IO Mabe IWO19JSPFFS Product manual

Factory:
CONTROLADORA MABE S.A DE C.V
CARRETERA FEDERAL 51 KM 110
POBLADO OJO SECO C.P. 38158
TEL. [phone].
CELAYA, GTO.
• Read this manual carefully and completely.
Models:
IWO19JSPFFS
ICO19JSPRSS
INO27JSPFFS
Refrigerator
Instructions
and Warnings
294D2334P001 Rev.1
THIS DEVICE IS DESIGNED FOR INDOOR AND SIMILAR APPLICATIONS.
THIS REFRIGERATOR IS FOR HOUSEHOLD USE ONLY.
For English version go to page...1
Para versión en español ir a página….27
Pour la version française, allez à la page....53
Ga voor de Duitse versie naar pagina....79
Per la versione in Italiano andare a pagina...105
Zum Bearbeiten in deutscher Seite...131
Para versão em Português ir a página...157
183
Для русской версии перейдите на страницу....209

2
INDEX
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
CONTROLS WITH TEMPERATURE LEVELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
DISPENSER, AUTOMATIC ICE MACHINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
ON THE SHELVES AND COMPARTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
FOOD POSITIONING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
FOOD PRESERVATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
INSTALLATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 -17
CLEANING AND CARE OF THE REFRIGERATOR . . . . . . . . . . . . . . . . . . . . . . . . 18-19
ABOUT THE XWF-INT WATER FILTER CARTRIDGE . . . . . . . . . . . . . . . . . . . . . 20-21
EPREL DATABASE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3
WARNING - Refrigerant R600a
IMPORTANT
IMPORTANT SAFETY INFORMATION READ ALL
INSTRUCTIONS BEFORE USE.
¡WARNING!
Use this electrical appliance only for the purpose described in this User's Manual.
SAFETY PRECAUTIONS
Before starting use, this refrigerator must be
installed and correctly located according to
the Installation Instructions. Also see the
section How to connect the electricity.
Do not allow children to climb, stand, or hang
from the refrigerator shelves. They could
damage it and be seriously injured.
Do not touch cold surfaces in the freezer
compartment with wet or damp hands. Your
skin could become attached to these extreme-
ly cold surfaces.
Do not store or use gasoline or other flamma-
ble vapors or liquids near this or any other
electrical appliance.
In refrigerators with automatic icemakers,
avoid any contact with the moving parts of
the ejector mechanism or the heating element
at the bottom of the ice-maker. Do not touch
the heating element while the refrigerator is
plugged in.
Connect only to the drinking water supply. A
cold-water supply is required for automatic
operation of the ice factory. Water pressure
should be between (275-827 KPa).
This appliance can be used by children as
young as 8 years old and by people with
limited physical, sensory or mental capabilities
or lack of experience and knowledge, provid-
ed they have been supervised and/or instruct-
ed in the safe use of the appliance and under-
stand the associated risks. Children should
not play with the appliance.
Cleaning and maintenance of the appliance
should not be done by unsupervised children.
Children between the ages of 3 and 8 are
allowed to load and unload refrigeration appli-
ances.
Children should be supervised to ensure that
they do not play with the appliance.
Warning: This appliance has an isobutane
refrigerant, R600a, a natural gas with a
high level of environmental compatibility.
However, it is also flamma-
ble.
Compliance with the follow-
ing warnings is requested:
In case of damage to the refrigerant pipe,
avoid flames or any source of ignition near the
product, ventilate the room where the prod-
uct is located for a few minutes.
When moving, installing, and operating the
appliance, care should be taken to avoid
damaging the refrigerant piping.
Service must be performed by factory autho-
rized service personnel, and components may
be replaced with manufacturer authorized
replacement components.
Refrigeration products contain refrigerants,
which according to federal law must be
disposed of before the product is discarded.
When using electrical appliances, several basic safety precautions should be followed,
such as:
Any volatile substances, such as solvent liquid
propane gas, etc. may not be stored in this
refrigerator.
Do not store explosive substances, such as
aerosol cans with a flammable propellant in
this appliance.
This appliance is designed for use in the
home. It is not intended for commercial use.
Keep your fingers out of "pinch areas"; the
spaces between the doors and the body of
the refrigerator are necessarily small. Be
careful closing the doors when children are
around.
Unplug the refrigerator before cleaning and
making any repairs.
NOTE: If repairs are required, we strongly
recommend that a qualified technician carry
out the repair.
•
•
•
•

