SPLIT CASE PUMP MODULE Page 7-2
15 July, 2019 IVEK Corp. P07R002P
7. SPLIT CASE PUMP MODULE
7.1 DESCRIPTION (Figure 7.1)
The Split Case Pump Module, hereafter referred to as Pump Module, is comprised of a ceramic piston and cylinder set,
two castellated sleeves and a split case assembly. Certain components of the Pump Module are in the direct liquid path.
The Pump Module has been designed to be easily disassembled and detached from the Motor/Base Module for ease of
cleaning, decontamination and sterilization.
The Pump Module's piston/cylinder set provides positive liquid displacement. Table 7.1 describes the total volumetric
output of this pump.
WARNING
Never remove a safety cover while the motor is running. Moving parts are located under these covers. Physical
harm to individuals is possible.
7.2 OPERATION
When the Pump Module is mounted on the Motor/Base Module, the piston is driven by a spherical bearing mounted within
a rotating spindle. This drive arrangement imparts both reciprocating and rotary motion to the piston. The magnitude of
the piston's stroke is adjustable by varying the angle of the axis of the pump head relative to the axis of the motor drive
shaft. This displacement range is infinitely adjustable within the pump specifications (refer to Table 7.1). The displacement
adjustment is easily made and recorded as a setting taken from the Motor/Base Module's vernier scale. Repeatability of
0.1% is obtainable once the stroke length is established.
On each rotation of the piston, the ports are opened alternately and exclusively, first to the inlet and then to the outlet.
During the rotation, the limited piston flat creates the void that allows the flow from only one port at a time, positively
displacing the liquid. The piston flat acts as a rotary valve, completing one pressure stroke and one suction stroke per
revolution as the pump rotates and reciprocates synchronously.
The end of the piston is never drawn back beyond the inlet and outlet ports in normal operation. The piston flat allows only
one port to communicate with the interior chamber of the pump cylinder at any one time. The effect is positive mechanical
valving, eliminating the need for check valves under normal operations.
The pump, which cannot be driven by either inlet or outlet pressure, essentially acts as a closed valve when the unit is not
in operation.
Castellated
Sleeve
Figure 7.1 Split Case Pump Module
Split Case
Piston

SPLIT CASE PUMP MODULE Page 7-3
15 July, 2019 IVEK Corp. P07R002P
The Pump Module can easily and accurately be set over the full displacement range. By changing the stroke length
through the angular adjustment of the metering head, displacement is changed from zero to the maximum. Once the
displacement is set, Pump Module maintenance can be performed without affecting the displacement.
7.2.1 Piston/Cylinder Set
The piston/cylinder set is constructed of high density alumina or magnesium stabilized zirconia ceramic. The ceramics are
compatible with most acids and bases. The precision piston/cylinder set has a radial clearance between the piston and
cylinder wall of approximately 1.3 micron (.00005") which minimizes fluid slip.
The ceramic piston operates within the ceramic cylinder with no lubrication other than the liquid being dispensed or metered. The
natural crystalline structure of the ceramics display zero porosity ensuring zero retention and carryover of one liquid to the next.
The combination of the ceramic material’s mechanical and thermal stability allows it to be machined and operated with a
close running clearance. This means that no compliant dynamic seals are needed, eliminating parts requiring frequent
replacement in traditional pump designs.
7.2.2 Split Case
The stainless steel split case design provides ease of disassembly for cleaning and maintenance. The ceramics, end cap
seal, and fitting sets are all serviceable parts. The ceramics are easily accessed by removing the upper half of the split
case either while attached to the Motor/Base Module or after its removal.
NOTE
The upper and lower halves of the case are matched parts and cannot be interchanged.
7.3 INSTALLATION
Installing the Pump Module into the Motor/Base Module involves the following: (refer to Figure 7.2) Refer to Section
7.5.5.1 for removal procedure.
CAUTION
Make sure the power is off and all hazardous liquids have been flushed from the system prior to performing any
disassembly or assembly procedures.
Spherical Pump Drive Mounting Swing Cap
Spindle Bearing Piston Module Pin Key Plate
Screws
Step 1 Step 2 Step 3 Steps 4 and 5
Figure 7.2 Split Case Pump Module Installation

