INVENTOR MWO-28L-BD User manual
· USER'S MANUAL
· ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ
· MANUALUL DE UTILIZARE
· BEDIENUNGSANLEITUNG
· MODE D'EMPLOI
· MANUALE D'USO
· MANUAL DE USUARIO
ENGLISH | ΕΛΛΗΝΙΚΑ | ROMANA | DEUTSCH | FRANÇAIS
ITALIANO | ESPAÑOL
MICROWAVE
MODEL:
MWO-28L-BD
2ΕΝ
Prior to the usage of this device, carefully read this manual and
store in a convenient location for future reference. This device
should be used only for its intended purpose, as described in this
user's manual.
3ΕΝ
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
• Do not attempt to operate this oven with the door open,
since this can result in harmful exposure to microwave
energy. It is important not to break or tamper with the safety
interlocks.
• Do not place any object in front of the oven door, and check
if the sealing surfaces are clear of any possible soil or cleaner
residue. Do not operate this unit if you suspect any damage.
Be certain that the door is closed properly with no defects on
the hinges and the door seals.
• Do not operate the microwave oven when it is empty. There
Specications
Model MWO-28L-BD
Voltage / Frequency 220 - 240V / 50Hz
Rated Input Power (Microwave) 1450W
Rated Output Power (Microwave) 900W
Rated Input Power (Grill) 1100W
Rated Input Power (Convection) 2500W
Oven Capacity 28L
Turntable Diameter 315mm
External Dimensions (LxWxH) 520x500x326mm
Net Weight Approx. 18.5kg
4ΕΝ
IMPORTANT SAFETY INSTRUCTIONS WARNING
exposure to excessive microwave oven energy when using your
appliance, follow basic precautions, including the following.
WARNING:
1. Liquids and foods should not be heated in sealed containers,
as there is a serious risk of their explosion.
2. It is hazardous for anyone other than a competent person
to carry out any service or repair operation that involves the
removal of a cover which gives protection against exposure
to microwave energy.
3. The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Keep this device and its power cord away from minors that
are under the age of 8 years old.
4. Minors should be supervised while using this device at all
5. Only use utensils that are suitable.
6. The oven should be cleaned regularly.
7. When heating food in plastic or paper containers, be extra
the oven of any possible residues.
8. Any detection of smoke, should result in the immediate
9. It is advised never to overcook food.
10. Do not use the oven cavity for storage purposes.
11. Remove wire twist-ties and metal handles from paper or
plastic containers/bags before placing them in the oven.
5ΕΝ
12. Install or locate this oven only in accordance with the
installation instructions provided.
13. Goods with a hard peel such as potatoes or chestnuts, should
be slightly punctured prior to cooking or warming up, for
better results.
14. It is not advised to heat nor cook eggs in microwave ovens, as
there is the possibility they might explode even after being
removed from the oven.
15. The microwave oven should not be operated empty, or with
a very small amount of food, as there is the possibility of a
16. Do not cook bacon directly on the tray. Excessive local heat
can break the tray.
17. This unit is not intended to prepare preserve food, as the
18. Be extra cautious when warming baby foods. The lid from
the jars and the bottles should be removed. Prior to
baby feeding, mix very well to achieve a homogeneous
temperature.
19. The temperature on the surface of the unit, while in
operation, could possibly rise. The power cord should be
kept away from the heated surfaces at all times. Vents
should never be covered.
20. To avoid the possibility of a potential burning, mix all liquid
foods well, prior to placing in the oven. Repeat during its
heating and once again prior to removing from the oven.
21. Avoid using fat for frying.
be very warm, once cooking is complete, be extra cautious
when removing. The use of a towel is advised.
23. WARNING: Never use the oven to dry clothes or pets.
24. The microwave should not be placed in a closet.
25. This device is not intended for usage with an external timer
or a remote control system.
6ΕΝ
26. During its operation, the unit may reach very high
temperatures. Be cautious when touching the inside of the
oven. This unit should be kept away from young children.
27. No steam cleaner may be used to clean the appliance.
MICROWAVE OVEN COOKING INSTRUCTIONS
1. Carefully place the food in the microwave. The smallest
portions of food on a dish should be placed on the outer
part.
2. Be observant of the cooking time. Add the least amount of
time to be cooked and if needed once completed add more
time. Overcook food may cause smoke.
