Jacobsen Eclipse 2 User manual

When Performance Matters.
™
Eclipse®2
InCommand™
63334 – Eclipse 2 118, 18” 11 Blade Reel, Gen-Set
63343 – Eclipse 2 118, 18” 11 Blade Reel, Battery Pack
63335 – Eclipse 2 118, 18” 15 Blade Reel, Gen-Set
63344 – Eclipse 2 118, 18” 15 Blade Reel, Battery Pack
63336 – Eclipse 2 118F, Floating 18” 11 Blade Reel, Gen-Set
63345 – Eclipse 2 118F, Floating 18” 11 Blade Reel, Battery Pack
63337 – Eclipse 2 118F, Floating 18” 15 Blade Reel, Gen-Set
63346 – Eclipse 2 118F, Floating 18” 15 Blade Reel, Battery Pack
63338 – Eclipse 2 122, 22” 11 Blade Reel, Gen-Set
63347 – Eclipse 2 122, 22” 11 Blade Reel, Battery Pack
63339 – Eclipse 2 122, 22” 15 Blade Reel, Gen-Set
63348 – Eclipse 2 122, 22” 15 Blade Reel, Battery Pack
63340 – Eclipse 2 122F, Floating 22” 11 Blade Reel, Gen-Set
63349 – Eclipse 2 122F, Floating 22” 11 Blade Reel, Battery Pack
63341 – Eclipse 2 122F, Floating 22” 15 Blade Reel, Gen-Set
63350 – Eclipse 2 122F, Floating 22” 15 Blade Reel, Battery Pack
63342 – Eclipse 2 126, 26” 7 Blade Reel, Gen-Set
63351 – Eclipse 2 126, 26” 7 Blade Reel, Battery Pack
WARNING
WARNING: If incorrectly used this machine can cause severe
injury. Those who use and maintain this machine should be
trained in its proper use, warned of its dangers and should
read the entire manual before attempting to set up, operate,
adjust or service the machine.
AVISO
ATENÇÃO: Esta máquina pode causar ferimentos graves se
for utilizada incorrectamente. A pessoa responsável pela sua
utilização e manutenção deve ser previamente instruída para
a sua utilização correcta, avisada sobre os perigos que ela
pode causar e deve ler todo o manual antes de tentar
preparar, conduzir, afinar ou reparar a máquina.
4260472-PT-Rev C
Technical Manual
Manual técnico
63334 – Eclipse 2 118, rolo de 11 lâminas de 457 mm, grupo gerador
63343 – Eclipse 2 118, rolo de 11 lâminas de 457 mm, bateria completa
63335 – Eclipse 2 118, rolo de 15 lâminas de 457 mm, grupo gerador
63344 – Eclipse 2 118, rolo de 15 lâminas de 457 mm, bateria completa
63336 – Eclipse 2 118F, rolo oscilante de 11 lâminas de 457 mm, grupo gerador
63345 – Eclipse 2 118F, rolo oscilante de 11 lâminas de 457 mm, bateria completa
63337 – Eclipse 2 118F, rolo oscilante de 15 lâminas de 457 mm, grupo gerador
63346 – Eclipse 2 118F, rolo oscilante de 15 lâminas de 457 mm, bateria completa
63338 – Eclipse 2 122, rolo de 11 lâminas de 559 mm, grupo gerador
63347 – Eclipse 2 122, rolo de 11 lâminas de 559 mm, bateria completa
63339 – Eclipse 2 122, rolo de 15 lâminas de 559 mm, grupo gerador
63348 – Eclipse 2 122, rolo de 15 lâminas de 559 mm, bateria completa
63340 – Eclipse 2 122F, rolo flutuante de 11 lâminas de 559 mm, grupo gerador
63349 – Eclipse 2 122F, rolo oscilante de 11 lâminas de 559 mm, bateria completa
63341 – Eclipse 2 122F, rolo flutuante de 15 lâminas de 559 mm, grupo gerador
63350 – Eclipse 2 122F, rolo oscilante de 15 lâminas de 559 mm, bateria completa
63342 – Eclipse 2 126, rolo de 7 lâminas de 660 mm, grupo gerador
63351 – Eclipse 2 126, rolo de 7 lâminas de 660 mm, bateria completa
PT
Portugal

© 2012, Jacobsen, A Textron Company/Textron Innovations Inc.
