Intercoax ETP-08R User manual
Overview
ETP-08R is an all-in-one 8-port Ethernet over 2-wire receiver and
Hybrid switch that simultaneously transmits network data and supplies
PoC power at high speed and long distance via 2-wire Twist cable, while
also supporting existing Ethernet and PoE converters that can transmit
IP data and PoE power for short and long distances.
Using of your existing analog cables (UTP, 2-wire), network cameras
are easy to install and it is a cost-effective and time-saving solution
to migrate from an existing analog system to an IP-based system.
The long-distance transmission feature of this device makes it easy
to overcome the usual 100m-distance limit, and combined with
the HPS-01 switch, transmission can be extended up to 250m at a
maximum speed of 100Mbps. Two power supplies are included for
redundance and power sharing.
Features
Simultaneous use of regular Ethernet and Power over 2-wire
Ethernet extension over existing 2-wire Twist cable
Data + Power over 2-wire cable (PoE, PoC)
Data up to 300m over 2-wire
100Mbps Full Duplex over 2-wire
PoE, PoE+, Extra PoE (Max. 60W Output) – Use of additional power
adaptor
Quality LED (Data, Power)
Plug & Play
Surge Protection
10/100/1000 Base-T Ethernet (Full Duplex) 8+2 Hybrid PoE Switch
8-port PoE (IEEE802.3af standard) / PoE+ (IEEE802.3at standard)
Extended Ethernet distance up to 250m (10/100 Base-T Ethernet
standard / With the HPS-01 switch)
19” Rack
Quick Start Guide
ETP-08R
Please read carefully the instruction manual before use. Depending
on the model, the image and the actual look of the product may vary.
Package
ETP-08R Bracket Quick Start
Guide
Rev.1.0
Hardware Overview
RJ45:
10/100/1000 Base-T Ethernet Port
/ 8 ports PoE+ (IEEE8002.3af/at –
Max.25.5W)
RJ45 Uplink:
10/100/1000 Base-T Ethernet Uplink
Port
DC IN:
DC Input ports (up to 57V DC input)
POWER :
Recommended use: 100-240V ~
50/60Hz2.0A
PORT:
Each port of the ETP-08R connects to
an ETP-01T via 2-wire cables
Bracket Holes:
Used to fix the product to the rack
Applications
DC 57V (When using PoE
DC48-57V adapter applied)
NVR
Max. 100m
HPS-01
PoE
Camera
Max. 250m
Max. 100m
PTZ IP PoE
Camera
PoE Camera
PoE/Non-PoE Switch
ETP-08R
PoE
Camera ETP-01T
PoE
Camera ETP-01T
PoE
Camera ETP-01T
Front
Front
Back
Side
POWER
❶
PORT
Caution
DO NOT USE Non-PoE camera with an ETP-01T. (PoE IP camera only)
When using a 2-wire cable, make sure to use a Twisted cable. When
connecting, pay attention to the (
,
) polarity
Please install devices following the installation guide.
Do not touch the device and cable with wet hands.
Keep away from moisture and shock.
Do not install near any heat sources such as radiators, heat
registers, stoves or other apparatus that produce heat.
Indoor use only. (Use waterproof junction box when it is used in
outdoor)
Do not use for other purposes.
Do not disassemble or modify this device.
Do not put any sticker or paint on it.
If this device is defective or malfunctioning, please unplug the power
source immediately and contact dealer or service center.
Please use the rated power supply for the product.
Connect DC power to this device first and then to AC outlet.
Warranty
This device has passed the quality control and product inspection.
Please install and use according to the installation guide.
The warranty period for this product is 24 months from the date of
purchase.
If this device is defective or malfunctioning, please unplug the power
adapter immediately and contact dealer or service center.
Any damages or breakage from user’s abuse, accident, modification
or natural disasters will not be covered manufacturer’s warranty.
© Intercoax Co., Ltd.
Installation Guide
1. Plug the Power on ETP-08R and check if the Power LEDs are properly lit.
2. Connect the Switch or NVR to the Uplink of the ETP-08R with a UTP cable (LAN, Cat.5e or superior) Check if the LED of the ETP-08R is turned on properly.
3. Connect the ETP-08R to the ETP-01T with a 2-wire Twist cable. Caution! When connecting the cable, pay attention to the
( , )
polarity.
4. Connect the ETP-01T to the IP camera with a UTP cable (LAN, Cat.5e or superior). Check if the LED of the ETP-01T is turned on properly.
5. Connect the PoE IP camera to the Ethernet port with a UTP cable (LAN, Cat.5e or superior). Check if the Ethernet LED is turned on properly.
2-Wire Twisted cable
Check LEDs
ETP-08R
ETP-01T
UTP cable
UTP cable
Power Cable
PoE Camera
PoE Camera
Ethernet cable
(Cat5e or better)
NVR / Switch
Specification
Model ETP-08R
Interface
2-Wire 8 x 2-Pin Terminal Block– Ethernet over
2-wire twisted cable
Ethernet
Downlink 8 x RJ-45 – 10/100/1000 Base-T with
Autodetect MDIX (IEEE802.3af/at)
Ethernet Uplink 2 x RJ-45 – 10/100/1000 Base-T with
Autodetect MDIX
Transmission
Rate
2-Wire 100Mbps Full Duplex
(100Mbps between Intercoax devices)
Ethernet Max. 1Gbps Full Duplex
Transmission
Distance
2-Wire Up to 300m (1 Pair of Cat.5e) / 7W camera
Ethernet Up to 100m
Up to 250m with HPS-01
(2 Port Hybrid Switch)
LED
Indication
Ethernet
(Downlink) 8 x RJ45 Data Link (Green)
Ethernet (Uplink) 2 x RJ45 Data Link (Green/Orange)
PoE Output 8 x PoE Output (Orange)
PWR Input 2 x Power Input (Blue)
Power Input 2 x Power input [ DC-Jack ] DC48V-57V
Power
Output
PoC PoE, PoE+, Extra PoE Max 60W over 2-Wire
PoE IEEE802.3af(PoE),
IEEE802.3at (PoE+ / up to 25.5W)
Mechanical Dimension 440(L) x 320(W) x 45(H)mm
Weight 4480g
Environment
Operating Temp -10 ~ 60°C
Storage Temp -30 ~ 80°C
Relative Humidity 10% ~ 90%
Compliance
Certification FCC, CE, KC, RoHS
Surge Protection IEC 61000-4-5 4kV(1.2 / 50us),
2kA(8 / 20us)
Optional Accessories ETP-01T, ETP-101T
Pay attention to
the ( , ) polarity
DO NOT USE Non-PoE camera on Tx.
PoE IP Camera Only
Please visit below website for more detailed information.
Web: http://www.intercoax.com Tel: +82. 31. 365. 3133~4
This device complies with part 15 of the fcc rules. Operation is subject to the
following two conditions :
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received including interference
that may cause undesired operation
