ITC T-6245 User manual
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
OPERATION MANUAL
DIGITALMIXER 6 ZONE
T-6245
PUBLIC ADDRESS SYSTEM
ON
OFF
POWER
T-6245
DIGITAL MIXER 6 ZONE
MUSICMICRO
RECSTOPPLAY
ACTIVEMIC
ZONE5 ZONE6
ZONE1 ZONE2 ZONE3 ZONE4TUNERCDTAPE OUTPUT LEVEL
0 0
0
1 1 1
2 2 2
3 3 3
4 4
4
5 5
5
6 6
6
7 7 7
8 8 8
9 9 9
10 10
10
MASTERBASS TREBLE
0 0
-10 -10
-8 -8
-6 -6
-4 -4
-2 -2+2 +2
+4 +4
+6 +6
+8 +8
+10 +10
MESSAGE RECORDER
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS .......................................................................................3
2. GENERAL DESCRIPTION ....................................................................................5
3. FEATURES ...............................................................................................................5
4. NOMENCLATURE AND FUNCTIONS
4.1 Front Panel ..............................................................................................................6
4.2 Rear Panel..............................................................................................................7
5. OPERATING INSTRUCTIONS...............................................................................8
5. CONNECTIONS .......................................................................................................9
6. APPLICATIONS .....................................................................................................10
8.BLOCK DIAGRAM .................................................................................................11
9.SPECIFICATIONS .................................................................................................12
10.DIMENSIONAL DIAGRAM .................................................................................13
2
Be sure to read the instructions in this section carefully before use.
Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
When Installing the Unit
Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.
Use the unit only with the voltage specified on the
unit. Using a voltage higher than that which is
specified may result in fire or electric shock.
Do not cut, kink, otherwise damage nor modify the
power supply cord. In addition, avoid using the
power cord in close proximity to heaters, and never
place heavy objects -- including the unit itself -- on
the power cord, as doing so may result in fire or
electric shock.
Be sure to replace the unit's terminal cover after
connection completion. Because high voltage is
applied to the speaker terminals, never touch these
terminals to avoid electric shock.
Be sure to ground to the safety ground (earth)
terminal to avoid electric shock. Never ground to a
gas pipe as a catastrophic disaster may result.
Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in the unit falling
down, causing personal injury and/or property
damage.
When the Unit is in Use
Should the following irregularity be found during
use, immediately switch off the power, disconnect
the power supply plug from the AC outlet and
contact your nearest dealer.
Make no further attempt to operate the unit in this
condition as this may cause fire or electric shock.
If you detect smoke or a strange smell coming
from the unit.
If water or any metallic object gets into the unit
If the unit falls, or the unit case breaks
If the power supply cord is damaged (exposure of
the core, disconnection, etc.)
If it is malfunctioning (no tone sounds.)
To prevent a fire or electric shock, never open nor
remove the unit case as there are high voltage
components inside the unit. Refer all servicing to
your nearest dealer.
ITC
ITC
Do not place cups, bowls, or other containers of
liquid or metallic objects on top of the unit. If they
accidentally spill into the unit, this may cause a fire
or electric shock.
Do not insert nor drop metallic objects or
flammable materials in the ventilation slots of the
unit's cover, as this may result in fire or electric
shock.
1.SAFETY PRECAUTIONS
3
An all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in
the electrical installation of the building.
When Installing the Unit
Never plug in nor remove the power supply plug
with wet hands, as doing so may cause electric
shock.
When unplugging the power supply cord, be sure
to grasp the power supply plug; never pull on the
cord itself. Operating the unit with a damaged
power supply cord may cause a fire or electric
shock.
When moving the unit, be sure to remove its power
supply cord from the wall outlet. Moving the unit
with the power cord connected to the outlet may
cause damage to the power cord, resulting in fire or
electric shock. When removing the power cord, be
sure to hold its plug to pull.
Do not block the ventilation slots in the unit's cover.
Doing so may cause heat to build up inside the unit
and result in fire.
Avoid installing the unit in humid or dusty locations,
in locations exposed to the direct sunlight, near the
heaters, or in locations generating sooty smoke or
steam as doing otherwise may result in fire or
electric shock.
When the Unit is in Use
Do not place heavy objects on the unit as this may
cause it to fall or break which may result in
personal injury and/or property damage. In
addition, the object itself may fall off and cause
injury and/or damage.
Make sure that the volume control is set to
minimum position before power is switched on.
Loud noise produced at high volume when power is
switched on can impair hearing.