4
PROPER DISPOSAL OF THE REFRIGERATOR
Before disposing of your old refrigerator
or freezer:
Refrigerant
Insulation
DANGER! CHILDREN ARE AT RISK OF BEING TRAPPED
The risk of children being trapped inside the
refrigerator and suffocating are not problems of
the past. Discarded or abandoned refrigerators
are still dangerous even if left there "only for a
few days. If you wish to dispose of your old
refrigerator, kindly follow the instructions below
to prevent accidents.
Remove the doors and dispose of them
separately.
Leave the shelves in place so that children
have a hard time locking themselves in the
refrigerator.
All refrigeration equipment contains refriger-
ants, which must be removed before disposal in
accordance with federal law. If you are dispos-
ing of an old refrigeration appliance, check with
the company in charge of disposing of the appli-
ance to find out what to do.
Cyclopentane is used as insulation. The gases in
the insulation material require a special removal
procedure. Please contact your local authorities
regarding the proper disposal of this product.
and also prevents overloading of your home's
electrical wiring, which could create a fire
hazard due to overheating of the wires. Please
refer to the refrigerator rating plate to verify the
correct voltage, wattage and frequency. If the
product's plug does not fit into the outlet, you
should replace it with a new one.
NOTE: A fused, grounded 220 - 240V AC, 50 -
60 Hz, 15 or 20A electrical supply is required.
This provides the best performance and also
prevents overloading of house wiring circuits,
which could cause a fire hazard by overheating
the wires.
WARNING: Keep ventilation open-
ings, in the appliance enclosure or in the struc-
ture, clear of obstruction.
WARNING: Do not use mechanical
devices or other means to accelerate the
defrosting process. Other than those recom-
mended by the manufacturer.
WARNING: Do not damage the refriger-
ant circuit.
•
•
•
WARNING: Do not use electrical appli-
ances inside food storage compartments. Of
the appliance, unless they are of the type
recommended by the manufacturer
Do not refreeze food that has been complete-
ly defrosted.
¡WARNING!
HOW TO CONNECT THE POWER
The power cord of this appliance is equipped
with a grounding plug that fits into a standard
grounded outlet to minimize the possibility of
electric shock from the appliance.
To ensure that the outlet is properly grounded,
have the power plug and circuit tested by a quali-
fied technician.
If you discover an ungrounded outlet, it is your
responsibility and obligation to replace it with a
properly grounded one.
The refrigerator should always be plugged into a
separate outlet. This ensures better performance
Note:The food to be frozen must not come into
direct contact with the food stored in the refriger-
ator.
•

5
READ AND FOLLOW THIS SAFETY INFORMATION
CAREFULLY.
SAVE THESE INSTRUCTIONS
IMPORTANT: Modification of electrical plugs
and cables should be performed by a qualified
technician or service representative. In some
countries, modification of power plugs and
cords is allowed only if a qualified technician
performs the work.
If the appliance supply cord is damaged in any
way, a qualified service representative must
replace it to avoid a safety hazard.
Never unplug the refrigerator by pulling on the
supply cord. Always grasp the refrigerator plug
firmly and remove it from the outlet.
WARNING: When placing the device,
make sure the supply cord is not trapped or
damaged.
WARNING: To avoid a hazard due to the
instability of the appliance, it must be fixed in
accordance with the instructions.
WARNING: Connect only to a potable
water supply system with an inlet pressure of
275-827 kPa.
WARNING: Do not place multiple
mobile sockets or mobile power supplies on the
back of the appliance.
Repair or replace all worn or damaged cords
immediately. Never use a cord which has cracks
or abrasive damage along its length or at its
ends.
When moving the refrigerator away from the
wall, be careful not to crush or damage the
power cord.
Replacing the cable
If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified personnel in order to avoid
a hazard.
CLIMATE CLASS
The refrigerator is designed for a certain climatic class (ambient temperature).
The models: IWO19JSPFSS, ICO19JSPRSS, INO27JSPFFS correspond to the letter T:
Climate class Ambient temperature range
SN
N
ST
T
+ 10 to +32 °C
+16 to +32 °C
+16 to +38 °C
+16 to +43 °C
WARNING: If the refrigerator operates outside
the climate class for which it is designed, it may not
satisfactorily maintain internal temperatures.

6
WARNING
READ USER MANUAL
GUIDELINES
FOR INSTALLATION
Anti-tip over
floor support
TOOLS THAT YOU MIGHT NEED
9.525 mm (3/8") drill bit
for concrete and 3 mm (1/8")
drill bit for wood
electric or manual
Measuring tape
11,113 mm spanner (7/16")
for concrete and
7.938 mm (5/16") for wood
Pencil
Under certain circumstances, this refrigera-
tor can be tilted forward. Personal injury
may result. Install the anti-tip bracket includ-
ed with this refrigerator.
WARNING
The door is flipped over (reversible), the anti-tip
bracket must be installed by the manufacturer or
its authorized service agent in order to avoid a
hazard.
Note: The anti-tip bracket must always be
positioned on the side opposite the door
hinge.
1MEASURE THE SPACE WHERE
YOU WILL LOCATE THE REFRIG-
ERATOR
Measure the width of the space where your W
refrigerator will be located. Take into account
any protrusions such as the thickness of the
base or any space that may interfere with the
cabinet.
Note: this appliance is not intended to be
used as a built-in appliance.
Installation place:
Select the area to place your refrigerator. We
recommend a large, dry and well ventilated area.
The appliance should not be installed in such a
way that it receives direct sunlight, nor should it
be located near active heat sources such as kitch-
ens, heaters, etc…
1228 mm
1004 mm
Model ICO19JSPRSS
Model IWO19JSPFSS
W
W
1392 mm
1111 mm
Model INO27JSPFFS
W
1537 mm
1239 mm

