Inventec B800 User manual

About This Manual
i
Board
B800
May, 2012 (Revision A,1)

About This Manual
ii
Copyright Notice
All rights, including copyright, in the content of this manual are owned or controlled by
Inventec (Pudong) Technology Corporation and protected by the Taiwan and international
copyright act.
No one may, transmit, adapt, assign, compile, rent, sale, change, copy, reproduce, distribute,
publish, display, broadcast, or use in any way the content of this manual, in whole or in part,
for any other purpose whatsoever without the prior written permission of Inventec (Pudong)
Technology Corporation.
Trademarks
All product names or brands mentioned herein are the trademarks of Inventec (Pudong)
Technology Corporation, its subsidiaries or other respective owners in Taiwan, United
States and other countries.
Disclaimer
This manual provides the information in relation to the set-up and installation of the product
herein. Nothing herein may be construed as granting any right or license relating to any
intellectual property rights of this manual or product. Unless otherwise provided in the
Purchase and Sale Agreement for this product, manufacturer and distributor of this product
will not be liable whatsoever relating to the distribution and/or use of this product. In addition,
manufacturer and distributor of this product hereby specifically disclaim any express or
implied warranties of merchantability, fitness for a particular purpose, or non-infringement of
third party rights in connection with this product.
Manufacturer of this product may have the right to change specifications and product
descriptions at any time without notice.

About This Manual
iii

About This Manual
iv
Contents
About This Manual ............................................................................................................... i
Conventions.........................................................................................................................i
Safety Symbols...................................................................................................................ii
Safety Precautions.............................................................................................................iii
Operation Safety.............................................................................................................iii
Electrical Safety..............................................................................................................iii
Battery Replacement Safety...........................................................................................iv
Laser Peripherals or Devices Safety................................................................................v
Intended Application Uses ...............................................................................................v
Site Selection ..................................................................................................................v
Tools Required.................................................................................................................v
Regulatory and Integration Information..............................................................................vi
Regulatory Compliance Identification Numbers ..............................................................vi
Product Regulatory Compliance .....................................................................................vi
1Introduction .................................................................................................................. 1
1.1 Audience Assumptions............................................................................................. 1
1.2 Manual Organization................................................................................................ 1
1.3 Product Features..................................................................................................... 2
1.4 Boards Layout.......................................................................................................... 4
1.5 System LED and Button Information........................................................................ 7
1.5.1 LED and Button Information of Motherboard Rear............................................. 7
2Hardware Operations ..................................................................................................10
2.1 Before You Start......................................................................................................10
2.2 Screw Holes............................................................................................................11
2.2.1 Motherboard Screw Holes................................................................................11
2.3 System Battery .......................................................................................................13
2.3.1 To remove and install the system battery..........................................................14
2.4 Processor ...............................................................................................................15
2.4.1 To remove the heat sink...................................................................................16
2.4.2 To install the heat sink......................................................................................16
2.4.3 To remove the processor..................................................................................17
2.4.4 To install the processor.....................................................................................18
2.5 System Memory......................................................................................................20
2.5.1 System Memory Organization Modes...............................................................22
2.5.2 DIMM Population Rule .....................................................................................24
2.5.2 To remove a DIMM...........................................................................................28
2.5.3 To install a DIMM..............................................................................................28
2.6 System Configuration Jumpers...............................................................................30

About This Manual
v
3Connectors, Jumpers and Switches ..........................................................................32
3.1 Power Management Connector (J98)......................................................................32
3.2 Power connector (J89)............................................................................................33
3.3 Fan Connectors (J106, J107, J108, J109, J110, J111, J112, J113, J114, J115, J116,
J117, J118, J119)..............................................................................................................34
3.4 P12V Power Connector (J88, J20)..........................................................................38
3.5 SATA Connectors (J40, J41, J42, J43, J44, J45).....................................................39
3.6 SGPIO Connector (J46)..........................................................................................42
3.7 Mini SAS Connectors (J104, J105).........................................................................43
3.8 Front Panel Connector (J90)...................................................................................45
3.9 Front USB Connector (J17).....................................................................................46
3.10 PCI-E Slots (J64, J80).........................................................................................47
3.10.1 PCI-Ex16 Slot (J64)......................................................................................47
3.10.2 PCI-Ex8 Slot (J80)........................................................................................48
3.11 SFP Connectors (J28, J29) .................................................................................50
3.12 NIC LAN and USB Ports (J95, J21).....................................................................52
3.12.1 Dedicate NIC and Rear USB Connector (J95) ..............................................52
3.12.2 Gbe NIC LAN port (J21)................................................................................53
3.13 COM and VGA Ports (J92) ..................................................................................55
4BIOS Setup...................................................................................................................58
4.1 BIOS Setup Utility...................................................................................................59
4.1.1 Main.................................................................................................................59
4.1.2 Advanced.........................................................................................................60
4.1.3 Boot .................................................................................................................84
4.1.4 Security............................................................................................................87
4.1.5 Save&Exit ........................................................................................................88
4.1.6 Event Logs.......................................................................................................89
4.1.7 Server Mgmt ....................................................................................................90
4.2 Utility and POST Code............................................................................................94
4.2.1 BIOS Requirements .........................................................................................94
4.2.2 Rom Flash........................................................................................................94
Appendix China RoHS Regulations.................................................................................. I
List of Figures
Figure 1-1 Motherboard Overview ............................................................................... 2
Figure 1-2 Connectors and Component Locations of Motherboard.............................. 4
Figure 1-3 LEDs of Motherboard Rear......................................................................... 7
Figure 2-1 Remove and Install the System Battery.....................................................14
Figure 2-2 Location of Processors ..............................................................................15
Figure 2-3 Remove Heat Sink.....................................................................................16

About This Manual
vi
Figure 2-4 Opening the Load Plate.............................................................................17
Figure 2-5 Lifting the Processor out of the Socket.......................................................17
Figure 2-6 Closing the Load Plate...............................................................................18
Figure 2-7 Pointing the Golden Corner toward the Socket..........................................18
Figure 2-8 Location of System Memories....................................................................20
Figure 2-9 DIMM Socket Location...............................................................................21
Figure 3-1 Power Management Connector .................................................................32
Figure 3-2 Power Connector.......................................................................................33
Figure 3-3 Fan Connector...........................................................................................34
Figure 3-4 P12VB Power Connector...........................................................................38
Figure 3-5 SATA Connectors.......................................................................................39
Figure 3-6 SGPIO Connector......................................................................................42
Figure 3-7 Mini SAS Connectors.................................................................................43
Figure 3-8 Front Panel Connector...............................................................................45
Figure 3-9 Front USB Connector ................................................................................46
Figure 3-10 PCI-Ex16 Slot..........................................................................................47
Figure 3-11 PCI-Ex8 Slot............................................................................................48
Figure 3-12 SFP Connectors ......................................................................................50
Figure 3-13 Dedicate NIC and Rear USB Connector..................................................52
Figure 3-14 Gbe NIC Ports .........................................................................................53
Figure 3-15 VGA and COM Ports................................................................................55
Appendix Figure I China RoHS Regulations ................................................................. I
List of Tables
Table 1-1 Manual Introduction...................................................................................... 1
Table 1-2 Product SKUs............................................................................................... 2
Table 1-3 Product Features.......................................................................................... 3
Table 1-4 Connectors and Component Locations of Motherboard................................ 4
Table 1-5 LED Information ........................................................................................... 7
Table 2-1 Function of Function Jumpers.....................................................................30
Table 3-1 Pin Definition of Power Management Connector (J98)................................32
Table 3-2 Pin Definition of Power Connector (J89)......................................................33
Table 3-3 Pin Definition of Fan Connector (J106)........................................................34
Table 3-4 Pin Definition of Fan Connector (J107) [Optional]........................................34
Table 3-5 Pin Definition of Fan Connector (J108)........................................................34
Table 3-6 Pin Definition of Fan Connector (J109) [Optional]........................................34
Table 3-7 Pin Definition of Fan Connector (J110)........................................................35
Table 3-8 Pin Definition of Fan Connector (J111) [Optional]........................................35
Table 3-9 Pin Definition of Fan Connector (J112)........................................................35
Table 3-10 Pin Definition of Fan Connector (J113) [Optional]......................................36
Table 3-11 Pin Definition of Fan Connector (J114) ......................................................36

About This Manual
vii
Table 3-12 Pin Definition of Fan Connector (J115) [Optional]......................................36
Table 3-13 Pin Definition of Fan Connector (J116)......................................................36
Table 3-14 Pin Definition of Fan Connector (J117) [Optional]......................................36
Table 3-15 Pin Definition of Fan Connector (J118)......................................................36
Table 3-16 Pin Definition of Fan Connector (J119) [Optional]......................................37
Table 3-17 Pin Definition of P12VA Power Connector (J88) ........................................38
Table 3-18 Pin Definition of P12VB Power Connector (J20)........................................38
Table 3-19 Pin Definition of SATA Connectors (J40)....................................................39
Table 3-20 Pin Definition of SATA Connectors (J41)....................................................39
Table 3-21 Pin Definition of SATA Connectors (J42)....................................................40
Table 3-22 Pin Definition of SATA Connectors (J43)....................................................40
Table 3-23 Pin Definition of SATA Connectors (J44)....................................................41
Table 3-24 Pin Definition of SATA Connectors (J45)....................................................41
Table 3-25 Pin Definition of SGPIO Connector (J46)...................................................42
Table 3-26 Pin Definition of Mini SAS Connectors (J104)............................................43
Table 3-27 Pin Definition of Mini SAS Connectors (J105) [for Patsburg–D SKU].........44
Table 3-28 Pin Definition of Front Panel Connector (J90)............................................45
Table 3-29 Pin Definition of Front USB Connector (J17) .............................................46
Table 3-30 Pin Definition of PCI-Ex16 Slot (J64).........................................................47
Table 3-31 Pin Definition of PCI-Ex8 Slot (J80)...........................................................48
Table 3-32 Pin Definition of SFP connector (J28) [Optional for 10Gbe SKU]...............50
Table 3-33 Pin Definition of SFP connector (J29)........................................................50
Table 3-34 Pin Definition of Dedicate NIC and Rear USB Connector (J95).................52
Table 3-35 Pin Definition of Gbe NIC Ports (J21) [for Gbe SKU] .................................53
Table 3-36 Pin Definition of COM (Up) Port (J92)........................................................55
Table 3-37 Pin Definition of VGA (Down) Port (J92)....................................................55

About This Manual
i
Conventions
Safety Symbols
Safety Precautions
Regulatory and Integration Information
About This Manual

i
About This Manual
Conventions
To make sure that you perform certain tasks properly, take note of the following symbols
used throughout this manual.
Warning:
Information to prevent injury to yourself when trying to complete a
task.
Caution:
Information to prevent damage to the components when trying to
complete a task.
Important:
Information that you must follow to complete a task.
Note:
Tips and information to aid in completing a task.

ii
Safety Symbols
Before troubleshooting, you must be familiar with the safety information listed below. In
order to avoid any potential hazards, the following symbols may be placed on some
components of the server.
The shape and the color of symbols shown below are mainly for your reference. Please take
the actual shipment as standard.
Indicates the potential hazard of energy circuits or electric shock. To reduce
the risk of injury from electric hazards, do not open this enclosure.
Warning: Any surface or area of the equipment marked with this symbol
indicates the presence of electric shock hazards. The enclosed area contains
no operator serviceable parts.
Indicates the potential hazard of electric shock. The enclosed area contains no
user of field serviceable parts. Do not open for any reason.
Warning: To reduce the risk of injury from electric shock hazards, do not open
this enclosure.
Indicates the presence of a hot surface or hot component.
Warning: To reduce the risk of injury from a hot component, allow the surface
to cool before touching it.
Any RJ45 receptacle marked with this symbol indicates a network interface
connection.
Warning: To reduce the risk of electric shock, fire, or damage to the
equipment,
Do not plug telephone or telecommunications connectors into this receptacle.
This symbol, on power supplies or systems, indicates that the equipment is
supplied by multiple sources of power.
Warning: To reduce the risk of injury from electric shock, remove all power
cords to completely disconnect power from the system.
Weight in kg
Weight in lb
This symbol indicates that the component exceeds the recommended weight for
one individual to handle safely.
Warning: To reduce the risk of personal injury or damage to the equipment,
observe local occupational health and safety requirements and guidelines for
manual material handling.

iii
Safety Precautions
Observe the following safety precautions when you are connecting or disconnecting any
device.
Regarding the standards of workstation regulations, do not place the server in the visual field
of the user, because of the glossy front of the case.
The product is non-consumer product and for profession technical person used only.
Operation Safety
Any operation on this server must be conducted by certified or experienced engineers.
Before operating your server, carefully read all the manuals included with the server
package.
Before using the server, make sure that all cables are correctly connected and power cords
are not damaged. If any damage is detected, contact your dealer as soon as possible.
To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots,
sockets and circuitry.
Before opening the chassis panels, make sure all power cords are unplugged.
Avoid dust, humidity, and extreme temperatures, place the server on a stable surface.
If the power supply is broken, do not try to fix it by yourself. Contact an authorized dealer.
It is recommended that you wear gloves when assembling or disassembling the server to
protect from cuts and scrapes.
When the server is powered on, heat sinks and the surfaces of certain IC devices may be hot.
Do not touch them. Check whether the fans are functioning properly.
Electrical Safety
Before installing or removing signal cables, ensure that the power cords for the system unit
and all attached devices are unplugged.
To prevent electric shock hazard, disconnect the power cord from the electrical outlet before
relocating the system.
When adding or removing any additional devices to or from the system, ensure that the
power cords for those devices are unplugged before the signal cables are connected. If
possible, disconnect all power cords from the existing system before you add a device.

iv
Use one hand, when possible, to connect or disconnect signal cables to prevent a possible
shock from touching two surfaces with different electrical potentials.
This product is equipped with a three-wire power cord and plug for user safety. Use the
power cord with a properly Grounded electrical outlet to avoid electric shock.
Motherboards, adapters, and disk drives are sensitive to static electricity discharge. These
devices are wrapped in antistatic bags to prevent this damage. Take the following
precautions:
If you have an antistatic wrist strap available, use it while handling the device.
Do not remove the device from the antistatic bag until you are ready to install the device in
the system unit.
With the device still in its antistatic bag, touch it to a metal frame of the system.
Grasp cards and boards by the edges. Hold drives by the frame. Avoid touching the solder
joints or pins.
If you need to lay the device down while it is out of the antistatic bag. Lay it on the antistatic
bag. Before picking it up again, touch the antistatic bag and the metal frame of the system
unit at the same time.
Handle the devices carefully to prevent permanent damage.
Battery Replacement Safety
This server is provided with an internal Lithium battery or battery pack. There is a danger of
explosion and risk of personal injury if the battery is incorrectly replaced or mistreated.
For more information about battery replacement or proper disposal, contact an authorized
reseller or your authorized service provider.
This server contains an internal Lithium Manganese Dioxide, or a Vanadium Pentoxide, or
an alkaline battery pack. There is risk of fire and burns if the battery pack is not handled
properly. To reduce the risk of personal injury:
Do not attempt to recharge the battery.
Do not expose to temperatures higher than 70°C.
Do not disassemble, crush, puncture, shorten external contacts, or dispose in fire or water.
Replace only with the spare parts designated for this product.

v
Batteries should not be littered along with the general household waste. Please use the
public collection system or return them to the supplier.
Laser Peripherals or Devices Safety
To avoid risk of radiation exposure and/or personal injury:
Do not open the enclosure of any laser peripheral or device.
Laser peripherals or devices are not user serviceable.
Return to manufacturer for servicing.
Intended Application Uses
This product was evaluated as Information Technology Equipment (ITE), which may be
installed in offices, schools, computer rooms, and similar commercial type locations. The
suitability of this product for other product categories and environments (such as medical,
industrial, residential, alarm systems, and test equipment), other than an ITE application,
may require further evaluation.
Site Selection
The system is designed to operate in a typical office environment. Choose a site that is:
Clean, dry, and free of airborne particles (other than normal room dust).
Well-ventilated and away from sources of heat including direct sunlight and radiators.
Away from sources of vibration or physical shock.
Isolated from strong electromagnetic fields produced by electrical devices.
In regions that are susceptible to electrical storms, we recommend you plug your system into
a surge suppresser and disconnect telecommunication lines to your modem during an
electrical storm.
Provided with a properly Grounded wall outlet.
Provided with sufficient space to access the power supply cord(s), because they serve as the
product's main power.
Tools Required
A cross screwdriver or a flat screwdriver is needed to install or remove the components in
the server.

vi
Regulatory and Integration Information
Regulatory Compliance Identification Numbers
For the purpose of regulatory compliance certifications and identification, this motherboard
is assigned a serial number. This server serial number can be found on the product label,
along with the required approval markings and information. When requesting certification
information for this product, always refer to this serial number. This serial number should not
be confused with the marketing name or model number.
Product Regulatory Compliance
Worldwide Safety approvals can be supplied according to the requirements from Marketing
or Customer.
Product Safety Compliance
The motherboard complies with the following safety requirements:
Table i Product Safety Requirements
UL 60950-1
Safety of Information Technology Equipment
UL 94
Tests for Flammability of Plastic Materials for Parts in Devices &
Appliances
Product EMC Compliance
This product has been tested and verified to comply with the following electromagnetic
compatibility (EMC) regulations.
Communications Commission Notice
Part 15 of the Federal Communications Commission (FCC) Rules and Regulations has
established Radio Frequency (RF) emission limits to provide an interference-free radio
frequency spectrum. Many electronic devices, including computers, generate RF energy
incidental to their intended function and are, therefore, covered by these rules. These rules
place computers and related peripheral devices into two classes, A and B, depending upon
their intended installation. Class A devices are those that may reasonably be expected to be
installed in a business or commercial environment. Class B devices are those that may
Only typical operating system is requested to comply with EMC regulations. Specific
regulation is based on sales region.

vii
reasonably be expected to be installed in a residential environment (for example, personal
computers). The FCC requires devices in both classes to bear a label indicating the
interference potential of the device as well as additional operating instructions for the user.
The rating label on the device shows which class (A or B) the equipment falls into. Class A
devices do not have an FCC logo or FCC ID on the label. Class B devices have an FCC logo
or FCC ID on the label. Once the class of the device is determined, refer to the following
corresponding statement.
Class A Equipment
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be required to correct the
interference at personal expense.
Declaration of Conformity for Products Marked with the FCC Logo—United States
Only
This device complies with Part 15 of the FCC Rules Operation and is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
For questions regarding your product, please contact the supplier.
To identify this product, refer to the Part, Series, or Model number found on the product.
European Union Notice
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the
Low-Voltage Directive (73/23/EEC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European Norms (in
brackets are the equivalent international standards):
Table ii European Union EMC Requirements
EN55022 (CISPR 22)
Electromagnetic Interference
EN55024 (IEC61000-4-2,3,4,5,6,8,11)
Electromagnetic Immunity
EN61000-3-2 (IEC61000-3-2)
Power Line Harmonics
EN61000-3-3 (IEC61000-3-3)
Power Line Flicker

viii
Canadian Notice (Avis Canadien)
Class A Equipment
Japanese Notice
Taiwanese Notice

Audience Assumptions
Manual Organization
Product Features
Boards Layout
System LED Information
Chapter 1
Introduction

1
1Introduction
1.1 Audience Assumptions
This document is for the person who installs, administers, and troubleshoots motherboard.
Inventec (Pudong) Technology Corporation assumes you are qualified in the servicing of
computer equipment and trained in recognizing hazards in products with hazardous energy
levels.
1.2 Manual Organization
This manual introduces the motherboard along with the hardware information and how to
replace the hardware. This manual is generally organized as follows:
Table 1-1 Manual Introduction
Introduction
General motherboard introduction and LED information.
Hardware Operations
The operation of the components on the motherboard, such as
system battery, processor, system memory, and so forth.
Connectors, Jumper
and Switch
Necessary information such as the locations and functions of
connectors and the system configuration jumper on the
motherboard.
BIOS Setup
BIOS setup information.
Appendix
China RoHS Regulations information.

2
1.3 Product Features
This chapter provides the detailed features for processor, chipset, and system memory,
onboard LAN, VGA, I/O and PCI-E with pictures for your reference.
Figure 1-1 Motherboard Overview
B800G2 MLB has five kinds of SKU. Each system can be identified through SKU_ID
configuration. The list of SKU code and PN is shown as the following table.
Table 1-2 Product SKUs
PCBA PN
SKU
SKU
PCH
AST2300
BOM DEPOP
ID[2:0]
Attribute
1395A2491601
10G_SP
0 0 1
Patsburg –A
V
CN + N6
1395A2491602
10G_DP
0 1 0
Patsburg –A
V
CN + N2
1395A2491603
10G_SP
1 0 1
Patsburg –D
V
CN + N5
1395A2491604
GBE
1 1 0
Patsburg –A
V
CN + N4
1395A2491605
GBE+10G_SP
1 0 0
Patsburg –A
V
CN + N3
This motherboard supports Intel Sandy Bridge-EP CPU with integrated memory controller.
Based on Romley-EP platform and Intel Patsburg chipset. The following highlights are the
main features of motherboard

3
Table 1-3 Product Features
Processor
Dual Processors
Intel® Xeon E5-2600
Chipset
Intel C600 Patsburg-A or Patsburg-D
System Memory
16x DDR3 DIMM slots
Two DIMMs per channel
Four DDR3 channels per CPU
Onboard Storage
Controllers
Use PCH SCU
BIOS ROM
AMI Aptio Core Base(EFI)
Networking
Intel® 10Gigabit controller 82599EN(single port) [ for
10Gbe SKU]
Intel® 10Gigabit controller 82599ES(dual port) [ for
10Gbe SKU]
Dual Channel Gbe Controller Intel® Powerville
i350-AM2 [for Gbe SKU]
Onboard Storage port
Four SATA 3Gbs ports
Two SATA 6Gbs ports
Four SATA 6Gbs ports(Patsburg-A) from SCU
Eight SATA/SAS 6Gbs ports(Patsburg-D) from SCU
Fan control
PWM fan speed control
Fourteen Fan connectors [Seven of these are optiona])
Media Bays and Ports
Two front USB connectors
Two rear USB connectors
Two inner USB connectors [Optional]
One VGA port
Two 10G SFP+ ports [for 10Gbe SKU and one is
optional]
Two Gbe Ethemet Port [for Gbe SKU]
One serial port
Onboard Slots
1 x PCIe Gen3 x16 slot, Slot6.
1 x PCIe Gen3 x8 slot, Slot2.
VGA
ASPEED AST2300
