iVision IV-WD1070A User manual

User’s Manual
Professional WDR Box Camera
Model No. IV-WD1070A
Video System NTSC/ PAL System
Sensor 1/3" Sony Double Scan 960H CCD
Numbers of Pixel NTSC: 976H*494V; PAL: 976H*582V
Resolution 650TVL(Color), 700TVL(B/W)
Day & Night AUTO, COLOR, B/W, EXT1, EXT2
Sync. Internal Sync/ Line in Lock
Burst ON/ OFF
Signal Noise Ratio 50dB Min. (AGC off)
ESC Auto Shutter NTSC: 1/60~1/100,000; PAL: 1/50~1/100,000
DC Manual Shutter 1/60(50), 1/120(100), 1/250, 1/500, 1/1000, 1/2000, 1/4000,
1/10000
DNR 3DNR, Off, 2DNR
Motion Detection OFF/ ON (4 Programmable Zone), Alarm Out
Privacy OFF/ ON (15 Programmable Zone)
Mirror Off, V-Flip, H-Flip, HV-Flip
Sharpness 0~15
White Balance ATW (2,000°K~10,000°K)
PUSH/ USER1/ USER2/ ANTICR/ MANUAL/ PUSH LOCK
OSD Language English
Auto Gain Control 0~20
Gamma Correction 0.45
Video Output 1.0Vp-p/ 75 ohm Video 0.714Vp-p Sync 0.286Vp-p
IR LEDs 36pcs
Min. Illumination 0.00003Lux (IR LEDs ON)
Auto Gain Control 0~20
Power Current 150mA
Voltage Input DC12V± 10%
Operation Temp. -20°C~50°C
Storage Temp. -25°C~70°C
Humidity Range 20%~90% RH
Dimension 118L*64W*64H mm
Net Weight 300g
Technical Specifications:
Feature:
 1/3" Sony Double Scan 960H CCD
 Ultra High Resolution 700TVL
 Super Low Sensitivity 0.00003Lux
 Ultra Wide Dynamic Range
 3D+2D Digital Noise Reduction
 Full OSD Menu operation via RS485 or OSD joystick
 Privacy Zone, Motion Detection
Installation:
 To prevent shock or damage to the waterproof body, tighten all the screws and cover
 Adjust the visor to prevent the lens from direct sunlight
 Do not directly touch the front glass. To clean the dust, wipe with soft cloth with alcohol.
 Don’t install it in the place where dithering and shake often
 Don’t install it in the place where temperature is above 50°C or below –20°C
 Video line tie-in and DC tie-in must be avoided to touch water.
 If abnormal, please power off and contact the manufacturer
Note : Non-regulated power supply may cause camera damaged.

SET UP MENU
LENS…………………...AUTO/MANUAL
SHUTTER/AGC……….AUTO/MANUAL
WHITEBAL…………….ATW/PUSH/USER1/USER2/
ANTI CR/MANUAL/PUSH LOCK
BACKLIGHT…………...OFF/BLC/HLC
PICK ADJUST
ATR…………………….OFF/ON
MOTION DET………….OFF/ON
NEXT
EXIT…………………….SAVE ALL
LENS(AUTO IRIS)
TYPE……………………….DC/VIDEO
MODE…………………….AUTO/OPEN/CLOSE
SPEED……………………..0~255
RETURN
SHUTTER/AGC(AUTO SET UP)
HIGH LUMINANCE
MODE………………………..SHUT+AUTO IRIS/AUTO IRIS
BRIGHTNESS ……………...0~255
LOW LUMINANCE
MODE ………………………..AGC/OFF
BRIGHTNESS……………….X0.25,X0.5,X0.75X1.0
RETURN
WHITE BAL (ATW)
SPEED …………………….239(0~255)
DELAY CNT……………...1(0~255)
ATW FRAME……………..X2.0(X1.5,X2,X0.5,X1.0)
ENVIRONMENT………….INDOOR/OUTDOOR
RETURN
PICK ADJUST
MIRROR…….. …………OFF/ON
BRIGHTNESS…….. …..0(0~255)
CONTRAST….…………130(0~255)
SHARPNESS………….140(0~255)
HUE…………………….120(0~255)
..GAIN…………………..140(0~255)
RETURN
DAY/NIGHT(AUTO)
BURST ……………………….OFF/ON
DELAY CNT…………………...1(1~255)
DAY→NIGHT……………….....2(1~255)
NIGHT→DAY………………….3(1~255)
RETURN
NR
NR MODE……………………...OFF/C/Y/YC
Y LEVEL
C LEVEL
RETURN
LENS
TYPE DC
MODE AUTO
SPEED 80
RETURN
PICK ADJUST
MIRROR
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
GAIN
RETURN
OFF
0
128
128
128
128
2-DNR
NRMODE Y/C
Y LEVELC 001
C LEVEL 004
RETURN
DAY/NIGHT
BURST OFF
DELAY CNT 1
DAY→NIGHT 2
NIGHT→DAY 3
RETURN
SETUP MENU
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
BACK LIGHT OFF
PICT ADJUST
D-WDR OFF
MOTIONDET OFF
NEXT
EXIT SAVEALL
External OSD Opertation
Press ENTER to open the main menu. Please note to press key "SAVE" to
operate your changes on OSD MENU before exit.
Use left or right with Enter to operate the submenu of each item listed as
follows:
SETUP MENU(NEXT)
PRIVACY OFF
DAY/NIGHT Auto
2DNR
CAMERA ID OFF
SYNC INT
LANGUAGE ENGLISH
CAMERA RESET
BACK
EXIT SAVE ALL
WHITEBAL
SPEED 239
DELAY CNT 1
ATWFRAME X2.0
ENVIRNMENT IN-
DOOR
RETURN
ATR
LUMINANCE MID
CONTRAST MID
RETURN
When access ON,press ENTER to confirm submenu to set
up the motion area and sensitivity
PRIVACY………………..OFF/ON
RETURN
When access ON,press ENTER to confirm submenu to set
up the privacy area
SHUTTER/AGC………AUTO
HIGH LUMINANCE
MODE SHUT AUTO IRIS
BRIGHTNESS 32
LOW LUMINANCE
MODE AGC
BRIGHTNESS X0.5
RETURN
SHUTTER/AGC………MANUAL
MODE SHUTTER+AGC
SHUTTER 1/50
AGC 6.0
RETURN
SHUTTER/AGC(MANUAL SET UP)
MODE………………………..SHUTTER+AGC
SHUTTER…………………...1/50(1/10000~1/50)
AGC………………………….6.0(6.0~44.8)
RETURN
SET UP MENU(NEXT)
PRIVACY…………………...OFF/ON
DAY/NIGHT……….AUTO/EXIT1/EXIT2/COLOR/B/W
Y/C Y/C/OFF
CANMERA ID………………OFF/ON
SANC………………………..INT
LANGUAGE…………Chinese, English , Japanese, Germen
French,Russian,Portuguese, Spanish.
CAMERA RESET
NEXT
EXIT…………………………SAVE ALL
MOTIONDET ………………..OFF/ON
RETURN
ATR(ON)
LUMINANCE……………LOW/MID/HIGH
CONTRAST…………….LOW/MID LOW/MID
/MID HIGH/HIGH
RETURN