“All rights reserved, including the right to reproduce this material
or portions thereof in any form.”
This manual contains safety, operating, adjustment,
maintenance, troubleshooting instructions and parts list
for your new Jacobsen machine. This manual should be
stored with the equipment for reference during operation.
Before you operate your machine, you and each operator
you employ should read the manual carefully in its
entirety. By following the safety, operating and
maintenance instructions, you will prolong the life of your
equipment and maintain its maximum efficiency.
If additional information is needed, contact your
Jacobsen Dealer.
The serial plate is located on the rear crossbar of the
frame. Jacobsen recommends you record these numbers
below for easy reference.
11524WILMAR BLVD,
CHARLOTTE,NC 28273
®
kg kW
1-800-848-1636 (US)
PRODUCT OF U.S.A. A Textron Company
2
Proposition 65 Warning
This product contains or emits
chemicals known to State of California
to cause cancer and birth defects or
other reproductive harm.
FOREWORD
Suggested Stocking Guide
To Keep your Equipment fully operational and productive, Jacobsen suggests you maintain a stock of the more
commonly used maintenance items. We have included part numbers for additional support materials and training aids.
To order any of the following material:
1. Write your full name and complete address on your
order form.
2. Explain where and how to make shipment:
?
UPS ? Regular Mail
?
Overnight ? 2nd Day
3. Order by the quantity desired, the part number, and
the description of the part.
4. Send or bring the order to your authorized Jacobsen
Dealer.
These are the original instructions verified by
Jacobsen, A Textron Company.
LITHO IN U.S.A. 9-2014
Service Parts
Service Support Material
Qty. Part No. Description Qty. Part No. Description
4102780 50 Amp Fuse 2811106 Motor to Pulley Belt
4262910 30 Amp Fuse 2811070 Pulley to Traction Drum Belt
4131618 Ignition Key
Qty. Part No. Description
4260472 Technical Manual
4260475 Operator Training Video 4262930 Floating Head Service Manual
4262932 Fixed Head Service Manual
Qty. Part No. Description

3
Table of Contents
1SAFETY
1.1How to Operate Safely . . . . . . . . . . . . . . . . . . . . 4
1.2 Important Safety Notes . . . . . . . . . . . . . . . . . 7
2 SPECIFICATIONS
2.1 Product Identification . . . . . . . . . . . . . . . . . . 8
2.2 Mower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 Traction and Differential . . . . . . . . . . . . . . . . 9
2.4 Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.5 Gen-Set Power Module . . . . . . . . . . . . . . . . 9
2.6 Battery Power Module . . . . . . . . . . . . . . . . 10
2.7 Accessories & Support Literature . . . . . . . . 11
2.8 Declaration of Conformity . . . . . . . . . . . . . . 12
3DECALS
3.1 Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4 CONTROLS
4.1 Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.2 Handle Controls . . . . . . . . . . . . . . . . . . . . . 18
4.3 LCD Display . . . . . . . . . . . . . . . . . . . . . . . . 19
4.4 Frequency of Cut . . . . . . . . . . . . . . . . . . . . 24
4.5 Gas Power Module Controls . . . . . . . . . . . . 29
4.6 Battery Power Module Controls . . . . . . . . . 29
5 OPERATION
5.1 Daily Inspection . . . . . . . . . . . . . . . . . . . . . 30
5.2 Interlock System (O.P.C.) . . . . . . . . . . . . . . 30
5.3 Operating Procedures . . . . . . . . . . . . . . . . . 31
5.4 Starting/Stopping . . . . . . . . . . . . . . . . . . . . 32
5.5 Mowing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.6 Transport Wheels (Optional) . . . . . . . . . . . . 34
5.7 Kickstand . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.8 Grass Catcher . . . . . . . . . . . . . . . . . . . . . . . 35
