iWantit IBTLI17 User manual

(iPod, iPhone and iPad are not included)
IBTLI17
instruction manual
wireless speaker dock for
iPod, iPhone and iPad with a
Lightning connector

Contents
safety warnings................................................................................................................................. 4
unpacking .......................................................................................................................................... 6
product overview ............................................................................................................................ 7
main unit ....................................................................................................................................................................... 7
top view......................................................................................................................................................................... 7
front view...................................................................................................................................................................... 7
rear view........................................................................................................................................................................ 7
remote control ............................................................................................................................................................ 8
remove the insulating strip from the remote control ............................................................... 9
battery replacement for the remote control............................................................................... 9
remote control operation range.................................................................................................. 10
installing the docking support/rubber pad .............................................................................. 10
power source................................................................................................................................... 11
general operation........................................................................................................................... 11
Bluetooth® audio. ........................................................................................................................... 12
aux in operation.............................................................................................................................. 12
usb operation.................................................................................................................................. 12
iPod / iPhone / iPad operation ..................................................................................................... 13
charging your iPod / iPhone / iPad.............................................................................................. 14
maintenance.................................................................................................................................... 14
hints and tips................................................................................................................................... 15
specications................................................................................................................................... 15

4
safety
• Always disconnect the unit from the mains
supply before connecting/disconnecting other
devices or moving the unit.
• Unplug the unit from the mains socket during
a lightning storm.
• In the interests of safety and to avoid
unnecessary energy consumption, never leave
the unit switched on while unattended for
long periods of time, e.g. overnight, while on
holiday or while out of the house. Switch it
o and disconnect the mains cable from the
mains socket.
mains Cable
• Make sure the unit or unit stand is not
resting on top of the mains cable, as the
weight of the unit may damage the mains
cable and create a safety hazard.
• If the mains cable is damaged it must be
replaced by the manufacturer, its service
agent, or similarly qualied persons in order
to avoid a hazard.
The mains plug is used as disconnect
device, the disconnect device shall remain
readily operable.
interference
• Do not place the unit on or near appliances
which may cause electromagnetic interference.
If you do, it may adversely aect the operating
performance of the unit, and cause a distorted
picture or sound.
batteries
• Batteries used in the remote control for this
unit are easily swallowed by young children
and this is dangerous.
• Keep loose batteries away from young children
and make sure that the battery holder tray is
secure in the remote control. Seek medical
advice if you believe a cell has been swallowed.
• Please dispose of batteries correctly by
following the guidance in this manual.
• Do not expose the battery to direct sunlight or
sources of excessive heat.
• Do not ingest the battery, Chemical Burn
Hazard.
• The remote control supplied with this product
contains a coin/button cell battery. If the coin/
button cell battery is swallowed, it can cause
severe internal burns in just 2 hours and can
lead to death.
• Keep new and used battery away from
children.
safety warnings
• Read all the instructions carefully before using
the unit and keep them for future reference.
• Retain the manual. If you pass the unit onto a
third party make sure to include this manual.
• Check that the voltage marked on the rating
label matches your mains voltage.
damage
• Please inspect the unit for damage after
unpacking.
• Do not continue to operate the unit if you are
in any doubt about it working normally, or if it
is damaged in any way - switch o, withdraw
the mains plug and consult your dealer.
location of unit
• The unit must be placed on a at stable surface
and should not be subjected to vibrations.
• Do not place the unit on sloped or unstable
surfaces as the unit may fall o or tip over.
• The mains socket must be located near the unit
and should be easily accessible.
• This unit is designed for indoor domestic use
only.
temperature
• Avoid extreme degrees of temperature, either
hot or cold. Place the unit well away from heat
sources such as radiators or gas/electric res.
• Avoid exposure to direct sunlight and other
sources of heat.
naked ames
• Never place any type of candle or naked ame
on the top of or near the unit.
moisture
• To reduce the risk of re, electric shock or
product damage, do not expose this unit
to rain, moisture, dripping or splashing. No
objects lled with liquids, such as vases, should
be placed on the unit. Do not operate the unit
with wet hands, near water or other liquid.
• If you spill any liquid into the unit, it can cause
serious damage. Switch it o at the mains
immediately. Withdraw the mains plug and
consult your dealer.
ventilation
• To prevent the risk of electric shock or re
hazard due to overheating, ensure that
curtains and other materials do not obstruct
the ventilation vents.
• Do not install or place this unit in a bookcase,
built-in cabinet or in another conned space.
Ensure the unit is well ventilated.

