ION SUPERSIGHT User manual

SUPERSIGHT
Quickstart Guide English ( 3 – 8 )
Guía de inicio rápido Español ( 9 – 13 )
Guide d'utilisation rapide Français ( 14 – 18 )
Guida rapida Italiano ( 19 – 23 )
Schnellstart-Anleitung Deutsch ( 24 – 28 )
Snelstartgids Nederlands ( 29 – 33 )
Appendix English ( 34 )

3
Quickstart Guide (English)
Introduction
Box Contents
Make sure that the items listed below are included in the box:
•SUPERSIGHT
•Mini USB Cable
•Cleaning Cloth
•Carrying Bag
•3 AAA Alkaline Batteries
•Quickstart Guide
Support
For the latest information about this product (system requirements, compatibility information,
etc.) and product registration, visit ionaudio.com.
For safety/warranty information, visit ionaudio.com/warranty

4
Safety Notes
•Keep SUPERSIGHT away from wet areas, rain, and other liquids. Do not submerge in
water.
•Clean only with a dry cloth.
•Do not attempt to repair SUPERSIGHT or open its case. This product contains no user
serviceable parts.
•Always operate SUPERSIGHT in a place where the temperature is between 32°F / 0°C and
113°F / 45°C.
•Store SUPERSIGHT in a cool, dry place at normal room temperature.
•Do not attempt to force any connector into the unit’s mini USB and micro SD port. All
appropriate connectors should fit easily into the port.
Correct Disposal of This Product: This marking indicates that this product should
not be disposed with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and collection systems
or contact the retailer where the product was purchased. They can take this product
for environmentally safe recycling.
Disposing of General Purpose & Alkaline Batteries:
•Alkaline batteries can be safely disposed of with normal household waste. Never dispose
of batteries in fire because they could explode.
•Alkaline batteries are composed primarily of common metals—steel, zinc, and
manganese—and do not pose a health or environmental risk during normal use or
disposal.
•It is important not to dispose of large amounts of alkaline batteries in a group. Used
batteries are often not completely “dead.” Grouping used batteries together can bring
these “live” batteries into contact with one another, creating safety risks.
•Proven cost-effective and environmentally safe recycling processes are not yet universally
available for alkaline batteries. Some communities offer recycling or collection of alkaline
batteries. Contact your local government for disposal practices in your area.

5
FCC Notice:
You are cautioned that changes or modifications not expressly approved by the part
responsible for compliance could void the user's authority to operate the equipment. This
equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
a. Reorient or relocate the receiving antenna.
b. Move this unit.
c. Increase the separation between the equipment and receiver.
d. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
e. Be sure that all cables are properly shielded, using a choke or ferrite where appropriate.
f. Consult the dealer or an experienced radio/television technician for help.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.

6
Features
1. Display: Shows what the lens is viewing.
Note: The display comes with a plastic protector on it.
Remove this for optimal viewing.
2. Magnify: Press this button to cycle through the 4 levels
of magnification: 5X, 6X, 7.5X, or 10X.
3. Contrast Setting: Press this button to cycle through the
3 different contrast settings: full color, enhanced
positive image, or enhanced negative image.
4. Freeze/Unfreeze/Forward: When in Reading
Mode, press this button to freeze/unfreeze the
image on the screen. When in Playback mode,
press this button to advance through the saved
images on the micro SD card.
5. Snapshot: Press this button to save the image seen on
the screen to a micro SD card.
6. Playback: Press the Folder button to view images
saved to the card.
7. Backward: When in Playback mode, press this button
to scroll through the saved images on the micro SD
card.
8. Mini USB port: Connect the included mini USB cable from SUPERSIGHT to a computer
to view the images saved to a micro SD card.
9. Micro SD card slot: Insert a micro SD card here to save a photo of what is seen on the
screen to a micro SD card by pressing the Snapshot button.
10. Power On/Off: Press this button to power SUPERSIGHT on or off.
Note: SUPERSIGHT will power off if it is not used after 15 minutes.
11. LED: These lights illuminate what is placed in front of the lens.
12. Lens: Place your text under this to view the image on the screen.
13. Battery Compartment: Install 3 AAA batteries here to power SUPERSIGHT.
14. Kickstand: Use this to support the unit at an ideal monitoring angle when taking
snapshots.
10
89
USB MICRO SD
11
12
13 14
FREEZE
SUPERSIGHT
2
3
4
5
6
7
1