5.9 Daily Maintenance . . . . . . . . . . . . . . . . . . . 35
6 ADJUSTMENTS (ALL UNITS)
6.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.2 Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.3 Speed Paddle Stops . . . . . . . . . . . . . . . . . . 36
6.4 Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6.5 Traction Belts . . . . . . . . . . . . . . . . . . . . . . . 37
6.6 Front Roller Weight . . . . . . . . . . . . . . . . . . . 38
6.7 Torque Specification . . . . . . . . . . . . . . . . . . 39
7 FIXED HEAD REEL ADJUSTMENTS
7.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.2 Reel To Bedknife . . . . . . . . . . . . . . . . . . . . 40
7.3 Bedknife Adjustment . . . . . . . . . . . . . . . . . . 41
7.4 Cutting Height . . . . . . . . . . . . . . . . . . . . . . . 41
8 CLASSIC FLOATING HEAD REEL ADJUSTMENTS
8.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
8.2 Bedknife-To-Reel . . . . . . . . . . . . . . . . . . . . 42
8.3 Bedknife Adjustment . . . . . . . . . . . . . . . . . . 43
8.4 Reel Bearing . . . . . . . . . . . . . . . . . . . . . . . .43
8.5 Cutting Height . . . . . . . . . . . . . . . . . . . . . . .44
8.6 Reel Assembly Removal . . . . . . . . . . . . . . .44
9 TRUESET FLOATING HEAD REEL ADJUSTMENTS
9.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
9.2 Bedknife-To-Reel . . . . . . . . . . . . . . . . . . . . .45
9.3 Bedknife Adjustment . . . . . . . . . . . . . . . . . .46
9.4 Cutting Height . . . . . . . . . . . . . . . . . . . . . . .46
9.5 Reel Bearing . . . . . . . . . . . . . . . . . . . . . . . .47
9.6 Bedknife Adjuster Spring . . . . . . . . . . . . . . .47
9.7 Bedknife Adjuster Tension . . . . . . . . . . . . . .47
9.8 Grinding Bedknife . . . . . . . . . . . . . . . . . . . .47
9.9 Reel Assembly Removal . . . . . . . . . . . . . . .48
10 BATTERY POWER MODULE
10.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
10.2 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
10.3 Maintenance . . . . . . . . . . . . . . . . . . . . . . . .50
10.4 Cleaning Batteries . . . . . . . . . . . . . . . . . . . .50
10.5 Battery Charger . . . . . . . . . . . . . . . . . . . . . .51
10.6 Battery Installation . . . . . . . . . . . . . . . . . . . .52
10.7 Replacing Battery Pack . . . . . . . . . . . . . . . .53
11 GEN-SET POWER MODULE
11.1 Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
11.2 Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . .54
11.3 Engine Oil Change . . . . . . . . . . . . . . . . . . . .55
11.4 Engine Speed . . . . . . . . . . . . . . . . . . . . . . .55
11.5 Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
12 MAINTENANCE
12.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
12.2 Tires (Option) . . . . . . . . . . . . . . . . . . . . . . . .57
12.3 Wheel Bearing . . . . . . . . . . . . . . . . . . . . . . .57
12.4 Backlapping and Grinding . . . . . . . . . . . . . .58
12.5 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
13 TROUBLESHOOTING
13.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
14 MAINTENANCE & LUBRICATION CHARTS
14.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
14.2 Maintenance Chart . . . . . . . . . . . . . . . . . . .61
14.3 Lubrication Chart . . . . . . . . . . . . . . . . . . . . 62
15 PARTS CATALOG
15.1 How To Use The Parts Catalog . . . . . . . . . .63
15.2 To Order Parts . . . . . . . . . . . . . . . . . . . . . . .63
15.3 Parts Catalog Table of Contents . . . . . . . . .63

1 SAFETY
4
1 SAFETY
1.1 HOW TO OPERATE SAFELY
SAFE OPERATION
a Read the Operator’s Manual and other training
material. If the operator or technician can not read
this manual, the owner is responsible to describe
this material to the operators and technicians.
