ITX SECURITY Prodigy M 2022 User manual

Graphics Card Compatibility Guide
Prodigy M 2022

ITX motherboard

3090 graphics card
150mm high PSU
ITX motherboard
Basic installation |ITX motherboard
ITX motherboard

3090 graphics card
200mm high PSU
ITX motherboard
If you use a 200mm high PSU, please remove the PSU bracket
and use a PCI-E extension cable to connect your motherboard and graphics card.
PCI-E extension cable
ITX motherboard

Basically, you can buy any PCI-E extension cable of any brand you like.The only one
point is to install the graphics card end.We recommend choose vertical type (Just like
pci-e on the motherboard).
ITX motherboard

M-ATX motherboard

Basic installation |M-ATX motherboard
3090 graphics card
150mm high PSU
M-ATX motherboard
M-ATX motherboard

Different types of M-ATX motherboards
3 PCI-E
1 PCI-E
(second slot)
2 PCI-E
(First and thirdslot)
2 PCI-E
(First and fourth)
M-ATX motherboard

The panel thickness on the PCB is up to 4mm
The thickness under the PCB is up to 51mm
PCB
M-ATX motherboard

4th PCI-E
supports up to 56mm
M-ATX motherboard
If you want to install graphics card on 4th PCI-E,
the graphics card supports up to 56mm ( MSI GeForce RTX™3090 GAMING X TRIO 24G)

200mm high PSU
3th PCI-E
1th PCI-E
please remove PSU bracket
If you want to install graphics card on 3th PCI-E,
the graphics card supports up to 69mm
M-ATX motherboard

If you want to install graphics card on 2th PCI-E,
there is no restriction on the thickness of the graphics card, the longest support is
339mm, if you install a 200mm PSU, please remove the PSU bracket
M-ATX motherboard
2th PCI-E
200mm high PSU
please remove PSU bracket

Vertical Graphics Card

The panel thickness on the PCB is up to 4.6mm
The thickness under the PCB is up to 50mm
Vertical Graphics Card

The thickness under the PCB is up to 55mm
PCB
The panel thickness on the PCB is up to 4mm
Vertical Graphics Card

PCB
The panel thickness on the PCB
is up to 4mm The thickness under the PCB
is up to 50mm
The overall thickness of the graphics card is recommended not to exceed 56mm
Vertical Graphics Card

15mm thick fan
We have a rubber crash pad inside,
which can be used if needed.
137mm wide graphics card
2 Slots
If the width of your graphics card exceeds 134mm, we will recommend you to use a
fan with a thickness of 15mm (generally a fan with a thickness of 25mm will not fit)
Vertical Graphics Card

The End