3. A special, microwave friendly, food cover is advised. Covering
the content, prevents possible food splashes due to the
heating, and assists in better cooking results.
4. The food should be turned over more than once, while
cooking, for better heating results.
5. In the event the unit is operating with the door open, power
USEFUL INSTRUCTIONS
1.
The ideal material for use in a microwave oven is transparent,
allowing microwaves to pass through and heat the food.
2. Microwaves cannot penetrate metal, so metal appliances or
decorative plates should not be used in the microwave.
3. Operating with the use of paper cups or plates, should be
short time, and always supervised.
4. Do not use recycled paper products when cooking with
microwaves as they may contain small pieces of metal and
5. Round or oval dishes, especially for use in a microwave oven,
are recommended as the edges tend to be cooked faster.
6. Do not use aluminum foil or other metal utensils to heat or
cook food.
7ΕΝ
The following list is a general guide to help you choose the right
cookware.
Cookware* Microwave
cooking
Pyrex Yes
Ceramics Yes
Plastics (marked as Microwave Friendly) Yes
Paper Cups and Dishes Yes
Non-heat resistant glassware No
Metal cookware No
Metal Grill No
Aluminum foil and aluminum packaging No
* Items that are designed to operate within a microwave, have
8ΕΝ
CLEANING INSTRUCTIONS
The following parts of the microwave oven should be cleaned on
a regular basis to prevent grease and food residue build-ups.
• Inside and outside surfaces
• Door and door seals
• Glass tray and rolling rings
Always ensure that the door seals are clean and the door closes
properly. Failure to maintain the oven in a clean condition could
operation of the appliance and possibly result in a hazardous
situation.
1. Clean the outside surfaces with a soft cloth and warm, soapy
water. Rinse and dry.
2. Remove any splashes or stains on the inside surfaces or on
the rolling ring with a soapy cloth. Rinse and dry.
3. To remove any unwanted food particles and smells, place a
cup of diluted lemon juice in the oven and operate the unit
for ten minutes.
4. Remove and wash the glass tray when necessary.
WARNING: Do NOT spill water in the vents.
WARNING: Do NOT use any abrasive products or chemical
solvents. Take particular care when cleaning the door seals to
ensure that no particles accumulate preventing the door from
closing.
• Do not clean the appliance by spraying water directly on it.
• Do not use gasoline or alcohol to clean the appliance. – It may
cause color change, deformation, damage, electric shock or
9ΕΝ
• Before cleaning or maintenance, unplug the appliance and
remove any food residue from the door and baking part. -
• Do not use hard cleaners with abrasive or sharp metal
scrapers to clean the glass door of the oven door, as it may
scratch the surface and cause the glass to break.
• Do not use the microwave to dry paper or clothes.
•
sprayers.
• Do not clean the device with a steam cleaner. – It may cause
corrosion.
GROUNDING INSTRUCTIONS
Before operating the microwave, make sure that it is properly
grounded. The microwave has a cable that has a ground wire
will prevent possible electric shock. For the operation of the
microwave oven, it is recommended to connect the plug to an
outlet and not to a power outlet with other electrical appliances.
CAUTION: Improper use of the grounded outlet can cause
electric shock.
Note:
• If you have any questions about grounding or other
• Damage or injury due to improper electrical connection is not
responsibility of the manufacturer or supplier.
• Cable Coloring:
o Green and yellow = Ground
o Blue = Neutral
o Brown = Power line
10 ΕΝ
INTERFERENCES
1. Operating the microwave oven may interfere with your radio,
television or other devices.
2. Interference may be reduced or even eliminated by following
the below measures:
- Clean the door as well as the insulation surfaces.
- Relocate the radio or TV antenna.
- Move the microwave to another location.
from other devices.
11ΕΝ
SETTING UP YOUR OVEN
Microwave Parts and Accessories
Remove the microwave oven and other objects, from the
packaging. The following accessories are included:
Glass Tray x1
Rolling Ring Assembly x1
Instruction Manual x1
F
G
A
C B
ED
B. Rolling Ring shaft
C. Rolling Ring
D. Glass tray
F. Door assembly
G. Safety interlock system
Grill Rack
(Can not be used in microwave function
and must be placed on the glass tray)
12 ΕΝ
Glass Tray Installation
a. Never place the glass tray upside
down. The glass tray should never
be restricted.
b. Both glass tray and rolling ring
assembly must always be used
during cooking.
c. All food and containers of food
are always placed on the glass
tray for cooking.
d. If glass tray or rolling ring
assembly cracks or breaks,
contact your nearest authorized
service center.
Hub (underside)
Glass tray
Rolling Ring
shaft
Rolling ring assembly
Remove all packing material and accessories. Examine the oven
for any damage such as dents or broken door. Do not install if
oven is damaged.
oven cabinet surface.
WARNING: The light brown Mica cover which is located on
the oven cavity, should never be removed. Its purpose is to
protect the magnetron.
MICA Cover
13ΕΝ
INSTALLATION
1. Select a level surface that provides enough open space for
the intake and/or outlet vents.
1. The installation height is
85cm to avoid possible
contact with children.
2. The rear surface of
appliance shall be placed
against a wall. Leave a
minimum clearance of
30cm above the oven,
a minimum clearance of 20cm is required between the
oven and any adjacent walls.
3. Do not remove the legs from the bottom of the oven.
4. Blocking the intake and/ or outlet openings can damage
the oven.
5. Place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to
your radio or TV reception.
2. Plug your oven into a standard household outlet. Be sure the
voltage and the frequency is the same as the voltage and the
frequency on the rating label.
WARNING: Do not install the oven over a range cooktop or other
heat-producing appliance. If installed near or over a heat source,
the oven could be damaged and the warranty would be void.
The accessible surface may be hot during
operation.
20cm
30cm
20cm
min85cm
0cm
14 ΕΝ
OPERATION
Control Panel and Buttons
+30 Sec.
+30 Sec.
"Microwave" Button
Activates Microwave Cooking program
"Grill/Combi" Button
Activates selection between Grill Cooking /
Combination Cooking
"Convection" Button
Selects Convection cooking programs
"Defrost" Button
Selects Defrost programs (by weight or by time)
"Timer/Clock" Button
Allows setting the clock, setting a timer, and checking
current time during operation
"Stop/Clear" Button
Pauses current operation
Clears paused operation
Locks the Control Panel (press and keep for 3seconds
while on standby)
"Start/+30Sec./Conrm" Button
Microwave - Quick Start
Start selected program
Add 30 seconds to current operation
Knob Selector
Activates Quick Menu (while on standby)
Activates Microwave - Quick Start (while on standby)
Changes program/timer/weight setting
+30 Sec.
15ΕΝ
OPERATING YOUR MICROWAVE OVEN
This microwave oven incorporates modern electronic control
adjusting your cooking parameters, to achieve optimal cooking.
Note: When you plug in the microwave oven, the screen will
display "0:00" and the unit will beep once.
1. Clock Setting
• While unit is in standby, press the "Timer/Clock" button once
to set the clock. The display will indicate "00:00" and the hour
• Turn the knob selector "
• Turn the knob selector "
• If "Stop/Clear" button is pressed, the unit will return to
previous state automatically.
2. Timer
• While unit is in standby, press the "Timer/Clock" button twice
to set the Timer. The display will indicate "00:00".
• Turn the knob selector "
minutes).
• When the timer reaches its set time, the microwave oven will
beep 5 times
Note: The display will continue to indicate the time, given the
digital clock has been set properly.
3. Microwave Cooking
• While unit is in standby, press the "Microwave" button once
the display.
16 ΕΝ
• Turn the knob selector " " or press again the "Microwave"
button to adjust the microwave’s power setting (P10 to P100,
• Turn the knob selector " " to adjust the cooking time (time
setting up to 95 minutes, step increment as in table 2). Press
and start the program.
Microwave Power Chart
Level High M.High Med M.Low Low
Power P100 P80 P50 P30 P10
W900 720 450 270 90
Table 1
Step increament of timer
0 to 1 min 5 seconds
1---5 min 10 seconds
5---10 min 30 seconds
10---30 min 1 minute
30---95 min 5 minutes
Table 2
4. Quick Microwave Cooking
button to immediately start cooking under the following
settings: microwave 100% power, 30 seconds timer.
by 30 seconds the cooking time. Repeat as many times as
needed (maximum timer setting up to 95 minutes).
Alternatively:
• Turn the knob selector " " to the left to select the cooking
17ΕΝ
once to immediately start cooking under the following
settings: microwave 100% power, 30 seconds timer.
by 30 seconds the cooking time. Repeat as many times as
needed (maximum timer setting up to 95 minutes).
5. Grill Cooking
• While unit is in standby, press the "Grill/Combi." button
the "G-1" (grill) program.
• Turn the knob selector " " to adjust the cooking time (time
setting up to 95 minutes, step increment as in table 2). Press
and start the program.
Note: The microwave will beep twice once half of the set time
has passed; this is a reminder to turn the prepared food on its
other side for universal cooking. It is recommended to turn the
prepared food on its other side for better results. Once you turn
program to continue.
6. Convection Cooking (with Preheating)
Convection cooking allows you to cook your food as you would
with a traditional convection oven. During convection cooking,
the microwaves are not activated. It is recommended to preheat
the oven to the appropriate temperature prior to placing the
food in the oven.
• While unit is in standby, press the "Convection" button once
the display.
• Turn the knob selector " " or press the "Convection"
button again to adjust the cooking temperature
(temperature setting can be from 140°C to 230°C). Press the
setting.
18 ΕΝ
the preheating. Once preheating has reached desired
temperature the microwave oven will beep twice to inform
you to add the prepared food into the microwave oven. The
desired food in the microwave oven and shut the door.
• Turn the knob selector " " to adjust the cooking time and
selection. The program will start.
7. Convection Cooking (Without Preheating)
• While unit is in standby, press the "Convection" button once
stay on the display).
• Turn the knob selector " " to adjust the cooking
temperature (temperature setting can be from 140°C to
the temperature setting.
• Turn the knob selector " " to adjust the cooking time and
selection. The program will start.
8. Combination Cooking
• While unit is in standby, press the "Grill/Combi." button
once to set the combination cooking program. "G-1" will
" to select the
combination program from C-1 to C-4 (as in table 3)
combination program.
• Turn the knob selector " " to adjust the cooking time (time
setting up to 95 minutes, step increment as in table 2) and
selection. The program will start.
19ΕΝ
Possible Combinations
Combination Display Microwave Grill Convection
1C-1 ● ●
2C-2 ● ●
3C-3 ● ●
4C-4 ●●●
Table 3
9. Defrost (by Weight)
• While unit is in standby, press the "Defrost" button once to
set the defrost by weight program. "d-1" will appear on the
display.
• Turn the knob selector " " to select the weight of the food
(weight setting can be from 100g to 2000g).(this setting can
be adjusted from 100g to 2000g)
selection. The program will start.
10. Defrost (by Time)
• While unit is in standby, press the "Defrost" button twice to
set the defrost by time program. "d-2" will appear on the
display.
• Turn the knob selector " " to select the time of the defrost
(time setting up to 95 minutes, step increment as in table 2).
selection. The program will start.
11. Dual Stage Cooking
Dual Stage Cooking allows two programs to operate in
succession. If one of the programs is defrosting, then it should
be placed at the initial stage. Once each operation is complete
the microwave oven will beep informing, while the next program
will begin automatically.
20 ΕΝ
Note: Timer, Quick Menu and Preheating are not available in
Dual Stage Cooking.
Example of Dual Stage Cooking with 5 minutes defrost and then
7 minutes of microwave cooking:
• While unit is in standby, press the "Defrost" button twice to
set the defrost by time program. "d-2" will appear on the
display.
• Turn the knob selector " " to adjust the time of the defrost
to 5 minutes.
• Press the "Microwave" button to start set the microwave
microwave cooking program. The "P100" indication will show
on the display.
• Turn the knob selector " " to select 80% microwave power
(the "P80" indication will stay on the display). Press the
• Turn the knob selector " " to adjust the cooking time to 7
minutes.
selection. The dual stage cooking program will start.
12. Quick Menu
• While unit is in standby, turn the knob selector " " to the
right to select the Quick Menu program. "A1" will appear on
the display.
• Turn the knob selector " " to select the menu program
(menu selection from A1 to A10, as in table 4). Press the
menu program.
• Turn the knob selector " " to select the weight of the
between menus, please advise available options listed in
table 4).
Table of contents
Languages:
Other INVENTOR Microwave Oven manuals