SPLIT CASE PUMP MODULE Page 7-4
15 July, 2019 IVEK Corp. P07R002P
Lubricate the drive pin with IVEK Spindle Bearing Lubricant (IVEK part number 052046) prior to assembly. Failure
to lubricate the drive pin may result in damage to the Pump Module and Motor/Base Module.
1. Rotate the spindle on the Motor/Base Module so the spherical bearing is at the 3 O'clock position.
2. Extend the piston, which is housed in the Pump Module, approximately 2/3 of the way out of the cylinder.
3. Slide the drive pin, which is pressed into the piston end cap, into the center bore of the spherical bearing.
4. Position the Pump Module on the swing plate with the locating pin of the swing plate inserted into the slot of the
Pump Module mounting key.
5. Secure the Pump Module to the swing plate by tightening the two #10 socket head cap screws on the swing plate.
NOTE
Figure 7.3 shows the inlet orientation of the Pump Module on both the Single Ended and Double Ended
Motor/Base Modules.
7.4 OPTIONS
IVEK Corporation offers a variety of options to best meet the customers’ needs. Following is a list and description of available
options for the Pump Module. Refer to the Title Section of this manual for the list of options provided with this system.
7.4.1 Special Piston/Cylinder Bore Clearances or Modifications
For certain applications, special clearances are required for the piston/cylinder bore. IVEK Corporation determines these
clearances by performing application tests using the application fluid. Contact IVEK Corporation for more information.
For certain applications, special machined modifications are required for the piston/cylinder. IVEK Corporation determines these
modifications by performing application tests using the application fluid. Contact IVEK Corporation for more information.
Inlet
Note connector
position Inlet
Inlet
Figure 7.3 Split Case Pump Module Orientation

SPLIT CASE PUMP MODULE Page 7-5
15 July, 2019 IVEK Corp. P07R002P
7.4.2 Rinse Gland
This option provides for rinsing the rear portion of the piston with a liquid passing at a low flow rate through the annular
gland. This precludes migration of the metered liquid beyond this groove, preventing it from reaching the rear of the pump.
This also reduces the chance of the piston binding in the cylinder.
7.4.3 Cartridge Heater Ports/Cartridge Heaters
Optional cartridge heater ports and cartridge heaters are available. IVEK Corporation will assist the user in determining
the optimum heater specification. Pump head heating is used to maintain liquid temperature. Heating is not used to
increase liquid temperature.
7.4.3.1 Cartridge Heater Ports
Optional cartridge heater ports can be provided in the pump case to keep the Pump Module at an elevated temperature.
The 1/ 4" diameter ports are located in the pump case 180Oapart.
7.4.3.2 Cartridge Heaters
Optional cartridge heaters can be mounted in the cartridge heater ports. A temperature controller and thermocouple may
also be provided. If a controller is provided, instructions for the controller are provided in Chapter 11.
7.4.4 Fittings
Fittings are available with the Pump Module. Chapter 9 lists the IVEK part numbers for the available fittings, associated
seals and sleeves when required. Not all fittings shown are applicable to the Split Case Pump Module.
7.5 MAINTENANCE
CAUTION
Never connect or disconnect the cable from the Motor/Base Module connector while power is on. Damage to the
equipment may result.
7.5.1 Preventative Maintenance
The ceramic components for the Pump Module have been designed to last for millions of repetitions without wear.
Preventative maintenance should include careful handling of the piston and cylinder when they have been removed from
the Pump Module. Always take great care when removing the piston from the cylinder and replacing the piston into the
cylinder. Never clean ceramic parts in such a way that they can vibrate against each other. This could cause chipping.
The piston and cylinder are a matched set and should always be kept together. Each piston and cylinder are identified
with a number which match the parts as a set.
CAUTION
Ceramic piston/cylinder sets are particularly sensitive to neglect and may “freeze” if allowed to dry out without
adequate cleaning.
7.5.1.1 General Applications; Routine Cleaning Procedure.
1. Disconnect inlet tubing from process liquid supply container.
2. Cycle pump in continuous mode until remaining process liquid has been purged from the Pump Module liquid path.