5
• If the battery compartment does not close
securely, stop using the product and keep it
away from children.
• If you think batteries might have been
swallowed or placed inside any part of the
body, seek immediate medical attention.
supervision
• Children should be supervised to ensure that
they do not play with the unit and the remote
control.
• Never let anyone especially children push
anything into the holes, slots or any other
openings in the case - this could result in a fatal
electric shock.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the
presence of uninsulated“dangerous
voltage” within the unit’s enclosure that
may be of sucient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the manual
accompanying the unit.
service
• To reduce the risk of electric shock, do not
remove screws. The unit does not contain
any user-serviceable parts. Please leave all
maintenance work to qualied personnel.
• Do not open any xed covers as this may
expose dangerous voltages.
maintenance
• Ensure to unplug the unit from the mains
socket before cleaning.
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the
unit’s surface.
• Do not use liquids to clean the unit.
• This equipment is a Class II or double
insulated electrical appliance. It has been
designed in such a way that it does not
require a safety connection to electrical
earth.
~ AC voltage: This symbol indicates that the rated
voltage marked with the symbol is AC voltage.
DC voltage: This symbol indicates that the
rated voltage marked with the symbol is DC
voltage.

6
The Main Unit Remote control Docking support
Mains CableAUX IN CableRubber Pad Instruction Manual
If items are missing or damaged, please contact Partmaster (UK only).
Tel: [phone] for assistance.
unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it, please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new product.
We recommend that you spend some time reading this instruction manual in order that you fully
understand all the operational features oered. You will also nd some hints and tips to help you
resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future
reference.
Instruction
Manual

7
product overview
main unit
front view
top view
bottom view
1. Docking station
2. USB Socket
3. Standby Button
4. SOURCE Button
5. /PAIR Button
6. VOL+/VOL– Button
Increase/decrease the volume
7. AUX IN Socket
8. Charging support insert slot
1 2 3 4 5 6 7 8
2 3 4 5 6 1 87 1
1
1. Speaker
2. Remote Control Sensor
3. Standby Indicator
4. DOCK mode Indicator
5. Bluetooth® mode Indicator
6. AUX IN mode Indicator
7. USB mode Indicator
8. Lightning Connecter
1. AC~ Socket

8
remote control
1. Standby Button
2. USB Button
3. MUTE Button
4. / Button
5. DFLT EQ Button
6. CLASSIC EQ Button
7. JAZZ EQ Button
8. DOCK Button
9. AUX Button
10. BT Button
11. VOL+ Button
12. PAIR Button
13. Button
14. VOL– Button
15. POP EQ Button
16. ROCK EQ Button
1
2
3
4
5
6
7
8
10
11
9
12
13
14
15
16

9
remove the insulating strip from the remote control
Remove the insulating mylar strip from the battery if the
battery is being used for the rst time. It is located at the
bottom back side of the remote control.
2. Pull out the battery holder and remove the old
battery.
battery replacement for the remote control
The remote control requires a CR2025, 3V Lithium battery.
1. Slide and hold the battery release tab in the direction
of the arrow.
3. Replace with a new battery.
4. Insert the battery holder back into the remote control.
handling the battery
• Improper or incorrect use of batteries may cause corrosion or battery leakage, which could cause
re, personal injury or damage to property.
• Install the battery correctly by following the polarity (+ and –) indications in the battery
compartment.
• When the battery is exhausted, the remote control will not function.
• Only use the battery type indicated in this manual.
• Do not dispose of the used battery as domestic waste. Dispose of it in accordance with the local
regulations.
• Small button cell batteries such as the one used in the remote control are easily swallowed by
young children and this is dangerous. Keep loose button cells away from young children and
make sure that the battery holder tray is secure in the remote control. Seek medical advice if you
believe a cell has been swallowed.

10
remote control operation range
Point the remote control at the unit no more than 5 metres
from the remote control sensor and within 40° of the front
of the unit. The operating distance may vary depending on
the brightness of the room.
handling the remote control
• Take care of your ngernails when you press and hold the battery release tab.
• Do not drop or cause impact to the remote control.
• Do not spill water or any liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight or near sources of excessive heat.
• Remove the battery from the remote control when not in use for a long period of time, as it could
cause corrosion or battery leakage and may result in physical injury and/or property damage
including re.
20° 20°
Within about 5 m
installing the docking support/rubber pad
To stabilise the iPod/iPhone/iPad on the unit, install
the docking support and rubber pad.
Rubber surface
Docking support
Rubber pad

