IR 2130AP User manual

1 Form P7727, Edition 2
Instructions For
Model 2130AP Super Duty
Automotive Impact Wrench
NOTICE
The 2130AP series of Impact Wrenches are designed for use in general automotive repair, tire service and heavy
duty fleet applications.
WARNING
• IMPORTANT SAFETY INFORMATION ENCLOSED - SAVE THESE INSTRUCTIONS
• READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THIS PRODUCT
• IT IS YOUR RESPONSIBILITY TO MAKE THIS SAFETY INFORMATION AVAILABLE TO
OTHERS THAT WILL OPERATE THIS PRODUCT
• FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY
PLACING TOOL IN SERVICE
• Always install, operate, inspect and maintain
this product in accordance with all applicable
standards and regulations (local, state,
country, federal, etc.).
• Always use clean, dry air at 90 psig (6.2 bar/620
kPa) maximum air pressure at the inlet. Higher
pressure may result in hazardous situations
including excessive speed, rupture, or incorrect
output torque or force.
• Be sure all hoses and fittings are the correct
size and are tightly secured. See Dwg. TPD905-
2 for a typical piping arrangement.
• Ensure an accessible emergency shut off valve
has been installed in the air supply line, and
make others aware of its location.
• Do not use damaged, frayed or deteriorated air
hoses and fittings.
• Keep clear of whipping air hoses. Shut off the
compressed air before approaching a whipping
hose.
• Always turn off the air supply, bleed the air
pressure and disconnect the air supply hose
before installing, removing or adjusting any
accessory on this tool, or before performing any
maintenance on this tool or any accessory.
• Do not lubricate tools with flammable or
volatile liquids such as kerosene, diesel or jet
fuel. Use only recommended lubricants.
• Use only proper cleaning solvents to clean
parts. Use only cleaning solvents which meet
current safety and health standards. Use
cleaning solvents in a well ventilated area.
• Keep work area clean, uncluttered, ventilated
and illuminated.
• Do not remove any labels. Replace any dam
aged label.
USING THE TOOL
• Always wear eye protection when operating or
performing maintenance on this tool.
• Always wear hearing protection when operating
this tool.
• Always use Personal Protective Equipment
appropriate to the tool used and material
worked. This may include dust mask or other
breathing apparatus, safety glasses, ear plugs,
gloves, apron, safety shoes, hard hat and other
equipment.
• When wearing gloves always be sure that the
gloves will not prevent the throttle mechanism
from being released. This tool is not designed
for working in explosive environments,
including those caused by fumes and dust, or
near flammable materials.
• This tool is not insulated against electric shock.
• Prevent exposure and breathing of harmful
dust and particles created by power tool use.
Some dust created by power sanding,
sawing, grinding, drilling and other
construction activities contains chemicals
known to cause cancer, birth defects or other
reproductive harm. Some examples of these
chemicals are:
- lead from lead based paints,
- crystalline silica from bricks and cement
and other masonry products, and
- arsenic and chromium from chemically
treated lumber.
Your risk from these exposures varies,
depending on how often you do this type of
work. To reduce your exposure to these
chemicals: work in a well ventilated area,
and work with approved safety equipment,
such as those dust masks that are specially
designed to filter out microscopic particles.
Form P7727-1
Edition 2
January, 2004
CCN 04589445
EN
Refer All Communications to the Nearest
Ingersoll-Rand Office or Distributor.
© Ingersoll-Rand Company 2004
Printed in China

Form P7727 Edition 2 26
EXPLODED VIEW
Model 2130AP

27 Form P7727 Edition 2
PARTS LIST
Model 2130AP
ITEM DESCRIPTION PART # ITEM DESCRIPTION PART #
* Housing Assy ................................................... 2130AP-A40 24 Inlet Parts Kit ................................................... 2131-K303
1 Housing ................................................. ----- 24A Washer.................................................... -----
3 Nameplate/Warning Label .................... ----- 24B O-Ring, Seal........................................... -----
2Screw, HammerCase (4 required) ................... 2130-638 24C Spring ..................................................... -----
3Nameplate/Warning Label ............................. 2130-AP-301 24D Valve....................................................... -----
4Power Regulator Assy ..................................... 2130-D249 24E Seat......................................................... -----
5Retaining Ring ................................................. 2131-6 24F Support ................................................... -----
6Ball Bearing (2 required) ................................. 402-22 24G Retainer .................................................. -----
7Cylinder ........................................................... 2130-3
8Rotor ................................................................. 2131-53 *Tune-Up Kit....................................................... CR2130-TK1
9Vane Pack (set of 6) ......................................... 2131-42A-6 5 Retaining Ring ...................................... -----
10 End Plate .......................................................... 2131-11 6 Ball Bearing (2) ..................................... -----
11 Rear Cap .......................................................... 2130-12 9 Vane Pack (set of 6)................................ -----
12 Hammer Case Gasket ..................................... 2130-36 12 Hammer Case Gasket ............................ -----
*Impact Mechanism Kit (2130AP) ................... 2130-IMK1 18 Trigger Assy........................................... -----
*Impact Mechanism Kit (2130AP-2) ............... 2130-IMK2 19 Motor Gasket.......................................... -----
12 Hammer Case Gasket ........................... ----- 20 Reverse Valve Assy................................ -----
13 Hammer (2) ........................................... ----- 24 Inlet Parts Kit ......................................... -----
14 Hammer Pin (2) .................................... -----
15 Anvil Assembly .................................... ----- *Inlet Clip Removal Tool ................................... 2131-322
16 Hammer Frame ..................................... -----
* Kit Grease ............................................. -----
17 HammerCase Assy .......................................... 2130-D727A
18 Trigger Assy ..................................................... 2130-D1093
19 Motor Gasket ................................................... 2130-283
20 Reverse Valve Assy .......................................... 2130-D329
21 Reverse Button ................................................ 2130-75
*Inlet Bushing Assy (Includes 22, 23 & 24) .... 2131-D565
22 Inlet Bushing .................................................... 2131-565
23 Inlet Clip .......................................................... 2131-57
When Ordering, use applicable Part Number
