty.
Note: To protect the amplifier from damage, it
will shut down automatically when its
temperature reaches 176°F (80°C).
The amplifier
gets very hot. • Make sure that the minimum speaker impedance is correct.
• Make sure that there are no speaker
shorts.
• Make sure that there is good airflow
around the amplifier. In some situations,
a fan may be required for proper cooling
of the unit.

11
www.insignia-products.com
The sound is
distorted. • Make sure that the level control(s) is set to match the signal level of the head unit.
• Make sure that the crossover
frequencies have been correctly set.
• Make sure that there are no shorts on
the speaker leads.
There is a high
squeal noise
coming from
the speakers.
Make sure that the RCA patch cords are
correctly grounded.
Sub-woofers
are not
working.
Always test the speakers and speaker wires.
Make sure the speakers are connected with
the correct polarity (positive (+) amplifier
output to positive (+) speaker terminal,
negative (-) amplifier output to negative (-)
speaker terminal).
Symptom Solution

12 www.insignia-products.com
1 Year Limited warranty
Insignia Products (“Insignia”) warrants to you, the original purchaser
of this new NS-P2000 (“Product”), that the Product shall be free of
defects in the original manufacture of the material or workmanship for
a period of one (1) year from the date of your purchase of the Product
(“Warranty Period”). This Product must be purchased from an
authorized dealer of Insignia brand products and packaged with this
warranty statement. This warranty does not cover refurbished
Product. If you notify Insignia during the Warranty Period of a defect
covered by this warranty that requires service, terms of this warranty
apply.
HOW LONG DOES THE COVERAGE LAST?
The Warranty Period lasts for 1 year (365 days) from the date you
purchased the Product. The purchase date is printed on the receipt
you received with the Product.
WHAT DOES THIS WARRANTY COVER?
During the Warranty Period, if the original manufacture of the material
or workmanship of the Product is determined to be defective by an
authorized Insignia repair center or store personnel, Insignia will (at
its sole option): (1) repair the Product with new or rebuilt parts; or (2)
replace the Product at no charge with new or rebuilt comparable
products or parts. Products and parts replaced under this warranty
become the property of Insignia and are not returned to you. If
service of Products or parts are required after the Warranty Period
expires, you must pay all labor and parts charges. This warranty lasts
as long as you own your Insignia Product during the Warranty Period.
Warranty coverage terminates if you sell or otherwise transfer the
Product.
HOW TO OBTAIN WARRANTY SERVICE?
If you purchased the Product at a retail store location, take your
original receipt and the Product to the store you purchased it from.
Make sure that you place the Product in its original packaging or
packaging that provides the same amount of protection as the original
packaging. If you purchased the Product from an online web site, mail
your original receipt and the Product to the address listed on the web
site. Make sure that you put the Product in its original packaging or
packaging that provides the same amount of protection as the original
packaging.To obtain in-home warranty service for a television with a
screen 25-inch or larger, call 1-888-BESTBUY. Call agents will
diagnose and correct the issue over the phone or will have an
Insignia-approved repair person dispatched to your home.

13
www.insignia-products.com
WHERE IS THE WARRANTY VALID?
This warranty is valid only to the original purchaser of the product in
the United States and Canada.
WHAT DOES THE WARRANTY NOT COVER?
This warranty does not cover:
• Customer instruction
•Installation
• Set up adjustments
• Cosmetic damage
• Damage due to acts of God, such as lightning strikes
• Accident
•Misuse
•Abuse
• Negligence
• Commercial use
• Modification of any part of the Product, including the antenna
• Plasma display panel damaged by static (non-moving) images
applied for lengthy periods (burn-in).
This warranty also does not cover:
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage supply
• Attempted repair by anyone other than a facility authorized by
Insignia to service the Product
• Products sold as is or with all faults
• Consumables, such as fuses or batteries
• Products where the factory applied serial number has been
altered or removed
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY
IS YOUR EXCLUSIVE REMEDY. INSIGNIA SHALL NOT BE LIABLE
FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR
THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON
THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA,
LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST
PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER EXPRESS
WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS
AND IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING,
BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF AND
CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A

14 www.insignia-products.com
PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE
WARRANTY PERIOD SET FORTH ABOVE AND NO WARRANTIES,
WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE
WARRANTY PERIOD. SOME STATES, PROVINCES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG
AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION
MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO
PROVINCE.
Contact Insignia:
For customer service please call 1-877-467-4289
www.insignia-products.com
INSIGNIA™ is a trademark of Best Buy Enterprise Services, Inc.
Distributed by Best Buy Purchasing, LLC.
Insignia, 7601 Penn Avenue South, Richfield, Minnesota, U.S.A.
Copyright
© 2007 Insignia. Insignia and the Insignia logo are trademarks of Best Buy Enterprise
Services, Inc. Other brands and product names are trademarks or registered
trademarks of their respective holders. Specifications and features are subject to
change without notice or obligation.
For service and support call [phone].