11
power source
connecting to the mains supply
• This unit was designed to
operate with an AC 220-240V
power supply.
• Connecting the unit to any other
power source may cause damage
to the unit. Unwind the mains
cable to its full length. Connect
the end of the cable to the AC~
Socket at the bottom of the unit
and then connect the mains plug
to the mains socket The unit is
now connected and ready to use.
• To switch the unit o completely,
unplug the mains cable from the mains socket.
While connecting the unit with the mains cable, do not place the unit inverted to avoid
damages to the lightning connector.
general operation
powering on/o
• When you rst connect the unit to the mains socket, the unit will be in STANDBY mode.
The standby indicator will light up red.
• Press the Standby button on the unit or remote control to switch on the unit. The unit
will enter the last selected mode.
• Press Standby button to switch the unit to STANDBY mode.
• To completely turn the unit o, switch the unit back to standby mode, and then
disconnect the unit from the mains socket.
If the unit is idle for more than 15 minutes, it will automatically switch to STANDBY mode.
Press the Standby button to switch on the unit again.
selecting a mode
Press the SOURCE button repeatedly on the unit or press the AUX, BT (Bluetooth), USB,
DOCK buttons on the remote control to select the desired mode.
adjusting the volume
• Press the VOL+/VOL– button to adjust the volume.
• If you wish to switch the sound o, press the MUTE button on the remote control. Press
the MUTE button again or the VOL+/VOL– button to resume normal listening.
Select Equaliser (EQ) Eect
• Press the DFLT/POP/CLASSIC/JAZZ/ROCK button on the remote control to select the
preset equaliser eect.
To the mains socket
Bottom view of the unit

12
Bluetooth® audio.
1. When the unit is in on mode, press the SOURCE button on on the unit or the BT
button on the remote control to switch to Bluetooth® mode. The BT Indicator will ash
in blue. The system is now in pairing mode.
2. Switch on the Bluetooth® function of your device. Search for the name“IBTLI17” in the
Bluetooth® device list on your device.
3. Select “IBTLI17” and enter “0000” for the password if necessary.
4. When connection is successful, the unit will prompt “PAIRED“. Your unit is now ready
for use.
• When the unit has found the last paired Bluetooth® device, it will connect automatically.
• Press and hold /PAIR button on the unit or PAIR button on the remote control to cancel
the current Bluetooth® connection. The unit will prompt “PAIRING“. Repeat steps 1 to 3 to
connect a new Bluetooth® device.
• If the media controls (Play/Pause, Skip/Search or Volume) on the unit do not work during
Bluetooth playback, please ensure the app on your device is up to date or try the default
audio playback app for your device (i.e. iTunes, Google Play Music).
• If the unit is not paired in approximate 15 minutes, it will exit pairing mode and return to standby
mode.
• The operating range of the Bluetooth® audio for this unit is 8 metres, without obstruction. Walls,
structures and other objects may aect the Bluetooth® range.
aux in operation
1. Before connecting to the mains socket, use a 3.5 mm to 3.5 mm stereo audio cable to
connect your audio device to the AUX IN socket at the rear of the unit.
2. Connect the mains cable to the mains socket.
3. Press button on the unit or remote control to switch on the unit
4. Press SOURCE button on the unit repeatedly or AUX button on the remote control to
select AUX IN mode. The AUX IN mode Indicator will light up green.
5. In AUX IN mode, the unit will automatically start playback. You may operate your
audio device directly for playback features.
usb operation
1. Before connecting to the mains socket, insert the USB device into the USB socket.
2. Connect the mains cable to the mains socket.
3. Press button on the unit or remote control to switch on the unit
4. Press SOURCE button on the unit repeatedly or USB button on the remote control to
select USB mode. The USB mode Indicator will light up orange.
5. In USB mode, the unit will automatically start playback.
The USB port only supports MP3 playback.

13
iPod / iPhone / iPad operation
Remove the protective case from your device for the best docking connection.
This unit can support the following iPhone/iPod/iPad models.
Type Support Model
iPhone • iPhone 5
• iPhone 5s
• iPhone 5c
• iPhone 6
• iPhone 6 Plus
• iPhone 7
• iPhone 7 Plus
iPod • iPod touch (5th generation)
• iPod nano (7th generation)
iPad • iPad Air
• iPad mini with Retina display
• iPad mini
• iPad (4th generation)
1. When the unit is in on mode, press the SOURCE Button on the unit repeatedly or
DOCK button on the remote control to select DOCK mode. The DOCK Indicator will
light up white.
2. Insert your iPhone into the dock.
3. If the iPhone/iPod/iPad is connected, the unit will start playback, it will take around
10 seconds to allow the unit to identify the iPod/iPhone/iPad. The iPod/iPhone/iPad
battery will start to charge automatically and will continue charging.
4. Select your desired music, or videos, etc., and play the connected iPod/iPhone/iPad as
usual.
You can use either the iPod/iPhone/iPad or:
• Press the /PAIR button on the unit or PAIR button on the remote control to start/
pause playback.
• Press the / button on the remote control to select the previous/next track.
• Press the VOL+/VOL– button on the unit or remote control to adjust the volume.
• Press the DFLT/POP/CLASSIC/JAZZ/ROCK button on the remote control to select
the preset equaliser eect.
• To control the menu operation of iPad series, iPhone series, iPod touch series and iPod nano 7th
generation, you need to enter the music menu on your iPod/iPhone/iPad rst.
• This manual provides the basic instructions of menu navigation on iPod/iPhone/iPad. For advance
operations, please refer to your iPod/iPhone/iPad instructions.
• The unit cannot show any music information of your iPod/iPhone/iPad. Please view the music
information from your iPod/iPhone/iPad display.
• To avoid damaging your iPod/iPhone/iPad or the unit please take care when inserting and
removing your iPod/iPhone/iPad from the dock.

