Instant Shade Umbrella Aurora Assembly Instructions

UMBRELLA INSTALLATION HARDWARE GUIDE v2 2021
Instant Shade Pty Ltd
90-98 Woodlands Drive, Braeside VIC 3195
Telephone: [phone] Email: [e-mail]
Bolt/Screw
Used for:
Umbrella Model / Screw Size / Notes
CONCRETE SCREWS
▪Concrete
▪Pavers/Tiles laid on
concrete
SPECTRA umbrella rotating spigot base:
▪M8 countersunk
AURORA/ECLIPSE umbrella base plate:
▪M10 countersunk or nut head
NOVA HD umbrella base plate:
▪Concrete screws can be used but
threaded rod & chem-set (see
below) is the preferred option,
particularly for very large sizes or
very windy/exposed areas
▪M10 countersunk or nut head
NOTE:
▪Various sizes available
▪The longer the better (depending
on depth of concrete, but
minimum screw length should be
at least 75mm).
▪If going through tiles/pavers, at
least 70mm of screw must be in
the concrete slab below
http://www.powers-
guide.com/Products/Mechanical/Blue-
Tip-2-Screw-Bolts/Countersunk

UMBRELLA INSTALLATION HARDWARE GUIDE v2 2021
Instant Shade Pty Ltd
90-98 Woodlands Drive, Braeside VIC 3195
Telephone: [phone] Email: [e-mail]
Bolt/Screw
Used for:
Umbrella Model / Screw Size / Notes
DYNA-BOLTS
▪Brick and concrete
walls
▪Concrete
floors/patios
▪Pavers/Tiles laid on
concrete
SPECTRA umbrella rotating spigot base:
▪M10 countersunk
PARAFLEX wall mounting bracket:
▪M8 countersunk
AURORA/ECLIPSE umbrella base plate:
▪M12 countersunk or nut head
NOTE:
▪Minimum screw length 75mm (at
least 70mm must be in concrete)

UMBRELLA INSTALLATION HARDWARE GUIDE v2 2021
Instant Shade Pty Ltd
90-98 Woodlands Drive, Braeside VIC 3195
Telephone: [phone] Email: [e-mail]
Bolt/Screw
Used for:
Umbrella Model / Screw Size / Notes
THREADED ROD &
CHEMICAL ANCHOR
▪Brick and concrete
walls, especially
where there are
hollow cavities
▪Concrete
floors/patios
▪Pavers/Tiles laid on
concrete
AURORA/ECLIPSE umbrella base plate:
▪M12 threaded rod with dome nut
NOVA HD umbrella base plate:
▪M12 threaded rod with dome nut
PARAFLEX wall mounting bracket:
▪M8 threaded rod with dome nut
NOTE:
▪Length determined by thickness
of concrete/brick
▪Use washers as well as nut
COACH SCREWS
▪Timber studs (for
wall mounting)
PARAFLEX wall mounting bracket:
▪M8 countersunk or nut head
NOTE:
▪OK to use for Paraflex wall
mounted umbrella
▪Not recommended for decking,
better to use nut & bolt as per
below

UMBRELLA INSTALLATION HARDWARE GUIDE v2 2021
Instant Shade Pty Ltd
90-98 Woodlands Drive, Braeside VIC 3195
Telephone: [phone] Email: [e-mail]
Bolt/Screw
Used for:
Umbrella Model / Screw Size / Notes
DECKING NUT & BOLT
▪Timber Decking (fix
into joists, bearers
or nogs below deck)
SPECTRA umbrella rotating spigot base:
▪M10 countersunk
AURORA/ECLIPSE umbrella base plate:
▪M12 countersunk or nut head
NOVA HD umbrella base plate:
▪M12 countersunk or nut head
NOTE:
▪Length determined by thickness
of joists or nogs under the deck
▪Use washers as well as nut
▪Preferable to use stainless steel
Hardware in this guide is a recommendation only. Consult with an installation professional if
you are not sure about the most appropriate hardware to use for your specific installation.
Instant Shade take no responsibility for the failure of installation hardware.
