Intellisystem IT I320SIR User manual

CCD
1/3”
http
://ww
w.in
tellisystem.it
The IT I320SIR is a professional high quality
Digital Day&Nigth CCD Camera with SONY
SuperHAD CCD technology and digital signal
processor (DSP).
With its
lightweight and compact size, this camera is
the perfect solution for professional
monitoring and surveillance application.
The camera is designed in
o r d e r t o b e s t r o n g l y r e s i s t a n t t o
electromagnetic field and to be installed in a
wide range of operating temperature.
CAUTIONS
1. The applied power supply is DC 11.5 14V, the
current should not be more than 300mA.
2. Do not expose the camera to rainy or highly
moist conditions.
3. Avoid using under abnormally high or low
t e m p e r a t u r e c o n d i t i o n s . ( R e c o m m e n d e d
temperature range: -10 0 ).
4. Do not install the camera in places with direct
sunlight.
5. Installing under fluorescent or incandescent light
immediately may cause flicker of the monitor. It
does not mean the camera is damaged.
6. When installing the camera in an industrial estate
or downtown (i.e. within workshops or near to other
electronic devices, etc.), make sure to avoid any
～
℃～ ℃5
Day&Nigth Digital CCD Camera
IT I320SIR
strong electromagnetic field.
7. Do not connect any power supply directly to
the terminal of the VIDEO OUT connector,
which may cause damage.
8. When using a video/power multiplex
transmission cable, check the specifications of
your monitor so as to connect with the video
signal terminal of the camera properly.
9. Do not make any connections or operations
to the camera with the wet hands. This may
cause an electric shock.
10. Once the camera not worked properly, cut
off the power supply immediately, then check all
connectors power supply cables and video
cables to see whether they are properly
connected.
1. Before the lens mounting, loosen the two
screws on the ring and rotate this ring clockwise
until it stops. If the ring is not fixed, the inner
glass of lens or CCD image sensor may be
damaged.
2. Focus or Back Focal Adjustment.
The following adjustment should be made by
qualified service personnel or system installers.
3. Tighten the screws on the back focal
adjusting ring.
,
!
!
!
!
Mount the lens by turning it clockwise on the
lens mount of the camera.
Connect the lens cable to the auto iris lens
mount of the camera.
Loosen the screws on the back focal adjusting
ring.
Turn the back focal adjusting ring to desired
position.
CAUTION: When the lens is mounted, do not
rotate the ring counter clockwise by force. If the
ring is rotated by force, the inner glass of lens
or CCD image sensor may be damaged.
NOTE : Facing the camera lens to sun light
directly may cause damages to the CCD.
OPERATION
DAY
NIGHT
&
TV LINE
420
VDC
12

Auto-iris Lens Connection:
Assemble the miniature plug
(not included) for the auto-iris
lens as below:
SWITCHES FUNCTION AND COMPONENTS
http
://ww
w.in
tellisystem.it
A - Video Out
B - Audio Out
C - Function
Switch
D - Power
Indicator
E - DC Drive
Lens Voltage
Adjusting Knob
F - Function
Switch
G - Power
connector
A
-
+
B
D
F
VIDEO
PL
GND
DC 12V
E
DC VIDEO
-
+
C
LEVEL
G
AUDIO
IRIS
BLC
AWB AGC
NC NC
FUNCTION OF ON/OFF SWITCHES
1. BackLight Compensation.
2. Lightness Control.
3. Mirror. (AGC Auto)
4. Selection of White Balance mode.
This function is used in the surroundings where the
lights of background is too strong. After it`s ON, you can
still obtain a distinct image.
ALC - auto lightness control, can be used to DC auto
iris lens;
ELC - electronic light control, can be used to manual iris
lens.
ATW - Auto Trace White Balance;
AWC - Auto White Balance. Recommended use AWC
in normal environment . (AWC is default mode).
If the proper picture does not appear on the
monitor, ensure that the following points
are correct:
!
!
!
!
!
Whether the power connector jack and the
video cable are firmly connected.
Whether the power cable and the video cable
are connected or not damaged.
Whether the specifications of the camera and
the monitor is matched. (NTSC/PAL system ?)
Whether the power supply is stable between
DC+10.8V-13.2V and the current used for the
camera is not more than 300mA.
Whether the lens unit aligns with the camera
visual access panel.
If the camera still does not work in a
proper way after checking the above items,
stop using it immediately and contact the
distributor or dealer from whom it was
purchased.
TECHNICAL SPECIFICATIONS
Image Pick Up Device:
Signal Format:
Effective Pixels:
Horizontal Resolution:
Minimum Illumination:
Scanning System:
Synchronization:
Infrared Wave Length:
S/N Ratio:
Auto Gain Control (AGC):
Electronic Shutter:
White Balance:
Back Light Compensation (BLC):
Video Output:
Gamma Ratio:
Auto-iris Lens:
Lens Mount:
Power Supply:
Power Consumption:
Working Temperature:
Dimensions:
Weight:
1/3” Sony SuperHad
CCD
PAL or NTSC (Color)
PAL:500H×582V
NTSC:510H×492V
420 TVL
PAL: 625TVL
NTSC: 525TVL; 2:1 Interlace
Internal Sync
Line Lock, External Sync
700-1000 mm
Over 48 dB (AGC off)
40dB (On) / 16dB
(Off); Selectable
On/Off (Up to 1/100.000
seconds
Auto Tracking White Balance
(ATW) 2500°K to 9500°K
On/Off;
Selectable
1.0 Vp-p 75 Composite,
BNCx1
0.45
Video or DC Driver; Selectable
CS Mount, With CMountAdaptor
12VDC ±10%
2,2W, 185mA
-10° to +50°, RH 95%
111mm(L)*63mm(W)*55mm(H)
370 gr (without lens)
Ω
0,8 Lux/F1,2 Color -
0,02 Lux/F1.2 BW - 0 Lux/F1,2 External
IR On
-20° to +60°, RH 95%Storage Temperature:
