ITALFILE RXJR-2C User manual

PRELIMINARY
2 channel receiver model RXJR-2C compatible with transmitter model JANE-R (red LED)
2 channel receiver model RXJF-2C compatible with transmitter model JANE-F (blue LED)
FEATURES
• 2 channel receiver with 2 relays equipped with OOK / ASK super heterodyne receiver
• microcontroller with decoding functions
• self-learning remote controls
• digital noise reduction filter
• independent mode switching for each channel
• SAW filter to suppress noise outside the band
• power supply with noise reduction filters and surge protection on power lines
APPLICATIONS
Remote control for automation, light switches, blinds, curtains etc.
All programming and configuration of channels carried out using the single
button on the circuit board. The colour of the LED matches the channel:
Green LED: all operations related to channel 1
Red LED: all operations related to channel 2
Orange LED: if both channels are turned on
STORING A JANE on the RX RECEIVER
CHANNEL 1
• Press the button once and release: the green LED lights up
• within 5 seconds make a transmission by pressing the JANE button to be associated with channel 1
• the green LED goes o for 0.5 seconds to confirm learning
• after 5 seconds the green LED goes o indicating the end of the learning phase
CHANNEL 2
• Press the button twice and release: the red LED lights up
• within 5 seconds make a transmission by pressing the JANE button to be associated with channel 1
• the red LED goes o for 0.5 seconds to confirm learning
• after 5 seconds the red LED goes o indicating the end of the learning phase
Each receiver consists of:
1. Double-sided adhesive support
2. Back plate
3. Two stainless steel screws
4. Electronic circuit board
5. Front shell
Signals on the Terminals:
1. power supply input (positive supply)
2. earth (negative supply)
3. common relay output 1
4. contact n.o. output 1
5. common relay output 2
6. contact n.o. output 2
7. aerial shielding
8. aerial input
1 2 4 5
3
Two-colour LED Button
22 mm
51 mm
16.2 mm
Patented product ®
via Spessa, 12/14 - 36051 Creazzo -Vicenza
www.telecomandojane.it
Guarantee: 24 months
Manufacturing and technology: 100% made in Italy
Patented product
Declaration of conformity:
The undersigned, Luigino Pellattiero, legal representative of ITALFILE srl, declares
that the receiver cod. RXJF-2C / RXJR-2C manufactured in 2010, was assembled in
compliance with the following standards:
Directive 2004/108/CE: known as Electromagnetic Compatibility directive
Directive 2002/95/CE: Known as directive RoHS
And therefore complies with current standards.
Luigino Pellattiero - Vicenza (Italy) 1-10-2011
Max. Permissible Values
Supply Voltage 33VAC / 35VDC
RF Input + 20 dBm
GND voltage of output pins 120V
Storage temperature - 40 / + 100 °C
Operating temperature - 20 / + 70 °C
Electrical characteristics at 25 °C:
Parameter Min Typical Max Unit Notes
Supply Voltage (VDC) 12 - 30 volts -
Supply Voltage (VAC) 12 - 28 volts -
Absorbed current (receive only) - 11 - mA -
Absorbed current (1 active channel) - 25 - mA -
Absorbed current (2 active channels) - 36 - mA -
Centre frequency - 433.92 - MHz -
Sensitivity - -105 - dBm Note 1
Passband RF – 3dB - +- 100 - kHz -
Spurious aerial signals - - -60 dBm -
Switch on time - - 2.8 S Note 2
Command implementation time - - 0.5 S Note 3
Max. contact output VDC - - 1A 24V Amp vdc -
Max. contact output VAC - - 1A 120V Amp vac -
Note 1: measurement carried out with 100% AM modulated signal, square wave, at frequency 1 kHz
Note 2: time period between switching on and reception of a valid sequence of data
Note 3: time period between command transmission (remote control button press) and its implementation (relay trip)
Note 4: all measurements relating to the RF parameters are valid with the 3 pin connected to a source or load impedance of 50 ohms

RXJR2C
After having stored the first jane (model jr), the next ones must be programmed using the receiver
RXJF2C
After having stored the first jane (model jf), the next ones can be programmed from each other using self learning without
using the receiver
RXJR-2C can have up to 250 JANE-R commands programmed
RXJF-2C can have up to 250 JANE-F commands programmed
DELETING A JANE FROM THE RX RECEIVER
• Press the button 3 times and release (the first press turns on the green LED, the second the red LED, and the third the
orange LED flashes)
• within 5 seconds make a transmission by pressing the JANE button to be deleted from the RXJ