Do not operate the unit for an extended period of
time with the sound distorting. This is an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
Contact your dealer as to the cleaning. If dust
is allowed to accumulate in the unit over a long
period of time, a fire or damage to the unit may
result.
ITC
If dust accumulates on the power supply plug or in
the wall AC outlet, a fire may result. Clean it
periodically. In addition, insert the plug in the wall
outlet securely.
Switch off the power, and unplug the power supply
plug from the AC outlet for safety purposes when
cleaning or leaving the unit unused for 10 days or
more. Doing otherwise may cause a fire or electric
shock.
SAFETY PRECAUTIONS
4
1. 6 zones sources selection and control function.
2. Build-in 3 record storage, can setting freely to play.
3. Build-in chime generator.
4. 3 CH sources input:1 CH MIC input, build-in optional control, build-in optional control+48V phantom power.
5. 3 CH pre-amp output :MUSIC, MUSIC PAGE, PAGE pre output.
6. 3 Classes priority.
A: Build-in record message (1and 2) Priority: TUNER,CD,MP3.
B: Build-in chime priority: record message(1and 2): TUNER,CD,MP3.
C: Select paging MIC override all audio sources.
7. Build-in voltage output indicator.
8. 485 COM port.
9. Can remember when the power is the current state of partition and audio source status.
3. FEATURES
T-6245 is a digital 6 zone mixer can provide an ideal public address solution from small to big places
such us mosques,schools,hotelsand factoriesto train stadium and air stations.
2. GENERAL DESCRIPTION
5
4.1 FRONT PANEL
1. AUDIO
key switch for audio input channel selection:
Tape, CD, Tuner
2. ZONE(1~6)
buttons for music selection In the 6 different zones
3. OUTPUT LEVEL
Signal level indicator
4. POWER
Power indicator
5. POWER SWITCH
On top of the opening Power
Press the end, power shut down
6. MASTER
Master level control
7. TREBLE
Adjust treble response. Rotate clockwise to increase
treble output and anticlockwise to reduce it.
8. BASS
Adjust bass response. Rotate clockwise to increase
bass output and anticlockwise to reduce it.
4. NOMENCLATURE AND FUNCTIONS
9. MUSIC
Music volume control
10.MICRO
Microphone volume control
11.REC
Key switch Rec message
Three messages of 60 seconds each
could be recorded; for message selection
see switch(13) on rear Panel
12.STOP
Key switch stop message
13.PLAY
Key switch play message for manual activation
14.ACTIVE
Indicator play message
15.MIC
Internal microphone for message recording
134
2
5
6
7
8
9
10
11
12
13
14
15
6
ON
OFF
POWER
MUSICMICRO
RECSTOPPLAY
ACTIVEMIC
ZONE5 ZONE6
ZONE1 ZONE2 ZONE3 ZONE4TUNERCDTAP E OUTPUT LEVEL
0 0
0
1 1 1
2 2 2
3 3 3
4 4
4
5 5
5
6 6
6
7 7 7
8 8 8
9 9 9
10 10
10
MASTERBASS TREBLE
0 0
-10 -10
-8 -8
-6 -6
-4 -4
-2 -2+2 +2
+4 +4
+6 +6
+8 +8
+10 +10
MESSAGE RECORDER
16. AC INLET
Connect to the supplied power cord.
17. Strong cut relay control output "alarm
/normal switch" in the alarm state, the
output DC 24 V level
18. Out mix music page voice
19. Out signal music
20. Remote paging output
21. CONTACT PLAY MESSAGE 1 OR 2
The third message is activated by
Microphone base directly.
22.SWITCH REC MESSAGE:
OFF, 1, 2, 3 .
REC MESSAGE switch to 1,2,3,
1,2,3 represent select storage;
When the switch is in the "OFF",
it means not record
23.SWITCH MESSAGE 1
TIME / CONTINUOS
- 1 TIME:
The recorded message plays only
Once
- CONTINUOS:
The recorded message plays
continuously till the message
contact is kept closed.