Preferred Installation –
Wood Preferred Installation -
Concrete
Minimum aceptable N°1 –
Wall plate support Minimum aceptable N°2 –
Wood floor
Minimum acceptable N°3 –
Concrete floor
Figure 2 -Locations of
acceptable screws
BHold the bracket in this position and use it as
a template to mark the holes based on the
configuration and type of construction, as
shown in step 3.
NOTE:
It is REQUIRED to use at least 2 screws to
mount the floor stand (one on each side
of the anti-tip floor stand). Both must be
in the wall or on the floor.
Figure 2 indicates all acceptable mounting
configurations for the screws. Identify the
screw holes in the roll-away bracket for your
configuration.
2HOW TO LOCATE THE ANTI-TIP
FLOOR SUPPORT (cont.)
Base support
in the
refrigerator
2 holes in
the wall
Refrigerator
left side
Floor - Concrete
(2 holes)
Floor - Wood
(2 holes)
130 mm
Floor
support
to be installed
Holes on
the right
INSTALLATION INSTRUCTIONS
2
A
HOW TO LOCATE THE ANTI-TIP
FLOOR SUPPORT
Inside the W space, where your refrigerator
will be located, make a small mark on the floor
attached to the back wall. This mark indicates
the desired location of the left side of the
refrigerator. From this mark measure 130 mm
to the right and place the anti-tip bracket. The
left edge of the holder must be 130 mm from
the left side of the refrigerator.
MATERIALS YOU MAY NEED
(not included)
Fastening screws 6.350 mm (¼") x
38.100 mm (1 ½") hex head for
concrete and #10-16 x 38 mm
(1 ½") hex head screws for wood
Plugs (9.525 mm (3/8")
external diameter).
Only for anti-tip supports mounted on concrete.
Drill properly for the plugs.
7

8
INSTALLATION INSTRUCTIONS
3
A
B
C
INSTALLATION OF ANTI-TIP
SUPPORT
Wall and floor construction in WOOD:
• Drill the appropriate number of 3mm holes
in the center of each floor support hole that
is being used (a nail or punch can be used if
a punch is not available).
• Install the anti-tip floor support by tightening
the 2, or preferably 4, #10-16 x 38mm (1
1/2”) hex head screws into place as shown in
Figure 3.
Figure 3 - Wall and floor connection
Concrete wall and floor construction
• Required Anchors (not included): 4 for each
¼" x ¼" (6,350 mm) x 38,100 mm (1½")
hex head 4 for each 3/8" (9,525 mm) outside
diameter anchor
• Drill holes of the recommended size for
anchors in concrete in the center of the holes
marked in Step 2.
• Install the anchors into the drilled holes.
Place the anti-tip floor support as outlined in
Step 2.
• Install the anchor bolts through the anti- tip
floor bracket and tighten properly.
Construction of WOOD wall and ceramic
floor
• For this special case, locate the 2 wall holes
identified in Fig. 1.
4
A
B
C
D
HOW TO POSITION THE REFRIG-
ERATOR TO OPERATE THE
ANTI-TIP DEVICE AND THE BASE
OF THE BRACKET.
Before putting the refrigerator in place, plug
the power cable into the power outlet and
connect the water line (if applicable) - Check
for leaks.
Locate the left side of the refrigerator and
move it back approximately in line with the left
side of the opening where your refrigerator
will be placed W. This should position the
anti-tip floor bracket so that the anti-tip floor
bracket can be connected to the refrigerator.
NOTE: When positioning the refrigerator,
make sure that the mark on the floor
matches the left side of the refrigerator.
Carefully slide the refrigerator into the cabinet
opening until it comes to a complete stop.
Check that the front of the refrigerator is
aligned with the front of the cabinet. If not,
gently swing the refrigerator back and forth
until it hooks and you notice that the refrigera-
tor is fully supported by the rear wall.
OPTIONAL D: Adjust the rear (and front) wheel
height settings to fully engage the rear anti-tip
brackets, while also aligning the front of the
refrigerator with the front of the cabinet.
2 screws
Rear right
end of the
fridge
Floor
Wall
plate
Floor
They must
go in a Wall
or metal base
Wall
NOTE:
If you separate the refrigerator from the
wall for any reason, make sure that the
anti-tip floor bracket is engaged when the
refrigerator is placed back against the wall.
WARNING
To avoid a hazard due to instability of the appli-
ance, it must be fixed in accordance with the
instructions.
Drill a 3 mm pilot hole at an angle (approx. as
shown in Fig. 3) in the center of each hole.
• Install the anti-tip floor support using the
minimum acceptable installation #1, as
shown in Fig. 2.
C

