BRIEF DESCRIPTION:
The F9000 V2 Mobile Validator is a component of the the F9000 V2 mechatronic
cylinder system operating with Iseo Atlas Master Controller.
The F9000 V2 Mobile Validator is a battery operated portable device that allows the
remote programming of the F9000 V2 keys for Mobile Workforce.
The F9000 V2 Mobile Validator connects to ISEO Atlas Master Controller using the
mobile device (smartphone or tablet) internet connection.
The F9000 V2 Mobile Validator communicates to the mobile device via Bluetooth
Smart.
PRODUCT:
Mobile Validator F9000 V2 - The remote F9000 V2 key programming unit
APPLICATION:
The F9000 V2 Mobile Validator allows Security Manager of remote and unmanned
sites to provide access authorization to a Mobile Workforce of technicians typically
on the move and connected to the office with smartphones or tablets.
THE REMOTE KEY PROGRAMMING PROCESS:
1.Start the Iseo V364 APP
The App links the ISEO Atlas Master controller with the F9000 V2 Mobile Validator:
- Atlas Server to App via Internet Protocol
- App to F9000 V2 Mobile validator via Bluetooth Smart
The App informs the user of the established links (without link it is not possible to update the
F9000 V2 Key).
2. Insert the F9000 key into the Mobile Validator
The F9000 V2 key is programmed.
Audit trail and battery status are uploaded to the ISEO Atlas Master Controller.
The user is informed about the operation result as in the wall or desktop F9000 V2 Validator.
When the key is removed the F9000 V2 Mobile validator goes in sleep mode to save battery.
MOBILE VALIDATOR
TECHNICAL
FEATURES:
Connectivity to Bluetooth Smart
Ready devices with a dedicated
software application available for:
- iOS from iphone 4s with iOS 7
- Android from version 4.3 (Jelly
Bean) featuring Bluetooth Smart
Ready hardware.
Powered with rechargeable lithium
battery (Single cylindrical cell
LiFePo4).
Micro USB Type B connector for
battery recharge via 5V DC external
power supply.
Visual Status signal:
- LED red, LED green.
Acoustic status signal:
- Buzzer.
Environmental characteristics:
- Operating temperature:
-20 °C to + 70 °C
- Storage temperature:
-25 °C to + 75 °C
- Protection System (IP Grading):
IP44.
Dimensions: 50x87x98 mm.
Software upgradable via Bluetooth
Smart or USB channel.
ST F9000 V2 MOBILE VALIDATOR - 02/2017 - Non contractual document. Subject to change.

F9000 V2
www.iseo.com
THESIS 2.0
PC
SMARTPHONE
ATLAS MASTER ATLAS SLAVE
TABLET
F9000 V2 CYLINDER F9000 V2 KEY
F9000 V2 CYLINDERS AND KEYS
MOBILE VALIDATOR
F9000 V2 CYLINDER
F9000 V2 KEY
MOBILE
VALIDATOR
F9000 V2 KEY
F9000 V2 KEY
DESKTOP
VALIDATOR
F9000 V2 KEY
WALL VALIDATOR
READER
ACTUATOR
F9000 V2 KEY
DESKTOP
VALIDATOR
F9000 V2 KEY
WALL VALIDATOR
READER
KEY POINTS
The F9000 V2 Mobile Validator offers
a solution to program from remote
the F9000 V2 Mechatronic keys al-
lowing to:
Change easily geographic access
permissions.
Provide limited time access to loca-
tions or weekly schedules.
Extend automatically the current
validity period for additional
predetermined hour.
Readout events from the user keys.
Get low battery alerts.