NOMENCLATURE AND FUCTIONS
4.2 REAR PANEL
16 17
38 35
18 19 20 21 22 23 24 25 26 27 28 29
36 34 33 32 31 30
24. Switch microphone alarm/normal
the mixer could work without
microphone console BMD6;A simple
microphone base with priority contact
could be connected to XLR microphone
input)
- ALARM:
The voice is simultaneously
distributed in all the 6 zones
- NORMAL:
The voice is distributed only in the
zone selected with front panel
Buttons
25. Volume REC message
26. Volume play message
27. Phantom power select switch
28. Chime volume control
29. Priority control port for BGM and internal chime
30. Remote microphone input interface (RJ 4 5)
. Background music signal input
31. Remote microphone volume control
32. Remote microphone gain adjustment
33. Local microphone gain adjustment
34. Microphone input XLR balanced
35. Audio source interface
36. OUT ZONE (1~6)
37. Emergency signal input audio source
38
7
MUSIC OUT
~230V 50Hz T1AL 250V
PRIORITY
TAPE CD TUNER MICRO
CONSOL
GAIN GAIN
CONSOL
VOLUME
VOLUME
CHIME
OFF
12
3
REC
MESSAGE 1 TIME
CONTINUOS
MESSAGE
NORMAL
ALARM VOL.PLAY
MESSAGE
VOL.REC MIC
+48V
PHANTOM
ZONE 6 OUTZONE 5 OUTZONE 4 OUTZONE 3 OUTZONE 2 OUTZONE 1 OUTOPEN RELE ININ COM ZONE
COM NO1 NO2
PLAY MESSAGE
MIX MUSIC-PAGE OUT
PAGE OUTRELE ZONE CONSOL OUT
123456
37
5.OPERATING INSTRUCTIONS
8
1. When the T-6245 rear panel REC MESSAGE switch to 1,2,3, 1,2,3, respectively, representing the
selected memory, press the T-6245 panel REC button, the indicator (ACTIVE) light from the panel
MIC port input signal to start recording; press the T-6245 panel STOP button to stop recording.
(Each memory can record one minute, store 3 pre-recorded alarm signal can be good when used in
alarm). According to the contents of the recording switch to the REC MESSAGE 1,2,3 position, you
can audition to play the content, press the play button panel, press the stop end.
2. Choose to play one or two storage reservoir playback; were short port PLAY MESSAGE of COM
-NO1/COM-NO2,, indicator (ACTIVE) light, start playing the sound, then you can choose to play one
time, and repeat play disconnect the port to stop playback.
3. Press the T-6245 panel STOP button to stop recording / stop playing the recording; choose T-6245
rear panel MESSAGE 1 TIME / CONTINUOUS represent a record player / continuous play audio;
switch REC MESSAGE to the OFF state, representatives can not be recorded.
4. Under NORMAL (normal operation) state, the T-6245 board IN COM ZONE port input signal, select
the T-6245 panel ZONE1-6 buttons, the T-6245 board ZONE1-6 OUT correspond with output, input
and output 1:1.
5. Three levels of priority function:
built-in recording information (1 and 2) Priority: TUNER, CD, MP3;
Built-in chime priority: Record Information (1 and 2): TUNER, CD, Mp3;
All audio remote call microphone priority: This function is used to "MIX MUSIC / PAGE" output port.
6. Failure to exclude guidance:
""
""
""
""
""
""
""
""
""
Reason
Phenomenon
All wires connected
but no voice output
Plugged in, but the alarm signal overload or short circuit
voltage is not stable, high or low
No sound output under normal
conditions
The machine is under high
temperature conditions to protect
wire connection error
no power or wrong plug connection
fuse burned
no input signal
7. ID consol address set
ADDRESS DEFINITION
1
2
3
ON
ON
ON
4
5
6
ADDRESS
ON
ON
ON
DEFINITION
6. CONNECTIONS
NETWORK CONNECTION LINE
78
A
123456
NET PRODUCTION LINE METHOD
Note: Network lines must adopt the five categories of twisted-pair with double-layer
shielding, RJ45 connectors must be used with shielded connector.