Manuals in additional languages may be available
on the Jacobsen or RansomesJacobsen website.
a Read all of the instructions for this mower carefully.
Know the controls and the correct operation of the
equipment.
b Children or persons who do not understand these
instructions must not use the mower. The local
regulations can limit the age of the operator.
c Never use a mower near persons, including
children or animals.
d Remember that the operator or owner is
responsible for accidents or hazards that occur to
other persons or their property.
e Never carry passengers.
f Never allow persons to operate or service the
mower or its attachments without correct
instructions.
g Do not operate equipment while tired, sick or after
you use alcohol or drugs.
PREPARATION
a When you operate the mower, wear correct
clothing, slip resistant work shoes or boots, work
gloves, hard hat, safety glasses and hearing
protection. Long hair, loose clothing or jewelry can
be caught in moving parts.
b Do not operate the equipment with the Interlock
System disconnected or the system does not
operate correctly. Do not disconnect or prevent the
operation of any switch.
c Never operate equipment that is not in correct
order or without decals, guards, shields, deflectors
or other protective devices fastened.
d Inspect the mower before you operate the mower.
Check the tire pressure, engine oil level, the
radiator coolant level and the air cleaner indicator.
Fuel is flammable. Use caution when you add the
fuel to the mower.
e Operate the mower in daylight or in good artificial
light. Use caution when you operate the mower
during bad weather. Never operate the mower with
lightning in the area.
f Inspect the area to select the accessories and
attachments that are needed to correctly and safely
do the job. Only use parts, accessories and
attachments approved by Jacobsen.
g Be careful of holes in the terrain and other hazards
that are not visible.
h Inspect the area where the equipment is operated.
Remove all objects you can find before you
operate. Be careful of obstructions above the
ground (low tree limbs, electrical wires) and also
underground obstacles (sprinklers, pipes, tree
roots). Enter a new area carefully. Look for
possible hazards.
i Inspect the cutting system before you start the
mower. Make sure the blades are free to rotate.
When you rotate one blade, other blades can
rotate.
OPERATION
a Never operate the engine without enough
ventilation or in an enclosed area. The carbon
monoxide in the exhaust fumes can increase to
dangerous levels.
b Never carry passengers. Keep other persons or
animals away from the mower.
c Disengage all drives and engage the parking brake
before you start the engine. Only start the engine
with the operator in the seat. Never start the engine
with persons near the mower.
WARNING
EQUIPMENT OPERATED INCORRECTLY OR WITHOUT TRAINING CAN BE DANGEROUS.
Know the location and correct operation of controls. Operators without experience must receive instruction from
another person that knows the correct operation of the equipment before you operate the mower.
Only use parts, accessories and attachments approved by Jacobsen.
!

SAFETY 1
5
d Keep your legs, arms and body inside the operator
compartment while the mower is in operation.
Keep your hands and feet away from the cutting
units.
e Do not use on the slopes greater than the safe
slope limit for the equipment.
f To guard against over turning or loss of control:
– Operate the mower across the face (horizontally),
but not up and down on the face of slopes
(vertically).
– Do not start or stop suddenly on slopes.
– Decrease the speed when you operate on slopes
or when you must turn. Use caution when you
change direction. Turf condition can change the
mower stability.
– Use caution when you operate the mower near
drop-offs, ditches or embankments.
– Be careful of holes in the terrain and other hazards
that are not visible.
g Always operate at speeds that allow you to have
complete control of the machine. Make sure of your
footing keep a tight grip the handle and walk.