SPLIT CASE PUMP MODULE Page 7-6
15 July, 2019 IVEK Corp. P07R002P
3. Connect the inlet tubing to an appropriate cleaning solution supply container.
4. Cycle pump in continuous mode at a high volume and rate to flush the cleaning solution through the entire liquid path.
NOTE
Routine flushing with a compatible solution after shutdown may provide sufficient cleaning for many applications.
7.5.2 Storage Options.
Storage refers to any extended time that the system remains idle. The main concern is liquid drying in the piston/cylinder
area, causing the piston to freeze in the cylinder. The duration of idle time requiring storage procedures is based on the
liquid being pumped, the Pump Module configuration, and the operating environment. The system can either remain
wetted with cleaning liquid, disassembled, or a liquid loop can be created.
7.5.2.1 Wetting With Cleaning Liquid
This option involves leaving the liquid circuit and Pump Module assembled in place. Load the liquid circuit with a compatible
cleaning liquid and leave the system wet until the next use when the stored liquid can be purged during setup for operations.
7.5.2.2 Disassembling
If it is desired not to leave cleaning liquid in the system, after rinsing with cleaning liquid as described in Section 7.5.1.1,
empty the system of cleaning liquid as described in Section 2.7.
Disassemble the liquid circuit and Pump Module, remove the piston from the cylinder and store the component parts disassembled until
the pump is again required. The instructions for disassembling the Pump Module are found in Section 7.5.5 of this chapter.
NOTE
If applicable, the disassembled liquid circuit and Pump Module components may be immersed and soaked or
further cleaned in an ultrasonic cleaning device using a compatible cleaning solution.
7.5.2.3 Liquid Loop
Fill a loop of flexible tubing with a compatible cleaning liquid or other chemical that will thin or neutralize the last liquid
pumped. Connect one end of the tube to the pump inlet port and the other to the outlet port. Cycle the pump a few times
in any operational mode to insure the piston and cylinder are wetted by the cleaning liquid. With this loop positioned
above the pump head, the ceramic surfaces and seal areas will stay moist and mobile for extended idle periods.
7.5.3 Extended Storage
If a pump is to be stored assembled for an extended period of time, it is recommended that after cleaning, the piston and
cylinder be dried before reassembly or stored separately in protective packaging. Wet components will have a tendency to
bind after materials have evaporated, leaving residue.
7.5.4 End Cap And Seal Assembly
The end cap and seal at the front of the Pump Module serve to contain liquid within the pump.
When properly maintained in a clean condition, the original seal may be expected to last for extended periods. If removed
for any reason, the seal should be carefully cleansed of all foreign particles prior to reassembly. The seal seating area
must also be free of particles and scratches to prevent leaks when reassembled.

SPLIT CASE PUMP MODULE Page 7-7
15 July, 2019 IVEK Corp. P07R002P
7.5.5 Assembly/Disassembly Procedures (Refer to Figure 7.5)
The Pump Module contains the following replaceable parts.
•End Cap, End Cap Seal and O-Ring (1, 9, 11)
•Key (6)
•Cylinder Locating Pin (5)
•Cylinder and Piston Fabrication (7,8)
•Slotted Ring (4)
•Castellated Sleeve (12)
CAUTION
Make sure the power is off and all hazardous liquids have been flushed from the system prior to performing any
disassembly or assembly procedures.
7.5.5.1 Pump Module Removal (Figure 7.4)
Removing the Pump Module from the Motor/Base Module involves the following. Refer to Section 7.3 for the installation procedure.
1. Rotate the spindle on the Motor/Base Module so the spherical bearing is at the 3 O'clock position.
2. Loosen the two #10 socket head cap screws securing the Pump Module to the swing plate.
3. Lift the Pump Module and pull up and away from the swing plate until the piston fabrication is approximately 2/3 of
the way out of the cylinder.
4. Move the Pump Module laterally until the pin in the piston fabrication slides out of the spherical bearing.
7.5.5.2 End Cap, End Cap Seal and O-Ring (Figure 7.5 Items 1, 9, 11)
Disassembly
1. Remove end cap, end cap seal, and O-ring (1, 9, 11) from split case pump fabrication (3) by placing the spanner
wrench (IVEK part# 142017, provided with equipment) on end cap (1) and turning in a counterclockwise direction.
2. Remove end cap, end cap seal, and O-ring (1, 9, 11).
NOTE
If installing the same end cap seal and/or O-ring, make sure it is clean and free of scratches before installing.
Spherical
Cap
Swing
Drive
Piston Mounting
Pump
Bearing
Screws
Plate
Pin
Key
Module
Steps 1 and 2 Step 3 and 4
Figure 7.4 Split Case Pump Module Removal

SPLIT CASE PUMP MODULE Page 7-8
15 July, 2019 IVEK Corp. P07R002P
Assembly
For O-ring Seal
1. Position O-ring (11) in end cap seal (9) and position in end cap (1) as shown in Figure 7.5.
For Teflon Seal
1. Position O-ring (11) in end cap seal (9) and position in end cap (1) with O-ring against end cap (1).
2. Position end cap (1) on split case pump fabrication (3) and finger tighten by turning in a clockwise direction.
3. Finish tightening using spanner wrench supplied.
7.5.5.3 Key (Figure 7.5 Item 6)
Disassembly
1. Remove the Pump Module from the Motor/Base Module as described in section 7.5.5.1.
2. Remove two 8 - 32 x .25" long socket head cap screws (10) securing key (6) to split case pump fabrication (3).
3. Remove key (6).
Assembly
1. Position key (6) on split case pump fabrication (3) and secure with two 8 - 32 x .25" long socket head cap screws (10).
2. Install the Pump Module on the swing plate as described in section 7.4.
Figure 7.5 Split Case Pump Module
1
2
9
11
4
12
7
8
12
10
6
3
5
13
3

SPLIT CASE PUMP MODULE Page 7-9
15 July, 2019 IVEK Corp. P07R002P
7.5.5.4 Cylinder Locating Pin (Figure 7.5 Item 5)
Disassembly
1. Remove the Pump Module from the Motor/Base Module as described in section 7.5.5.1.
2. Remove the fitting sets (12) from split case pump fabrication (3) by placing the spanner wrench (provided with
equipment) on the fitting retainer and turning in a counterclockwise direction.
3. Remove end cap, end cap seal and O-ring (1, 9, 11) from split case pump fabrication (3) by placing the spanner
wrench (provided with equipment) on end cap (1) and turning in a counterclockwise direction.
4. Loosen the four captive slotted screws (13) securing the two halves of split case pump fabrication (3) and remove
the upper half of split case pump fabrication (3). Lanyard (2) will keep the two Pump Module halves together.
5. Remove slotted ring (4).
6. Remove piston fabrication (8) and cylinder (7) from split case pump fabrication (3).
7. Remove two socket head cap screws (10) securing key (6) to split case pump fabrication (3) and remove key (6).
8. Using a punch smaller than .125" (3.175mm), gently push cylinder locating pin (5) out of the lower half of split case
pump fabrication (3).
Assembly
1. Position key (6) on split case pump fabrication (3) and secure with two socket head cap screws (10).
2. Place cylinder locating pin (5) in position and gently press in until it contacts key (6).
3. Install the cylinder and piston fabrication, (7, 8) by aligning over the cylinder locating pin (5) in lower half of split
case pump fabrication (3).
4. Install slotted ring (4) by sliding over piston fabrication (8).
5. Position the upper half of split case pump assembly (3) on the lower half and secure with the four slotted screws (13).
6. Place end cap, end cap seal and O-ring (1, 9, 11) over end of cylinder (7). Finger tighten only.
7. Position the two fitting sets (12) on split case pump fabrication (3). Finger tighten only.
8. Tighten end cap (1) on split case pump fabrication (3) using spanner wrench provided.
9. Tighten fitting sets (12) to a maximum of 1.4 N-M (12 in. lbs.) the two fitting sets (12) using spanner wrench
provided. Refer to Figure 7.6.
10. Install the Pump Module on the swing plate as described in section 7.3.
7.5.5.5 Cylinder And Piston Fabrication (Figure 7.5 Items 7,8)
Disassembly
1. Remove the Pump Module from the Motor/Base Module as described in section 7.5.5.1.
2. Remove the fitting sets (12) from split case pump fabrication (3) by placing the spanner wrench (provided with
equipment) on the fitting retainers and turning in a counterclockwise direction.
Customer supplied
torque wrench with
1/4" socket adapter
Figure 7.6 Torque Setup for Fittings (12)

