iolloi TH213-ES010 User manual

USER GUIDE
TH213-ES010
Download the App
Manual Languages:
English / Deutsch / français / Spanish

WiFi Thermostat
2-17
18-33
34-49
3-8
9-15
19-24
25-31
35-40
41-47
Thermostat feature & oper
APP Oper
APP-Bedienung
English
Deutsh
français
50-65
51-56
57-63
Función y operación del termostato
Operación de la aplicación
Español

Technical Data
Dimension
86mm
86mm
13mm
39mm
100-240VAC, 50/60HZ
16A
＜1.5W
NTC 10k B :3950K
Power Supply:
Current Load:
Sensor:
±1°C
5~35°C
86*86*13mm
PC+ABS(flame retardant)
Accuracy:
Set Temp Range:
Size:
Shell Material:
25/50
03
WiFi Thermostat
Manual Languages:
English / Deutsch / français / Spanish
In the box you will find
Thermostat 1pc
Screws 2pcs
User Guide 1pc

Connect to the heat
device (load)
L line
N line
Connect to the external
sensor
TH213-Electric is for electric
1/4:
2:
3:
5/6:
Wiring Diagram
load
Power
Supply
Installa n
1.
2.
Cut off power supply
Connect the terminals to right wires according the wiring
diagram.See a
ress box with screws.
See b
Fix the display panel to the plate. See c
The thermostat fits for Standard
ress box or UK 86mm
ress box.
3.
4.
5.
Remov by screw driver, pls be careful,
do not damage the temperature sensor.
05
CAUTION
High Voltage. The thermostat should be installed
by an authorised electrician.
You will be working with mains voltage, so please

Switch mode
Power on or off
Increase the temperature
Decrease the temperature
Enter the pairing WiFi mode
Press ‘ ’ & ‘ ’ for 3s to lock or unlock
Other Oper
a. External & Internal Temperature Check:
Long press the ‘ ’ and ‘ ’ to switch the internal temperature
or the external temperature.
b. Temperature Pr Warning:
When the temperature is higher than the pr value, ‘ ’
will flash, the heater stops working, and adjust the temperature
to 2℃lower of the pr value, ‘ ’ will stop flash and the
pr
c. ERR Ex ：
When the ‘ ’ light up, it means the sensor mode was wrong or
the sensor was broken. And the temperature value in the screen
will show ‘ -- ’.
Press ‘ ’ :
Press ‘ ’ 3s:
Press ‘ ’ ：
Press ‘ ’ :
Press ‘ ’ 3s:
‘ ’ ‘ ’:
Home Screen Quick Reference
MANUAL
WINDOW OPEN
ad
b
Increase
Decrease
&
Pairing
c
Mode
On&Off
a
b
c
Current Temperature
Target Temperature
rt
Fr t：
d
Loading, Lock, Cloud
07
WUTO
HOWE AWAY

When the thermostat is power on, long press the ‘ ’ and ‘ ’ (5s),
pr ress ‘ ’ or ‘ ’ to select.
Advanced Se Connect to the Internet
3Sensor type
00: Internal 01: External 02: Internal & External. Default is 00
4High temperature pr
20~90℃, Default is 28℃SSS, ‘ -- ’ Cancel the pr You can get it on Google play or
Download on the Apple Store .
5
6
7
8
9
10
1 2
11
12
13
Swing: 1-9 ℃，Default 2 ℃
Temperature calibr ：-9℃~+9℃, Default is 0℃
35~90℃, Default is 35℃
Highest target temperature:
Lowest target temperature: 0~30 ℃, Default is 5℃
Home mode target temperature: Default is 22℃
Away mode target temperature: Default is 15℃
System restart:
Press ‘ ’ or ‘ ’ to switch the ‘ -- ’ to ‘ == ’ and wait for 5s
Press ‘ ’ or ‘ ’ to switch the ‘ -- ’ to ‘ == ’ and wait for 5s
F
AUTO mode target temperature: Default is 20℃
Window open
1Download the ‘ Smart life ’ APP .
2Register account .
3Connect your thermostat to WiFi .
rt
09
Before you start the Wi-Fi configura on, please note below:
The thermostat works with 2.4 GHz Wi-Fi,but not works with 5
GHz Wi-Fi. Before using it, Please configure WiFi signal and
ngs through App with smartphone or tablet.

Turn on the thermostat, long press ‘ ’ key for 3s, ‘ ’ will keep
flashing quickly.
On APP
On your thermostat
Click ‘ ’ on upper right corner of the main page, then select ‘Small
home A...’ in le your figure to choose device type
‘ Thermostat ’ in right side.
Then select the WIFI network
and input ‘password’ of the
WIFI network and click ‘Next’
in the App page. The therm-
ostat wil be connected aut-
ly.
11
xxxx x x
Power on/off
Increase or decrease the set
temperature .
Programming your thermostat in App
Click to change modes:
Home, Away, Smart(Auto),Sleep.
Click to parameters and
program .

Select ‘ Share Device ’ and click‘Add Sharing ’to enter the account you
want to share.
You can s ee the sharing account
you have s ent and the device
you have shared in this page.
You can add as ma ny as rooms
you want.
How to share your device with your family member?
Home management
Click ‘ ’ on right bottom corner
of the thermostat home page.
Then you can ‘Creat a home’ or
‘ Join a home’ in ‘Home Manage-
ment’ .
13
Schedule Se
ermostat home page
in App. Then enter “Program”
to set schedule.
How to create a group?
Click ‘ ’ icon on upper right
corner of the thermostat home
page, then click ‘Creat Group ’
to include thermostats you want
as a group.
The one who creats this group can
control all rooms of the group
e.

Click ‘ ’ on right b m corner of the thermostat homepage .
Then enter ‘More Service ’ to
integrate to third-p arty service
like Alexa, Google Assistant,
etc. Then follow the oper n
steps as prompts.
‘ Alex
‘ Alex rees ’
How to connect your device to Amazon
Echo or Google Home？
For example, you can say:
Ao ng your App acount
to your Amazon account allows
you to control this WiFi thermostat
through Amazon Echo s peakers.
(Or Google Assistant, or Tmall
Genie)
You can use voice assistant to
control the thermotats.
15

FAQ
Q: Can I control m
A: You can contr e, etc by Electric
series thermostat(100-230Vac, 16A).
Q: Can I control water hea ng valve actuator with this thermostat?
A: You can control valve actuator with Water series
thermostat(100-230Vac, 3A).
Q: Can I control boiler with this thermostat?
A: Boiler series thermosat provides volf-free contact signal for
boiler(note: it provide only volt-free signal).
Q: What type of pa ress box suits for this thermostats?
A: 60mm European standar ress box.
Q: Can I control all thermostats at the sa n App.
A: Yes, you can creat group to control the thermostat
simultaneously.