B: 1 Blue 2 White Blue 3 Brown 4 White Brown 5 Orange 6 White Orange
7 Green 8 White Green
A: 1 Blue 2 White Blue 3 Brown 4 White Brown 5 Orange 6 White Orange
7 Green 8 White Green
Paging Station
Digital Mixer 6 zone
12345678
B
A
B
Network Line
AB
9
MUSICOUT
~230V 50Hz T1AL 250V
PRIORITY
TAPE CD TUNER MICRO
CONSOL
GAIN GAIN
CONSOL
VOLUME
VOLUME
CHIME
OFF
12
3
REC
MESSAGE 1 TIME
CONTINUOS
MESSAGE
NORMAL
ALARM VOL.PLAY
MESSAGE
VOL.REC MIC
+48V
PHANTOM
ZONE6 OUTZONE 5 OUTZONE 4 OUTZONE 3 OUTZONE2 OUTZONE 1 OUTOPEN RELE ININ COM ZONE
COM NO1 NO2
PLAY MESSAGE
MIX MUSIC-PAGE OUT
PAGE OUTRELE ZONE CONSOL OUT
123456
CHIME
VOLUME
VOLUME TREBLE BASS
ID CONSOL LINE IN LINK OUT
-10 -10+10 +100 010 10
DC24V 1A
POWER
CHIME
VOLUME
VOLUME TREBLE BASS
ID CONSOL LINE IN LINK OUT
-10 -10+10 +100 010 10
DC24V 1A
POWER
A
B
7. APPLICATIONS
1 amplifier for music 1 amplifier for voice for 6 zone
10
COM 4-16 70V 100V
OUTPUTS
COMCOM
GND
LIFT
INPUTS LINK
INPUTS LINK
12
3
XLR BAL
1-GND
2-HOT+
3-COLD-
Voice
Music
CD player
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
Zone 6
CHIME
VOLUME
VOLUME TREBLE BASS
ID CONSOL LINE IN LINK OUT
-10 -10+10 +100 010 10
DC24V 1A
POWER
CHIME
VOLUME
VOLUME TREBLE BASS
ID CONSOL LINE IN LINK OUT
-10 -10+10 +100 010 10
DC24V 1A
POWER
CHIME
VOLUME
VOLUME TREBLE BASS
ID CONSOL LINE IN LINK OUT
-10 -10+10 +100 010 10
DC24V 1A
POWER
CHIME
VOLUME
VOLUME TREBLE BASS
ID CONSOL LINE IN LINK OUT
-10 -10+10 +100 010 10
DC24V 1A
POWER
CHIME
VOLUME
VOLUME TREBLE BASS
ID CONSOL LINE IN LINK OUT
-10 -10+10 +100 010 10
DC24V 1A
POWER
CHIME
VOLUME
VOLUME TREBLE BASS
ID CONSOL LINE IN LINK OUT
-10 -10+10 +100 010 10
DC24V 1A
POWER
ON
OFF
POWER
OPEN/
CLOSE
CD/
USB
/SD
PLAY STOP NEXTPREVIOUS
USB
COM 4-16 70V 100V
OUTPUTS
COMCOM
GND
LIFT
INPUTS LINK
INPUTS LINK
12
3
XLR BAL
1-GND
2-HOT+
3-COLD-
MUSICOUT
~230V 50Hz T1AL 250V
PRIORITY
TAPE CD TUNER MICRO
CONSOL
GAIN GAIN
CONSOL
VOLUME
VOLUME
CHIME
OFF
12
3
REC
MESSAGE 1 TIME
CONTINUOS
MESSAGE
NORMAL
ALARM VOL.PLAY
MESSAGE
VOL.REC MIC
+48V
PHANTOM
ZONE6 OUTZONE 5 OUTZONE 4 OUTZONE 3 OUTZONE 2 OUTZONE 1 OUTOPEN RELE ININ COM ZONE
COM NO1 NO2
PLAY MESSAGE
MIX MUSIC-PAGE OUT
PAGE OUTRELEZONE CONSOL OUT
123456
VOLUME
CHIME
VOLUME
M1
1
8
CONSOL
GND
POWER
+24V
MAX485
CONTROL
SIGNAL
M1
NORMAL
ALARM
PRIORITY
VCC
GAIN
VOLUME
A 2
+48V
PHANTOM
MICRO
CHIME
SIGNAL MESSAGE 1 - 2 - 3
BASS
A 3
CONTROL
A 5
MUTE 4
ON/OFF
MUTE 4
A 4
VOLUME
MUSIC
VOLUME
MESSAGE
PLAY
MESSAGE 3
VOLUME
REC
CD
TAPE
TUNER
MIC
MUTE 2
A 1
MUTE 1
CONTROL
REC/PLAY
MESSAGE
ZONE 3
ZONE 6
ZONE 5
ZONE 4
ZONE 2
ZONE 1
TREBLE
MUTE 3
CONTROL ISD4003