7







Using SUPERSIGHT





Installing Batteries



1. Slightly push on the latch and pull up on the door to
open the battery compartment. 
2. Load the batteries in the proper direction as shown
inside the compartment and close the battery door.
Note: Remove the alkaline batteries when SUPERSIGHT will
not be used for a long period of time. Rechargeable AAA alkaline or
NI-MH batteries can be used however do not mix and match
different battery types together.
Note: If the battery level is low, a black battery symbol will appear in
the lower right corner of the screen, indicating the batteries need to
be replaced.
Importing Images to a Computer
1. Power on SUPERSIGHT.
2. Connect the included mini USB cable from SUPERSIGHT to your computer’s USB port.
When connected, the SUPERSIGHT screen will go to USB connection mode.
3. On Windows, go to your Computer drives section to locate the micro SD card, which will
appear as a removeable drive. On Mac OS X, the micro SD card will appear as a
removeable drive on the desktop.
4. Double click the removeable drive icon and open the DCIM folder to locate your photos.

8
Troubleshooting
If you experience any difficulties, please refer to the troubleshooting steps below.
PROBLEM SOLUTION
The screen is blank.
Ensure the power is on.
Ensure fresh batteries are installed.
Verify the text you want to magnify is positioned correctly
under the center of the screen.
The unit does not power on.
Ensure fresh batteries are installed.
Ensure the batteries are installed in the correct position.
The image on the screen is
dark and/or distorted.
Ensure the unit is positioned flat on the page you are
reading.
Ensure that the kickstand is fully extended.
There are smudges or
blemishes on the screen.
Ensure the plastic protector has been removed from the
screen for optimal viewing.
Clean the screen or the lens (located on the bottom of the
unit) using the included cleaning cloth.
The text is too small to read. Press the magnify button.

9
Guía de inicio rápido (Español)
Introducción
Contenido de la caja
Asegúrese de que todos los elementos abajo indicados estén incluidos en la caja.
•SUPERSIGHT
•Cable mini USB
•Paño de limpieza
•Bolso de transporte
•3 pilas alcalinas AAA
•Guía de inicio rápido
•Manual sobre la seguridad y garantía
Soporte
Para obtener la información más reciente acerca de este producto (requisitos de sistema,
información de compatibilidad, etc.) y registrarlo, visite ionaudio.com.
Para información acerca de la seguridad y la garantía, visite ionaudio.com/warranty.

10
Notas sobre la seguridad
•Mantenga al SUPERSIGHT alejado de superficies húmedas, lluvia y otros líquidos. No lo sumerja en
agua.
•Límpielo sólo con un paño seco.
•No intente reparar el SUPERSIGHT ni abrir su carcasa. Este producto no contiene piezas reparables.
•Utilice siempre el SUPERSIGHT en un lugar en donde la temperatura de entre 32°F / 0° C y 113° F / 45°
C.
•Almacene el SUPERSIGHT en un lugar fresco y seco a temperatura ambiente normal.
•No intente insertar a la fuerza ningún conector en el puerto mini USB y micro SD de la unidad. Todos los
conectores apropiados deberían entrar fácilmente en el puerto.
•Precaución: Peligro de explosión si las pilas no se reemplazan correctamente. Reemplace las pilas
solamente con otras del mismo tipo o uno equivalente. No exponga a las pilas a calor excesivo, como
por ejemplo, luz solar, fuego, etc.
Disposición final correcta de este producto: Esta marca indica que ese producto no debe
desecharse junto con otros desperdicios domésticos en toda la Unión Europea. Para evitar
posibles daños al medio ambiente o a la salud humana debidos a la disposición final sin control de
los residuos, recíclelo responsablemente a fin de promover la reutilización sustentable de los
recursos materiales. Para devolver su producto usado, use los sistemas de devolución o
recolección o póngase en contacto con el comercio minorista donde adquirió dicho producto. El
mismo puede recibir este producto para un reciclado ambientalmente seguro.
Disposición final de las pilas de propósitos generales y alcalinas
•Las pilas alcalinas pueden desecharse en condiciones seguras con los residuos domésticos normales.
Nunca deseche las pilas en el fuego porque pueden explotar.
•Las pilas alcalinas están compuestas primariamente de metales comunes —acero, zinc y manganeso— y
no representan un riesgo para la salud o el medio ambiente durante el uso normal o la disposición final.
•Es importante no desechar grandes cantidades de pilas alcalinas en grupo. Las pilas usadas a menudo
no están completamente "agotadas". Si se agrupan pilas usadas, estas pilas "activas" pueden entrar en
contacto entre sí y crear riesgos para la seguridad.
•No se dispone aún a nivel universal de procesos de reciclado probados, rentables y seguros para el
medio ambiente aplicables a las pilas alcalinas. Algunas comunidades ofrecen el reciclado o recolección
de pilas alcalinas. Comuníquese con su gobierno local para conocer las prácticas de disposición final
vigentes en su área.