9
AREA
Arrange the following space for easy installation, proper air circulation and plumbing and electrical connections:
Rear 50 mm.
INSTALLATION OF THE WATER SUPPLY
5CONNECT THE TUBE TO THE REFRIG-
ERATOR
NOTES:
• Before connecting to the refrigerator, make
sure that the cable is not plugged into the wall
outlet.
• If your water supply contains sand or
particles that could clog the refrigerator water
valve, we recommend that you install a water
filter. Install it in the refrigerator's water pipe.
BEFORE YOU START
The installation of the water line is not covered by
the manufacturer of the refrigerator or ice cube
machine. Follow these recommendations careful-
ly to minimize the risk of costly water damage.
Water that sounds like a hammer in the pipes can
damage some parts of the refrigerator and also
cause leaks or flooding. Call a qualified technician
to fix plumbing problems before installing the
water supply in the refrigerator.
To prevent burns and damage to the appliance,
do not connect it to the hot water outlet.
If you use the refrigerator before the water
connection is installed on the ice maker, set the
refrigerator operating switch to the O (off)
position.
Do not install the ice maker tube in places where
the temperature could fall below freezing.
When using an electrical device (such as a drill)
during installation, make sure the device is electri-
cally isolated or connected so that there is no
danger of electrical shock.
All installations must comply with current
standards for plumbing work. The installation of
the automatic ice maker must be carried out by a
qualified technician.
Use the new hose-set supplied with the refrigera-
tor. Old hose-sets must not be reused.
1. Turn off the water supply.
2. Connect the molded end to the water inlet of
the refrigerator.
3. Tighten the nut by hand, then turn an
additional turn with a wrench (DO NOT
OVER-tighten).
4. Connect the plastic water line adapter to the
household water line. Tighten by hand, then
turn an additional quarter turn. (DO NOT OVER-
TIGHTEN AS THIS WILL DAMAGE THE SEAL).
5. Turn on the water supply. If leaks appear,
tighten connections further.
Refrigerator
conection
Sleeve
6.35 mm pipe

10
WARNING
INSTALLATION OF THE REFRIGERATOR
Ice maker
Feeler Arm
Switch
6START UP THE ICE MAKING
DEVICE
Turn the ice maker power switch to the l
position. The ice maker will not operate until it
has reached its operating temperature of -9°C,
or lower. At that time, it will operate if the
power switch on the device is in position l.
NOTE: In the event that the water pressure is
low, it may take up to three times as long to
fill the ice maker with enough water.
When the
right door
is lower
than the
right door
When the
left door is
higher than
the right
door
Adjusting point
Refrigerator Opening
PLACE THE REFRIGERATOR IN ITS
POSITION
Move the refrigerator to its final position.
REFRIGERATOR HANDLING
To move the refrigerator
take it from the sides as
shown in the picture, slide it
to the position where it will
be placed with slow and
controlled movements.
LEVEL THE REFRIGERATOR
The leveling feet at the front corners of the
refrigerator should be adjusted so that the refriger-
ator is positioned firmly on the floor, and the front
is raised enough so that the door closes easily
when opened approximately halfway. To adjust
the leveling legs, turn the legs clockwise to raise
the refrigerator, and counterclockwise to lower it.
REVERSIBILITY
(FULL DOOR MODELS ONLY)
Some models have Reversibility on the door, for this
see Reversibility manual or the user's manual.
LEVELING OF THE DOORS OF THE
REFRIGERATOR (on some models)
Remember that the refrigerator must be level so
that the doors are perfectly supported. If you need
help, check the previous section on leveling the
refrigerator.
If the doors are still uneven, turn the adjustable
bolt to raise the lower door using a 1/4" Allen
wrench to turn the bolt.
Connect only to a potable water supply system
with an inlet pressure of 275-827 kPa.
Green
power light