SPLIT CASE PUMP MODULE Page 7-10
15 July, 2019 IVEK Corp. P07R002P
3. Remove end cap, end cap seal and O-ring (1, 9, 11) from split case pump fabrication (3) by placing the spanner
wrench (provided with equipment) on end cap (1) and turning in a counterclockwise direction.
4. Loosen the four captive slotted screws (13) securing the two halves of split case pump fabrication (3) and remove
the upper half of split case pump fabrication (3). Lanyard (2) will keep the two Pump Module halves together.
5. Remove slotted ring (4).
6. Remove piston fabrication (8) and cylinder (7) from split case pump fabrication (3).
Assembly
1. Install the cylinder and piston fabrication, (7,8) by aligning over the cylinder locating pin, (5) in lower half of split
case pump fabrication (3).
2. Install slotted ring (4) by sliding over piston fabrication (8).
3. Position the upper half of split case pump assembly (3) on the lower half and secure with the four captive slotted
screws (13).
4. Place end cap, end cap seal and O-ring (1, 9, 11) over end of cylinder (7). Finger tighten only.
5. Position the two fitting sets (12) on split case pump fabrication (3). Finger tighten only.
6. Tighten end cap (1) on split case pump fabrication (3) using spanner wrench provided.
7. Tighten a maximum of 1.4 N-M (12 in. lbs.) the two fitting sets (12) using spanner wrench provided.
8. Install the Pump Module on the swing plate as described in section 7.3.
7.5.5.6 Slotted Ring (Figure 7.5 Items 4)
Disassembly
1. Remove the Pump Module from the Motor/Base Module as described in section 7.5.5.1.
2. Remove the fitting sets (12) from split case pump fabrication (3) by placing the spanner wrench (provided with
equipment) on the fitting retainers and turning in a counterclockwise direction.
3. Remove end cap, end cap seal and O-ring (1, 9, 11) from split case pump fabrication (3) by placing the spanner
wrench (provided with equipment) on end cap (1) and turning in a counterclockwise direction.
4. Loosen the four captive slotted screws (13) securing the two halves of split case pump fabrication (3) and remove
the upper half of split case pump fabrication (3). Lanyard (2) will keep the two Pump Module halves together.
5. Remove slotted ring (4).
Assembly
1. Install slotted ring (4) by sliding over piston fabrication (8).
2. Position the upper half of split case pump assembly (3) on the lower half and secure with the four captive slotted
screws (13).
3. Place end cap, end cap seal and O-ring (1, 9, 11) over end of cylinder (7). Finger tighten only.
4. Position the two fitting sets (12) on split case pump fabrication (3). Finger tighten only.
5. Tighten end cap (1) on split case pump fabrication (3) using spanner wrench provided.
6. Tighten a maximum of 1.4 N-M (12 in. lbs.) the two fitting sets (12) using spanner wrench provided.
7. Install the Pump Module on the swing plate as described in section 7.3.
7.5.5.7 Castellated Sleeve (Figure 7.5 Items 12)
Disassembly
1. Remove the fitting sets (12) from split case pump fabrication (3) by placing the spanner wrench (provided with
equipment) on the fitting retainers and turning in a counterclockwise direction.

SPLIT CASE PUMP MODULE Page 7-11
15 July, 2019 IVEK Corp. P07R002P
Assembly
1. Tighten a maximum of 1.4 N-M (12 in. lbs.) the two fitting sets (12) using spanner wrench provided.
7.6 PROBLEM GUIDE
7.6.1 Piston Frozen In The Cylinder
If the piston gets frozen in the cylinder perform the following steps.
CAUTION
DO NOT TRY TO FORCE THE PISTON FREE!
Damage to the piston/cylinder set may occur.
1. Carefully remove the Pump Module from the Motor/Base Module. Remove the piston and cylinder from the split
case then soak in a compatible solvent.
2. If the Pump Module is not conveniently removable, the tube loop described in section 7.5.2.3 of this chapter may
permit solvent to dissolve the “frozen” residue in reasonable time.
3. If the aforementioned procedures fail, contact IVEK for technical help. It may be necessary to ship the Pump Module back
to the factory. Provide a note describing, in detail, what conditions caused the seizure and what liquids are being pumped.
It may also be necessary to return the Controller and Motor/Base Modules along with the Pump Module should
readjustment of the pump drive components be required to free the pump.
Table 7.2 contains a list of possible problems, causes and solutions for the Pump Module.
7.7 SPECIFICATIONS
7.7.1 Volume
The volume represents the liquid displaced for a single revolution of the motor. If this system is used for dispensing, the
dispenser’s VOLUME STROKES setting will determine the total volume for each dispense cycle. Table 7.1 list the
recommended minimum and maximum displacement per stroke for the different size Pump Modules.
Table 7.1 Pump Module Displacement Specifications
Recommended
Size
Max Displacement
Min Displacement
Per Stroke
Per Stroke
B
0.295 ml
0.015 ml
C
0.739 ml
0.037 ml
D
1.478 ml
0.074 ml
16mm
1.886 ml
0.094 ml
7.8 MODEL NUMBER
The model number provides important information about the specifics of your Pump Module. Refer to this number when calling
IVEK Technical support. The model number for your Pump Module is located in the Title Page section of this manual.

