JA Audio JA-PED 4W User manual

JA-PED 4W
4” 2 Way Pendant Speaker
Installation Instructions
Thank you for purchasing JA Audio speakers. We
take pride in our products and are committed to
provide years of entertainment pleasure. JA-PED
series is a 70/100V music distributed-line system
oering superb sound quality. This booklet covers
the necessary information for an intuitively easy
installation guide.
Contents: 1 speaker, 1 cover plate w/ 3 screws, 1 hanging kit

1. Unpack speaker
and Gripple cable
mounting hardware.
3. Attach snap hook by
inserting one end through the
hold on mounting bracket.
2. Thread hanging or safety
cable through Gripple cable
mechanisms as shown.
5. Connect signal wires
to (+) and (-) inputs.
4. Attach the hanging
cable by securing it
vstructure as shown.
6. Thread cable end(s)
through Gripple cable
mechanisms as shown.
Installation Instructions

7. Select desired tap position.
Switch is preset to maximum
70V (100V) mode.
9. Place cover plate onto
top of speaker and slightly
rotate until alignment
indicators meet.
8. Adjust speaker hanging height
with Gripple cable mechanism. Pull
to tighten & press button on Gripple
cable as shown to loosen or adjust.
11. Tighten all three
(3) screws to lock
cover plate in place.
10. Slide cover plate over
hanging and safety cables
and run signal wire through
center hole.
12. Done.

Limited Lifetime Warranty
JA Audio warrants to the original retail purchaser
only that this JA Audio product will be free from
defects in materials and workmanship, provided
the speaker was purchased from an JA Audio
authorized dealer. If the product is determined
to be defective, except for the grille, which is
warranted for ten (10) years, it will be repaired or
replaced at JA Audio discretion. If the product
must be replaced yet it is no longer manufactured,
it will be replaced with a model of equal to or
greater value that is the most similar to the original.
If this is the case, installing the replacement model
may require mounting modifications; JA Audio will
not be responsible for any such related costs.
©2019JA Audio, Inc. All rights reserved.
An Intrasonic Company
1-877-435-0670
www.intrasonictechnology.com
Requirements and Warranty Coverage
This warranty may not be valid if the product was
purchased through an unauthorized dealer. This
warranty only applies to the individual that made
the original purchase, and it cannot be applied to
other purchases. The purchaser must be prepared
to provide proof of purchase (receipt). This warranty
will not be valid if the identifying number or serial
number has been removed, defaced, or altered.
This warranty does not cover the following:
Accidental Damage
Damage caused by abuse or misuse
Damage caused by attempted repairs/
modifications by anyone other than
JA Audio or an authorized dealer
Damage caused by improper installation
Normal wear, maintenance,
and environmental issues
Damage caused by voltage inputs in excess
of the rated maximum of the unit
Damage inflicted during the return shipment