Never run when you operate the mower.
h Use caution when you go near corners, trees or
other objects that can prevent a clear view.
i Equipment must meet the current regulations to be
driven on the public roads.
j Before you move across or operate on the paths or
roads, turn off the PTO switch, lift the mowers and
travel at decreased speed. Look for traffic.
k Stop the blades when the mower is on any surface
that is not grass.
l Do not release the cut grass in the direction of
persons or allow persons near the mower while in
operation.
m Do not operate the mower with damaged guards or
without safety devices in position.
n Do not change the engine governor setting or over-
speed the engine. Never change or tamper with
adjusters that are closed with a seal for the engine
speed control.
o Before you leave the operator compartment, for
any reason:
– Disengage all the drives and lower attachments to
the ground.
– Engage the parking brake.
– Stop the engine and remove the key.
p When you hit an object or mower starts to cause
the vibration that is not normal, inspect the mower
for damage and make repairs.
q Decrease the throttle setting before you stop the
engine.
r Do not use this equipment for uses that the mower
was not made for.
SAFE HANDLING OF FUELS
a The fuel and the fuel vapors are flammable. Use
caution when you add the fuel to the mower. The
fuel vapors can cause an explosion.
b Never use the containers that are not approved to
keep or transfer fuel.
c Never keep the mower or fuel containers near an
open flame or any device that can cause the
ignition of fuel or fuel vapors.
d Never fill the fuel containers inside a vehicle or on
a truck or trailer with a plastic liner. Always put the
fuel container on the ground away from your
vehicle before you fill the container.
e Refuel the mower before you start the engine.
When the engine is in operation or while the engine
is hot, never remove the fuel cap or add fuel to the
mower.
f Refuel outdoors only and do not smoke when you
add fuel. Extinguish all types of ignition.
g The fuel nozzle must touch the rim of the fuel tank
when you add fuel to the mower. Do not use a
device to lock the fuel nozzle in the open position.
h Do not over fill the fuel tank. Leave at least 1 inch
(25 mm) below the filler neck.
i Always tighten the fuel tank cap and container cap
after you add fuel.
j If the fuel spills on your clothing, change your
clothing immediately.
MAINTENANCE AND STORAGE
a Before you clean, adjust or repair this equipment,
stop the engine and disconnect the spark plug
wire. Keep the wire away from the plug to prevent
the engine to start. Disconnect the power
connector
b Make sure the mower is parked on a solid and level
surface.
c Never work on a mower that is lifted only by the
jack. Always use the jack stands.

1 SAFETY
6
d Do not remove battery pack without unit on
kickstand.
e Never allow persons to service the mower or its
attachments without correct instructions.
f When the mower is parked, put into storage or left
without an operator, lower the cutting device unless
a positive mechanical lock is used.
g When you put the mower on a trailer or put the
mower in storage, close the fuel valve. Do not keep
fuel near flames or drain the fuel inside a building.
h Disconnect the battery before you service the
mower. Always disconnect the negative battery
cable before the positive battery cable. Always
connect the positive battery cable before the
negative battery cable.
i Charge the battery in an area with good airflow.
The battery can release hydrogen gas that is
explosive. To prevent an explosion, keep any
device that can cause sparks or flames away from
the battery.
j Disconnect the battery charger from the power
supply before you connect or disconnect the
battery charger to the battery. Wear protective
clothing and use insulated tools when you service
the battery.
k Be careful and wear gloves when you check or
service the cutting unit blades. Replace any
damaged blades, do not try to correct a damaged
blade.
l Keep your hands and feet away from parts that
move. Do not adjust the mower with the engine in
operation, unless the adjustment needs the engine
in operation.
m Carefully release the pressure from components
with stored energy.
n Keep the mower and the engine clean.
o Allow the engine to become cool before storage
and always remove the ignition key.
p Keep all nuts, bolts and screws tight to make sure
the equipment is in safe condition.
q Replace worn or damaged parts for safety.