11
Stainless steel with anti-fingerprint finish
Model INO27JSPFFS. Instructions for cleaning exterior surfaces, door handles and edges.
DO NOT use stainless steel cleaners on door surfaces.
IMPORTANT: Using the wrong products can damage the fingerprint-resistant outer finish on stainless steel
models. Follow these instructions and use only the appropriate items below to clean the surfaces of your refrigera-
tor.
• Clean the interior/exterior surfaces with warm water, mild soap or detergent and a soft or microfiber cloth to
prevent damage.
• Dry the surface of the refrigerator with a soft, clean cloth or microfiber towel to avoid stains or water droplets.
CLEANING AND CARE OF THE REFRIGERATOR
USED
Soft, clean cloth or sponge microfiber
cloth
Mild detergent mixed with warm water
DO NOT USE
Abrasive cloths, paper towels, carving sponges (with or
without soap). steel wool scourers or sponges
Abrasive powders, liquids or aerosols.
Window cleaners, ammonia or lye Citrus or vegetable oil
based cleaners Acid or vinegar based cleaners Oven
cleaners Alkaline cleaners Stainless steel cleaners
Stainless steel.
Models ICO19JSPRSS, IWO19JSPFSS. Instructions for cleaning exterior surfaces, door handles
and edges.
NOTE: DO NOT allow stainless steel cleaner to come in contact with any plastic parts, such as finishing parts,
handle attachments, and coatings. If unintentional contact occurs between the cleaners and plastic parts, clean
the plastic part with a sponge and cloth mixed with mild detergent and warm water.
USED
Soft, clean cloth or sponge microfiber
cloth
Mild detergent mixed with warm water.
Approved cleaners for stainless steel.
DO NOT USE
Abrasive cloths, paper towels, carving sponges (with or
without soap). steel scourers or sponges
Abrasive powders, liquids or aerosols. Window cleaners,
ammonia or lye Citrus or vegetable oil based cleaners
Acid or vinegar based cleaners Oven cleaners Cleaners
containing acetone Cleaners with plastic use warning.
*Easily remove stains and fingerprints

12
If air got caught in the system, it is possible that the
cartridge will be ejected at the time it is removed. Be
careful when removing it.
Open the filter cartridge
housing by pressing the 2
front tabs and gently push-
ing down.
Position the filter ports in
line with the ports on the
filter cartridge housing and
gently insert the filter.
Slowly turn the filter clock-
wise until it stops. DO NOT
OVER TIGHTEN. As you turn
the filter, it will automatical-
ly adjust into position. The
filter will rotate approxi-
mately 1/4 or 90 degrees,
until the arrow on the filter
is aligned with the arrow on
the filter cartridge housing.
Slowly push the filter up
over the clips.
CAUTION
INFORMATION ABOUT THE WATER FILTER CARTRIDGE XWF-INT
WATER FILTER CARTRIDGE
The water filter cartridge is located at the upper right
rear end of the refrigerator's fresh cooking compart-
ment.
Selected models use radio frequency identification
(RFID) to detect leaks and monitor filter status.
WHEN TO REPLACE THE FILTER
If there is a water filter cartridge replacement indicator
light on the dispenser, a red filter light will begin flash-
ing to indicate that the filter needs to be replaced soon.
- On models with a top control, the filter light will blink
while the door is open until the filter is replaced.
On models that do not have an indicator light, the filter
cartridge should be replaced every six months, or
sooner if there is a reduction in water flow to the
dispenser or ice machine.
FILTER REMOVAL
If you are replacing the filter, first remove the old one:
1. Open the filter cartridge housing by pressing the 2
front tabs and gently pushing down.
2. Rotate the filter downwards.
3. Gently pick up the filter and slowly turn it approxi-
mately 1/4 counterclockwise. The filter should release
automatically when you have rotated it far enough to
the left. A small amount of water may leak out.
FILTER BYPASS PLUG
In order to reduce the risk of property damage due to
water loss, you MUST use the filter bypass plug when
filter cartridge replacement is not available. The
dispenser and ice machine will not operate if the filter
or filter bypass plug is not installed. The filter bypass
plug is installed in the same manner as a filter
cartridge.
INSTALLATION OF THE FILTER IN THE
REFRIGERATOR WITH FREEZER IN THE
INFERIOR PART
1.
2.
3.
4.
5.
6.
7.
Close the filter cartridge housing by gently pressing
the cover upwards until the tabs are locked in
position.
Run a small amount of water from the 2-gallon
dispenser or for approximately 5 minutes to clean
the system. Water may spurt out or bubbles may be
visible during the process. If no water is flowing,
check to make sure the filter has been turned
completely to the right.
Press and hold the WATER FILTER button (specific
models only) on the dispenser for three seconds.

13
Service Flow 0.5 gpm (1.89 l/min)
Supply of Drinking Water
Water Pressure (172-827 kPa)
Water Temperature (0.6°C-38°C)
Capacity (643.5 liters)
Application Guidelines/ Water Supply
INFORMATION ABOUT THE XWF-INT WATER FILTER CARTRIDGE
WARNING
In order to reduce the risk associated with choking,
do not allow children under the age of 3 to have
access to small parts during installation of this prod-
uct. The disposable filter cartridge should be
replaced every 6 months after the capacity is
exhausted, or sooner if there is a noticeable reduc-
tion in flow.
This symbol means that the electrical and electronic products used must not be mixed with gener-
al household waste.
Do not attempt to dismantle the system and unit yourself, as this could have harmful effects on
your health and the environment.
Refrigerators must be treated at a specialised treatment center for recycling and recovery and may
not be disposed of in municipal containers. This appliance is marked with the symbol of compli-
ance by the European Directive 2012/19/EU relative to the used electric and electronic appliances.

