TempStar™ HH (70°F-rise Booster)
Models
TempStar™ HH
Door Type
Project
Item
Quantity
CSI Section 11400
Approval
Date
Mandatory Specs
Specify voltage
Specify booster size
Specify electric or steam
Optional Features
40˚F- (4.5˚C- ) rise booster
heater available at no
additional cost if specied
at time of order
With no booster heater
Scaltrol
Flanged feet
Water hammer arrestor
Standard Features
Accessories
36” (914 mm) compartment
rack 4 1/6” (4 mm) tall
36” (914 mm) compartment
rack 5 5/8” (16 mm) tall
36” (914 mm) compartment
rack 7” (178 mm) tall
Combination rack
Peg rack
Sheet pan rack (18” x 26”/
457 mm x 660 mm baking
pans)
U s es 1.36 g a l lon s (5 l i t e rs) of 180˚F
(82˚C) wat e r per r a c k
T o tal a u t omatic (no r m al) c y cle - 6 2
s e c ond s
53 r ack s per h o ur n o r m al c y cle
2 H P w a s h p u mp m o t o r
Single-po i n t c onn e c tions f o r a l l u t i l i t i e s
Buil t -in water p r e ssur e r e gula t o r a n d
gau g e
Field c o n v e r t ible f r o m s t r aigh t - thr o ugh
t o c o r ner oper a t ion s
Hea v y dut y s tainless s t eel c onstruc t i o n
Specifications
Sani-Sure™ feature assures proper rinse
water temperature
Multi-cycle timer (Extra Heavy, Heavy,
Medium, Normal)
Extended 15 sec. high-temperature rinse
provides superior coverage and rapid
drying
20 3/4” (527 mm) wide x 27” (686 mm)
high opening accommodates 18”(457)
X 26” (660 mm) sheet pans and 60-quart
mixing bowls
Auto-ll / auto-start
Safety door switch
Delime/manual wash switch
Low-watt density electric wash tank
heater
Hi-limit thermostat and low-water pro-
tection
Adjustable bullet feet
Uses standard 20” x 20”(508 mm x 508
mm) racks
Front dress panel
Detergent/rinse additive signal connec-
tion fuse box
Built-in 70˚F(21˚C)-rise booster heater is
part of Sani-Sure™ feature and standard
Lower counterrotating wash arms and
upper wash arm provide optimum spray
coverage and superior cleaning action
Self-draining stainless steel pump
Split-door design accommodates instal-
lations with low ceilings
Large scrap tray
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
07610-002-66-60B (11/08)
MAILING ADDRESS
P. O. Box 1060
Barbourville, KY 40906
Tel: [phone]
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
www.jacksonmsc.com
SHIPPING ADDRESS
Gray, KY 40734
6209 North U.S. Highway 25E
TempStar™ HH (40°F-rise Booster) TempStar™ HH with No Booster
Drain quench system

07610-002-66-60B (11/08)
OPERATING CAPACITY
Racks per Hour Normal
53
Medium
28
Heavy
19
Extra Heavy
11
OPERATING CYCLE (sec)Wash Rinse DwellTotal Cycle
Normal 45 15 2 62
Medium103 15 2 120
Heavy 163 15 2 180
Extra Heavy 283 15 2 300
OPERATING TEMPERATURES
Wash (Minimum) 150˚F/ (66˚C)
Rinse (Minimum) 180˚F/ (82˚C)
MODEL NO.
SIZE DRAIN
HEIGHT
SHIPPING INFO DIMENSIONS
HEIGHT WIDTH DEPTH WEIGHT CLASS CUBE HEIGHT WIDTH DEPTH
TempStar™HH76-3/4”
(1949 mm)
25-1/4”
(641 mm)
25-1/4”
(641 mm)
11-3/4”
(298 mm)
420 lbs
(191 kg)
92.571.4
cu. ft.
85”
(2159 mm)
44”
(1118 mm)
33”
(838 mm)
DIMENSIONS--STANDARD MODEL
How To Specify - TempStar™ HH
STEAM REQUIREMENTS
Steam Flow Pressure (PSIG) 15-20
Consumption @ 15 PSIG (lbs/hr) 45
WATER REQUIREMENTS
Inlet Tempterature
40˚F / (4˚C) Rise 140˚F / (82˚C)
70˚F / (21˚C) Rise 110˚F / (60˚C)
Gallons per hour 72.1 / 273 Ltr.
Gallons per rack1.36 / 5 Ltr
Waterline Size IPS (Minimum-inches)3/4
Drainline Size IPS (Minimum-Inches)1-1/2
Waterline Flow Rate (GPM) 5.44
Flow Pressure (PSI)15-25
Tank Capacity 3 gals/ (11 ltrs)
Wash Tank 8 Gal. / (30 ltr)
Booster Tank 3 Gal. / (11 ltr)
APPROXIMATE LOAD AMPS
40˚F (4˚C) Rise70˚F (21˚C) Rise
Power Supply AMPS AMPS
208V/60HZ/1PH74.281.4
208V/60HZ/3PH 47.651.8
230V/60HZ/1PH 80.989.0
230V/60HZ/3PH51.456.2
460V/60HZ/3PH 23.425.8
DIMENSION REQUIREMENTS
Minimum Ceiling Height (Recommended) 88”/ (2 meters)
Wall Clearance (Minimum) 4” / (102 mm)
Standard Table Height 34”/ (864 mm)
Inside Clearance 17-1/4”/ (438 mm)
34 [861mm]
731
4[1863mm]
25 [637mm]
863
4[2202mm] B
17 [432mm]
C
73 [1856mm]
27 [687mm]
LEGEND
A - DRAIN 1 1/2" IPS
B - WATER INLET 3/4" IPS
C - ELECTRICAL CONNECTION
All vertical dimensions are +/- 1/2" due to
adjustable bullet feet.
A
251
4[639mm]
B
1 [27mm]
3 [79mm]
C
151
4[387mm]
113
4[298mm]
A
3[76mm]
4[101mm]
4[102mm]
B
WASH PUMP MOTOR
Wash Pump Motor Horsepower 2 HP
VoltsKW
Electric Wash Tank Heater 208V4.1
230V5.0
460V5.0
Electric Rinse Tank Heater 40˚F (4˚C) Rise 208V9.0
230V11.0
460V11.0
70˚F (21˚C) Rise 208V10.5
230V12.9
460V12.9
MAILING ADDRESS
P. O. Box 1060
Barbourville, KY 40906
Tel: [phone]
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
www.jacksonmsc.com
SHIPPING ADDRESS
Gray, KY 40734
6209 North U.S. Highway 25E
No Booster
AMPS
31
23
33
24
10