Replace damaged or worn decals. Only use parts,
accessories and attachments approved by
Jacobsen.
r To decrease the fire hazard, remove materials that
burn from the engine, muffler, battery tray and fuel
tank area.
s Disconnect the battery and controller connectors
before you weld on this mower.
WHEN YOU PUT THE MOWER ON A
TRAILER
a Be careful when you load or unload the mower on
a trailer. Trailer must be wider than the mower and
can carry the weight of the mower.
b Use a full-width ramp to load or unload the mower
on a trailer.
c Use straps, chains, cables or ropes to fasten the
mower to the trailer. Both front and rear straps
must be sent down and toward sides of trailer.
d Make sure that all latches are correctly fastened.

SAFETY 1
7
1.2 IMPORTANT SAFETY NOTES________________________________________________
This safety alert symbol is used to alert you to potential hazards.
DANGER - Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury.
WARNING - Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious
injury.
CAUTION - Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury
and property damage. It may also be used to alert against unsafe practices.
NOTICE - Indicates a potentially hazardous situation which, if not avoided, MAY result in property damage. It may
also be used to alert against unsafe practices.
For pictorial clarity, some illustrations in this manual may show shields, guards or plates open or removed. Under no
circumstances should this equipment be operated without these devices securely fastened in place.
By following all instructions in this manual, you will prolong the life of your machine and maintain its maximum
efficiency. Adjustments and maintenance should always be performed by a qualified technician.
If additional information or service is needed, contact your Authorized Jacobsen Dealer who is kept informed of the
latest methods to service this equipment and can provide prompt and efficient service.
WARNING
The Interlock System on this machine will shut off the reel and traction drive
if the operator releases the O.P.C. (Operator Presence Control) bail.
To protect the operator and others from injury, never operate equipment with
the Interlock System disconnected or malfunctioning.
!
WARNING
1. Before leaving the operator’s position for any reason:
a. Disengage all drives.
b. Engage parking brake.
c. Disconnect power connector.
2. Keep hands, feet, and clothing away from moving parts. Wait for all
movement to stop before you clean, adjust, or service the machine.
3. Keep the area of operation clear of all bystanders and pets.
4. Chock or block the wheels if the machine is left on an incline.
5. Never operate mowing equipment without the discharge deflector
securely fastened in place.
!

2 SPECIFICATIONS
8
2 SPECIFICATIONS
2.1 PRODUCT IDENTIFICATION_________________________________________________
63334............................ Eclipse®2 118 base unit with 18 in.
(457 mm) 11 blade reel and
InCommand™ control system.
Gen-Set power module.
63343............................ Eclipse®2 118 base unit with 18 in.
(457 mm) 11 blade reel and
InCommand™ control system.
Battery power module.
63335............................ Eclipse®2 118 base unit with 18 in.
(457 mm) 15 blade reel and
InCommand™ control system.
Gen-Set power module.
63344............................ Eclipse®2 118 base unit with 18 in.
(457 mm) 15 blade reel and
InCommand™ control system.
Battery power module.
63336............................ Eclipse®2 118F base unit with
floating 18 in. (457 mm) 11 blade
reel and InCommand™ control
system. Gen-Set power module.
63345............................ Eclipse®2 118F base unit with
floating 18 in. (457 mm) 11 blade
reel and InCommand™ control
system. Battery power module.
63337............................ Eclipse®2 118F base unit with
floating 18 in. (457 mm) 15 blade
reel and InCommand™ control
system. Gen-Set power module.
63346............................ Eclipse®2 118F base unit with
floating 18 in. (457 mm) 15 blade
reel and InCommand™ control
system. Battery power module.
63338............................ Eclipse®2 122 base unit with 22 in.
(559 mm) 11 blade reel and
InCommand™ control system.
Gen-Set power module.
63347............................ Eclipse®2 122 base unit with 22 in.
(559 mm) 11 blade reel and
InCommand™ control system.
