Ironman4x4 IFRIDGE30 User manual

This user guide includes information on the following IceCube Fridge/ Freezer models:
IFRIDGE30 (30L), IFRIDGE40 (40L) and IFRIDGE50 (50L)
USER GUIDE
Instruction Manual
30L
CAPACITY
40L
CAPACITY
50L
CAPACITY
www.ironman4x4.com

2
Dear Customer,
Thank you for purchasing an Ironman 4x4 IceCube Fridge/Freezer. Our fridge/freezer
is an ideal companion for keeping your beverages, refreshments and food refrigerated
while on outback trips, picnics, camping, fishing or shopping trips.
Features:
• Danfoss BD-35F Compressor - The world’s most reliable cooling system.
• The best electronic technology, high efficiency and low energy consumption.
• Multi-Voltage System (DC 12-24V) and (AC 100-120/ 220-240V)
• Automatic Battery Protection
Contents in box:
• IceCube Fridge/Freezer Unit
• 12V/ 24V Power Cable
• 240V Power Cable
Also available separately for this product:
• Heavy Duty Insulated Transit Bag
• Fridge Slide
• Fridge Tie Down Straps
• Ironman 4x4 Dual Battery Kits
IMPORTANT: Before first time use of this unit, you should carefully read these instructions to
familiarise yourself with the correct connection and operations for your fridge.

3
Product Safety............................................................................................................... Page 4
General Notes................................................................................................................ Page 4
Connection .................................................................................................................... Page 5
Operation....................................................................................................................... Page 6
Cleaning and Maintenance ............................................................................................ Page 7
Troubleshooting ............................................................................................................. Page 7
Technical Data
IFRIDGE30 - 30L............................................................................................................ Page 8
IFRIDGE40 - 40L............................................................................................................ Page 9
IFRIDGE50 - 50L............................................................................................................ Page 10
Warranty........................................................................................................................ Page 11
INDEX

4
Product Safety
Do NOT touch exposed cables with your bare hands, this especially applies when operating
the appliance from an AC source.
It is dangerous to touch the plug with wet hands.
When using the refrigerator in a vehicle or boat, make sure that power supply circuit is
properly fused.
The installation of a DC power source should only be handled by qualified persons
Make sure unit is only connected to the correct power supply.
Do not immerse in water.
Do not place any electrical devices inside refrigerator.
General Notes:
Your product requires good ventilation, especially around the back of the refrigerator.
Allow a gap of at least 200mm around the back of unit and approximately a 100mm gap
to the right hand side.
Avoid humidity inside the appliance: Humidity inside the appliance can form frost and impair
cooling. Therefore defrost the unit regularly.
Never clean appliance under running water or in dishwasher.
Avoid placing your refrigerator near a heat source as this will reduce the cooling efficiency.
Place the refrigerator on a flat surface away from edges.
When placing the unit into a vehicle, make sure it is secured properly.

5
Connection
Power: The 12/ 24V and mains power can be present at the same time, the device will always
set itself to the mains power supply as a priority.
Unit must always be connected to an adequate power supply and DC connection must always
be fused.
For cable length and specification, refer to table below.
Cable Area 12V Max Cable Length 24V Max Cable Length
[mm2] AWG [m] [ft.] [m] [ft.]
2.5 12 < 2.5 < 8 < 5 < 16
4 12 < 4 < 13 < 8 < 26
6 10 < 6 < 20 < 12 < 39
10 8 < 10 < 33 < 20 < 66
(AWG - American Wire Gauge)
The length measurement in the above table is from the battery to the refrigerator.
Protection: This unit has an in built automatic low-voltage cutout system, designed to protect
your battery from discharging completely. This will automatically turn off the compressor when
the battery discharges to Cut-Out voltage (See table below). The compressor will automatically
restart when voltage increases to Cut-In (See table below).
IMPORTANT: If your fridge cuts out prematurely, this may be due to the Battery Protection being
set too high. Consider lowering the battery protection level via the switch located
on the rear power panel.
Battery
Protection 12V Cut-Out 12V Cut-In 24V Cut-Out 24V Cut-In
LOW 10.2V 11.2V 21.6V 23.0V
MED 10.7V 11.7V 22.6V 24.0V
HIGH 11.7V 12.7V 24.6V 26.0V

