Immunity test IEC 60601 test level Compliance level Electromagnetic environment - guidance
Conducted RF
rf coupled into lines
(IEC 61000-4-6)
150 kHz to 80 MHz
outside ISM bandsa
3 Vrms Portable and mobile RF communications equipment,
including cables, should be used no closer to any
part of the DLX UltraLite® Pro Camera Controller
Unit than the recommended separation distance
calculated from the equation applicable to the
frequency of the transmitter as below:
Recommended separation distance
d=1.2/V1]√P
radiated rf
(IEC 61000-4-3)
150 kHz to 80 MHz
in ISM bandsa
80 MHz - 2.5 GHz
10 Vrms
10 V/m
d=1.2/√P 80 MHz to 800 MHz
d=2.3/√P 800 MHz to 2.5 GHz
Where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter
manufacturer and d is the recommended separation
distance in meters (m).
Field strengths from fixed RF transmitters, as
determined by an electromagnetic site surveya,
should be less than the compliance level in each
frequency rangeb.
Interference may occur in the vicinity of equipment
marked with the following symbol:
This equipment is intended for use in the electromagnetic environment specified below.
The customer or user of this equipment should assure that it is used in such an environment.
aThe ISM (industrial, scientific and medical) bands between 150 kHz and 80 MHz are 6,765 MHz to 6,795 MHz; 13,553 MHz to 13,567 MHz;
26,957 MHz to 27,283 MHz; and 40,66 MHz to 40,70 MHz.
bField strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur
radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the
location in which the equipment is used exceeds the applicable RF compliance level above, the equipment should be observed to verify
normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the
equipment.
Immunity against IEC 60601-1-2 test level Compliance level
(of this device)
Electromagnetic environment
electrostatic discharge,
ESD (IEC 61000-4-2)
contact discharge:± 6 kv
air discharge: ± 8 kv
± 6 kv
± 8 kv
Floors should be wood, concrete or ceramic tile.
If floors are covered with synthetic material,
the relative humidity should be kept at levels to
reduce electrostatic charge to suitable levels.
electrical fast
transient/bursts
(IEC 61000-4-4)
power supply lines: ± 2 kv
longer input/output lines: ± 1 kv
± 2 kv
± 1 kv
Mains power quality should be that of a typical
commercial or hospital environment.
surges on AC mains lines
(IEC 61000-4-5)
common mode: ± 2 kv
differential mode: ± 1 kv
± 2 kv
± 1 kv
Mains power quality should be that of a typical
commercial or hospital environment.
power frequency
magnetic field 50/60 Hz
(IEC 61000-4-8)
3 A/m 3 A/m Equipment which emits high levels of power
line magnetic fields (in excess of 3A/m) should
be kept at a distance to reduce the likelihood of
interference
voltage dips and short
interruptions on AC
mains input lines
(IEC 61000-4-11)
dip >95%, 0.5 periods
dip 60%, 5 periods
dip 30%, 25 periods
dip >95%, 5 seconds
>95%, 0.5 per.
60%, 5 per.
30%, 25 per.
>95%, 5 sec.
Mains power quality should be that of a typical
commercial or hospital environment. If user
requires continued operation during power
mains interruptions, insure that batteries are
installed and charged. Insure that battery life
exceeds longest anticipated power outages
or provide an additional uninterrupted power
source.
Electromagnetic Immunity
This equipment is intended for use in the electromagnetic environment specified below.
The user of this equipment should assure that it is used in such an environment.
