Inventronics PRG-CASE2 User manual

Fixture for mass programming
PRG-CASE2 Rev. A
www.inventronics-co.com Tel: [phone] Fax: [phone] [email protected]
1 / 4
S
p
ecifications are sub
j
ect to chan
g
es without notice.
Features
•Easy connect to programmer PRG-MUL2
•LED indicator for programming status
•Long life push button for mass programming application
•Optional Built-in buzzer for programming status

Description
The PRG-CASE2 is a mass programming tool designed for PRG-MUL2. It contains a green and red LED
indicator, a programming push button, and a buzzer. PRG-MUL2 can easily be installed inside the CASE
using the 3 provided plug-in cables, then the CASE can be mounted to a flat surface by the mounting holes.





Fixture for mass programming
PRG-CASE2 Rev. A
www.inventronics-co.com Tel: [phone] Fax: [phone] [email protected]
2 / 4
S
p
ecifications are sub
j
ect to chan
g
es without notice.
Quick Installation
1. Mount the PRG-MUL2 into the PRG-CASE2 with the provided screws.
2. Connect the USB cable to the PRG-MUL2.
3. Connect the cable number 2 to the PRG-MUL2.
4. Connect the cable number 3 to slot besides the push button in PRG-MUL2.
5. Close the cover and connect the USB to PC or a USB charger to start the programming.
Note: Before you start Off-line programming, please ensure you have already set the programmer to Off-line
mode by Inventronics programming GUI.
Model
Name Description Part Number
Programming Fixture For mass programming Application PRG-CASE2
Environmental Specifications
Parameters Min Typ. Max Note
Operating temperature -20°C- +50°CHumidity: 10%RH to 90%RH.
No condensation.
Storage temperature -40°C- +70°CHumidity: 5%RH to 90%RH.
No condensation.
General Specifications
Parameter Min. Typ. Max. Notes
Dimensions
Inches (L × W × H)
Millimeters (L × W × H)
5.9 × 4.72 × 4.19
150 × 120 × 106.5
Net Weight - 752 g -
Note: All specifications are typical at 25°C unless otherwise stated.

Fixture for mass programming
PRG-CASE2 Rev. A
www.inventronics-co.com Tel: [phone] Fax: [phone] [email protected]
3 / 4
S
p
ecifications are sub
j
ect to chan
g
es without notice.
Packing List
Packing List Function
PRG-CASE2 Mass programming tool.
6 Pin Plug-in Cable Connects programmer and PCB(Led indicator, Buzzer, Button)
3 Pin Plug-in Cable Connects programmer and programming terminals.
Mechanical Outline


Fixture for mass programming
PRG-CASE2 Rev. A
www.inventronics-co.com Tel: [phone] Fax: [phone] [email protected]
4 / 4
S
p
ecifications are sub
j
ect to chan
g
es without notice.
Revision History
Change
Date Rev. Description of Change
Item From To
2015-05-06 A / /