6
Operation
Set Temperature Mode: When the fridge is on, press and hold the SET button and momentarily
press the UP button. The screen will display an ‘F’ for fahrenheit, or ‘C’ for celcius. Press the
UP button to alternate between either mode. The screen display will flicker for 3 seconds, then
auto-save your selection and automatically exit.
Set Temperature Compensation: The temperature compensation setting is used to set the temp
probe and inner cabinet temperature difference, with a range of -10 to +10. When the fridge is
on, press and hold the SET button and momentarily press the DOWN button. The screen will
scroll through the 3 setting variations each time you momentarily press the DOWN button.
F1: -10ºC
F2: 0ºC
F3: +10ºC
Temperature Setting Range: -30˚C~40˚C, -22˚F~104˚F
LED Display Range: -20˚C~45˚C, -40˚F~113˚F
Plug in the DC or AC power. Press the ON/OFF Button to turn the unit on. The LED Display on the
control panel will illuminate and the interior temperature of unit will be displayed.
Press the UP and DOWN to adjust the temperature. Press the UP button to increase the
temperature, or the DOWN to decrease the temperature.
Press the ECO Button to activate the Economy running mode, the ECO indicator light will
illuminate green. Press the button again to activate MAX running mode, the MAX indicator light
will then illuminate red.
ECO Mode: Reduces power consumption and is used once fridge is down to its desired
operating temperature.
MAX Mode: Is used to reduce the internal temperature more rapidly.
NOTE: Fridge will consume more power on this setting.
If power supply is cut off, refrigerator will automatically restart when power supply is restored.
LED Display ECO Indicator Light
Running Mode AdjustmentPower Switch Temperature Adjustment
MAX Indicator Light

7
Cleaning and Maintenance
Clean the unit inside and out with a damp cloth. For more stubborn dirt, sodium bicarbonate
dissolved in lukewarm water may be used.
Never use abrasive products, detergents or soap. After washing rinse with clean water and dry
carefully. Make sure power is disconnected while doing this.
If unit is not being used for long periods of time, do NOT fully close lid. This is to prevent mould
and odours.
Troubleshooting
If unit will not turn on, check:
• Power supply ie. Battery voltage (See Battery Protection table on Page 5)
• Check all connections between battery and fridge
• Check condition of fuse
• Check that the unit is turned on
If contents of fridge are freezing:
• Temperature setting is too low
Poor refrigeration performance:
• Too much food has been placed inside refrigerator
• Temperature of food placed in fridge is too high
• The door is not closed properly
• Door seal is broken
Poor cooling:
• Make sure adequate ventilation room is left around unit (See General Notes Page 4)
• Ambient temperature is extremely high
• Temperature is not set correctly
Sound of water from inside of unit:
• This is normal due to flow of refrigerant
Noise
• Unit is not on a flat or level surface
• Check for vibrations in surrounding objects
CODE ERROR TYPE
E5 Compressor has overheated (Internal temperature too high due to insufficient
airflow)
E3 Compressor motor starter error (Motor blockage, cooling system pressure difference
or low voltage battery
E2 Fan fault
E1 Battery protection stop (Voltage over setting) - Refer to page 5

8
Technical Data
Item No. IFRIDGE30
Approx gross capacity (L) 30L
Supply Voltage (V) 12/ 24 // 100-240
Dimensions (mm)H - 380mm
W - 350mm
L - 585mm
Temp. Range / regulation +10 to -18˚C
Approx. Weight (kg) 16kg
Material CFC free CFC-Free
Insulation PU foam
Interior light LED
Average power consumption 40 Watt
Current draw on 12V
(5C inside, 20C outside) approx. 0.7 Ah/h
Certification GS/ CE/ E certified
Guarantee period 5 year on compressor
3 year on components
Battery protection 3 Stage low voltage protection

9
Technical Data
Item No. IFRIDGE40
Approx gross capacity (L) 40L
Supply Voltage (V) 12/ 24 // 100-240
Dimensions (mm)H - 490mm
W - 350mm
L - 585mm
Temp. Range / regulation +10 to -18˚C
Approx. Weight (kg) 17kg
Material CFC free CFC-Free
Insulation PU foam
Interior light LED
Average power consumption 40 Watt
Current draw on 12V
(5C inside, 20C outside) approx. 0.7 Ah/h
Certification GS/ CE/ E certified
Guarantee period 5 year on compressor
3 year on components
Battery protection 3 Stage low voltage protection

10
Technical Data
Item No. IFRIDGE50
Approx gross capacity (L) 50L
Supply Voltage (V) 12/ 24 // 100-240
Dimensions (mm)H - 530mm
W - 350mm
L - 585mm
Temp. Range / regulation +10 to -18˚C
Approx. Weight (kg) 18.5kg
Material CFC free CFC-Free
Insulation PU foam
Interior light LED
Average power consumption 40 Watt
Current draw on 12V
(5C inside, 20C outside) approx. 0.7 Ah/h
Certification GS/ CE/ E certified
Guarantee period 5 year on compressor
3 year on components
Battery protection 3 Stage low voltage protection

11
Warranty
This fridge/ freezer comes with a 5 year compressor warranty and a 3 year components warranty
from the day of purchase under the following conditions. Any warranty claims exclude parts such
as fuses, connectors, plugs, etc.
• All defects are variably attributable to material or production errors.
• Warranty claim must be made within the warranty period.
• Purchase receipt must be presented with unit warranty claim.
• Improper use of unit will void warranty.
• Warranty will be void if the unit is run with supplementary parts or accessories from other
manufacturers.
• Warranty does not cover fridge content spoilage or loss.
Claims other than the above are not covered by warranty, Ironman 4x4 reserves the right
to repair or replace at our discretion.
For any service issues or warranty claims please contact Ironman 4x4 on our toll-free number
1300 731 137.

30L
CAPACITY
40L
CAPACITY
50L
CAPACITY
www.ironman4x4.com
280916
