RESCUE GUIDE ‒Technical information
Contents
–Printed 692.68.340 –1st Ed. 04/2015
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
Contents
3
–Printed 692.68.340 –1st Ed. 04/2015
Contents
DIESELVEHICLES ........................ 5
Positionoftank ....................... 5
Tank technical specifications . . . . . . . . . . . . . . . 5
Fuel refilling (New DAILY vehicles) . . . . . . . . . . . 5
AdBlue refilling (New DAILY vehicles) . . . . . . . . . 7
CNG / CNG-PETROL VEHICLES (NATURAL
POWER).............................. 8
Description .......................... 8
Natural gas (CNG) / petrol refuelling . . . . . . . . . 13
4
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
–Printed 692.68.340 –1st Ed. 04/2015
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
DIESEL VEHICLES
5
–Printed 692.68.340 –1st Ed. 04/2015
TECHNICAL INFORMATION
DIESEL VEHICLES
Position of tank
226170 Figure 1
The fuel tank (1) is normally situated on the left side of the vehicle
as illustrated in the figure. The position and capacity of the tank may
vary depending on the vehicle version and type.
Tank technical specifications
●Material: HDPE (High density polyethylene); STAMYLEX XL 400 UP plastic
●Capacity: from 70 to 120 litres
Note Diesel fuel is assigned Fire Class B in compliance with the European EN2 Standard on "Combustible materials of various
nature".
Fuel refilling (New DAILY vehicles)
226149 Figure 2
The fuel filler (1) is located to the side of the front door.
6
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
DIESEL VEHICLES
–Printed 692.68.340 –1st Ed. 04/2015
226150 Figure 3
Open the front door next to the small door (1).
Lift the small door (1) by acting on the recess (2).
226151 Figure 4
Unscrew the cap (1) slowly in case any fuel should spray out.
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
DIESEL VEHICLES
7
–Printed 692.68.340 –1st Ed. 04/2015
AdBlue refilling (New DAILY vehicles)
226152 Figure 5
The cap (1) of the AdBlue tank is situated on the front right side of
the vehicle. It opens when unscrewed in an anticlockwise direction. It
closes when screwed in a clockwise direction.
226153 Figure 6
Open the front door next to the small door (1).
Lift the small door (1) by acting on the recess (2).
226154 Figure 7
Unscrew the cap (1) slowly to avoid any fumes.
8
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
CNG / CNG-PETROL VEHICLES (NATURAL POWER)
–Printed 692.68.340 –1st Ed. 04/2015
CNG / CNG-PETROL VEHICLES (NATURAL POWER)
Description
The following specifications may vary depending on the vehicle version and type:
●Number of cylinders.
●Cylinder layout.
●Presence of fuel tank (petrol).
The CNG vehicles can be recognized from the writing "CNG" or "NATURAL POWER" on the side of the vehicle and from the
presence of cylinders under the body.
Capacity
●Petrol tank (if present): 15 litres
●Total capacity of CNG cylinders: from 196 litres to 302 litres
CNG power supply system diagram
219810 Figure 8
1 Accumulator (rail)/Gas-air mixer/Temperature pres-
sure sensor
2 Electro-injectors
3 Medium pressure flexible gas pipe
4 Pressure reducer/pressure sensor
5 IAW-5SF control unit
6 Inertial switch
7 Filling valve*
8 High pressure flexible gas pipe
9 Solenoid valve with check valve*
10 Cylinder
11 Solenoid valve without check valve
12 Optional cylinder
13 High-pressure rigid gas pipes
* In the mono-fuel version, the filling valve may be po-
sitioned on the left or the right of the vehicle. In the
bi-fuel versions the fuel filling valve is always on the left
while the CNG filling valve is always on the right.