SPLIT CASE PUMP MODULE Page 7-12
15 July, 2019 IVEK Corp. P07R002P
092122 - # # ###
Case Type
1 - No Heater Ports, 420SS Locating Key
2 - No Heater Ports, 316SS Locating Key
3 - Heater Ports, 420SS Locating Key
4 - Heater Ports, 316SS Locating Key
O-Ring Material
1 - Buna-N
2 - Ethylene Propylene
3 - Kalrez
4 - Polyurethane
5 - Silicone
6 - Teflon
7 - Teflon Encapsulated Silicone
8 -Viton
Ceramic Size and Material
001 - B-Size Alumina
002 - B-Size Zirconia
003 - C-Size Alumina
004 - C-Size Zirconia
005 - D-Size Alumina
006 - D-Size Zirconia
013 - 16mm-Size Alumina
101 - B-Size Alumina W/Gland
102 - B-Size Zirconia W/Gland
103- C-Size Alumina W/Gland
104- C-Size Zirconia W/Gland
105- D-Size Alumina W/Gland
106- D-Size Zirconia W/Gland
113 - 16mm Size Alumina W/Gland
An example of a Pump Module model number would be 092122-18004. This would be a Split Case Pump Module without
heater ports, 420SS Locating Key with a Viton O-ring and C-size Zirconia piston/cylinder set.
7.9 ILLUSTRATED PARTS BREAKDOWN
The illustrated parts breakdown (Figure 7.7) contains the information required for identifying and ordering parts for the
Split Case Pump Module.

SPLIT CASE PUMP MODULE Page 7-13
15 July, 2019 IVEK Corp. P07R002P
Table 7.2 Common Operational Problems And Solutions
PROBLEM
PROBABLE CAUSE
POSSIBLE SOLUTION
Power is on, Controller Module
Loose fittings or seals.
Check port seals and front cap seal.
accepts trigger, motor spindle
rotates, but Pump Module does
Broken piston or loose piston
Remove and inspect piston/cylinder set.
not move any fluid.
cap.
If none of the above solves the problem, contact
IVEK technical support for assistance.
Fluid is leaking from front of
Leaky seals.
Inspect for scratches or grit (clean or replace if
pump.
necessary.
End cap will not tighten
Grit in threads.
Clean end cap and split case.
smoothly.
Ceramic cylinder will not seat in
Misalignment
Make sure the slot on the ceramic cylinder aligns
split case.
with the cylinder locating pin.
Make sure the cylinder locating pin is not dam-
aged.
Piston does not rotate or rotates
Piston seized
Clean by soaking.
slowly.
Port fittings are too tight
Loosen castellated sleeve and recheck piston.

SPLIT CASE PUMP MODULE Page 7-14
15 July, 2019 IVEK Corp. P07R002P
Figure 7.7 Split Case Pump Module (Sheet 1 of 3)
1
2
9
14
11
13
3
4
7
12
12
3
5
6
10

