French Door Refrigerator
E23BC78IPS professional series
23 CU.FT. COUNTER-DEPTH
FRENCH DOOR REFRIGERATOR
CAPACITIES
Total Capacity
Fresh Food Volume
Freezer Volume
Total Shelf Area
Fresh Food Shelf Area
Freezer Shelf Area
EXTERIOR
Professional Doors and Handle Design
Wave-Touch™Electronic Controls
Door Hinge Covers
Ice/Water Dispenser
Custom-Set™Temperature Control System and Display
Crushed/Cubes/Water
Air and Water Filter Indicator/Reset
Ice Maker On/Off
Fast Freeze™
Lock
Dispenser Light Control
FRESH FOOD CONVENIENCES
PureAdvantage®Water & Ice / Air Filtration
Water Filter Location
Temp Alarm System / Door Ajar Alarm / Power Failure Alarm
Custom-Design™Glass Shelves
Smooth-Glide™Humidity-Controlled Left Crisper
Smooth-Glide™Humidity-Controlled Right Crisper
Custom Temp Drawer™
Wine Rack
Clear Gallon Adjustable Door Bins
Clear 1/2-Gallon Adjustable Door Bins
Clear 2-Liter/1/2-Gallon Removable Door Bins
Locking Clear Utility Bin
Tilt-Out Can Racks
Theatre Ramp-Up Multilevel Lighting – LED
Automatic Ice Maker
FREEZER CONVENIENCES
Self-Closing Drawer
Sliding Full-Width Freezer Baskets
Plastic Basket Tray
Tilt-Out Wire Door Racks
Theatre Ramp-Up Multilevel Lighting – LED
ADDITIONAL FEATURES
ENERGY STAR®
Sabbath Mode (Star-K®Certified)
SPECIFICATIONS
Overall Exterior Dimensions –
Height (with Hinges and 3/8" Rollers)
Width
Depth (Including Handle)
(with 90° Doors Open)
(with Drawer Fully Extended)
Power Supply Connection Location
Water Inlet Location
Voltage Rating
Connected Load (kW Rating)@120 Volts ‡
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
‡An electrical supply with grounded three-prong receptacle is required. The power supply
circuit must be installed in accordance with current edition of National Electrical Code
(NFPA 70) and local codes & ordinances.
1Under normal conditions – 0°F freezer, 37°F fresh food and based on bottom freezer models
with exterior ice and water and a suggested MSRP greater than $2700.
NOTE: Always consult local and national electric and plumbing codes. Refer to Product
Installation Guide for detailed installation instructions on the web at electroluxicon.com.
Specifications subject to change.
22.6 Cu.Ft.
15.7 Cu.Ft.
6.9 Cu.Ft.
26.45 Sq.Ft.
18.72 Sq.Ft.
7.7 Sq.Ft.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bottom Left
Yes
3 Half Width
1 Quarter Width
Yes
Yes
Yes
Yes
1
1
2
Yes
2
Yes
Yes
Yes
3 Smooth-Glide™
(2 with Dividers)
1
1
Yes
Yes
Yes
69-1/2"
35-5/8"
29-1/2"
42-9/16"
44-1/2"
Right Bottom Rear
Left Bottom Rear
120V/60Hz/15 or 20A
1.02
15
341 Lbs.
Custom Temp Drawer™
Features 9 preset selections including
White/Sparkling Wine, Fish/Shellfish, Snacks
and Chilled Beer, plus three customizable '
My Favorites', giving you an array of choices
to store or serve whatever you want at the
ideal temperature.
Custom-Design™Organization System
Our tri-level freezer organization system features
three Smooth-Glide™baskets with removable
dividers and top removable baskets, so you can
keep food organized and easily at hand.
Twice the Ice
You get filtered, restaurant-quality ice featuring
a new drink-friendly shape, twice the ice as
any refrigerator ice maker1— up to 9 pounds
in 24 hours.
PureAdvantage®Filtration Systems
Our filtration system keeps clean, filtered air
circulated throughout to prevent odor transfer
and keeps fresh, clean water and ice at
your fingertips.
Replacement Water Filter – PN# EWF01
Replacement Air Filter – PN# EAFCBF

French Door Refrigerator
E23BC78IPS professional series
High standards of quality at Electrolux Home Products, Inc. mean we are
constantly working to improve our products. We reserve the right to change
specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287) •
electroluxicon.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxicon.ca
E23BC78IPS 09/09 © 2009 Electrolux Home Products, Inc. Printed in the U.S.A.
B
C
A
“Built-In Look” Cutout Dimensions
(A) 70 1/4" (B) 36" (C) 25"
Top View
24"
Cabinet
25"
Countertop
Recessed
water line Recessed electrical outlet
25"Side Panels,1/2"min. width
Allow 1" min. clearance at rear
for proper air circulation and
water/electrical connections
Standard Depth
Standard
Refrigerator Depth
vs. Counter Depth
235/8"
Counter Depth
281/2"
68 3/16"
with
3/8"
rollers
26 7/8"355/8"
69 1/2"
with
3/8"
rollers
Power
cord
location
(right
bottom
rear)
Water
line inlet
location
(left
bottom
rear)
47/8"
42 9/16"(with doors
90°open)
23 5/8"
44 1/2"
(with drawer
fully extended
including handle)
291/2"
Counter-Depth French Door Refrigerator Specifications
•
Product Weight – 348 Lbs.
•
An electrical supply with grounded three-prong receptacle is required.The
power supply circuit must be installed in accordance with current edition
of National Electrical Code (NFPA 70) and local codes & ordinances.
•
Voltage Rating –120V/60Hz/15 or 20 Amps
•
Connected Load (kW Rating) @120 Volts = 1.02kW
•
Amps @120 Volts = 8.5 Amps
•
Always consult local and national electric & plumbing codes.
•
Floor should be level surface of hard material, capable of supporting fully
loaded refrigerator.
•
When installing refrigerator adjacent to wall, cabinet or other appliance
that extends beyond front edge of unit, 20" minimum clearance
recommended to allow for optimum 120° to 180° door swing, providing
complete drawer/crisper access and removal. (Absolute 4-1/2" minimum
clearance will ONLY allow for 90°door swing which will provide
drawer/crisper access with restricted removal.)
•
To ensure optimum performance, avoid installing in direct sunlight or
close proximity to range, dishwasher or other heat source.
•
For proper ventilation, front grille MUST remain unobstructed.
•
Recess electrical outlet when possible.
•
Water recess on rear wall recommended to prevent water line damage.
•
Water Pressure – Cold water line must provide between 30 and 100
pounds per square inch (psi).
•
Copper tubing with 1/4" O.D. recommended for water supply line with
length equal to distance from rear of unit to household water supply line
plus 7 additional feet. Optional Water Supply Installation Kits available.
•
Adjustable front rollers to assist with door alignment.
“Built-In Look” Specifications
•
Minimum opening of 70-1/4"H x 36"W x 25"D required to allow for ease
of installation, proper air circulation, and plumbing/electrical connections.
•
Remove all wall/floor molding prior to installation.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxicon.com for detailed instructions.