Battery power module.
63339............................ Eclipse®2 122 base unit with 22 in.
(559 mm) 15 blade reel and
InCommand™ control system.
Gen-Set power module.
63348............................ Eclipse®2 122 base unit with 22 in.
(559 mm) 15 blade reel and
InCommand™ control system.
Battery power module.
63340............................ Eclipse®2 122F base unit with
floating 22 in. (457 mm) 11 blade
reel and InCommand™ control
system. Gen-Set power module.
63349............................ Eclipse®2 122F base unit with
floating 22 in. (457 mm) 11 blade
reel and InCommand™ control
system. Battery power module.
63341.............................Eclipse®2 122F base unit with
floating 22 in. (457 mm) 15 blade
reel and InCommand™ control
system. Gen-Set power module.
63350.............................Eclipse®2 122F base unit with
floating 22 in. (457 mm) 15 blade
reel and InCommand™ control
system. Battery power module.
63342.............................Eclipse®2 126 base unit with 26 in.
(660 mm) 7 blade reel and
InCommand™ control system.
Gen-Set power module.
63351.............................Eclipse®2 126 base unit with 26 in.
(660 mm) 7 blade reel and
InCommand™ control system.
Battery power module.
Serial Number ...............An identification plate, like the one
shown, listing the serial number, is
attached to the rear crossbar.
Product Vibration M/S2
Arms
Fixed Head
Floating Head 1.79 ± 1.3 2.03 ± 1.3
11524WILMAR BLVD,
CHARLOTTE,NC 28273
®
kg kW
1-800-848-1636 (US)
PRODUCT OF U.S.A. A Textron Company
92.3 2.6 XXXX
63334001651

SPECIFICATIONS 2
9
2.2 MOWER__________________________________________________________________
Reel..................................7, 9, 11, or 15 blades, hardened
high manganese carbon steel.
Reel Diameter..................5 in. (127 mm)
Cutting Width ...................18, 22 or 26 in. (457, 559 or
660 mm)
Height of cut.....................1/16 to 7/16 in. (1.6 to 11 mm)
Bedknives ........................Hardened carbon steel
High Profile ................5/32” - 7/16” (4 - 11 mm) cut
Low Profile.................1/8” - 7/32” (3.2 - 5.6 mm) cut
Tournament................3/32” - 5/32” (2.4 - 4 mm) cut
Super Tournament.....5/64” - 7/64” (2.1 - 2.8 mm) cut
Championship............1/16” - 7/64” (1.6 - 2.8 mm) cut
Frequency of Cut
15 Blade Reel............0.064 - 0.133 in. (1.6 - 3.4 mm)
11 Blade Reel ............0.087 - 0.178 in. (2.2 - 4.5 mm)
9 Blade Reel..............0.106 - 0.217 in. (2.7 - 5.5 mm)
2.3 TRACTION AND DIFFERENTIAL______________________________________________
Transport Tires (Option)...11 x 4 pneumatic bidirectional.
Reel Drive........................Independent direct drive motor.
Traction Drive...................Independent drive motor with two
synchronous polyurethane belts.
