iTheater BlueWave User manual

User Guide
What you can find in the package:
1. Two iTheater Bluetooth Speakers
2.
Remote Controll
. Drawstring Accessories Bag
AC Power Cable
3. 1/8” Audio Cable
4. 16AWG Speaker Wire (9.75 ft)
5.
6
7. Two Drawstring Speaker Bags
8. iTheater™ User Guide
www.itheater.net
PAGE 1

BT CD AUX
OUT TO
RIGHT
OUTPUT
DC +5V
INPUT
AUX L R L R
POWER
ON OFF
FUSE
115V~
T1.6AL 250V T2.0AL 125V
230V~
Tweeter
Mute/Standby
Bluetooth
Power
Bluetooth
Input
CD Input
AUX Input
Remote
Sensor
Woofer
Volume
Bass Tube
Output
DC Charger
Power On/Off
Fuse
Power Plug
Power Switch
AUX Input
RCA Input
RCA Output
Primary Secondary
User Guide
PAGE 2

www.itheater.net
OUT TO
RIGHT
OUTPUT
DC +5V
INPUT
AUX L R L R
POWER
ON OFF
FUSE
115V~
T1.6AL 250V T2.0AL 125V
230V~
1
1
2
Speaker-Wire Connection
Connect the RED (+) and BLACK (-) terminals of the left speaker to the
corresponding terminals of the speaker on right using the speaker wire supplied.
Be sure the gold color speaker wire line should go between the RED (+)
terminals of both speakers while the silver color speaker wire line connects the
BLACK (-) terminals.
> Remove the pre-cut insulation on the end of the speaker wire and twist the exposed wire strands 2-3
times.
> Loosen the binding post connector with your thumb and fingers.
> Insert each speaker wire into the holes on the side of the binding post connector.
> Tighten the binding posts. The stripped portion should be secured firmly in the connector.
> Repeat the above steps to connect the other speaker. Be sure to match the wire line color to the same
terminal color on each speaker. Also make sure that none of the speaker wire strands come in contact
with adjacent terminal.
Step by Step:
NOTE: As the iTheater™ speaker system is self powered, do not connect
the speaker terminals to the speaker outputs of a stereo receiver.
PAGE 3

> Please make sure that the power switch on the rear panel is in the OFF position.
> Connect power cord to mains as shown.
2
3
Power Cable Connection
The following configurations describe the most common audio setups for the
iTheater™ BlueWave 01 Bluetooth Speaker.
Audio Configurations
Configuration A (all devices with Bluetooth transmitter)
1. To use the Bluetooth on your iTheater™ speakers, you must establish a wireless connection to an
audio device. You may pair the iTheater™ speakers to another audio device according to the following
steps.
2. Turn on your iTheater™ speakers and you will notice a yellow LED light.
This means the Bluetooth is ready on you iTheater™ speakers.
3. Press the “pair” button on your remote control and you will see a blue LED flash rapidly. This indicates
that the Bluetooth is now in pairing mode for the next 50 seconds and is ready to pair up with another
Bluetooth enabled audio device. A beep sound will generate from the speaker to show pairing is
successful. The separate Bluetooth-enabled audio device should be turned on and in its own separate
pairing mode in order for it to pair up with the iTheater™ speakers. On a notebook computer, you may
need to enter the passkey, which is: 0-0-0-0 to pair up with the iTheater™ speakers. Please reference
item 6 for this procedure if you use iTheater BlueTooth USB dongle bundled in the package for pairing
and connecting.
4. When the iTheater™ speakers are paired up, you will notice a
blue led flashing fast. This indicates that the two devices are
paired successfully. And the iTheater™ speakers are now
looking for this paired device. Once the blue led stops flashing
and lights on steady, you may start playing your music and
listening wirelessly with the iTheater™ speakers.
5. When the iTheater™ speakers are turned off or if the
connection is lost, please restart from step 2 again.
6. To use iTheater BlueTooth USB dongle.
BT CD AUX
BT CD AUX
2
45
3
BT CD AUX
User Guide
PAGE 4

www.itheater.net
Bluesoliel Utility Installation
i. Insert the BlueSoliel CD into the CD-ROM drive of your computer. The software
will run automatically. If it doesn't, please find the in the CD and
double-click it to install the utility.
ii. Follow the instruction, to accept the license agreement, to have a short cut …,
and click next.
iii. Follow the steps to finish the installation.
setup.exe
PAGE 5

Start Application
iv. Start Application by click the “BlueSoleil” icon.
v. Plug the USB dongle into a free USB port on your computer. Wait for the
Bluetooth icon on tool bar changing from gray to blue.
vi. Find Bluetooth devices around you.
Click this sphere to start/stop
discover Bluetooth devices
User Guide
PAGE 6

www.itheater.net
vi. Find Bluetooth device's functions.
viii. DoubleClick the device's
function on the upper right
conner which you want to use.
Then IVT will show out a
window to ask you fill up the
PIN key. Please Key in the
correct PIN key 0000.
iv. After input correct PIN key, the Bluetooth connection will be built, and you can
use the BlueWave speaker now. You can see also a check symbol displayed
by the BlueWave icon and a dotted line connecting with the central sphere.
1. Double click BlueWave device
which you want to use.
2. Will show the device here in color.yellow
The icon will be connected to be green color.
The dotted line shows that BlueWave is
connected will be connected to be green color.
A check symbol displayed by the BlueWave
icon connected will change to green color.
PAGE 7

www.itheater.net
Configuration B (all products with 1/8” audio cable output)
Configuration C (all products with RCA output)
Configuration D (subwoofer with RCA output)
Connect the 1/8 inch audio cable from the OUTPUT from
your audio device to the AUDIO IN jack on the rear panel
of the iTheater™ primary speaker.
Connect the RCA audio cable from the RCA output to the
RCA input on the rear panel.
For more bass, the iTheater™ speaker system can support
a subwoofer. Connect the RCA audio cable from the RCA output
on the rear panel to the RCA input on the subwoofer.
Troubleshooting
If the front panel LED does not light up, check…
If there is no sound, check…
If bass output is low, check…
If there is no output from the primary speaker, check…
If the Bluetooth is not working on the iTheater™ Speakers, check...
that the AC power cord is firmly plugged into the rear panel and wall socket.
if the power switch on the speaker rear panel is ON.
that the speaker is getting power from the wall socket.
the fuse in the AC IN on the rear panel. If the fuse needs to be replaced, it is important to replace with the same
fuse type.
that the speaker is turned on (blue LED illuminated).
to make sure the primary speaker is properly connected to the secondary speaker.
that the volume on the speaker front panel is not on low.
the volume level on the iPod or other audio source.
to make sure the iPod audio cable is inserted all the way at both ends.
to make sure that the iPod is seated correctly on the dock.
the speaker wire polarity (verify that the wires are going to the same color terminals on both speakers).
that the speaker rear panels are not blocked.
that the speaker wire is properly connected from the left to the right speakers. Check by removing the speaker
wire from both terminals and then reconnecting each speaker.
that the speaker is not turned off.
that the speakers and audio device are in a range of within 2 feet.
to make sure the speaker is paired properly with your audio device through the included Bluetooth instructions.
















User Guide
OUT TO
RIGHT
OUTPUT
DC +5V
INPUT
AUX L R L R
POWER
ON OFF
FUSE
115V~
T1.6AL 250V T2.0AL 125V
230V~
INPUT
AUX L R
INPUT
LR
CD Player
OUTPUT
LR
DVD Player
Subwoofer
PAGE 8