CONTROLS WITH TEMPERATURE LEVELS
Figure A
Filter Status Turbo Cool
Hold 3 Sec
Door Alarm Fridge
Recommended 3°C
Freezer
Recommended -18°C
1. Freezer temperature control.
Freezer compartment temperature adjustment. The
freezer temperature is pre-set at the factory to -18°C.
Allow 24 hours for the temperature to stabilize at the
recommended default setting, this temperature
allows the refrigerator to be better utilized for energy.
To change the freezer temperature, press the Freezer
button and the currently set temperature will be
displayed, press the button again and release, contin-
ue to do this until the desired temperature is found.
2. Refrigerator temperature control.
Refrigerator temperature control.
Setting the refrigerator temperature. The temperature
of fresh food is preset at the factory to 3°C. Allow 24
hours for the temperature to stabilize at the recom-
mended pre-set setting. This temperature allows the
refrigerator to make better use of energy.
To change the refrigerator temperature, press the
Fridge button and the currently set temperature will
be displayed, press the button again and release,
continue to do this until the desired temperature is
found.
3. Filter status.
The LED on the Filter Status button will light up when
the filter needs to be changed. After changing the
filter, press the Filter Status button for three seconds
to reset the filter change time timer.
4. TurboCool ™
To configure the TurboCool ™, press the Turbo-Cool
button ™ for 3 seconds. The display will show tc.
TurboCool ™ quickly cools the refrigerator compart-
ment for faster cooling of the feeds. Use TurboCool
™ when adding a large amount of food to the refriger-
ator, storing foods that have been at room tempera-
ture or storing warm food scraps.
It can also be used if the refrigerator has been
unplugged for an extended period.
NOTE: The temperature of the refrigerator cannot be
changed while using TurboCool ™. The freezer
temperature is not affected during the use of Turbo-
Cool ™. When opening the refrigerator door during
TurboCool ™ use, the fans will continue to run if they
have been activated.
5. Door alarm.
To set the alarm, press the Door Alarm key until the
indicator light lights up. This alarm will sound if one of
the doors remains open for more than 2 minutes. The
light turns off and the beep stops when the door is
closed.
NOTE: To turn the refrigerator control OFF, press the
words Freezer and Fridge simultaneously for 3 seconds.
Power to the refrigerator cannot be turned off by any
control panel setting.
SABBATH MODE
Activate the standby mode to deactivate the temperature control and advanced functions. (E.g. door alarm).
Depending on the model, the interior lights will be off or dim regardless of whether the door is open or closed.
The compressor will run on a programmed defrost when in Sabbath mode.
Models with controls in Figure A
Press and hold the Alarm and Filter Status key simultaneously for 5 seconds to
enter and exit Sabbath mode
The ice maker must be turned off manually during the sabbatical mode. To turn off
the ice factory, turn the switch to the OFF position.
To turn the ice machine on, set the switch to the ON position.
Note: Sabbatical mode does not affect the temperature of the refrigerator.
Ice
maker
Feeler Arm
Switch
Green power
light
14

DISPENSER
Internal water dispenser
The water dispenser is located on the left-hand wall
inside the refrigerator.
To dispense water:
1. Hold the glass against the opening.
2. Press the button on the water dispenser.
3. Hold the glass under the dispenser for 2-3 seconds
after releasing the dispenser button.
If water is not dispensed after the first installation of
the refrigerator, there may be air in the water pipe
system. Press the dispenser button for at least five
minutes to remove any trapped air from the water line
and fill the system with water. During this process,
dispenser noise may be high when purging air from
the water line system. To remove impurities from the
water line, throw away the first six glasses of water.
NOTE: To avoid water deposits, the dispenser should
be cleaned periodically with a clean cloth or sponge.
NOTE: In order to guarantee the temperature in the
water dispenser, the demand time should not exceed 2
minutes (2 liters) and 15 minutes should pass before
the ideal temperature of the water in the dispenser is
reached again.
15
CAUTION
Ice maker
Feeler Arm
Switch
AUTOMATIC ICE MACHINE
It can take between 12 and 24 hours for a newly
installed refrigerator to start making ice. The ice-maker
will produce seven cubes per cycle-approximately
100-130 cubes in a 24-hour cycle, depending on the
freezer temperature, room temperature, number of
times the door is opened, and other conditions of use.
Discard the first few loads of ice cubes to allow the
water line to clean.
It can take between 12 and 24 hours for a newly installed refrigerator to start making ice. The ice-maker will
produce seven cubes per cycle-approximately 100-130 cubes in a 24-hour cycle, depending on the freezer tempera-
ture, room temperature, number of times the door is opened, and other conditions of use. Discard the first few
loads of ice cubes to allow the water line to clean.
ON THE SHELVES AND COMPARTMENTS
Not all functions correspond to all models.
Lift from the front and then
up from the back to remove
the shelf.
The Quick Space Shelf (on some models) can be folded
to half its size for storage of tall items on the bottom
shelf. Push the shelf out and up and slide it back until it
stops to form a half shelf. Push up and forward, then
down to re-form the entire shelf.
The adjustable door
drawers can be
removed for clean-
ing.
Green Power light