Traction Reduction Ratio..15.15:1
Mowing speed..................0 - 3.4 m.p.h. (5.31 km/h)
Differential........................Full automotive type, housed in
traction drum
Rear Drive Drum..............Machined aluminum alloy
2 Section, 7-3/4 (O.D.) x 10-31/32
2.4 WEIGHTS ________________________________________________________________
Gen Set Mowers
Weights: Without Grass Catcher Lbs. (kg)
63334 – Eclipse 2 118 11 Blade s................. 214 (97.1)
63335 – Eclipse 2 118 15 Blade s................. 217 (98.4)
63336 – Eclipse 2 118F 11 Blade s............... 254 (115.2)
63337 – Eclipse 2 118F 15 Blade s............... 257 (116.6)
63338 – Eclipse 2 122 11 Blade l.................. 221 (100.2)
63339 – Eclipse 2 122 15 Blade l................. 224 (101.6)
63340 – Eclipse 2 122F 11 Blade l............... 265 (120.2)
63341 – Eclipse 2 122F 15 Blade l............... 268 (121.6)
63342 – Eclipse 2 126 n................................ 243 (110.2)
Battery Pack Mowers
Weights: Without Grass Catcher Lbs. (kg)
63343 – Eclipse 2 118 11 Blade s................. 234 (106.1)
63344 – Eclipse 2 118 15 Blade s................. 237 (107.5)
63345 – Eclipse 2 118F 11 Blade s............... 274 (124.3)
63346 – Eclipse 2 118F 15 Blade s............... 277 (125.6)
63347 – Eclipse 2 122 11 Blade l................. 241 (109.3)
63348 – Eclipse 2 122 15 Blade l................. 244 (110.7)
63349 – Eclipse 2 122F 11 Blade l............... 285 (129.3)
63350 – Eclipse 2 122F 15 Blade l............... 288 (130.6)
63351 – Eclipse 2 126 l................................ 263 (119.3)
s With Steel Grooved Roller 68618
l With Machined Aluminum Grooved Roller 68614
n With Machined Aluminum Grooved Roller 68617
2.5 GEN-SET POWER MODULE _________________________________________________
Engine..............................Honda GX-120 K1QJG2 4-Cycle,
4HP (2.98 kW) at 4000 RPM
Speed...............................Engine speed set at factory for
generator to produce 59.8 volts
with no load. (2750 to 3250 rpm)
Fuel..................................Regular Grade (Unleaded)
Fuel Tank .........................0.66 Gallon (2.5 liter)
Use clean, fresh, regular unleaded gasoline, 85 octane
minimum. Refer to the engine’s operator manual for fuel
recommendations when using blended fuel.

2 SPECIFICATIONS
10
2.6 BATTERY POWER MODULE ________________________________________________
To ensure the longest battery life possible, the batteries
are not shipped with the power module and must be
ordered separately. For optimum range and performance
use batteries that equal or exceed the Amp-hour rating
listed.
System Voltage............. 48 Volt DC
Batteries ...................... (4) 12 volt, valve regulated,
non-spillable sealed lead acid
batteries.
Charger......................... 5 Amp, 48 Volt DC, dual input
voltage 115/230 Volt AC, 50/60
Hz.
Recommended Battery:
CSB battery is the Jacobsen recommended battery for
use in the Eclipse mower.
CSB batteries can be ordered from these CSB
distributors, or from any local battery dealer.
Electronic Distributing
920 Brookstown Ave
Winston Salem, NC 27101
Phone Number - 800-777-1096
Fax Number - 336-723-1098
E-Mail - [email protected] (E-Mail)
Contact Name - Bill Turner
URS Electronics
123 N.E. 7th
Portland, OR 97232
Phone Number - 800-955-4877
Fax Number - 503-232-3373
E-Mail - mark.twietme[email protected]
Contact Name - Mark Twietmeyer
Alternate Batteries:
These alternate batteries are also currently available.
These batteries have the same dimensions and amp-
hour ratings, but have not been tested by Jacobsen, and
no recommendation is stated or should be implied.
Contact your local battery dealer or the manufacturer for
sourcing on these batteries.
(USE ONLY 12 VOLT SLA BATTERIES)
Battery Brand Battery Part Number
CSB EVX12200
Length
in. (mm) Width in. (mm) Height in. (mm) Weight lbs. (kg) Rating Amp-Hr Volts Qty
Req’d
7-1/8
(181) 3 (76) 6-9/16 (167) 14.7 (6.7) 20 12 4
Battery Brand Battery
Part Number
Yuasa Enersys NPX 80
Panasonic LC-X1220AP
Panasonic LC-X1220P
Discover D12200
Power Sonic PSH-12180
B.B. Battery EB20-12