The CNG power supply system basically consists of the following components:
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
CNG / CNG-PETROL VEHICLES (NATURAL POWER)
9
–Printed 692.68.340 –1st Ed. 04/2015
●filling valve;
●high and medium pressure gas hoses;
●high-pressure rigid gas pipes;
●unions;
●cylinders;
●solenoid valve with VBE 498 check valve;
●solenoid valves without check valves VBE 474;
●pressure reducer with CNG shut-off solenoid valve and CNG pressure sensor;
●CNG accumulator (rail) with gas pressure/temperature sensor.
●electro-injectors;
●common petrol power supply system inertial switch.
NGVI-P30 filling valve description
138643 Figure 9
1 Filling valve
2 Check valve
A Filling valve with EEC -
NGVI- 30 connector
B Filling valve with Italian
connector
The cylinders are refilled using the filling valve (1).
The check valve (2) allows the cylinders to be filled while preventing
the gas from flowing outwards.
VBE shut-off and safety solenoid valve description
VBE 474 solenoid valve without check valve
117672 Figure 10
1 Tap
2 Flow limiter
3 Coil
Each cylinder is fitted with a solenoid valve consisting of the following devices:
10
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
CNG / CNG-PETROL VEHICLES (NATURAL POWER)
–Printed 692.68.340 –1st Ed. 04/2015
Manual closure for maintenance and shut-off
Solenoid valve(3) controlled by ignition key.
The solenoid valve is one-way and does not shut off the flow into the cylinder; thus the cylinders must be charged when the solen-
oid valves are not powered.
Safety functions:
●Flow limiter (2) that intervenes in the event of a sudden change in pressure, effectively limiting the outward flow of gas
from the cylinders; for example if a pipe breaks. After the downstream leak has been eliminated, and the pressure equilibrium
has been re-established, the outflow limiter valve in its closed position still allows a small flow of gas to enable resetting the
device.
VBE 498 solenoid valve with check valve
117673 Figure 11
1 Tap
2 Discharge device with
fusible plug
3 Solenoid valve
4 Check valve
5 Gas inlet union
●fusible plug locked in the discharge device (2) that melts at 110±10°C.
The safety circuit, composed of the fusible plug, allows the gas to be discharged safely in case of fire on the vehicle, preventing cylin-
der explosions due to overpressure.
This circuit communicates directly with the exterior independently of: outflow limiter valve, manual valve and solenoid valve.
Upstream of the interceptor solenoid valve there is a manual tap valve which performs the same function as the previous solenoid
valve, but is operated manually; its presence is important in case of any maintenance of the system, when it becomes necessary to
close the cylinders.
The solenoid valve fitted on the first cylinder is connected to the filling valve and is equipped with a check valve.
The function of this valve is to prevent the flow of CNG from the cylinder to the filling valve and is moreover another safety ele-
ment as it is in addition to the valve in the filling valve.
The valve opens due to the pressure of the gas during filling.
●Flow limiter: if a pipe bursts or the valve assembly breaks (for example due to an accident), CNG escapes (gas leak) and
the flow limiter trips to limit the flow of CNG to approximately 0.5% of the setting for normal engine operation, eliminating
the danger deriving from the presence of a considerable flow rate of CNG. The flow limiter is positioned in the threaded
shank of the valve assembly so as to remain inside the cylinder, ensuring operation even in the event of the solenoid valve
body breaking as a result of an accident.
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
CNG / CNG-PETROL VEHICLES (NATURAL POWER)
11
–Printed 692.68.340 –1st Ed. 04/2015
Cylinders description
Solenoid valve on cylinder
226155 Figure 12
1 Cylinder 2 Solenoid valve
The CNG, compressed at a pressure of 200 bar, is stored in some cylinders, positioned in the chassis frame and protected by spe-
cial sheet metal guards.
The cylinders, connected together in series, are filled via a filling valve equipped with a check valve.
A second check valve is included in the solenoid valve fitted on the first cylinder connected to the filling union.
The function of the check valves is to prevent the gas escaping outwards and the dispenser being removed from the filling valve
after refilling or a pipe bursting.