16
Shelf Reorganization
The shelves in the refrigerator are adjustable
Refrigerator compartment to remove the entire shelf.
Remove all elements.
Lift the shelf up.
To Remove the Modular Shelf
While tilting the shelf up, insert the top hook on the back of the shelf into
the slot on the slide.
Lower the front of the shelf until the bottom of the shelf snaps into place.
To remove: lift the shelf straight up and then remove it.
To replace: Insert shelf into door molded brackets and push down. It will snap into
place.
To remove: Lift the shelf straight up and then pull it out.
To replace: Insert shelf into door molded brackets and push down. It will snap into
place.
Shelves
Shelves placed in the ideal location for the best energy efficiency.
IWO19JSPFSS
Model 527 liters
French door with drawer
freezer
INO27JSPFFS
Model 764 liters
OPP door with drawer
freezer
ICO19JSPRSS
Model 530 liters
Single door with drawer
freezer
Note: Do not block the air outlets with food. Erratic temperatures may occur.
Note: Images for reference only.

17
In the following image you can identify the refrigerator and freezer compartments mentioned in the table.
FOOD POSITIONING
In order to make the most of your refrigerator, we recommend that you follow these recommendations on the
storage and conservation of your food.
MODEL ICO19JSPRSS
LOCATION RECOMMENDED FOODS TO BE STORED
to improve its conservation during the longest possible Impact of temperature adjustments on food waste.
1
2
3
4
5
6
7
8
9
10
11
Raw meat, poultry, beer, soft drinks
Desserts, eggs, wines
Milk, juice gallons, large fruit such as
watermelon, melon, homemade food containers
Apples, citrus fruits, berries, ripe avocados
Tomatoes, lettuce, cucumber, eggplant, corn.
Any type of cheese, ham, sausages
Condiments for sauces, dressings, syrups.
Soda, yogurt and dairy products, children's snacks,
soft drinks, water, alcoholic beverages
Juices and UHT milk, water bottle, pitcher.
Meat containers, frozen prepared foods
Ice cream, frozen fruits and vegetables, French fries
Increasing the temperature of the refrigerator can accelerate food
deterioration; lowering the temperature of the refrigerator can
freeze the food.
Changing the temperature of the refrigerator does not affect
conservation.
Increasing the temperature of the refrigerator can accelerate food
deterioration; lowering the temperature of the refrigerator can
freeze the food.
Changing the temperature of the refrigerator does not affect
conservation.
Changing the temperature of the refrigerator does not affect
conservation.
Increasing the temperature of the refrigerator can accelerate the
deterioration of the food; lowering the temperature of the
refrigerator can freeze the food.
Changing the temperature of the refrigerator does nota afecte
conservarían.
Changing the temperature of the refrigerator does not affect
conservation.
Changing the temperature of the refrigerator does not affect
conservation.
Increasing the temperature of the freezer can defrost the food
Increasing the temperature of the freezer can defrost the food

18
In order to make the most of your fridge, we recommend that you follow these recommendations on the storage
and conservation of your food.
MODELS IWO19JSPFSS, INO27JSPFFS.
LOCATION
RECOMMENDED FOODS TO BE STORED
to improve its conservation during the longest
possible period
1
2
3
4
5
6
7
8
9
10
11
12
Raw meat, poultry, beer, soft drinks
Desserts, eggs, wines
Milk, juice gallons, large fruit such as watermelon,
melon, homemade food containers
Apples, citrus fruits, berries, ripe avocados
Tomatoes, lettuce, cucumber, eggplant, corn.
Any type of cheese, ham, sausages
Condiments for sauces, dressings, syrups.
Soda, yogurt and dairy products, children's snacks,
soft drinks, water, alcoholic beverages
Juices and UHT milk, water bottle, pitcher.
Leftover food, small packages and containers
Meat packaging, frozen prepared foods
Ice cream, frozen fruits and vegetables, French fries.
Increasing the temperature of the refrigerator can accelerate the
deterioration of raw meat, the low temperature of the refrigerator
can freeze the food.
Changing the temperature of the refrigerator does not affect
storage.
Increasing the temperature of the refrigerator can accelerate the
deterioration of the food; a lower refrigerator temperature can
freeze the food.
Changing the temperature of the refrigerator does not affect
conservation.
Changing the temperature of the refrigerator does not affect
conservation.
Increasing the temperature of the refrigerator can accelerate the
deterioration of the food; lowering the temperature of the
refrigerator can freeze the food.
Changing the temperature of the refrigerator does not affect
conservation.
Changing the temperature of the refrigerator does not affect
conservation.
Changing the temperature of the refrigerator does not affect
conservation.
Changing the temperature of the refrigerator does not affect
conservation.
Increasing the temperature of the freezer can defrost the food
Increasing the temperature of the freezer can defrost the food
In the following image you can identify the refrigerator and freezer compartments mentioned in the table.
Impact of temperature adjustments on food waste.