15
www.insignia-products.com
Bienvenue
Félicitations d’avoir acheté ce produit Insignia de haute qualité. Le
modèle NS-P2000 représente la dernière avancée technologique
dans la conception d’amplificateurs stéréo de voiture et a été conçu
pour des performances et une fiabilité exceptionnelles.
Découpe pour le haut-parleur =
11,02 po (27,99 cm) de diamètre

16 www.insignia-products.com
Table des matières
Bienvenue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Informations sur la sécurité. . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Installation de l’amplificateur. . . . . . . . . . . . . . . . . . . . . . . . . . 17
Utilisation de l’amplificateur . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Spécifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Problèmes et solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Garantie limitée d’un an . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Informations sur la sécurité
Attention Faire preuve d’extrême prudence quand l’amplificateur est utilisé
près d’un réservoir d’essence ouvert ou de fils électriques. Le
non-respect de ces instructions peut provoquer des blessures
graves, voire mortelles.
Attention Les haut-parleurs peuvent être endommagés par des niveaux de
volume élevés.
Protéger les fils de connexion et les pièces pour éviter des
dommages ou des courts-circuits.
Pour protéger l’amplificateur, s’assurer que la connexion de
l’alimentation de la borne positive (+) de la batterie à l’amplificateur
est dotée d’un fusible approprié.
Le système sonore doit être mis hors tension avant de vérifier
l’amplificateur.
Lors du remplacement du fusible de l’amplificateur, prendre soin
d’utiliser un fusible de même type et puissance (30 A).

17
www.insignia-products.com
Installation de l’amplificateur
Schémas de câblage
CONFIGURATION À2 CANAUX (STÉRÉO)
Connecter au câble de
mise en marche à distance
de la source.
Connecter
à la masse
du châssis
du véhicule Impédance des haut-parleurs 4
à 8 ohms

18 www.insignia-products.com
CONFIGURATION EN MODE PONTÉ
Connecter au câble de
mise en marche à distance
de la source.
Connecter
à la masse
du châssis
du véhicule Impédance des haut-parleurs 4
à 8 ohms

19
www.insignia-products.com
Utilisation de l’amplificateur
Fonctions et commandes
Élément Nom Fonction ou commande
AHAUTE
IMPÉDANCE Entrées de haute impédance gauches et droites à
l’amplificateur. Connexion des entrées de haute
impédance.
BBASSE
IMPÉDANCE Entrées des canaux gauches et droits à
l’amplificateur. Pour connecter les sorties du
préamplificateur à partir d’une source (telle qu’une
radio, un lecteur de CD ou un lecteur de cassettes)
ou d’un filtre électronique passif externe.
CGAIN Réglage de la gamme de volume.
DHPF Pour le réglage de la fréquence du filtrage
passe-haut (45 Hz à 300 Hz).
E AMPLIFICAT
ION DES
GRAVES
Réglage de l’amplification des graves souhaitée (0
dB, + 6 dB, ou + 12 dB).
F Témoin DEL DEL verte allumée – l’amplificateur est sous
tension et fonctionne normalement.
DEL rouge allumée – l’amplificateur est en mode
d'autoprotection.
GX-OVER
Commutateur de sélection du filtre passe-haut
(PH), du filtre passe-bande (PB) ou du filtre
passe-bas (PB).
B
ACD E
FGH

20 www.insignia-products.com
Connexions électriques
HLPF Réglage de la fréquence du filtre passe-bas (45 Hz
à 300 Hz).
Élément Nom Fonction ou commande
APOWER
(Alimentation
)/BATTERY
(Batterie)
•+ 12 V - Connexion à la borne positive (+) de
la batterie.
•REM – Connexion au câble distant du signal
source au câble distant de commande de
commutation de l’amplificateur. La tension
appliquée doit être comprise entre 7 et 15 V
CC.
•GND – Connexion à la masse, telle que le
châssis de la voiture ou une partie métallique
du châssis. La longueur du câble de masse
doit être la plus courte possible.
B FUSE
(Fusible) Fusible de protection de l’amplificateur. Le
remplacer par un fusible de même type et de même
puissance.
C SPEAKER
(Haut-parleur
)/BRIDGED
(Ponté)
Bornes de connexion des haut-parleurs.
Élément Nom Fonction ou commande
ABC