• the orange LED goes o for 0.5 seconds to confirm the deletion (if the JANE had not previously been stored the deletion
is not reported
• after 5 seconds the LED stops flashing and goes o indicating the end of the deletion phase
SETTING THE CHANNELS
Both channels can be set in the following ways:
• SINGLE FIXED MODE: on receiving a code the output remains active for the duration of the reception of the code
• DUAL FIXED MODE: on receiving a code the output activates if previously it was inactive and vice versa
• TIMED MODE: on receiving a code the output is active for the time set
If the mode is not set on the RXJ the default mode is SINGLE FIXED
SETTING CHANNEL 1 TO SINGLE FIXED MODE
• Press the button once and keep it pressed - the green LED lights up - after 3 seconds the green LED begins to flash rapidly
entering SINGLE FIXED MODE
• Release the button and wait until the LED stops flashing and goes o confirming the mode
SETTING CHANNEL 2 TO SINGLE FIXED MODE
• Press and release the button - the green LED lights up
• press the button a second time and keep it pressed - the red LED lights up – after 3 seconds the red LED begins to flash
rapidly entering SINGLE FIXED MODE
• Release the button and wait until the LED stops flashing and goes o confirming the mode
SETTING CHANNEL 1 TO DUAL FIXED MODE
• Press the button once and keep it pressed - the green LED lights up - after 3 seconds the green LED begins to flash rapidly
entering SINGLE FIXED MODE
• Release the button – press the button a second time within 5 seconds and release – the green LED flashes twice entering
DUAL FIXED MODE – wait for the LED to stop flashing and go out confirming the mode
SETTING CHANNEL 2 to DUAL FIXED MODE
• Press the button and release - the green LED lights up
• press the button a second time and keep it pressed - after 3 seconds the red LED begins to flash rapidly entering SINGLE
FIXED MODE
• Release the button
• Press the button a second time within 5 seconds and release – the red LED flashes twice entering DUAL FIXED MODE
• Wait for the LED to stop flashing and go out confirming the mode
SETTING CHANNEL 1 TO TIMED MODE
• Press the button once and keep it pressed - the green LED lights up - after 3 seconds the green LED begins to flash rapidly
entering SINGLE FIXED MODE
• Release the button
• Press the button a second time within 5 seconds and release – the green LED flashes twice entering DUAL FIXED MODE
• Press and release the button a third time - the green LED begins to flash three times entering TIMED MODE
• Wait for the LED to change to orange – if the button is not pressed again the orange LED goes o confirming TIMED MODE
set to 60 seconds – if the button is pressed again before the orange LED goes o the time will be set to 5 seconds – to set
the time to 20 seconds press the button 4 times in a row - the maximum time which can be set is 20 minutes using 240
key presses
SETTING CHANNEL 2 TO TIMED MODE
• Press the button and release - the green LED lights up
• Press the button a second time and keep it pressed - after 3 seconds the red LED begins to flash rapidly entering SINGLE
FIXED MODE
• Release the button
• Press the button a second time within 5 seconds and release – the red LED flashes twice entering DUAL FIXED MODE
• Press and release the button a third time - the red LED begins to flash three times entering TIMED MODE
• Wait for the LED to change to orange – if the button is not pressed again the orange LED goes o confirming TIMED MODE
set to 60 seconds – if the button is pressed again before the orange LED goes o the time will be set to 5 seconds – to set
the time to 20 seconds press the button 4 times in a row - the maximum time which can be set is 20 minutes using 240
key presses
DELETING ALL JANEs FROM THE RECEIVER MEMORY
• Press the receiver button three times, and keep it pressed
• Wait until the orange LED flashes for 3 seconds and becomes fixed and then goes o - when the orange LED goes o all
memory has been deleted and both channels are set back to SINGLE FIXED MODE
Application Note: Change relay outputs
Instructions for changing relay outputs from Normally Open (N.O.) to Normally Closed (N.C.)
• Cut the path relative to the required channel at the point as shown in figure 1
channel1channel 2
FOUR CHANNEL SOLUTION
RX 1
CHANNEL DIAGRAM
RX 2
1
2
1
2
1
2
3
4
1
RX 1 RX 2
1
2
23
4
1 2
RX 1 RX 2
1
23
4
1 2
1 2
Figure 1: Back of the RXJ PCB
1. Cut the path where indicated by “X”
2. Join where indicated by the dash “-“ using a drop of solder
After cutting the path remember to join the pads using a drop of solder.