19
VACUUM-PACKED AND DELICATE PRODUCTS
Egg and chicken salads,
Tuna, ham and macaroni
prepared in the store
(or homemade)
Cookies prepared meals
3 - 5 days
3 - 4 days
DO NOT FREEZE
DO NOT FREEZE
FOOD PRESERVATION
Follow the guidelines below to store food in the refrigerator and freezer. Time limits for refrigerated food at home
will help prevent it from spoiling or becoming unsafe to eat. It is recommended that the refrigerator be used at the
factory preset temperature. (3°C in the refrigerator and -18°C)
PRODUCTS DURATION
REFRIGERATOR FREEZE
EGGS
Fresh egg with shell
Raw yolks
Boiled egg
Closed pasteurized liquid egg
3 - 5 weeks
2 - 4 days
1 week
3 days
DO NOT FREEZE
1 YEAR
DO NOT FREEZE
DO NOT FREEZE
HAMBURGER MEAT
Meat for hamburgers and
stews from meats
Ground turkey, beef, pork,
lamb
1 - 2 days
1 - 2 days
3 - 4 months
3 - 4 months
HAM, HOT DOGS AND COLD MEATS
Ham, fully cooked, whole.
Ham, fully cooked, sliced.
Hot dogs, open package
Hot dogs, closed package
7 days
1 week
1 week
2 weeks
1 - 2 months
1 - 2 months
1 - 2 months
1 - 2 months
PRODUCTS DURATION
REFRIGERATOR FREEZE
SOUPS AND STEWS
Added vegetables or meat
and their mixtures 3 - 4 days 2 - 3 months
BACON AND SAUSAGES
Bacon
Raw sausages from
pork, beef, chicken
or turkey
7 days
1 - 2 days
1 month
1 - 2 months
FRESH MEAT
Steaks
Chops
Roasts
3 - 5 days
3 - 5 days
3 - 5 days
6 - 12 months
4 - 6 months
4 - 12 months
LEFTOVER MEAT
Cooked meats and meat
de carne dishes
Meat broth and sauce
3 - 4 days
1 - 2 days
2 - 3 months
2 - 3 months

20
USEFUL TIPS
To avoid food contamination, please follow the instructions below:
• Purchase the product before the expiration date.
• Follow the recommendations for handling the product.
• Keep meat and poultry in its package until just before use.
• If you freeze meat and poultry in its original package for more than 2 months, wrap these packages with airtight
aluminum foil, plastic wrap or freezer paper; or place the package inside a plastic bag.
• Prolonged door openings are susceptible to significant temperature increases in refrigerator compartments.
• Regularly clean food contact surfaces and accessible disposal systems.
• Clean water containers if they have not been used for 48 hours; clean the distribution system connected to the
water supply network if the water has not been removed for 5 days.
• Store raw meat and fish in appropriate containers in the refrigerator so that they do not come into contact with
each other or drip on each other.
• If the refrigerator remains empty for a prolonged period, disconnect it by defrosting, cleaning, drying and leaving
the door open to prevent the development of mould inside the appliance.
• If the refrigerator is temporarily out of use, we recommend that you empty it, disconnect it and when you use it
again, leave it on for 12 hours and then open it and put it away.
COOKED POULTRY, LEFTOVERS
Fried chicken
Cooked poultry meals
Chicken nuggets, pasties
3 - 4 days
3 - 4 days
3 - 4 days
4 months
4 - 6 months
1 - 3 months
PRODUCTS DURATION
REFRIGERATOR FREEZE
FRESH POULTRY MEAT
Whole chicken or turkey
Chicken or turkey parts
1 - 2 days
1 - 2 days
1 year
9 months
FISH AND SEAFOOD
Lean fish
Fish with fat
Cooked fish
Fresh shrimp, scallops,
crabs, squid
Open canned seafood
1 - 2 days
1 - 2 days
3 - 4 days
1 -2 days
3 - 4 days
6 - 8 months
2 - 3 months
4 - 6 months
3 - 6 months
2 months
PRODUCTS DURATION
REFRIGERATOR FREEZE
FROZEN DESSERTS
Ice cream
Frozen desserts
Frozen fruits and
vegetables
Should not be
stored in the
refrigerator should
be stored in the
freezer only
Should not be
stored in the
refrigerator should
be stored in the
freezer only
Should not be
stored in the
refrigerator should
be stored in the
freezer only
2 - 3 months
6 months
1 year
