IOGear GWP511 User manual

Wireless-G
Notebook Network Card
GWP511 Quick Start Guide
Read this guide thoroughly and follow the installation and operation procedures
carefully to prevent any damage to the unit and/or any of the devices it connects to.
GWP511 package contains:
1 802.11g PC Card
1 Quick Start Guide
1 Installation & Manual CD-ROM
1 Warranty/Registration Card
Copyright © 2003 IOGEAR®
All brand names and trademarks are the registered
property of their respective owners
PKG-M0092/QS ®

Thank you for choosing IOGEAR®to serve your wireless needs. In no time you will be sharing files
or surfing the Internet wirelessly. We hope you will have as much fun using your IOGEAR®
Wireless-G Notebook Network Card, as we had designing it.
Rest assured, your IOGEAR®Wireless-G Notebook Network Card is built rock-solid to ensure
maximum up-time for you to stay up-and-running. If for any reason you have a problem, we stand
behind our products with an industry-leading 3 year factory warranty, so you can have peace-of-
mind with your current and future IOGEAR®purchases.
We want you to be happy with your purchase, so we have made every effort to ensure product
quality, reliability, and ease-of-use.
Note:
Your order has been carefully packaged and inspected, and we hope you are pleased with the
IOGEAR®product you purchased. Please inspect the contents of the package to ensure that you
have received all items and that nothing has been damaged. If you discover a problem, please
contact your dealer immediately for assistance.
Contact Information:
949-453-8782
23 Hubble
Irvine, CA 92618
USA
www.iogear.com
[e-mail]
2. Hardware Requirements & Features
1. Welcome
Requirements
• Pentium® class notebook computers with one available Cardbus slot
• Microsoft Windows 98SE/ME/2000/XP
• CD-ROM Drive
Features
• Turn-key Installation - Up and running in minutes!
• 54 Mbps wireless connection speed -- up to five times faster than 802.11
• Sleek, low profile antenna is designed for maximum reception
• 802.11b (11Mbps) and 802.11g (54Mbps) Compatible - Nothing is obsolete!
• Solid 3-year manufacturer warranty -- built to last!

3. Installation
Step. 1
Step. 3
The Installation software will search your machine for any existing 802.11g installations. This is to
ensure proper installation of the IOGEAR®11g Network Adapter Cad.
Insert the IOGEAR CD-ROM into your computer's CD-ROM drive. A Window will pop-up, displaying
the installation prompt.
The Welcome screen - Click Next
Step. 2
NOTE: You must run the installation software before you install the IOGEAR®11g Network Adapter Card.

Click finish. After the Installation software has completed setting up your machine, you may insert the
IOGEAR®11g Network Adapter Card into your notebook computer. The New Hardware Wizard will
appear. Click Next.
Windows will find the card in your machine. Select Search for a suitable driver for my device
(recommended), then click Next.
Step. 6
Select only "Specify a location", then click Next.
Step. 5
Step. 4

Click the Browse button.
Step. 7
Select the Look in pull-down menu, then select the IOGEAR CD-ROM.
Step. 8
Select the Driver folder.
Step. 9

Step. 10
Select the .INF Driver, then select Open.
Step. 11
Click OK.
Step. 12
Windows will now install the IOGEAR®11g Network Adapter Card.

Step. 13
Step. 14
You have completed the installation. Click Finish.
Windows will now ask you to see a list of nearby, available networks. Click on the yellow balloon.
Step. 15
Select which network you wish to use, then click Connect.
Please refer to the manual in CD-ROM for operation details and wireless utilities.

4. Radio and TV Interference
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation
IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID FOR
THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION.
The direct vendor makes no warranty or representation, expressed, implied, or statutory with
respect to the contents or use of this documentation, and especially disclaims its quality,
performance, merchantability, or fitness for any particular purpose.
The direct vendor also reserves the right to revise or update the device or documentation without
obligation to notify any individual or entity of such revisions, or update. For further inquiries,
please contact your direct vendor.
5. Warranty
IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT,
DISK, OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE PRODUCT.
The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect
to the contents or use of this documentation, and especially disclaims its quality, performance,
merchantability, or fitness for any particular purpose.
The direct vendor also reserves the right to revise or update the device or documentation without
obligation to notify any individual or entity of such revisions, or updates. For further inquiries please
contact your direct vendor.