14
charging your iPod / iPhone / iPad
1. Your iPod/iPhone/iPad has an internal non-removable battery. The battery may need
to be charged if it has not been used for a while.
2. You can automatically charge the iPod/iPhone/iPad through the unit when it is docked.
• If you charge the iPod/iPhone/iPad while playing music, it may take a longer time.
• In any time, you can control the iPod/iPhone/iPad player on the unit or iPod/iPhone/iPad player
itself while the unit in the iPod/iPhone/iPad mode.
• 1st, 2nd & 3rd generation iPods cannot be charged.
maintenance
Ensure the unit is fully unplugged from the mains socket before cleaning.
To clean the unit, wipe the case with a slightly moist, lint-free cloth.
• Do not use any cleaning uids containing alcohol, ammonia or abrasives.
• Do not spray an aerosol at or near the unit.

15
hints and tips
If a problem does occur, it may often be due to something very minor. The following table
contains various tips.
problem cause / solution
power
System does not
turn on or does
not respond to the
remote control.
• Make sure mains plug is connected to the mains socket and the unit
properly and that it has power.
• Check that the remote control has a battery. The battery may need to
be replaced.
iPad/iPhone/iPad
The unit doesn’t play
iPod/iPhone/iPad les
or doesn’t function as
expected.
• Make sure the function is set to iPod/iPhone/iPad mode.
• Vibrations may have caused the iPod/iPhone/iPad to come loose from
the docking station. Make sure the iPod/iPhone/iPad is connected
properly.
• Make sure the iPod/iPhone/iPad is switched on.
• If the unit is in pause mode, press the /PAIR button on the unit or
on the remote control to resume playback.
Bluetooth®
I cannot nd “IBTLI17”
on my Bluetooth®
device
• Ensure the Bluetooth® function is activated on your Bluetooth® device.
• Ensure the unit is in pairing mode.
• Re-pair the unit to the device.
When in audio on
mode, the unit will
sometimes switch
back to standby mode
automatically.
• When the input signal is close to mute or is idle for approximately 15
minutes, it will automatically switch to standby mode.
• Increase the volume level of your external device.
specications
model IBTLI17
power supply AC 220 -240V ~50/60Hz
rate power 25 W
output power 2 × 20 Watts
DC output voltage Lightning Docking: 5V 2.1A Max.
USB Socket 5V 500 mA Max.
Bluetooth®
Bluetooth® Version V4.2
Maximum power
transmitted 5 dBm
Frequency bands 2402 MHz ~ 2480 MHz
Net weight 1.5 kg
Dimension (W × D × H) 260 mm × 195 mm × 99 mm
Specications and features are subject to change without prior notice.

IB-IBTLI17-180710V2
The symbol on the product or its packaging indicates that this product
must not be disposed of with your other household waste. Instead, it is
your responsibility to dispose of your waste equipment by handing it over
to a designated collection point for the recycling of waste electrical and
electronic equipment. The separate collection and recycling of your waste
equipment at the time of disposal will help conserve natural resources and
ensure that it is recycled in a manner that protects human health and the
environment.
For more information about where you can drop o your waste for
recycling, please contact your local authority, or where you purchased your
product.
Visit Partmaster.co.uk today for the easiest way to buy
electrical spares and accessories. With over 1 million spares
and accessories available we can deliver direct to your door
the very next day. Visit www.partmaster.co.uk or call 0344 800 3456 (UK customers only)
Calls charged at National Rate.
All trademarks are the property of their respective owners and all rights are acknowledged.
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth
SIG, Inc. and any use of such marks by DSG Retail Limited is under license. Other trademarks
and trade names are those of their respective owners.
“Made for iPod,”“Made for iPhone,” and “Made for iPad” mean
that an electronic accessory has been designed to connect
specically to iPod, iPhone, or iPad, respectively, and has been
certied by the developer to meet Apple performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and regulatory standards. Please note that
the use of this accessory with iPod, iPhone, or iPad may aect wireless performance. iPad, iPhone,
iPod, iPod classic, iPod nano, iPod touch, and Retina are trademarks of Apple Inc., registered in
the U.S. and other countries. iPad Air, iPad mini, and Lightning are trademarks of Apple Inc.
DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
For general information about this appliance
and handy hints and tips, please visit
www.TeamKnowhow.com/discover
or call 0344 561 1234