REC
OUT VCC
PLAY
MESSAGE 1
PLAY
MESSAGE 2
PLAY STOP
MCU
OFF
123
1 TIME
CONTINUOS
RL1B
RL2B
OUT +24 V zone 4
OUT +24 V zone 3
OUT +24 V zone 2
OUT +24 V zone 1
OUT -24 V com
OUT +24 V zone 6
OUT +24 V zone 5
OUT RELE'
ZONE CONSOL
CONTACT (15)
COLD
GND
HOT
GND
COLD
COLD
COLD
COLD
HOT
HOT
HOT
GND
GND
GND
HOT
BALANCED
RL1A
RL2A
OUT ZONE 1
CONTACT (21)
OUT OPEN RELE'
CONTACT (20)
OUT PAGE
0 dB
CONTACT (19)
OUT ZONE 2
CONTACT (21)
OUT ZONE 3
CONTACT (21)
LEVEL OUTPUT (VU METER)
RL3B
RL4B
RL5B
RL6B
GND
COLD
GND
HOT
COLD
COLD
COLD
HOT
GND
HOT
GND
HOT
RL3A
RL4A
RL5A
RL6A
OUT ZONE 4
CONTACT (21)
OUT ZONE 5
CONTACT (21)
OUT ZONE 6
CONTACT (21)
IN COM ZONE
CONTACT (16)
IN COM ZONE
CONTACT (16)
COLD
GND
HOT
GND
COLD
HOT
BALANCED
BALANCED
OUT MUSIC
0 dB
CONTACT (18)
OUT MIX MUSIC-PAGE
0 dB
CONTACT (17)
8. BLOCK DIAGRAM
11
T-6245
Model
1 Mircophone input
Sensitivity -50/-2dB 5/200 mV
S/N ratio >68dB
Frequency response 50Hz-16KHz(-3dB)
Phantom power 48V
3 Auxiliaryinputs
Tuner and Tape input sensitivity /
impedance 200 mV / 47 K
500 mV / 47 K
>80 dB
20Hz-16KHz(-3dB)
CD input sensitivity / impedance
Frequency response
S/N ratio
Control
Bass 10dB
10dB
4 tone active for contact free in
priority and BGM
0.1%
Treble
Normal distortion
Chime
Operating condition
Main power supply ~220-240V/ 50/60Hz
484X322X88
6
Dimension(mm)
Max number of microphone bases
Weight 6Kg
Consol input
Sensitivity 350mV
S/N ratio >68dB
Frequency response 50Hz-16KHz(-3dB)
9. SPECIFICATIONS
12
Strong cut relay control output DC 24V
10. DIMENSIONAL DIAGRAM
100
Over
100
Over
Over
100
UNIT:mm
UNIT:mm
6
84 84
322
316
88
94
436
484
13
ON
OFF
POWER
MUSICMICRO
RECSTOPPLAY
ACTIVEMIC
ZONE5 ZONE6
ZONE1 ZONE2 ZONE3 ZONE4TUNERCDTAPE OUTPUT LEVEL
0 0
0
1 1 1
2 2 2
3 3 3
4 4
4
5 5
5
6 6
6
7 7 7
8 8 8
9 9 9
10 10
10
MASTERBASS TREBLE
0 0
-10 -10
-8 -8
-6 -6
-4 -4
-2 -2+2 +2
+4 +4
+6 +6
+8 +8
+10 +10
MESSAGE RECORDER
MUSIC OUT
~230V 50Hz T1AL 250V
PRIORITY
TAPE CD TUNER MICRO
CONSOL
GAIN GAIN
CONSOL
VOLUME
VOLUME
CHIME
OFF
12
3
REC
MESSAGE 1 TIME
CONTINUOS
MESSAGE
NORMAL
ALARM VOL.PLAY
MESSAGE
VOL.REC MIC
+48V
PHANTOM
ZONE 6 OUTZONE 5 OUTZONE 4 OUTZONE 3 OUTZONE 2 OUTZONE 1 OUTOPEN RELE ININCOM ZONE
COM NO1 NO2
PLAY MESSAGE
MIX MUSIC-PAGE OUT
PAGEOUTRELE ZONE CONSOL OUT
123456
ON
OFF
POWER
MUSICMICRO
RECSTOPPLAY
ACTIVEMIC
ZONE5 ZONE6
ZONE1 ZONE2 ZONE3 ZONE4TUNERCDTAPE OUTPUT LEVEL
0 0
0
1 1 1
2 2 2
3 3 3
4 4
4
5 5
5
6 6
6
7 7 7
8 8 8
9 9 9
10 10
10
MASTERBASS TREBLE
0 0
-10 -10
-8 -8
-6 -6
-4 -4
-2 -2+2 +2
+4 +4
+6 +6
+8 +8
+10 +10
MESSAGE RECORDER
PUBLIC ADDRESS SYSTEM
VersionV0.2
Table of contents
