Interior Solutions 15-37A720D User manual

WARNING
1. Use this product only one person at a time.
2. Do not use this chair unless all bolts screws and knobs are
securely tightened.
3. Check that all bolts screws and knobs are tight every three
months or as needed.
4. Do not overturn back tilt knob when decreasing tension.
5. Dispose of packing material properly. Do not use plastic
cover as head covering. It may cause suffocation.
6. Do not use chair as a stepladder.
7. Use this chair for its intended purpose only.
8. Use mild detergent only for cleaning.
LIMITED WARRANTY
SPACE®chairs are warranted* from the date of purchase against failure due to material and workmanship as follows:
s,IFETIMEONCOMPONENTPARTSINCLUDINGPNEUMATICCYLINDERCONTROLMECHANISMBASEANDCASTERS
s9EARSONUPHOLSTERYFABRICANDFOAMAGAINSTWEARANDDETERIORATION
*All warranties are limited to the original purchaser for normal commercial usage defined as a standard forty hour work week by persons weighing 300 lbs. or
less. This warranty will not cover labor, freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other
event beyond the control of Office Star Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or
consequential damages is excluded. The user assumes all risk of injury resulting from use of this product. When usage is more than 40 hours per week, a five
year warranty on all parts applies. Fabric is warranted for one year. 4HISWARRANTYGIVESYOUSPECIlCLEGALRIGHTSANDYOUMAYALSOHAVEOTHERRIGHTSWHICHVARY
FROMSTATETOSTATE
To make a warranty claim, contact Parts Department via e-mail parts@officestar.net, by Fax [phone], or toll free parts
number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00 p.m. Pacific Time. Provide model number and description of the
problem and obtain confirmation number. At it’s option Office Star Products will:
(a) Supply compatible components of current manufacture.
(b) Repair the customer’s component.
It is the customer’s responsibility to prepay freight on any components returned to the factory. Return freight on components
covered by warranty will be paid by Office Star Products.
15-37A720D
BIG MAN’S DRAFTING CHAIR
OPERATING INSTRUCTIONS
1
23
FEATURES
s PNEUMATIC SEAT HEIGHT ADJUSTMENT
4ORAISESEATREMOVEPRESSUREFROMSEATANDLIFTLEVERUP4OLOWER
SEATHEIGHTSITONCHAIRANDLIFTLEVERUP
NOTE:)TISNORMALFORCHAIRTOSLIGHTLYLOWERUNDER
BODYWEIGHT
s&//42).'(%)'(4!$*534-%.4
4OADJUSTFOOTRINGHEIGHTLOOSENKNOBSADJUSTFOOTRINGTO
 DESIREDHEIGHTANDTIGHTENKNOBSCOMPLETELYTOSECURE
 FOOTRINGINTOPOSITION

15-37A720D
BIG MAN’S DRAFTING CHAIR
ASSEMBLY INSTRUCTIONS
©/FlCE3TAR0RODUCTS*ULY
STEP 1 STEP 2 STEP 3
STEP 4 STEP 5
PART QTY
1. Base .......................1
2. Casters .....................5
3. Pneumatic Cylinder ............1
4. Seat Cushion w/ Seat Plate ......1
5. Back Assembly ...............1
6. Footring .....................1
7. Knobs ......................2
8. Screws ......................4
9. Back Support (Pre-Installed) .....1
10. Allen Wrench ................1
1
1
X4
2
3
1
6
3
6
5
8
9
10
X5
Remove all parts from carton, separate by part numbers indicated on parts list, and verify part quantities.
STEP 1 )NSERTlVE#ASTERSINTO"ASEPUSHHARDUNTILYOUFEELORHEARTHE#ASTERSNAPINTOPLACE
STEP 2 3LIDE0NEUMATIC#YLINDERTHROUGH&OOTRINGANDINTO"ASE
STEP 3 3ECURE&OOTRINGTO0NEUMATIC#YLINDERUSINGTWO+NOBSFULLY TIGHTEN KNOBS (7).
STEP 4 !TTACH"ACK3UPPORTTOREAROF3EAT#USHIONW3EAT0LATEUSINGFOUR3CREWS 
FULLY TIGHTEN ALL SCREWS (8) USING ALLEN WRENCH (10).
STEP 5 0LACETHEASSEMBLEDSEATONTOPOF0NEUMATIC#YLINDERANDAPPLYDOWNWARDPRESSURE
ATTENTION: MAKE SURE ALL SCREWS ARE FULLY TIGHTENED BEFORE USING CHAIR.
X2
3
7
4