Pressure reducer description
138645 Figure 13
1 Solenoid valve
2 Valve mobile equip-
ment
3 Cooling water duct
4 Cooling water duct
5 Low pressure CNG
outlet
6 Reducer valve mobile
equipment
7 CNG pressure sensor
8 High pressure CNG
inlet
9 Filter
10 Discharge chamber
The pressure reducer decreases the CNG pressure from the value
in the cylinders to the electric injector supply value (6 ±1 bar), in all
engine operating conditions.
The pressure reduction takes place in a single stage in which the
pressure is reduced from 200 to 6 bar
Since the CNG drops sharply in temperature because it expands due
to the jump in pressure, the engine cooling circuit has a branch that
allows the engine coolant to heat the pressure reducer assembly so
as to avoid any trouble due to the change in temperature, such as the
formation of condensation or even ice that could block the pressure
reducer.
It is equipped with a CNG shut-off solenoid valve and a CNG pres-
sure sensor.
12
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
CNG / CNG-PETROL VEHICLES (NATURAL POWER)
–Printed 692.68.340 –1st Ed. 04/2015
Note The pressure reducer must be positioned with the solenoid valve (1) facing upwards.
A maximum tilt of 15°from the vertical axis is permitted.
CNG shut-off solenoid valve
The CNG shut-off solenoid valve is normally closed.
This allows CNG to flow only when it is energized.
It is powered via the ignition key through a specific contactor and is connected directly to ground.
With the solenoid valve powered (ignition key set to MAR), CNG can flow towards the pressure reducer valve and then towards
the electro-injectors.
Inertial switch description
117678 Figure 14
1 Inertial switch
2 Flexible cover
3 Switch
4 Switch seat
5 Connector
6 Permanent magnet
7 Permanent magnet
seat
8 Ball
This switch (1) trips in case of accident, cutting off the supply to the
solenoid valves both on the cylinders and on the pressure reducer,
consequently cutting off the gas supply.
A steel ball (8) fitted into a tapered housing is normally kept secured
by the attraction force of an adjacent magnet.
Under specific acceleration loads, the ball is released from the mag-
netic retainer (6) and gradually comes out of the tapered support
with an upward movement, according to the cone angle.
Above the ball (8) is a quick-connect mechanism that generates the
normally closed (N.C.) electric circuit.
The mechanism changes position when it is hit by the ball, from N.C.
(normally closed) circuit to N.O. (normally open) circuit, thus cutting
off the solenoid valve supply ground circuit.
In case of impact in any of the three orthogonal directions, the switch
will operate above the 12 g peak (acceleration values), equivalent to
an impact at 25 km/h.
The inertia switch (1) can be restored by pushing the button (3)
protected by a flexible cover (2) (that is also used to protect against
any foreign bodies).
The switch (1) is located in the engine compartment.
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
CNG / CNG-PETROL VEHICLES (NATURAL POWER)
13
–Printed 692.68.340 –1st Ed. 04/2015
Fuel tank (if present)
222677 Figure 15
The CNG vehicle may also be fitted with a fuel tank (petrol).
Natural gas (CNG) / petrol refuelling
226149 Figure 16
The refuelling fillers (1) of CNG gas and petrol are situated alongside the front door (right or left depending on the version). Refer
to the following table for details on their position.
14
RESCUE GUIDE ‒Technical information
TECHNICAL INFORMATION
CNG / CNG-PETROL VEHICLES (NATURAL POWER)
–Printed 692.68.340 –1st Ed. 04/2015
226149 Figure 16
Location of the refuelling fillers on the vehicle
VEHICLE DRIVING POWER SUPPLY
FILLER LOCATION
(vehicle side)
CNG PETROL
NEW DAILY Left Only CNG Left or Right –
NEW DAILY Left CNG + PETROL Right Left side
NEW DAILY Right Only CNG Left or Right –
NEW DAILY Right CNG + PETROL Right Left side
Note To access the refuelling fillers, it is necessary to open the corresponding front doors. See the following procedure.
226150 Figure 17
Open the front door next to the small door (1).
Lift the small door (1) by acting on the recess (2).
Table of contents
Other Iveco Automobile manuals
