Intec CVM Series Guide

Original System
Item Quantity Part Number Description
1 1 CVMxxx Car Vision Monitor
2 1 CVXLPxxMA Cable
3 1 CVCxxxXL Car Vision Camera
1
2
3
The following instructions will guide you through the steps required to replace your older Car Vision® system with a new Car Vision® system
using the existing cable. Please read and understand all the instructions before proceeding with the installation.
Removing the existing monitor:
Disconnect Ground from the vehicle battery.
Unplug the monitor pigtail from the main cable. Note: Some CVM series monitors have removable pigtails, the pigtail needs to be
disconnected from the main cable, not the back of the monitor.
Cut the power (red), ground (black), and reverse trigger (blue) wires about a foot from the monitor.
Remove the monitor.
Install the new CVS100M controller:
Plug the main cable into the CVS100M controller camera connector. Note: The controller can be installed anywhere inside the vehicle as
long as it is within the 6 meter length of the CVDC6MA controller to display cable. Refer to the wiring diagram on page 2 for additional
information.
Plug the CVS100MP3M power harness into the controller.
Plug the CVDC6MA cable into the controller.
Connect to power by splicing the CVS100MP3M power harness to the existing power wires; red to red, black to black, and blue to blue.
Install the new display and remote:
Follow the directions on the quick installation guide provided with your new display.
Attach the CVDC6MA cable to the display’s Controller (inside) connector. Refer to the graphic on page 2.
Connect the CVR100 remote to the display’s Remote (outside) connector. Refer to the graphic on page 2.
Temporarily install the new display and remote.
Install the new camera:
Remove the existing camera and unplug it from the main cable.
Plug the new camera into the main cable.
Test the system and Complete the installation:
Reconnect the vehicles battery ground.
Turn the system on and adjust as needed.
Secure the new display, remote, controller and camera.
CVM Series to CVD Series
Replacement Instructions
Single Camera System
1

2
Power Connection Table – CVS100
Color Function
Red Power (+11 to +32 VDC)
Black Ground
Blue Reverse Trigger (+11 to +32 VDC)
Green Source Alarm Out (Functional Only
with Optional Radar Component)
DISPLAY VIDEO OUT/IN CAMERA POWER
Controller Connection Detail
Upgraded System
1
2
3
4
5
6
7
8
DISPLAY CVD640LCD
Controller Remote
Display Connection Detail
See The Power Connection Table
Below For Wire Connection Details
Item Quantity Part Number Description
1 1 CVDxxxLCD Car Vision Display
2 1 CVDR5MA Optional Remote Extension Cable
3 1 CVR100 Remote Control
4 1 CVDC6MA Six Meter Display to Controller Cable
5 1 CVS100M Controller – Molex Version
6 1 CVS100MP3M Power Harness for Molex Controller
7 1 CVXLPxxMA Existing Cable
8 1 CVCxxxXL CVC XL Series Camera
For additional information, please visit www.intecvideo.com/support.html
You may also call us toll free at 800‐468‐3254 (West) or 800‐522‐5989 (East) or e‐mail [e-mail] with any questions.
