Intellinet 524315 User manual

WIRELESS
802 .11n
GIGABIT
ROUTER
QUICK
INSTALL
GUIDE
MODEL 524315
INT-524315-QIG-0808-02

Thank you for purchasing the INTELLINET NETWORK SOLUTIONS
™
Wireless 802.11n Gigabit Router, Model 524315.
This quick install guide presents the rudimentary steps required to set up
and operate this device. For specications and more detailed instructions,
refer to the user manual 1) on the CD enclosed with this product; 2) on the
Web site listed below; or 3) in some cases, printed and enclosed with this
product. Contact your INTELLINET NETWORK SOLUTIONS dealer with
comments or questions, or visit www.intellinet-network.com for information
on the latest software and rmware updates, related products and additional
contact information.
Safety Information
For the safety of users and their equipment, follow these safety
guidelines:
• This device is for indoor use only; DO NOT place this router outdoors.
• DO NOT place this device in or near excessive heat or humidity.
• DO NOT yank any connected cables; disconnect them gently.
• If placing this device at heights or on a wall, make sure it’s rmly
secured to prevent damage and possible injury.
• Router parts, such as antennas or the power supply, are dangerous.
Children should not put the small parts in their nose or mouth. Keep
this device out of the reach of children.
• The router will become hot when used a long time. This is normal and
is not a malfunction. Keep the router away from paper, cloth and other
ammable materials.
• There’s no user-serviceable part inside the router. If you nd that the
router is not working properly, contact your dealer (place of purchase)
and ask for help. DO NOT disassemble the router: Doing so will void
the warranty.
• If the router falls into water while turned on, DO NOT touch it to remove
it! Turn off its power source before you do anything, or contact an
experienced technician for help.
• If you smell something strange or see smoke coming out of the router
or power supply, remove the power supply or turn the power off
immediately, then call the dealer for help.
3

Package Contents
Before you start to install and operate this router, make sure the following
items are enclosed; otherwise, contact your dealer for assistance.
• Gigabit router
• A/C power adapter
• Ethernet Cat5 RJ-45 cable: 1.0 m (3 ft.)
• Quick installation guide & user manual CD-ROM
Installation
1. Connect your DSL or cable modem to the WAN port of the router using
the provided RJ-45 Ethernet cable. NOTE: Standard modems provided
by Internet service providers come with at least one LAN/Ethernet
port, which connects to the WAN port of the INTELLINET NETWORK
SOLUTIONS Wireless 802.11n Gigabit Router.
2. Connect all your computers and network devices (network-enabled
components like game consoles, network media players, network
storage units or LAN switches) to the LAN ports (1-4) of the router.
4
ADSL
or Cable
Modem
ADSL
or
Cable
Modem
Hub/
Switch, etc.

3. Connect the A/C power adapter to the wall socket, and then connect it
to the power jack of the router.
4. Check all LEDs on the front panel. The PWR LED should be on, and
the WAN and LAN LEDs should be on if the computer or network
device connected to the corresponding router port(s) is powered on
and correctly connected.
5. Connect your computer to one of the LAN ports of the router, then
activate the network connection. Start the Web browser — e.g., MS
Internet Explorer — and open http://192.168.2.1 to display a login window.
6. Enter “admin” as
the username and
“1234” as the
password.
Additional installation
instructions — as well
as explanations for all
the setup options —
can be found in the
Wireless 802.11n
Gigabit Router
user manual on the
enclosed CD.
5

NOTES
6

INTELLINET NETWORK SOLUTIONS™offers a complete line
of active and passive networking products.
Ask your local computer dealer for more information or visit
www.intellinet-network.com.