SPLIT CASE PUMP MODULE Page 7-15
15 July, 2019 IVEK Corp. P07R002P
Figure Figure 7.7 Split Case Pump
Module (Sheet 2 of 2)
Figure 7.7 Split Case Pump
Module (Sheet 2 of 2)
PART
UNITS
NUMBER
DESCRIPTION
PER
ASSY
092122-#####
Split Case Pump Module
1
Model Dwg
# Index Part
Tab
#
#
Description
Qty
1
092250
End Cap, Pump Case, 1.063-20
1
2
092090
Lanyard Fabrication
1
4
092081
Ring, Slotted, Split Case Pump
1
5
092068
Cylinder Locating Pin
1
9
092285
Seal, End Cap, W/ -016 O-Ring Groove
1
10
182011-C08025
Screw, Soc Hd Cap, 18-8; 8-32 X 0.25
2
12
142084
Sleeve, Threaded, Castellated
2
13
092064
Screw, Captive, #10-32X1" Dia 3/8X7/16 HD, SST
4
14
182005-C08012
Screw, But Hd Soc Cap, 18-8 Inch, #8-32 X 1/8
2
092122 - # # ### CASE TYPE (Includes item 5) Contains 2 of the Following:
1
3
092065-1
Split Pump Case Fabrication; W/O Heater Ports
1
1
6
092074-01
Key, Locating, Split Case Pump, 420 SST
1
2
3
092065-1
Split Pump Case Fabrication; W/O Heater Ports
1
2
6
092074-02
Key, Locating, Split Case Pump, 316 SST
1
3
3
092065-2
Split Pump Case Fabrication; W/ Heater Ports
1
3
6
092074-01
Key, Locating, Split Case Pump, 420 SST
1
4
3
092065-2
Split Pump Case Fabrication; W/ Heater Ports
1
4
6
092074-02
Key, Locating, Split Case Pump, 316 SST
1
092122 - ## ### O-RING MATERIAL Contains 1
of the Following:
1
11
142294-01601
O-Ring
; -016 Buna-N
1
2
11
142294-01602
"
; -016 Ethylene Propylene
1
3
11
142294-01603
"
; -016 Kalrez
1
4
11
142294-01604
"
; -016 Polyurethane
1
5
11
142294-01605
"
; -016 Silicon
1
6
11
142294-01607
"
; -016 Teflon
1
7
11
142294-01608
"
; -016 Teflon Encapsulated Silicon
1
8
11
142294-01609
"
; -016 Viton
1
092122 - # # ### CERAMIC SIZE AND MATERIAL Contains 1 of the Following:
001
7
022218-001
Ceramic Piston/Cylinder Set; B-Size Alum
1
002
7
022218-002
"
; B-Size Zirc
1
003
7
022218-003
"
; C-Size Alum
1
004
7
022218-004
"
; C-Size Zirc
1
005
7
022218-005
"
; D-Size Alum
1
006
7
022218-006
"
; D-Size Zirc
1
013
7
022218-013
"
; 16mm Alum
1
101
7
022218-101
"
; B-Size Alum W/Gland
1
102
7
022218-102
"
; B-Size Zirc W/Gland
1
Figure 7.7 Split Case Pump Module (Sheet 2 of 3)

SPLIT CASE PUMP MODULE Page 7-16
15 July, 2019 IVEK Corp. P07R002P
Figure Figure 7.7 Split Case Pump
Module (Sheet 2 of 2)
Figure 7.7 Split Case Pump
Module (Sheet 2 of 2)
Model Dwg
# Index Part
Tab
#
#
Description
Qty
103
7
022218-103
"
; C-Size Alum W/Gland
1
104
7
022218-104
"
; C-Size Zirc W/Gland
1
105
7
022218-105
"
; D-Size Alum W/Gland
1
106
7
022218-106
"
; D-Size Zirc W/Gland
1
113
7
022218-113
"
; 16mm Alum W/Gland
1
Figure 7.7 Split Case Pump Module (Sheet 3 of 3)

SPLIT CASE PUMP MODULE Page 7-17
15 July, 2019 IVEK Corp. P07R002P
CHAPTER REVISIONS
O 7/15/19 Per DCR/N 19186, updated options for Locating Key and per DCR/N
19248, corrected Lanyard mounting screw.
N 3/18/16 Per DCR/N 17114 added Encapsulated Viton O-Ring.
M 10/17/11 Per DCR/N 14014 corrected table 7.1 to agree with current
marketing literature.
L 12/30/10 Per DCR/N 13494 corrected Nm typo on p 8 and 9
K 10/27/08 Per DCR/N corrected Nm conversion for Castellated Sleeve
torque.
J 2/10/04 Updated Per DCR/N #9909.
I 8/28/03 Updated Per DCR/N #9662.
H 1/8/03 Updated Per DCR/N #9292 (Changed gland Ceramics Part #)
G 9/3/02 Updated Per DCR/N #9019 (Changed O-Ring Size)
F 8/8/02 Updated Per DCR/N #8987 (Corrected Reference #)
E 3/7/02 Updated Per DCR/N # 8549. (New Model Number System)
D 6/18/01 Updated Per DCR/N # 8052. (16mm ceramics)
C 11/20/00 Updated Per DCR/N # 7298.
B 2/5/99 Corrected Table 7.3 and Chapter reference in section 7.4.3.2.
A 2/4/98 Added update to change the standard end cap and seal.
- 6/12/97 Original release

DRAFT DOCUMENT CARRIER SHEET
Document Number: P07R002P
Description: Split Case Pump Module
Date Submitted: July 15, 2019
Reviewed By
Date
Delivered
Date
Returned
Signature
Engr. Mgr.
IS Mgr.
Sales Mgr.
Operations Mgr.
