Procedures
1. Plug the C328 module into J1 of the EV board
2. Connect the EV board to a PC using the RS232 cable included
3. Apply power to EV board through J2 or J3
4. Run “C328Ap.exe”
Software Overview
After initialization, the appearance of the user interface will look like Figure 3.
Image will be displaying in the Preview Window. The Progress Bar shows the progress of the loading
operation of the image.
C328-EV232 Evaluation Board 3 2004.5.10
1. SnapShot Group
User can select the required resolution and then click “Go!” to get a picture.
The picture will be shown in the SnapShot Picture View Window and stored as “snapshot.jpg”
in the same directory where “C328Ap.exe” is located. If you want to keep the image, you need to
rename the file name, otherwise, it will be replaced by the new captured image.
2. View Group
This Group contains three buttons, Begin,
Set and Stop. User can pause and
resume to preview the live image by
pressing the button Stop and Begin
respectively.
When the button Set is pressed, a dialog
containing the data parameter will be
shown as Figure 4. User can change the
image size accordingly in the dialog box.
Click Apply to confirm the setting.
Fig 4- Parameter setting
Preview Window
Progress Bar
View Group
SnapShot Picture
View Window
Status Bar SnapShot
Group
Figure 3 – User Interface of C328-EV232
